Pdf2gerb: Perl Script Converts PDF Files to Gerber format

pdf2gerb

Perl script converts PDF files to Gerber format

Pdf2Gerb generates Gerber 274X photoplotting and Excellon drill files from PDFs of a PCB. Up to three PDFs are used: the top copper layer, the bottom copper layer (for 2-sided PCBs), and an optional silk screen layer. The PDFs can be created directly from any PDF drawing software, or a PDF print driver can be used to capture the Print output if the drawing software does not directly support output to PDF.

The general workflow is as follows:

1. Design the PCB using your favorite CAD or drawing software.
2. Print the top and bottom copper and top silk screen layers to a PDF file.
3. Run Pdf2Gerb on the PDFs to create Gerber and Excellon files.
4. Use a Gerber viewer to double-check the output against the original PCB design.
5. Make adjustments as needed.
6. Submit the files to a PCB manufacturer.

Please note that Pdf2Gerb does NOT perform DRC (Design Rule Checks), as these will vary according to individual PCB manufacturer conventions and capabilities. Also note that Pdf2Gerb is not perfect, so the output files must always be checked before submitting them. As of version 1.6, Pdf2Gerb supports most PCB elements, such as round and square pads, round holes, traces, SMD pads, ground planes, no-fill areas, and panelization. However, because it interprets the graphical output of a Print function, there are limitations in what it can recognize (or there may be bugs).

See docs/Pdf2Gerb.pdf for install/setup, config, usage, and other info.

---

pdf2gerb_cfg.pm

#Pdf2Gerb config settings:
#Put this file in same folder/directory as pdf2gerb.pl itself (global settings),
#or copy to another folder/directory with PDFs if you want PCB-specific settings.
#There is only one user of this file, so we don't need a custom package or namespace.
#NOTE: all constants defined in here will be added to main namespace.
#package pdf2gerb_cfg;

use strict; #trap undef vars (easier debug)
use warnings; #other useful info (easier debug)


##############################################################################################
#configurable settings:
#change values here instead of in main pfg2gerb.pl file

use constant WANT_COLORS => ($^O !~ m/Win/); #ANSI colors no worky on Windows? this must be set < first DebugPrint() call

#just a little warning; set realistic expectations:
#DebugPrint("${\(CYAN)}Pdf2Gerb.pl ${\(VERSION)}, $^O O/S\n${\(YELLOW)}${\(BOLD)}${\(ITALIC)}This is EXPERIMENTAL software.  \nGerber files MAY CONTAIN ERRORS.  Please CHECK them before fabrication!${\(RESET)}", 0); #if WANT_DEBUG

use constant METRIC => FALSE; #set to TRUE for metric units (only affect final numbers in output files, not internal arithmetic)
use constant APERTURE_LIMIT => 0; #34; #max #apertures to use; generate warnings if too many apertures are used (0 to not check)
use constant DRILL_FMT => '2.4'; #'2.3'; #'2.4' is the default for PCB fab; change to '2.3' for CNC

use constant WANT_DEBUG => 0; #10; #level of debug wanted; higher == more, lower == less, 0 == none
use constant GERBER_DEBUG => 0; #level of debug to include in Gerber file; DON'T USE FOR FABRICATION
use constant WANT_STREAMS => FALSE; #TRUE; #save decompressed streams to files (for debug)
use constant WANT_ALLINPUT => FALSE; #TRUE; #save entire input stream (for debug ONLY)

#DebugPrint(sprintf("${\(CYAN)}DEBUG: stdout %d, gerber %d, want streams? %d, all input? %d, O/S: $^O, Perl: $]${\(RESET)}\n", WANT_DEBUG, GERBER_DEBUG, WANT_STREAMS, WANT_ALLINPUT), 1);
#DebugPrint(sprintf("max int = %d, min int = %d\n", MAXINT, MININT), 1);

#define standard trace and pad sizes to reduce scaling or PDF rendering errors:
#This avoids weird aperture settings and replaces them with more standardized values.
#(I'm not sure how photoplotters handle strange sizes).
#Fewer choices here gives more accurate mapping in the final Gerber files.
#units are in inches
use constant TOOL_SIZES => #add more as desired
(
#round or square pads (> 0) and drills (< 0):
    .010, -.001,  #tiny pads for SMD; dummy drill size (too small for practical use, but needed so StandardTool will use this entry)
    .031, -.014,  #used for vias
    .041, -.020,  #smallest non-filled plated hole
    .051, -.025,
    .056, -.029,  #useful for IC pins
    .070, -.033,
    .075, -.040,  #heavier leads
#    .090, -.043,  #NOTE: 600 dpi is not high enough resolution to reliably distinguish between .043" and .046", so choose 1 of the 2 here
    .100, -.046,
    .115, -.052,
    .130, -.061,
    .140, -.067,
    .150, -.079,
    .175, -.088,
    .190, -.093,
    .200, -.100,
    .220, -.110,
    .160, -.125,  #useful for mounting holes
#some additional pad sizes without holes (repeat a previous hole size if you just want the pad size):
    .090, -.040,  #want a .090 pad option, but use dummy hole size
    .065, -.040, #.065 x .065 rect pad
    .035, -.040, #.035 x .065 rect pad
#traces:
    .001,  #too thin for real traces; use only for board outlines
    .006,  #minimum real trace width; mainly used for text
    .008,  #mainly used for mid-sized text, not traces
    .010,  #minimum recommended trace width for low-current signals
    .012,
    .015,  #moderate low-voltage current
    .020,  #heavier trace for power, ground (even if a lighter one is adequate)
    .025,
    .030,  #heavy-current traces; be careful with these ones!
    .040,
    .050,
    .060,
    .080,
    .100,
    .120,
);
#Areas larger than the values below will be filled with parallel lines:
#This cuts down on the number of aperture sizes used.
#Set to 0 to always use an aperture or drill, regardless of size.
use constant { MAX_APERTURE => max((TOOL_SIZES)) + .004, MAX_DRILL => -min((TOOL_SIZES)) + .004 }; #max aperture and drill sizes (plus a little tolerance)
#DebugPrint(sprintf("using %d standard tool sizes: %s, max aper %.3f, max drill %.3f\n", scalar((TOOL_SIZES)), join(", ", (TOOL_SIZES)), MAX_APERTURE, MAX_DRILL), 1);

#NOTE: Compare the PDF to the original CAD file to check the accuracy of the PDF rendering and parsing!
#for example, the CAD software I used generated the following circles for holes:
#CAD hole size:   parsed PDF diameter:      error:
#  .014                .016                +.002
#  .020                .02267              +.00267
#  .025                .026                +.001
#  .029                .03167              +.00267
#  .033                .036                +.003
#  .040                .04267              +.00267
#This was usually ~ .002" - .003" too big compared to the hole as displayed in the CAD software.
#To compensate for PDF rendering errors (either during CAD Print function or PDF parsing logic), adjust the values below as needed.
#units are pixels; for example, a value of 2.4 at 600 dpi = .0004 inch, 2 at 600 dpi = .0033"
use constant
{
    HOLE_ADJUST => -0.004 * 600, #-2.6, #holes seemed to be slightly oversized (by .002" - .004"), so shrink them a little
    RNDPAD_ADJUST => -0.003 * 600, #-2, #-2.4, #round pads seemed to be slightly oversized, so shrink them a little
    SQRPAD_ADJUST => +0.001 * 600, #+.5, #square pads are sometimes too small by .00067, so bump them up a little
    RECTPAD_ADJUST => 0, #(pixels) rectangular pads seem to be okay? (not tested much)
    TRACE_ADJUST => 0, #(pixels) traces seemed to be okay?
    REDUCE_TOLERANCE => .001, #(inches) allow this much variation when reducing circles and rects
};

#Also, my CAD's Print function or the PDF print driver I used was a little off for circles, so define some additional adjustment values here:
#Values are added to X/Y coordinates; units are pixels; for example, a value of 1 at 600 dpi would be ~= .002 inch
use constant
{
    CIRCLE_ADJUST_MINX => 0,
    CIRCLE_ADJUST_MINY => -0.001 * 600, #-1, #circles were a little too high, so nudge them a little lower
    CIRCLE_ADJUST_MAXX => +0.001 * 600, #+1, #circles were a little too far to the left, so nudge them a little to the right
    CIRCLE_ADJUST_MAXY => 0,
    SUBST_CIRCLE_CLIPRECT => FALSE, #generate circle and substitute for clip rects (to compensate for the way some CAD software draws circles)
    WANT_CLIPRECT => TRUE, #FALSE, #AI doesn't need clip rect at all? should be on normally?
    RECT_COMPLETION => FALSE, #TRUE, #fill in 4th side of rect when 3 sides found
};

#allow .012 clearance around pads for solder mask:
#This value effectively adjusts pad sizes in the TOOL_SIZES list above (only for solder mask layers).
use constant SOLDER_MARGIN => +.012; #units are inches

#line join/cap styles:
use constant
{
    CAP_NONE => 0, #butt (none); line is exact length
    CAP_ROUND => 1, #round cap/join; line overhangs by a semi-circle at either end
    CAP_SQUARE => 2, #square cap/join; line overhangs by a half square on either end
    CAP_OVERRIDE => FALSE, #cap style overrides drawing logic
};

#number of elements in each shape type:
use constant
{
    RECT_SHAPELEN => 6, #x0, y0, x1, y1, count, "rect" (start, end corners)
    LINE_SHAPELEN => 6, #x0, y0, x1, y1, count, "line" (line seg)
    CURVE_SHAPELEN => 10, #xstart, ystart, x0, y0, x1, y1, xend, yend, count, "curve" (bezier 2 points)
    CIRCLE_SHAPELEN => 5, #x, y, 5, count, "circle" (center + radius)
};
#const my %SHAPELEN =
#Readonly my %SHAPELEN =>
our %SHAPELEN =
(
    rect => RECT_SHAPELEN,
    line => LINE_SHAPELEN,
    curve => CURVE_SHAPELEN,
    circle => CIRCLE_SHAPELEN,
);

#panelization:
#This will repeat the entire body the number of times indicated along the X or Y axes (files grow accordingly).
#Display elements that overhang PCB boundary can be squashed or left as-is (typically text or other silk screen markings).
#Set "overhangs" TRUE to allow overhangs, FALSE to truncate them.
#xpad and ypad allow margins to be added around outer edge of panelized PCB.
use constant PANELIZE => {'x' => 1, 'y' => 1, 'xpad' => 0, 'ypad' => 0, 'overhangs' => TRUE}; #number of times to repeat in X and Y directions

# Set this to 1 if you need TurboCAD support.
#$turboCAD = FALSE; #is this still needed as an option?

#CIRCAD pad generation uses an appropriate aperture, then moves it (stroke) "a little" - we use this to find pads and distinguish them from PCB holes.
use constant PAD_STROKE => 0.3; #0.0005 * 600; #units are pixels
#convert very short traces to pads or holes:
use constant TRACE_MINLEN => .001; #units are inches
#use constant ALWAYS_XY => TRUE; #FALSE; #force XY even if X or Y doesn't change; NOTE: needs to be TRUE for all pads to show in FlatCAM and ViewPlot
use constant REMOVE_POLARITY => FALSE; #TRUE; #set to remove subtractive (negative) polarity; NOTE: must be FALSE for ground planes

#PDF uses "points", each point = 1/72 inch
#combined with a PDF scale factor of .12, this gives 600 dpi resolution (1/72 * .12 = 600 dpi)
use constant INCHES_PER_POINT => 1/72; #0.0138888889; #multiply point-size by this to get inches

# The precision used when computing a bezier curve. Higher numbers are more precise but slower (and generate larger files).
#$bezierPrecision = 100;
use constant BEZIER_PRECISION => 36; #100; #use const; reduced for faster rendering (mainly used for silk screen and thermal pads)

# Ground planes and silk screen or larger copper rectangles or circles are filled line-by-line using this resolution.
use constant FILL_WIDTH => .01; #fill at most 0.01 inch at a time

# The max number of characters to read into memory
use constant MAX_BYTES => 10 * M; #bumped up to 10 MB, use const

use constant DUP_DRILL1 => TRUE; #FALSE; #kludge: ViewPlot doesn't load drill files that are too small so duplicate first tool

my $runtime = time(); #Time::HiRes::gettimeofday(); #measure my execution time

print STDERR "Loaded config settings from '${\(__FILE__)}'.\n";
1; #last value must be truthful to indicate successful load


#############################################################################################
#junk/experiment:

#use Package::Constants;
#use Exporter qw(import); #https://perldoc.perl.org/Exporter.html

#my $caller = "pdf2gerb::";

#sub cfg
#{
#    my $proto = shift;
#    my $class = ref($proto) || $proto;
#    my $settings =
#    {
#        $WANT_DEBUG => 990, #10; #level of debug wanted; higher == more, lower == less, 0 == none
#    };
#    bless($settings, $class);
#    return $settings;
#}

#use constant HELLO => "hi there2"; #"main::HELLO" => "hi there";
#use constant GOODBYE => 14; #"main::GOODBYE" => 12;

#print STDERR "read cfg file\n";

#our @EXPORT_OK = Package::Constants->list(__PACKAGE__); #https://www.perlmonks.org/?node_id=1072691; NOTE: "_OK" skips short/common names

#print STDERR scalar(@EXPORT_OK) . " consts exported:\n";
#foreach(@EXPORT_OK) { print STDERR "$_\n"; }
#my $val = main::thing("xyz");
#print STDERR "caller gave me $val\n";
#foreach my $arg (@ARGV) { print STDERR "arg $arg\n"; }

---

Download Details:

Author: swannman
Source Code: https://github.com/swannman/pdf2gerb

License: GPL-3.0 license

#perl

How to Choose the Fastest Web Hosting [Infographic]

Having a good website to draw in potential clients and in a time where more and more businesses are moving to a virtual platform, having a stable and fast website is more important than ever.

Google’s Best Practices say that your website ideally should be fully loaded in 3 seconds or less. Different types of website hosting have their own specialties, pros, and cons.

Shared hosting has multiple websites stored on one server and uses the shared server resources such as CPU and RAM. This kind of hosting can sometimes take longer to load as the resources available to it can be split up amongst a number of other websites but it can also be considerably cheaper than other hosting types.

A virtual private server, or VPS, is a type of hosting where each site is stored within its own space on a shared server, and offers more customization options and more storage space. Dedicated server hosting is where each site is stored on its own server, and site owners control all aspects of hosting, and offers more resources available to the website at the cost of a higher price.

Cloud hosting is where the load of a website is spread across a number of separate servers and runs applications using combined computing resources from the multiple servers.

Finally, managed WordPress hosting is a concierge service where all technical aspects of running WordPress is controlled solely by the host, and it includes speed, security, WordPress updates, daily backups, website uptime, and more.

A number of key factors change how fast a website loads. Poorly coded or out of date plugins can heavily contribute to making a website load slower.

Failing to cache pages may cause your server to crash, substantially slowing your website and even sometimes crashing it entirely. Overcrowded pages, stuffed full of too many elements, can make a page load much longer than it should.

External scripts, such as ads, font loaders can lead to poor site performance as servers become overloaded.

Learn more about the benefits of speeding up your website and how to speed it up easily and without a massive price tag here. Link.

#hosting #web-hosting #web-hosting-provider #web-hosting-options #infographic #wordpress #wordpress-website #technology

Google Cloud Platform Hosting Services in USA | SISGAIN

We strive to provide every customer business with google cloud hosting web services and managed series that are entirely personalized around the commercial and development goals of the company in USA. Businesses that work with us will see a marked improvement in efficiency. Managed Google Cloud Platform services from SISGAIN helps organisations leverage this relative newcomer’s big data and machine learning capabilities via our team of approachable experts. From solution design to in-life support we take the operational burden off dev and product development teams. For more information call us at +18444455767 or email us at hello@sisgain.com

#google cloud platform services #google cloud hosting web services #google cloud web hosting #gcp web hosting #google cloud server hosting #google vps hosting

Green Web Hosting Providers, Powered By Renewable Energy

Should I Switch to Green Web Hosting?

This question comes to my mind every time I see any website with a Green Host Badge. In a few seconds, I find myself on Google pondering over thoughts that eventually make me turn away from taking the eco-friendly switch.

My inner thoughts:

• Green Hosting is expensive as compared to your regular host.
• Am I compromising on a quality host?
• How much impact it will make by me going to use a Green Web Host?
• Is it just the badge or they really use Green Technologies?

It’s strange that even after spending long hours on Google I couldn’t make the switch. But with time and my curiosity levels I’ve got the privilege to understand Green Hosting more closely.

• how it works,
• the Green Mechanism,
• harmful aftereffects of regular hosting,
• environmental impact (or lack of it)
• the resources we’ll save by making the switch
• energy consumption
• carbon emissions

What is Green Web Hosting?

All websites are hosted on web servers kept in data centers. These Data Centers can be found in many places across the globe. But, their setup requires a continuous supply of energy for the cooling system, security facilities and powering web servers. Plus they emit a heavy amount of harmful carbon in the environment.

To save the environment the concept of Green Web Hosting was introduced to minimize the harmful impact of these Data Centers on the environment. Green Web Hosting enables the use of using eco-friendly resources like renewable energy to power Data Centers and curb carbon emissions in the environment.

Wind Energy and Hydro Plants are the primary sources of renewable energy that facilitates the use of Green Web Hosting.

Impact of Web Hosting on Environment

Data Centers using conventional methods to host web servers have left a lasting impact on our environment. Below are some facts to understand what we are facing at if we don’t switch to Green Web Hosting:

• A web server produces an average of 650kg of Carbon dioxide.
• The annual energy consumption of a web server is about 1000 KWh
• According to the Department of Energy, Unites States about 10% of the total electricity of the country is used to run of Data Servers.
• In the year 2005, the total electricity bill consumed in running Data Servers in the US stands at a whopping $2.7 billion.
• Average carbon emission of Global Internet equals to the carbon emitted by 65 Coal Burning power stations with full capacity in a year.

#web-hosting-provider #web-hosting #green-web-hosting #technology #website-development

Cloud Hosting vs Dedicated Web Hosting

Hosting a website these days has boiled down to picking between two major options: Cloud Hosting and Dedicated Hosting.

Naturally, there are also shared hosting and virtual private server platforms but any website owner with half a decent knowledge of web hosting knows that cloud and dedicated hosting are unbeatable options for the practical purposes of scalability and uptime guarantee.

There has never been a better time to build a website. With the fluid options made accessible by cloud platforms that can integrate custom dedicated server capabilities, small businesses can now optimize enterprise-grade features that are still within their budget range.

Some hosting providers and website builders like Wix even provide free web hosting to clients without compromising standard industry features like website security and optimal uptime guarantee.

Choosing Between Cloud Hosting and Dedicated Hosting

It is often a debate for any serious website owner as to whether to use a cloud hosting option or to go with a dedicated server. Both options have their advantages and would guarantee website stability, a fast loading speed for high website traffic, vast compatibility options for software and applications, and data security.

But both platforms do have their differences and specifics to the optimal solutions they provide. The avant-garde nature of cloud hosting plans is however closing this gap and we’re getting closer to a world where complex custom web server requirements can be provided by cloud solutions.

We won’t be able to fully understand the advantages that flexible cloud solutions have over dedicated servers without first understanding the dynamics of both platforms.

#web-hosting #cloud-web-hosting #cloud hosting #cloud
