A guide to Object Detection with OpenCV and Swift

A guide to Object Detection with OpenCV and Swift

In this article, we’ll see how to create and launch a object detection algorithm using OpenCV and Swift

Swift has been with us for a while now, and through its iterations, it has brought to us all the features of a modern object-oriented programming language. These include optionals, generics, tuples, structs that support methods, extensions and protocols, and many more. But if your application relies on a library that’s written using C++ then you can’t count on Swift anymore. Luckily Objective-C++ is here to help us.

Since its introduction, Swift has had great interoperability with Objective-C and we will use Objective-C for bridging Swift with C++. Objective-C++ is nothing more than Objective-C with the ability to link with C++ code, and using that, in this blog post, we will create a simple app that will recognize the Toptal logo inside the image using OpenCV. When we detect that logo, we’ll open the Toptal home page.

As stated on the OpenCV web page:

"OpenCV was designed for computational efficiency and with a strong focus on real-time applications. Written in optimized C/C++, the library can take advantage of multi-core processing."
This is a great solution if you want fast to develop and reliable computer vision.

Creating the OpenCV Objective-C++ Wrapper

In this tutorial, we will design the application which will match a Toptal logo inside an image and open Toptal web page. To begin, create a new Xcode project and set up CocoaPods using pod init. Add OpenCV to Podfile pod 'OpenCV and run pod install in Terminal. Be sure to uncomment use_frameworks! statement inside Podfile.

Now, when we have OpenCV inside Xcode project, we have to connect it with Swift. Here is a quick outline of the steps involved:

Step 1: Create a new Objective-C class OpenCVWrapper. When Xcode asks you “Would you like to configure an Objective-C bridging header?” choose “Create bridging header.” The bridging header is the place where you import Objective-C classes, and then they are visible inside Swift.

Step 2: In order to use C++ inside Objective-C, we have to change the file extension from OpenCVWrapper.m to OpenCVWrapper.mm. You can do it by simply renaming the file inside Xcode’s project navigator. Adding .mm as an extension will change the file type from Objective-C to Objective-C++.

Step 3: Import OpenCV into OpenCVWrapper.mm using the following import. It’s important to write the given import above #import "OpenCVWrapper.h" because this way we avoid a well-known BOOL conflict. OpenCV contains enum that has the value NO which causes a conflict with the Objective-C BOOL NO value. If you don’t need classes that use such enum, then this is the simplest way. Otherwise, you have to undefine BOOL before importing OpenCV.

#ifdef __cplusplus

#import <opencv2/opencv.hpp>

#import <opencv2/imgcodecs/ios.h>

#import <opencv2/videoio/cap_ios.h>

#endif

Step 4: Add #import "OpenCVWrapper.h" to your bridging header.

Open OpenCVWrapper.mm and create a private interface where we will declare private properties:

@interface OpenCVWrapper() <CvVideoCameraDelegate>

@property (strong, nonatomic) CvVideoCamera *videoCamera;

@property (assign, nonatomic) cv::Mat logoSample;

@end

In order to create CvVideoCamera, we have to pass UIImageView to it, and we will do that through our designator initializer.

- (instancetype)initWithParentView:(UIImageView *)parentView delegate:(id<OpenCVWrapperDelegate>)delegate {



    if (self = [super init]) {

        self.delegate = delegate;



        parentView.contentMode = UIViewContentModeScaleAspectFill;



        self.videoCamera = [[CvVideoCamera alloc] initWithParentView:parentView];

        self.videoCamera.defaultAVCaptureDevicePosition = AVCaptureDevicePositionBack;

        self.videoCamera.defaultAVCaptureSessionPreset = AVCaptureSessionPresetHigh;

        self.videoCamera.defaultAVCaptureVideoOrientation = AVCaptureVideoOrientationPortrait;

        self.videoCamera.defaultFPS = 30;

        self.videoCamera.grayscaleMode = [NSNumber numberWithInt:0].boolValue;

        self.videoCamera.delegate = self;



        // Convert UIImage to Mat and store greyscale version

        UIImage *templateImage = [UIImage imageNamed:@"toptal"];

        cv::Mat templateMat;

        UIImageToMat(templateImage, templateMat);

        cv::Mat grayscaleMat;

        cv::cvtColor(templateMat, grayscaleMat, CV_RGB2GRAY);

        self.logoSample = grayscaleMat;



        [self.videoCamera start];

    }

    return self;

}

Inside it, we configure CvVideoCamera that renders video inside the given parentView and through delegate sends us cv::Mat image for analysis.

processImage: method is from CvVideoCameraDelegate protocol, and inside it, we will do template matching.

- (void)processImage:(cv::Mat&)image {



    cv::Mat gimg;



    // Convert incoming img to greyscale to match template

    cv::cvtColor(image, gimg, CV_BGR2GRAY);



    // Get matching

    cv::Mat res(image.rows-self.logoSample.rows+1, self.logoSample.cols-self.logoSample.cols+1, CV_32FC1);

    cv::matchTemplate(gimg, self.logoSample, res, CV_TM_CCOEFF_NORMED);

    cv::threshold(res, res, 0.5, 1., CV_THRESH_TOZERO);



    double minval, maxval, threshold = 0.9;

    cv::Point minloc, maxloc;

    cv::minMaxLoc(res, &minval, &maxval, &minloc, &maxloc);



    // Call delegate if match is good enough

    if (maxval >= threshold)

    {

        // Draw a rectangle for confirmation

        cv::rectangle(image, maxloc, cv::Point(maxloc.x + self.logoSample.cols, maxloc.y + self.logoSample.rows), CV_RGB(0,255,0), 2);

        cv::floodFill(res, maxloc, cv::Scalar(0), 0, cv::Scalar(.1), cv::Scalar(1.));



        [self.delegate openCVWrapperDidMatchImage:self];

    }

}

First, we convert the given image to grayscale image because inside the init method we converted our Toptal logo template matching image to grayscale. Next step is to check for matches with a certain threshold which will help us with scaling and angles. We have to check for angles because you can capture a photo in various angles in which we still want to detect logo. After reaching the given threshold we will invoke delegate and open Toptal’s web page.

Don’t forget to add NSCameraUsageDescription to your Info.plist otherwise, your application will crash right after calling [self.videoCamera start];.

Now Finally Swift

So far we were focusing on Objective-C++ because all the logic is done inside it. Our Swift code will be fairly simple:

  1. Inside ViewController.swift, create UIImageView where CvVideoCamera will render content.
  2. Create an instance of OpenCVWrapper and pass the UIImageView instance to it.
  3. Implement OpenCVWrapperDelegate protocol to open Toptal’s web page when we detect the logo.
class ViewController: UIViewController {



    var wrapper: OpenCVWrapper!



    @IBOutlet var imageView: UIImageView!

    override func viewDidLoad() {

        super.viewDidLoad()

        // Do any additional setup after loading the view, typically from a nib.



        wrapper = OpenCVWrapper.init(parentView: imageView, delegate: self)

    }

}

extension ViewController: OpenCVWrapperDelegate {

    //MARK: - OpenCVWrapperDelegate



    func openCVWrapperDidMatchImage(_ wrapper: OpenCVWrapper) {

        UIApplication.shared.open(URL.init(string: "https://toptal.com")!, options: [:], completionHandler: nil)

    }

}

OpenCV Swift in Action

In this article, we have shown how you can integrate C++ code with Swift and create wrapper classes that are here for bridging C++ code with Swift. Now, when we detect the Toptal Logo through the camera, we open Toptal’s home page.

For future updates, you may want to run CV template matching in a background thread. This way, you won’t block the main thread and the UI will stay responsive. Because this is a simple example of OpenCV, template matching may not be extra successful, but the purpose of this article was to show you how you can start using it.

Thanks for reading

If you liked this post, share it with all of your programming buddies!
