A Flutter Plugin to Use The Firebase ML Custom Models API
Firebase Machine Learning Custom A Flutter plugin to use the Firebase ML Custom Models API.
For Flutter plugins for other Firebase products, see README.md.
Usage
To use this plugin, add firebase_ml_custom as a dependency in your pubspec.yaml file. You must also configure Firebase for each platform project: Android and iOS (see the example folder or https://codelabs.developers.google.com/codelabs/flutter-firebase/#4 for step by step details).
Android
In order to use methods referencing those of Firebase Model Manager minimum SDK version required is 24. Otherwise minimum SDK version is 21. This can be specified in your app-level build.gradle file.
iOS
A minimum deployment target of 9.0 is required. You can add the line platform :ios, '9.0' in your iOS project Podfile.
You may also need to update your app's deployment target to 9.0 using Xcode. Otherwise, you may see compilation errors.
Using Firebase Model Manager
1. Create a FirebaseCustomRemoteModel.
Create a FirebaseCustomRemoteModel object. You should already have a model in your Firebase console available for download. Use the name that you gave your model in the Firebase console.
FirebaseCustomRemoteModel remoteModel = FirebaseCustomRemoteModel('myModelName');
2. Create a FirebaseModelDownloadConditions.
Create a FirebaseModelDownloadConditions object. Specify optional platform-specific conditions for the model download.
FirebaseModelDownloadConditions conditions =
FirebaseModelDownloadConditions(
androidRequireWifi: true,
androidRequireDeviceIdle: true,
androidRequireCharging: true,
iosAllowCellularAccess: false,
iosAllowBackgroundDownloading: true);
All of these parameters except iosAllowCellularAccess default to false if not specified. iosAllowCellularAccess defaults to true. Each platform looks only at its platform-specific parameters and ignores the rest.
3. Create an instance of FirebaseModelManager.
Create a FirebaseModelManager object corresponding to the default FirebaseApp instance.
FirebaseModelManager modelManager = FirebaseModelManager.instance;
4. Call download() with FirebaseCustomRemoteModel and FirebaseModelDownloadConditions.
Initiate the download of a remote model if the download hasn't begun. If the model's download is already in progress, the current download task will continue executing. If the model is already downloaded to the device, and there is no update, the call will immediately succeed. If the model is already downloaded to the device, and there is update, a download for the updated version will be attempted.
await modelManager.download(remoteModel, conditions);
5. Call isModelDownloaded() with FirebaseCustomRemoteModel.
Return whether the given remote model is currently downloaded.
if (await modelManager.isModelDownloaded(model) == true) {
// do something with this model
} else {
// fall back on a locally-bundled model or do something else
}
You can also check if download was successfully completed by surrounding download method with try and catch.
5. Call getLatestModelFile() with FirebaseCustomRemoteModel.
Return the File containing the latest model for the remote model name. This will fail if the model is not yet downloaded on the device or valid custom remote model is not provided.
File modelFile = await modelManager.getLatestModelFile(model);
You can feed this file directly into an interpreter or preprocess it, depending on the interpreter of your choice.
Possible Flutter TF Lite interpreters:
Google does not recommend usage of any specific interpreter and leaves it up to the user to decide.
Getting Started
See the example directory for a complete sample app using Firebase Machine Learning Custom.
Issues and feedback
Please file Flutterfire specific issues, bugs, or feature requests in our issue tracker.
Plugin issues that are not specific to Flutterfire can be filed in the Flutter issue tracker.
To contribute a change to this plugin, please review our contribution guide, and send a pull request.
Use this package as a library
Depend on it
Run this command:
With Flutter:
$ flutter pub add firebase_ml_customThis will add a line like this to your package's pubspec.yaml (and run an implicit dart pub get):
dependencies:
firebase_ml_custom: ^0.2.0+3
Alternatively, your editor might support flutter pub get. Check the docs for your editor to learn more.
Import it
Now in your Dart code, you can use:
import 'package:firebase_ml_custom/firebase_ml_custom.dart';// ignore_for_file: require_trailing_commas
// Copyright 2020, the Chromium project authors. Please see the AUTHORS file
// for details. All rights reserved. Use of this source code is governed by a
// BSD-style license that can be found in the LICENSE file.
// @dart=2.9
import 'dart:async';
import 'dart:io';
import 'package:firebase_ml_custom/firebase_ml_custom.dart';
import 'package:flutter/material.dart';
import 'package:image_picker/image_picker.dart';
void main() {
runApp(
MaterialApp(
home: MyApp(),
),
);
}
/// Widget with a future function that initiates actions from FirebaseML.
class MyApp extends StatefulWidget {
@override
_MyAppState createState() => _MyAppState();
}
class _MyAppState extends State<MyApp> {
File _image;
List<Map<dynamic, dynamic>> _labels;
//When the model is ready, _loaded changes to trigger the screen state change.
Future<String> _loaded = loadModel();
/// Triggers selection of an image and the consequent inference.
Future<void> getImageLabels() async {
try {
final pickedFile =
await ImagePicker().getImage(source: ImageSource.gallery);
final image = File(pickedFile.path);
if (image == null) {
return;
}
// TODO TFLite plugin is broken, see https://github.com/shaqian/flutter_tflite/issues/139#issuecomment-836596852
// var labels = List<Map>.from(await Tflite.runModelOnImage(
// path: image.path,
// imageStd: 127.5,
// ));
var labels = List<Map>.from([]);
setState(() {
_labels = labels;
_image = image;
});
} catch (exception) {
print("Failed on getting your image and it's labels: $exception");
print('Continuing with the program...');
rethrow;
}
}
/// Gets the model ready for inference on images.
static Future<String> loadModel() async {
final modelFile = await loadModelFromFirebase();
return loadTFLiteModel(modelFile);
}
/// Downloads custom model from the Firebase console and return its file.
/// located on the mobile device.
static Future<File> loadModelFromFirebase() async {
try {
// Create model with a name that is specified in the Firebase console
final model = FirebaseCustomRemoteModel('mobilenet_v1_1_0_224');
// Specify conditions when the model can be downloaded.
// If there is no wifi access when the app is started,
// this app will continue loading until the conditions are satisfied.
final conditions = FirebaseModelDownloadConditions(
androidRequireWifi: true, iosAllowCellularAccess: false);
// Create model manager associated with default Firebase App instance.
final modelManager = FirebaseModelManager.instance;
// Begin downloading and wait until the model is downloaded successfully.
await modelManager.download(model, conditions);
assert(await modelManager.isModelDownloaded(model) == true);
// Get latest model file to use it for inference by the interpreter.
var modelFile = await modelManager.getLatestModelFile(model);
assert(modelFile != null);
return modelFile;
} catch (exception) {
print('Failed on loading your model from Firebase: $exception');
print('The program will not be resumed');
rethrow;
}
}
/// Loads the model into some TF Lite interpreter.
/// In this case interpreter provided by tflite plugin.
static Future<String> loadTFLiteModel(File modelFile) async {
try {
// TODO TFLite plugin is broken, see https://github.com/shaqian/flutter_tflite/issues/139#issuecomment-836596852
// final appDirectory = await getApplicationDocumentsDirectory();
// final labelsData =
// await rootBundle.load('assets/labels_mobilenet_v1_224.txt');
// final labelsFile =
// await File('${appDirectory.path}/_labels_mobilenet_v1_224.txt')
// .writeAsBytes(labelsData.buffer.asUint8List(
// labelsData.offsetInBytes, labelsData.lengthInBytes));
// assert(await Tflite.loadModel(
// model: modelFile.path,
// labels: labelsFile.path,
// isAsset: false,
// ) ==
// 'success');
return 'Model is loaded';
} catch (exception) {
print(
'Failed on loading your model to the TFLite interpreter: $exception');
print('The program will not be resumed');
rethrow;
}
}
/// Shows image selection screen only when the model is ready to be used.
Widget readyScreen() {
return Scaffold(
appBar: AppBar(
title: const Text('Firebase ML Custom example app'),
),
body: Column(
children: [
if (_image != null)
Image.file(_image)
else
const Text('Please select image to analyze.'),
Column(
children: _labels != null
? _labels.map((label) {
return Text("${label["label"]}");
}).toList()
: [],
),
],
),
floatingActionButton: FloatingActionButton(
onPressed: getImageLabels,
child: const Icon(Icons.add),
),
);
}
/// In case of error shows unrecoverable error screen.
Widget errorScreen() {
return const Scaffold(
body: Center(
child: Text('Error loading model. Please check the logs.'),
),
);
}
/// In case of long loading shows loading screen until model is ready or
/// error is received.
Widget loadingScreen() {
return Scaffold(
body: Center(
child: Column(
mainAxisAlignment: MainAxisAlignment.center,
children: const <Widget>[
Padding(
padding: EdgeInsets.only(bottom: 20),
child: CircularProgressIndicator(),
),
Text('Please make sure that you are using wifi.'),
],
),
),
);
}
/// Shows different screens based on the state of the custom model.
@override
Widget build(BuildContext context) {
return DefaultTextStyle(
style: Theme.of(context).textTheme.headline2,
textAlign: TextAlign.center,
child: FutureBuilder<String>(
future: _loaded, // a previously-obtained Future<String> or null
builder: (BuildContext context, AsyncSnapshot<String> snapshot) {
if (snapshot.hasData) {
return readyScreen();
} else if (snapshot.hasError) {
return errorScreen();
} else {
return loadingScreen();
}
},
),
);
}
}#flutter #dart #mobile #mobile-apps
