Stellar Core: The Reference Implementation for The Peer to Peer Agent

Stellar-core is a replicated state machine that maintains a local copy of a cryptographic ledger and processes transactions against it, in consensus with a set of peers. It implements the Stellar Consensus Protocol, a federated consensus protocol. It is written in C++14 and runs on Linux, OSX and Windows. Learn more by reading the overview document.

Documentation

Documentation of the code's layout and abstractions, as well as for the functionality available, can be found in ./docs.

Installation

Installation Instructions

These are instructions for building stellar-core from source.

For a potentially quicker set up, the following projects could be good alternatives:

stellar-core in a docker container
stellar-core and horizon in a docker container
pre-compiled packages

Picking a version to run

Best is to use the latest stable release that can be downloaded from https://github.com/stellar/stellar-core/releases

Alternatively, branches are organized in the following way:

branch name	description	quality bar
master	development branch	all unit tests passing
testnet	version deployed to testnet	acceptance tests passing
prod	version currently deployed on the live network	no recall class issue found in testnet and staging

For convenience, we also keep a record in the form of release tags of the versions that make it to production:

pre-releases are versions that get deployed to testnet
releases are versions that made it all the way to production

Containerized dev environment

We maintain a pre-configured Docker configuration ready for development with VSCode.

See the dev container's README for more detail.

Runtime dependencies

stellar-core does not have many dependencies.

If core was configured (see below) to work with Postgresql, a local Postgresql server will need to be deployed to the same host.

To install Postgresql, follow instructions from the Postgresql download page.

Build Dependencies

c++ toolchain and headers that supports c++17
- clang >= 10.0
- g++ >= 8.0
pkg-config
bison and flex
libpq-dev unless you ./configure --disable-postgres in the build step below.
64-bit system
clang-format-10 (for make format to work)
perl
libunwind-dev

Ubuntu

Ubuntu 18.04

You can install the test toolchain to build and run stellar-core with the latest version of the llvm toolchain.

Alternatively, if you want to just depend on stock Ubuntu, you will have to build with clang and have use libc++ instead of libstdc++ when compiling.

Ubuntu 18.04 has clang-10 available, that you can install with

# install clang-10 toolchain
sudo apt-get install clang-10

After installing packages, head to building with clang and libc++.

Adding the test toolchain (optional)

# NOTE: newer version of the compilers are not
#    provided by stock distributions
#    and are provided by the /test toolchain
sudo apt-get install software-properties-common
sudo add-apt-repository ppa:ubuntu-toolchain-r/test
sudo apt-get update

Installing packages

# common packages
sudo apt-get install git build-essential pkg-config autoconf automake libtool bison flex libpq-dev libunwind-dev parallel
# if using clang
sudo apt-get install clang-10
# clang with libstdc++
sudo apt-get install gcc-8
# if using g++ or building with libstdc++
# sudo apt-get install gcc-8 g++-8 cpp-8

In order to make changes, you'll need to install the proper version of clang-format.

In order to install the llvm (clang) toolchain, you may have to follow instructions on https://apt.llvm.org/

sudo apt-get install clang-format-10

OS X

When building on OSX, here's some dependencies you'll need:

Install xcode
Install homebrew
brew install libsodium
brew install libtool
brew install autoconf
brew install automake
brew install pkg-config
brew install libpq (required for postgres)
brew install openssl (required for postgres)
brew install parallel (required for running tests)
brew install ccache (required for enabling ccache)

You'll also need to configure pkg-config by adding the following to your shell (.zshenv or .zshrc):

export PKG_CONFIG_PATH="$PKG_CONFIG_PATH:$(brew --prefix)/opt/libpq/lib/pkgconfig" export PKG_CONFIG_PATH="$PKG_CONFIG_PATH:$(brew --prefix)/opt/openssl@3/lib/pkgconfig"

Windows

See INSTALL-Windows.md

Basic Installation

git clone https://github.com/stellar/stellar-core.git
cd stellar-core
git submodule init
git submodule update
Type ./autogen.sh.
Type ./configure (If configure complains about compiler versions, try CXX=clang-10 ./configure or CXX=g++-8 ./configure or similar, depending on your compiler.)
Type make or make -j<N> (where <N> is the number of parallel builds, a number less than the number of CPU cores available, e.g. make -j3)
Type make check to run tests.
Type make install to install.

Building with clang and libc++

On some systems, building with libc++, LLVM's version of the standard library can be done instead of libstdc++ (typically used on Linux).

NB: there are newer versions available of both clang and libc++, you will have to use the versions suited for your system.

You may need to install additional packages for this, for example, on Linux Ubuntu 18.04 LTS with clang-10:

# install libc++ headers
sudo apt-get install libc++-10-dev libc++abi-10-dev

Here are sample steps to achieve this:

export CC=clang-10
export CXX=clang++-10
export CFLAGS="-O3 -g1 -fno-omit-frame-pointer"
export CXXFLAGS="$CFLAGS -stdlib=libc++"
git clone https://github.com/stellar/stellar-core.git
cd stellar-core/
./autogen.sh && ./configure && make -j6

Building with Tracing

Configuring with --enable-tracy will build and embed the client component of the Tracy high-resolution tracing system in the stellar-core binary.

The tracing client will activate automatically when stellar-core is running, and will listen for connections from Tracy servers (a command-line capture utility, or a cross-platform GUI).

The Tracy server components can also be compiled by configuring with --enable-tracy-gui or --enable-tracy-capture.

The GUI depends on the capstone, freetype and glfw libraries and their headers, and on linux or BSD the GTK-2.0 libraries and headers. On Windows and MacOS, native toolkits are used instead.

# On Ubuntu
$ sudo apt-get install libcapstone-dev libfreetype6-dev libglfw3-dev libgtk2.0-dev

# On MacOS
$ brew install capstone freetype2 glfw

Contributing

See Contributing

Running tests

Running tests

There are two ways to run tests:

src/stellar-core test
make check

Always build before running tests, unless using make check which will build for you. See INSTALL.md for instructions for how to build.

Running tests basics with `src/stellar-core test`

run tests with: src/stellar-core test

run one test with: src/stellar-core test testName

run one test category with: src/stellar-core test '[categoryName]'

Categories (or tags) can be combined: AND-ed (by juxtaposition) or OR-ed (by comma-listing).

Tests tagged as [.] or [hide] are not part of the default test.

Tests tagged as [acceptance] are not part of make check test runs.

supported test options can be seen with src/stellar-core test --help

display tests timing information: src/stellar-core test -d yes '[categoryName]'

xml test output (includes nested section information): src/stellar-core test -r xml '[categoryName]'

Tests may also be run with make check, see [Running tests in parallel](#running tests-in-parallel-with-make-check).

Running tests against postgreSQL

There are two options. The easiest is to have the test suite just create a temporary postgreSQL database cluster in /tmp and delete it after the test. That will happen by default if you run make check.

You can also use an existing database cluster so long as it has databases named test0, test1, ..., test9, and test. To set this up, make sure your PGHOST and PGUSER environment variables are appropriately set, then run the following from bash:

for i in $(seq 0 9) ''; do
    psql -c "create database test$i;"
done

You will need to set the TEMP_POSTGRES environment variable to 0 in order to use an existing database cluster.

Running tests in parallel with `make check`

The make check command runs tests and supports parallelization. This functionality is enabled with the following environment variables:

ALL_VERSIONS: If 0, runs the latest protocol version, if 1 runs all protocol version tests.
TEST_SPEC: Used to run just a subset of the tests (default: "~[.]")
NUM_PARTITIONS: Partitions the test suite (after applying TEST_SPEC) into $NUM_PARTITIONS disjoint sets (default: 1)
BATCHSIZE: The number of tests to be batched together to reduce setup overhead. (default: 5)
RUN_PARTITIONS: Run only a subset of the partitions, indexed from 0 (default: "$(seq 0 $((NUM_PARTITIONS-1)))")
TEMP_POSTGRES: Automatically generates temporary database clusters instead of using an existing cluster (default: 1)
RND_SEED: Can be set to a specific value to affect the random test ordering. (default: 1)

For example, env TEST_SPEC="[history]" NUM_PARTITIONS=4 RUN_PARTITIONS="0 1 3" make check will partition the history tests into 4 parts then run parts 0, 1, and 3.

Running stress tests

There are a few special stress tests included in the test suite. Those are subsystem level tests, not to be confused with more advanced tests that would be done as part of performance evaluation.

We adopt the convention of tagging a stress-test for subsystem foo as [foo-stress][stress][hide].

Then, running:

stellar-core test [stress] will run all the stress tests,
stellar-core test [foo-stress] will run the stress tests for subsystem foo alone, and
neither stellar-core test nor stellar-core test [foo] will run stress tests.

Running and updating TxMeta checks

The stellar-core test unit tests can be run in two special modes that hash the TxMeta of each transaction executed. These two modes can increase confidence that a change to stellar-core does not alter the semantics of any transactions. The two modes are:

--record-test-tx-meta <dirname> which records TxMeta hashes into <dirname>
--check-test-tx-meta <dirname> which checks TxMeta hashes against <dirname>

Continuous integration tests automatically run the --check-test-tx-meta mode against a pair of captured baseline directories stored in the repository, called test-tx-meta-baseline-current (for the current protocol) and text-tx-meta-baseline-next (for the next protocol). If you make intentional changes to the semantics of any transactions, or add any new transactions that need to have their hashes recorded, you can re-record the baseline using a command like:

stellar-core test [tx] --all-versions --rng-seed 12345 --record-test-tx-meta test-tx-meta-baseline-current

for a build with only the current protocol enabled, and:

stellar-core test [tx] --all-versions --rng-seed 12345 --record-test-tx-meta test-tx-meta-baseline-next

for a build configured with --enable-next-protocol-version-unsafe-for-production.

These commands will rewrite the baseline files, which are human-readable JSON files. You should then inspect to see that only the transactions you expected to see change did so. If so, commit the changes as a new set of baselines for future tests.

Download Details:
Author: stellar
Source Code: https://github.com/stellar/stellar-core
License: View license

#blockchain #stellar #c #cpluplus
