# Understand Types of Analytics in 5 mins

## Exploring the three different types of analytics Descriptive, Predictive, Prescriptive

The best data scientist or data analyst from others is their ability to identify the kind of analytics that can be leveraged to benefit the business — at an optimum. There are three dominant types of analytics –Descriptive, Predictive and Prescriptive analytics. Each of these analytic types offers a different insight.

# Descriptive Analysis

Descriptive statistics are simply the summarizing statistic that quantitatively describes or summarizes features from a collection of information, also we can say coefficients that summarize a given data set.

## Types of Descriptive Statistics

• measures of central tendency
• measures of spread

# measures of central tendency

## Mean

The mean is a descriptive statistic that looks at the average value of a data set.

let’s see the example on the data set using python.

import pandas as pd
import numpy as np

df = pd.read_csv('Bengaluru_House_Data.csv')
df.head(3)

Dataset

Now see the mean of this all numerical columns.

df.mean()

Mean

## Median

In the median, we first need to reorganize our data set in ascending order. Then the median is the value that coincides with the middle of the data set.

Let’s see the example

df.median()

Median

#analytics #statistics #data-science #predictive-analytics #data analysis

1655019480

## Learning Google V8

The sole purpose of this project is to aid me in leaning Google's V8 JavaScript engine

### Isolate

An Isolate is an independant copy of the V8 runtime which includes its own heap. Two different Isolates can run in parallel and can be seen as entirely different sandboxed instances of a V8 runtime.

### Context

To allow separate JavaScript applications to run in the same isolate a context must be specified for each one. This is to avoid them interfering with each other, for example by changing the builtin objects provided.

### Template

This is the super class of both ObjecTemplate and FunctionTemplate. Remember that in JavaScript a function can have fields just like objects.

class V8_EXPORT Template : public Data {
public:
void Set(Local<Name> name, Local<Data> value,
PropertyAttribute attributes = None);
void SetPrivate(Local<Private> name, Local<Data> value,
PropertyAttribute attributes = None);
V8_INLINE void Set(Isolate* isolate, const char* name, Local<Data> value);

void SetAccessorProperty(
Local<Name> name,
Local<FunctionTemplate> getter = Local<FunctionTemplate>(),
Local<FunctionTemplate> setter = Local<FunctionTemplate>(),
PropertyAttribute attribute = None,
AccessControl settings = DEFAULT);

The Set function can be used to have an name and a value set on an instance created from this template. The SetAccessorProperty is for properties that are get/set using functions.

enum PropertyAttribute {
/** None. **/
None = 0,
/** ReadOnly, i.e., not writable. **/
ReadOnly = 1 << 0,
/** DontEnum, i.e., not enumerable. **/
DontEnum = 1 << 1,
/** DontDelete, i.e., not configurable. **/
DontDelete = 1 << 2
};

enum AccessControl {
DEFAULT               = 0,
ALL_CAN_READ          = 1,
ALL_CAN_WRITE         = 1 << 1,
PROHIBITS_OVERWRITING = 1 << 2
};

### ObjectTemplate

These allow you to create JavaScript objects without a dedicated constructor. When an instance is created using an ObjectTemplate the new instance will have the properties and functions configured on the ObjectTemplate.

This would be something like:

const obj = {};

This class is declared in include/v8.h and extends Template:

class V8_EXPORT ObjectTemplate : public Template {
...
}
class V8_EXPORT Template : public Data {
...
}
class V8_EXPORT Data {
private:
Data();
};

We create an instance of ObjectTemplate and we can add properties to it that all instance created using this ObjectTemplate instance will have. This is done by calling Set which is member of the Template class. You specify a Local for the property. Name is a superclass for Symbol and String which can be both be used as names for a property.

The implementation for Set can be found in src/api/api.cc:

void Template::Set(v8::Local<Name> name, v8::Local<Data> value, v8::PropertyAttribute attribute) {
...

i::ApiNatives::AddDataProperty(isolate, templ, Utils::OpenHandle(*name),
value_obj,
static_cast<i::PropertyAttributes>(attribute));
}

There is an example in objecttemplate_test.cc

### FunctionTemplate

Is a template that is used to create functions and like ObjectTemplate it inherits from Template:

class V8_EXPORT FunctionTemplate : public Template {
}

Rememeber that a function in javascript can have properties just like object.

There is an example in functiontemplate_test.cc

An instance of a function template can be created using:

Local<FunctionTemplate> ft = FunctionTemplate::New(isolate_, function_callback, data);
Local<Function> function = ft->GetFunction(context).ToLocalChecked();

And the function can be called using:

MaybeLocal<Value> ret = function->Call(context, recv, 0, nullptr);

Function::Call can be found in src/api/api.cc:

bool has_pending_exception = false;
auto self = Utils::OpenHandle(this);
i::Handle<i::Object> recv_obj = Utils::OpenHandle(*recv);
i::Handle<i::Object>* args = reinterpret_cast<i::Handle<i::Object>*>(argv);
Local<Value> result;
has_pending_exception = !ToLocal<Value>(
i::Execution::Call(isolate, self, recv_obj, argc, args), &result);

Notice that the return value of Call which is a MaybeHandle<Object> will be passed to ToLocal which is defined in api.h:

template <class T>
inline bool ToLocal(v8::internal::MaybeHandle<v8::internal::Object> maybe,
Local<T>* local) {
v8::internal::Handle<v8::internal::Object> handle;
if (maybe.ToHandle(&handle)) {
*local = Utils::Convert<v8::internal::Object, T>(handle);
return true;
}
return false;

So lets take a look at Execution::Call which can be found in execution/execution.cc and it calls:

return Invoke(isolate, InvokeParams::SetUpForCall(isolate, callable, receiver, argc, argv));

SetUpForCall will return an InvokeParams. TODO: Take a closer look at InvokeParams.

V8_WARN_UNUSED_RESULT MaybeHandle<Object> Invoke(Isolate* isolate,
const InvokeParams& params) {
Handle<Object> receiver = params.is_construct
? isolate->factory()->the_hole_value()
: params.receiver;

In our case is_construct is false as we are not using new and the receiver, the this in the function should be set to the receiver that we passed in. After that we have Builtins::InvokeApiFunction

auto value = Builtins::InvokeApiFunction(
isolate, params.is_construct, function, receiver, params.argc,
params.argv, Handle<HeapObject>::cast(params.new_target));
result = HandleApiCallHelper<false>(isolate, function, new_target,
fun_data, receiver, arguments);

api-arguments-inl.h has:

FunctionCallbackArguments::Call(CallHandlerInfo handler) {
...
ExternalCallbackScope call_scope(isolate, FUNCTION_ADDR(f));
FunctionCallbackInfo<v8::Value> info(values_, argv_, argc_);
f(info);
return GetReturnValue<Object>(isolate);
}

The call to f(info) is what invokes the callback, which is just a normal function call.

Back in HandleApiCallHelper we have:

Handle<Object> result = custom.Call(call_data);

RETURN_EXCEPTION_IF_SCHEDULED_EXCEPTION(isolate, Object);

RETURN_EXCEPTION_IF_SCHEDULED_EXCEPTION expands to:

Handle<Object> result = custom.Call(call_data);
do {
Isolate* __isolate__ = (isolate);
((void) 0);
if (__isolate__->has_scheduled_exception()) {
__isolate__->PromoteScheduledException();
return MaybeHandle<Object>();
}
} while (false);

Notice that if there was an exception an empty object is returned. Later in Invoke in execution.cca:

auto value = Builtins::InvokeApiFunction(
isolate, params.is_construct, function, receiver, params.argc,
params.argv, Handle<HeapObject>::cast(params.new_target));
bool has_exception = value.is_null();
if (has_exception) {
if (params.message_handling == Execution::MessageHandling::kReport) {
isolate->ReportPendingMessages();
}
return MaybeHandle<Object>();
} else {
isolate->clear_pending_message();
}
return value;

Looking at this is looks like passing back an empty object will cause an exception to be triggered?

### Address

Address can be found in include/v8-internal.h:

typedef uintptr_t Address;

uintptr_t is an optional type specified in cstdint and is capable of storing a data pointer. It is an unsigned integer type that any valid pointer to void can be converted to this type (and back).

### TaggedImpl

This class is declared in `src/objects/tagged-impl.h and has a single private member which is declared as:

public
constexpr StorageType ptr() const { return ptr_; }
private:
StorageType ptr_;

An instance can be created using:

i::TaggedImpl<i::HeapObjectReferenceType::STRONG, i::Address>  tagged{};

Storage type can also be Tagged_t which is defined in globals.h:

using Tagged_t = uint32_t;

It looks like it can be a different value when using pointer compression.

See tagged_test.cc for an example.

### Object

This class extends TaggedImpl:

class Object : public TaggedImpl<HeapObjectReferenceType::STRONG, Address> {

An Object can be created using the default constructor, or by passing in an Address which will delegate to TaggedImpl constructors. Object itself does not have any members (apart from ptr_ which is inherited from TaggedImpl that is). So if we create an Object on the stack this is like a pointer/reference to an object:

+------+
|Object|
|------|
|ptr_  |---->
+------+

Now, ptr_ is a StorageType so it could be a Smi in which case it would just contains the value directly, for example a small integer:

+------+
|Object|
|------|
|  18  |
+------+

See object_test.cc for an example.

### ObjectSlot

i::Object obj{18};
i::FullObjectSlot slot{&obj};
+----------+      +---------+
|ObjectSlot|      | Object  |
|----------|      |---------|
| address  | ---> |   18    |
+----------+      +---------+

See objectslot_test.cc for an example.

### Maybe

A Maybe is like an optional which can either hold a value or nothing.

template <class T>
class Maybe {
public:
V8_INLINE bool IsNothing() const { return !has_value_; }
V8_INLINE bool IsJust() const { return has_value_; }
...

private:
bool has_value_;
T value_;
}

I first thought that name Just was a little confusing but if you read this like:

bool cond = true;
Maybe<int> maybe = cond ? Just<int>(10) : Nothing<int>();

I think it makes more sense. There are functions that check if the Maybe is nothing and crash the process if so. You can also check and return the value by using FromJust.

The usage of Maybe is where api calls can fail and returning Nothing is a way of signaling this.

See maybe_test.cc for an example.

### MaybeLocal

template <class T>
class MaybeLocal {
public:
V8_INLINE MaybeLocal() : val_(nullptr) {}
V8_INLINE Local<T> ToLocalChecked();
V8_INLINE bool IsEmpty() const { return val_ == nullptr; }
template <class S>
V8_WARN_UNUSED_RESULT V8_INLINE bool ToLocal(Local<S>* out) const {
out->val_ = IsEmpty() ? nullptr : this->val_;
return !IsEmpty();
}

private:
T* val_;

ToLocalChecked will crash the process if val_ is a nullptr. If you want to avoid a crash one can use ToLocal.

See maybelocal_test.cc for an example.

### Data

Is the super class of all objects that can exist the V8 heap:

class V8_EXPORT Data {
private:
Data();
};

### Value

Value extends Data and adds a number of methods that check if a Value is of a certain type, like IsUndefined(), IsNull, IsNumber etc. It also has useful methods to convert to a Local, for example:

V8_WARN_UNUSED_RESULT MaybeLocal<Number> ToNumber(Local<Context> context) const;
V8_WARN_UNUSED_RESULT MaybeLocal<String> ToNumber(Local<String> context) const;
...

### Handle

A Handle is similar to a Object and ObjectSlot in that it also contains an Address member (called location_ and declared in HandleBase), but with the difference is that Handles acts as a layer of abstraction and can be relocated by the garbage collector. Can be found in src/handles/handles.h.

class HandleBase {
...
protected:
Address* location_;
}
template <typename T>
class Handle final : public HandleBase {
...
}
+----------+                  +--------+         +---------+
|  Handle  |                  | Object |         |   int   |
|----------|      +-----+     |--------|         |---------|
|*location_| ---> |&ptr_| --> | ptr_   | ----->  |     5   |
+----------+      +-----+     +--------+         +---------+
(gdb) p handle
\$8 = {<v8::internal::HandleBase> = {location_ = 0x7ffdf81d60c0}, <No data fields>}

Notice that location_ contains a pointer:

(gdb) p /x *(int*)0x7ffdf81d60c0
\$9 = 0xa9d330

And this is the same as the value in obj:

(gdb) p /x obj.ptr_
\$14 = 0xa9d330

And we can access the int using any of the pointers:

(gdb) p /x *value
\$16 = 0x5
(gdb) p /x *obj.ptr_
\$17 = 0x5
(gdb) p /x *(int*)0x7ffdf81d60c0
\$18 = 0xa9d330
(gdb) p /x *(*(int*)0x7ffdf81d60c0)
\$19 = 0x5

See handle_test.cc for an example.

### HandleScope

Contains a number of Local/Handle's (think pointers to objects but is managed by V8) and will take care of deleting the Local/Handles for us. HandleScopes are stack allocated

When ~HandleScope is called all handles created within that scope are removed from the stack maintained by the HandleScope which makes objects to which the handles point being eligible for deletion from the heap by the GC.

A HandleScope only has three members:

internal::Isolate* isolate_;
internal::Address* prev_next_;
internal::Address* prev_limit_;

Lets take a closer look at what happens when we construct a HandleScope:

v8::HandleScope handle_scope{isolate_};

The constructor call will end up in src/api/api.cc and the constructor simply delegates to Initialize:

HandleScope::HandleScope(Isolate* isolate) { Initialize(isolate); }

void HandleScope::Initialize(Isolate* isolate) {
i::Isolate* internal_isolate = reinterpret_cast<i::Isolate*>(isolate);
...
i::HandleScopeData* current = internal_isolate->handle_scope_data();
isolate_ = internal_isolate;
prev_next_ = current->next;
prev_limit_ = current->limit;
current->level++;
}

Every v8::internal::Isolate has member of type HandleScopeData:

HandleScopeData* handle_scope_data() { return &handle_scope_data_; }
HandleScopeData handle_scope_data_;

HandleScopeData is a struct defined in src/handles/handles.h:

struct HandleScopeData final {
Address* next;
Address* limit;
int level;
int sealed_level;
CanonicalHandleScope* canonical_scope;

void Initialize() {
next = limit = nullptr;
sealed_level = level = 0;
canonical_scope = nullptr;
}
};

Notice that there are two pointers (Address*) to next and a limit. When a HandleScope is Initialized the current handle_scope_data will be retrieved from the internal isolate. The HandleScope instance that is getting created stores the next/limit pointers of the current isolate so that they can be restored when this HandleScope is closed (see CloseScope).

So with a HandleScope created, how does a Local interact with this instance?

When a Local is created this will/might go through FactoryBase::NewStruct which will allocate a new Map and then create a Handle for the InstanceType being created:

Handle<Struct> str = handle(Struct::cast(result), isolate());

This will land in the constructor Handlesrc/handles/handles-inl.h

template <typename T>
Handle<T>::Handle(T object, Isolate* isolate): HandleBase(object.ptr(), isolate) {}

HandleBase::HandleBase(Address object, Isolate* isolate)
: location_(HandleScope::GetHandle(isolate, object)) {}

Notice that object.ptr() is used to pass the Address to HandleBase. And also notice that HandleBase sets its location_ to the result of HandleScope::GetHandle.

Address* HandleScope::GetHandle(Isolate* isolate, Address value) {
DCHECK(AllowHandleAllocation::IsAllowed());
HandleScopeData* data = isolate->handle_scope_data();
CanonicalHandleScope* canonical = data->canonical_scope;
return canonical ? canonical->Lookup(value) : CreateHandle(isolate, value);
}

Which will call CreateHandle in this case and this function will retrieve the current isolate's handle_scope_data:

HandleScopeData* data = isolate->handle_scope_data();
Address* result = data->next;
if (result == data->limit) {
result = Extend(isolate);
}

In this case both next and limit will be 0x0 so Extend will be called. Extend will also get the isolates handle_scope_data and check the current level and after that get the isolates HandleScopeImplementer:

HandleScopeImplementer* impl = isolate->handle_scope_implementer();

HandleScopeImplementer is declared in src/api/api.h

HandleScope:CreateHandle will get the handle_scope_data from the isolate:

Address* HandleScope::CreateHandle(Isolate* isolate, Address value) {
HandleScopeData* data = isolate->handle_scope_data();
if (result == data->limit) {
result = Extend(isolate);
}
// Update the current next field, set the value in the created handle,
// and return the result.
data->next = reinterpret_cast<Address*>(reinterpret_cast<Address>(result) + sizeof(Address));
*result = value;
return result;
}

Notice that data->next is set to the address passed in + the size of an Address.

The destructor for HandleScope will call CloseScope. See handlescope_test.cc for an example.

### EscapableHandleScope

Local handles are located on the stack and are deleted when the appropriate destructor is called. If there is a local HandleScope then it will take care of this when the scope returns. When there are no references left to a handle it can be garbage collected. This means if a function has a HandleScope and wants to return a handle/local it will not be available after the function returns. This is what EscapableHandleScope is for, it enable the value to be placed in the enclosing handle scope to allow it to survive. When the enclosing HandleScope goes out of scope it will be cleaned up.

class V8_EXPORT EscapableHandleScope : public HandleScope {
public:
explicit EscapableHandleScope(Isolate* isolate);
V8_INLINE ~EscapableHandleScope() = default;
template <class T>
V8_INLINE Local<T> Escape(Local<T> value) {
internal::Address* slot = Escape(reinterpret_cast<internal::Address*>(*value));
return Local<T>(reinterpret_cast<T*>(slot));
}

template <class T>
V8_INLINE MaybeLocal<T> EscapeMaybe(MaybeLocal<T> value) {
return Escape(value.FromMaybe(Local<T>()));
}

private:
...
internal::Address* escape_slot_;
};

From api.cc

EscapableHandleScope::EscapableHandleScope(Isolate* v8_isolate) {
i::Isolate* isolate = reinterpret_cast<i::Isolate*>(v8_isolate);
escape_slot_ = CreateHandle(isolate, i::ReadOnlyRoots(isolate).the_hole_value().ptr());
Initialize(v8_isolate);
}

So when an EscapableHandleScope is created it will create a handle with the hole value and store it in the escape_slot_ which is of type Address. This Handle will be created in the current HandleScope, and EscapableHandleScope can later set a value for that pointer/address which it want to be escaped. Later when that HandleScope goes out of scope it will be cleaned up. It then calls Initialize just like a normal HandleScope would.

i::Address* HandleScope::CreateHandle(i::Isolate* isolate, i::Address value) {
return i::HandleScope::CreateHandle(isolate, value);
}

From handles-inl.h:

Address* HandleScope::CreateHandle(Isolate* isolate, Address value) {
DCHECK(AllowHandleAllocation::IsAllowed());
HandleScopeData* data = isolate->handle_scope_data();
Address* result = data->next;
if (result == data->limit) {
result = Extend(isolate);
}
// Update the current next field, set the value in the created handle,
// and return the result.
DCHECK_LT(reinterpret_cast<Address>(result),
reinterpret_cast<Address>(data->limit));
data->next = reinterpret_cast<Address*>(reinterpret_cast<Address>(result) +
sizeof(Address));
*result = value;
return result;
}

When Escape is called the following happens (v8.h):

template <class T>
V8_INLINE Local<T> Escape(Local<T> value) {
internal::Address* slot = Escape(reinterpret_cast<internal::Address*>(*value));
return Local<T>(reinterpret_cast<T*>(slot));
}

An the EscapeableHandleScope::Escape (api.cc):

i::Address* EscapableHandleScope::Escape(i::Address* escape_value) {
i::Heap* heap = reinterpret_cast<i::Isolate*>(GetIsolate())->heap();
Utils::ApiCheck(i::Object(*escape_slot_).IsTheHole(heap->isolate()),
"EscapableHandleScope::Escape", "Escape value set twice");
if (escape_value == nullptr) {
*escape_slot_ = i::ReadOnlyRoots(heap).undefined_value().ptr();
return nullptr;
}
*escape_slot_ = *escape_value;
return escape_slot_;
}

If the escape_value is null, the escape_slot that is a pointer into the parent HandleScope is set to the undefined_value() instead of the hole value which is was previously, and nullptr will be returned. This returned address/pointer will then be returned after being casted to T*. Next, we take a look at what happens when the EscapableHandleScope goes out of scope. This will call HandleScope::~HandleScope which makes sense as any other Local handles should be cleaned up.

Escape copies the value of its argument into the enclosing scope, deletes alli its local handles, and then gives back the new handle copy which can safely be returned.

TODO:

### Local

Has a single member val_ which is of type pointer to T:

template <class T> class Local {
...
private:
T* val_
}

Notice that this is a pointer to T. We could create a local using:

v8::Local<v8::Value> empty_value;

So a Local contains a pointer to type T. We can access this pointer using operator-> and operator*.

We can cast from a subtype to a supertype using Local::Cast:

v8::Local<v8::Number> nr = v8::Local<v8::Number>(v8::Number::New(isolate_, 12));
v8::Local<v8::Value> val = v8::Local<v8::Value>::Cast(nr);

And there is also the

v8::Local<v8::Value> val2 = nr.As<v8::Value>();

See local_test.cc for an example.

### PrintObject

Using _v8_internal_Print_Object from c++:

\$ nm -C libv8_monolith.a | grep Print_Object
0000000000000000 T _v8_internal_Print_Object(void*)

Notice that this function does not have a namespace. We can use this as:

extern void _v8_internal_Print_Object(void* object);

_v8_internal_Print_Object(*((v8::internal::Object**)(*global)));

Lets take a closer look at the above:

v8::internal::Object** gl = ((v8::internal::Object**)(*global));

We use the dereference operator to get the value of a Local (*global), which is just of type T*, a pointer to the type the Local:

template <class T>
class Local {
...
private:
T* val_;
}

We are then casting that to be of type pointer-to-pointer to Object.

gl**        Object*         Object
+-----+      +------+      +-------+
|     |----->|      |----->|       |
+-----+      +------+      +-------+

An instance of v8::internal::Object only has a single data member which is a field named ptr_ of type Address:

src/objects/objects.h:

class Object : public TaggedImpl<HeapObjectReferenceType::STRONG, Address> {
public:
constexpr Object() : TaggedImpl(kNullAddress) {}
explicit constexpr Object(Address ptr) : TaggedImpl(ptr) {}

#define IS_TYPE_FUNCTION_DECL(Type) \
V8_INLINE bool Is##Type() const;  \
V8_INLINE bool Is##Type(const Isolate* isolate) const;
OBJECT_TYPE_LIST(IS_TYPE_FUNCTION_DECL)
HEAP_OBJECT_TYPE_LIST(IS_TYPE_FUNCTION_DECL)
IS_TYPE_FUNCTION_DECL(HashTableBase)
IS_TYPE_FUNCTION_DECL(SmallOrderedHashTable)
#undef IS_TYPE_FUNCTION_DECL
V8_INLINE bool IsNumber(ReadOnlyRoots roots) const;
}

Lets take a look at one of these functions and see how it is implemented. For example in the OBJECT_TYPE_LIST we have:

#define OBJECT_TYPE_LIST(V) \
V(LayoutDescriptor)       \
V(Primitive)              \
V(Number)                 \
V(Numeric)

So the object class will have a function that looks like:

inline bool IsNumber() const;
inline bool IsNumber(const Isolate* isolate) const;

And in src/objects/objects-inl.h we will have the implementations:

bool Object::IsNumber() const {
return IsHeapObject() && HeapObject::cast(*this).IsNumber();
}

IsHeapObject is defined in TaggedImpl:

constexpr inline bool IsHeapObject() const { return IsStrong(); }

constexpr inline bool IsStrong() const {
#if V8_HAS_CXX14_CONSTEXPR
DCHECK_IMPLIES(!kCanBeWeak, !IsSmi() == HAS_STRONG_HEAP_OBJECT_TAG(ptr_));
#endif
return kCanBeWeak ? HAS_STRONG_HEAP_OBJECT_TAG(ptr_) : !IsSmi();
}

The macro can be found in src/common/globals.h:

#define HAS_STRONG_HEAP_OBJECT_TAG(value)                          \
(((static_cast<i::Tagged_t>(value) & ::i::kHeapObjectTagMask) == \
::i::kHeapObjectTag))

So we are casting ptr_ which is of type Address into type Tagged_t which is defined in src/common/global.h and can be different depending on if compressed pointers are used or not. If they are not supported it is the same as Address:

using Tagged_t = Address;

src/objects/tagged-impl.h:

template <HeapObjectReferenceType kRefType, typename StorageType>
class TaggedImpl {

StorageType ptr_;
}

The HeapObjectReferenceType can be either WEAK or STRONG. And the storage type is Address in this case. So Object itself only has one member that is inherited from its only super class and this is ptr_.

So the following is telling the compiler to treat the value of our Local, *global, as a pointer (which it already is) to a pointer that points to a memory location that adhers to the layout of an v8::internal::Object type, which we know now has a prt_ member. And we want to dereference it and pass it into the function.

_v8_internal_Print_Object(*((v8::internal::Object**)(*global)));

### ObjectTemplate

But I'm still missing the connection between ObjectTemplate and object. When we create it we use:

Local<ObjectTemplate> global = ObjectTemplate::New(isolate);

In src/api/api.cc we have:

static Local<ObjectTemplate> ObjectTemplateNew(
i::Isolate* isolate, v8::Local<FunctionTemplate> constructor,
bool do_not_cache) {
i::Handle<i::Struct> struct_obj = isolate->factory()->NewStruct(
i::OBJECT_TEMPLATE_INFO_TYPE, i::AllocationType::kOld);
i::Handle<i::ObjectTemplateInfo> obj = i::Handle<i::ObjectTemplateInfo>::cast(struct_obj);
InitializeTemplate(obj, Consts::OBJECT_TEMPLATE);
int next_serial_number = 0;
if (!constructor.IsEmpty())
obj->set_constructor(*Utils::OpenHandle(*constructor));
obj->set_data(i::Smi::zero());
return Utils::ToLocal(obj);
}

What is a Struct in this context?
src/objects/struct.h

#include "torque-generated/class-definitions-tq.h"

class Struct : public TorqueGeneratedStruct<Struct, HeapObject> {
public:
inline void InitializeBody(int object_size);
void BriefPrintDetails(std::ostream& os);
TQ_OBJECT_CONSTRUCTORS(Struct)

Notice that the include is specifying torque-generated include which can be found out/x64.release_gcc/gen/torque-generated/class-definitions-tq. So, somewhere there must be an call to the torque executable which generates the Code Stub Assembler C++ headers and sources before compiling the main source files. There is and there is a section about this in Building V8. The macro TQ_OBJECT_CONSTRUCTORS can be found in src/objects/object-macros.h and expands to:

constexpr Struct() = default;

protected:
template <typename TFieldType, int kFieldOffset>
friend class TaggedField;

inline explicit Struct(Address ptr);

So what does the TorqueGeneratedStruct look like?

template <class D, class P>
class TorqueGeneratedStruct : public P {
public:

Where D is Struct and P is HeapObject in this case. But the above is the declartion of the type but what we have in the .h file is what was generated.

This type is defined in src/objects/struct.tq:

@abstract
@generatePrint
@generateCppClass
extern class Struct extends HeapObject {
}

NewStruct can be found in src/heap/factory-base.cc

template <typename Impl>
HandleFor<Impl, Struct> FactoryBase<Impl>::NewStruct(
InstanceType type, AllocationType allocation) {
Map map = Map::GetStructMap(read_only_roots(), type);
int size = map.instance_size();
HeapObject result = AllocateRawWithImmortalMap(size, allocation, map);
HandleFor<Impl, Struct> str = handle(Struct::cast(result), isolate());
str->InitializeBody(size);
return str;
}

Every object that is stored on the v8 heap has a Map (src/objects/map.h) that describes the structure of the object being stored.

class Map : public HeapObject {
1725      return Utils::ToLocal(obj);
(gdb) p obj
\$6 = {<v8::internal::HandleBase> = {location_ = 0x30b5160}, <No data fields>}

So this is the connection, what we see as a Local is a HandleBase. TODO: dig into this some more when I have time.

(lldb) expr gl
(v8::internal::Object **) \$0 = 0x00000000020ee160
(lldb) memory read -f x -s 8 -c 1 gl
0x020ee160: 0x00000aee081c0121

(lldb) memory read -f x -s 8 -c 1 *gl
0xaee081c0121: 0x0200000002080433

You can reload .lldbinit using the following command:

(lldb) command source ~/.lldbinit

This can be useful when debugging a lldb command. You can set a breakpoint and break at that location and make updates to the command and reload without having to restart lldb.

Currently, the lldb-commands.py that ships with v8 contains an extra operation of the parameter pased to ptr_arg_cmd:

def ptr_arg_cmd(debugger, name, param, cmd):
if not param:
print("'{}' requires an argument".format(name))
return
param = '(void*)({})'.format(param)
no_arg_cmd(debugger, cmd.format(param))

Notice that param is the object that we want to print, for example lets say it is a local named obj:

param = "(void*)(obj)"

This will then be "passed"/formatted into the command string:

"_v8_internal_Print_Object(*(v8::internal::Object**)(*(void*)(obj))")

#### Threads

V8 is single threaded (the execution of the functions of the stack) but there are supporting threads used for garbage collection, profiling (IC, and perhaps other things) (I think). Lets see what threads there are:

\$ LD_LIBRARY_PATH=../v8_src/v8/out/x64.release_gcc/ lldb ./hello-world
(lldb) br s -n main
(lldb) r
(lldb) thread list
thread #1: tid = 0x2efca6, 0x0000000100001e16 hello-world`main(argc=1, argv=0x00007fff5fbfee98) + 38 at hello-world.cc:40, queue = 'com.apple.main-thread', stop reason = breakpoint 1.1

So at startup there is only one thread which is what we expected. Lets skip ahead to where we create the platform:

Platform* platform = platform::CreateDefaultPlatform();
...
DefaultPlatform* platform = new DefaultPlatform(idle_task_support, tracing_controller);
platform->SetThreadPoolSize(thread_pool_size);

(lldb) fr v thread_pool_size
(int) thread_pool_size = 0

Next there is a check for 0 and the number of processors -1 is used as the size of the thread pool:

(lldb) fr v thread_pool_size
(int) thread_pool_size = 7

This is all that SetThreadPoolSize does. After this we have:

platform->EnsureInitialized();

for (int i = 0; i < thread_pool_size_; ++i)
thread_pool_.push_back(new WorkerThread(&queue_));

new WorkerThread will create a new pthread (on my system which is MacOSX):

result = pthread_create(&data_->thread_, &attr, ThreadEntry, this);

ThreadEntry can be found in src/base/platform/platform-posix.

### International Component for Unicode (ICU)

International Components for Unicode (ICU) deals with internationalization (i18n). ICU provides support locale-sensitve string comparisons, date/time/number/currency formatting etc.

There is an optional API called ECMAScript 402 which V8 suppports and which is enabled by default. i18n-support says that even if your application does not use ICU you still need to call InitializeICU :

V8::InitializeICU();

### Local

Local<String> script_name = ...;

So what is script_name. Well it is an object reference that is managed by the v8 GC. The GC needs to be able to move things (pointers around) and also track if things should be GC'd. Local handles as opposed to persistent handles are light weight and mostly used local operations. These handles are managed by HandleScopes so you must have a handlescope on the stack and the local is only valid as long as the handlescope is valid. This uses Resource Acquisition Is Initialization (RAII) so when the HandleScope instance goes out of scope it will remove all the Local instances.

The Local class (in include/v8.h) only has one member which is of type pointer to the type T. So for the above example it would be:

String* val_;

You can find the available operations for a Local in include/v8.h.

(lldb) p script_name.IsEmpty()
(bool) \$12 = false

A Local has overloaded a number of operators, for example ->:

(lldb) p script_name->Length()
(int) \$14 = 7

Where Length is a method on the v8 String class.

The handle stack is not part of the C++ call stack, but the handle scopes are embedded in the C++ stack. Handle scopes can only be stack-allocated, not allocated with new.

### Persistent

https://v8.dev/docs/embed: Persistent handles provide a reference to a heap-allocated JavaScript Object, just like a local handle. There are two flavors, which differ in the lifetime management of the reference they handle. Use a persistent handle when you need to keep a reference to an object for more than one function call, or when handle lifetimes do not correspond to C++ scopes. Google Chrome, for example, uses persistent handles to refer to Document Object Model (DOM) nodes.

A persistent handle can be made weak, using PersistentBase::SetWeak, to trigger a callback from the garbage collector when the only references to an object are from weak persistent handles.

A UniquePersistent handle relies on C++ constructors and destructors to manage the lifetime of the underlying object. A Persistent can be constructed with its constructor, but must be explicitly cleared with Persistent::Reset.

So how is a persistent object created?
Let's write a test and find out (test/persistent-object_text.cc):

\$ make test/persistent-object_test
\$ ./test/persistent-object_test --gtest_filter=PersistentTest.value

Now, to create an instance of Persistent we need a Local instance or the Persistent instance will just be empty.

Local<Object> o = Local<Object>::New(isolate_, Object::New(isolate_));

Local<Object>::New can be found in src/api/api.cc:

Local<v8::Object> v8::Object::New(Isolate* isolate) {
i::Isolate* i_isolate = reinterpret_cast<i::Isolate*>(isolate);
LOG_API(i_isolate, Object, New);
ENTER_V8_NO_SCRIPT_NO_EXCEPTION(i_isolate);
i::Handle<i::JSObject> obj =
i_isolate->factory()->NewJSObject(i_isolate->object_function());
return Utils::ToLocal(obj);
}

The first thing that happens is that the public Isolate pointer is cast to an pointer to the internal Isolate type. LOG_API is a macro in the same source file (src/api/api.cc):

#define LOG_API(isolate, class_name, function_name)                           \
i::RuntimeCallTimerScope _runtime_timer(                                    \
isolate, i::RuntimeCallCounterId::kAPI_##class_name##_##function_name); \
LOG(isolate, ApiEntryCall("v8::" #class_name "::" #function_name))

If our case the preprocessor would expand that to:

i::RuntimeCallTimerScope _runtime_timer(
isolate, i::RuntimeCallCounterId::kAPI_Object_New);
LOG(isolate, ApiEntryCall("v8::Object::New))

LOG is a macro that can be found in src/log.h:

#define LOG(isolate, Call)                              \
do {                                                  \
v8::internal::Logger* logger = (isolate)->logger(); \
if (logger->is_logging()) logger->Call;             \
} while (false)

And this would expand to:

v8::internal::Logger* logger = isolate->logger();
if (logger->is_logging()) logger->ApiEntryCall("v8::Object::New");

So with the LOG_API macro expanded we have:

Local<v8::Object> v8::Object::New(Isolate* isolate) {
i::Isolate* i_isolate = reinterpret_cast<i::Isolate*>(isolate);
i::RuntimeCallTimerScope _runtime_timer( isolate, i::RuntimeCallCounterId::kAPI_Object_New);
v8::internal::Logger* logger = isolate->logger();
if (logger->is_logging()) logger->ApiEntryCall("v8::Object::New");

ENTER_V8_NO_SCRIPT_NO_EXCEPTION(i_isolate);
i::Handle<i::JSObject> obj =
i_isolate->factory()->NewJSObject(i_isolate->object_function());
return Utils::ToLocal(obj);
}

Next we have ENTER_V8_NO_SCRIPT_NO_EXCEPTION:

#define ENTER_V8_NO_SCRIPT_NO_EXCEPTION(isolate)                    \
i::VMState<v8::OTHER> __state__((isolate));                       \
i::DisallowJavascriptExecutionDebugOnly __no_script__((isolate)); \
i::DisallowExceptions __no_exceptions__((isolate))

So with the macros expanded we have:

Local<v8::Object> v8::Object::New(Isolate* isolate) {
i::Isolate* i_isolate = reinterpret_cast<i::Isolate*>(isolate);
i::RuntimeCallTimerScope _runtime_timer( isolate, i::RuntimeCallCounterId::kAPI_Object_New);
v8::internal::Logger* logger = isolate->logger();
if (logger->is_logging()) logger->ApiEntryCall("v8::Object::New");

i::VMState<v8::OTHER> __state__(i_isolate));
i::DisallowJavascriptExecutionDebugOnly __no_script__(i_isolate);
i::DisallowExceptions __no_exceptions__(i_isolate));

i::Handle<i::JSObject> obj =
i_isolate->factory()->NewJSObject(i_isolate->object_function());

return Utils::ToLocal(obj);
}

TODO: Look closer at VMState.

First, i_isolate->object_function() is called and the result passed to NewJSObject. object_function is generated by a macro named NATIVE_CONTEXT_FIELDS:

#define NATIVE_CONTEXT_FIELD_ACCESSOR(index, type, name)     \
Handle<type> Isolate::name() {                             \
return Handle<type>(raw_native_context()->name(), this); \
}                                                          \
bool Isolate::is_##name(type* value) {                     \
return raw_native_context()->is_##name(value);           \
}
NATIVE_CONTEXT_FIELDS(NATIVE_CONTEXT_FIELD_ACCESSOR)

NATIVE_CONTEXT_FIELDS is a macro in src/contexts and it c

#define NATIVE_CONTEXT_FIELDS(V)                                               \
...                                                                            \
V(OBJECT_FUNCTION_INDEX, JSFunction, object_function)                        \
Handle<type> Isolate::object_function() {
return Handle<JSFunction>(raw_native_context()->object_function(), this);
}

bool Isolate::is_object_function(JSFunction* value) {
return raw_native_context()->is_object_function(value);
}

I'm not clear on the different types of context, there is a native context, a "normal/public" context. In src/contexts-inl.h we have the native_context function:

Context* Context::native_context() const {
Object* result = get(NATIVE_CONTEXT_INDEX);
DCHECK(IsBootstrappingOrNativeContext(this->GetIsolate(), result));
return reinterpret_cast<Context*>(result);
}

Context extends FixedArray so the get function is the get function of FixedArray and NATIVE_CONTEXT_INDEX is the index into the array where the native context is stored.

Now, lets take a closer look at NewJSObject. If you search for NewJSObject in src/heap/factory.cc:

Handle<JSObject> Factory::NewJSObject(Handle<JSFunction> constructor, PretenureFlag pretenure) {
JSFunction::EnsureHasInitialMap(constructor);
Handle<Map> map(constructor->initial_map(), isolate());
return NewJSObjectFromMap(map, pretenure);
}

NewJSObjectFromMap

...
HeapObject* obj = AllocateRawWithAllocationSite(map, pretenure, allocation_site);

So we have created a new map

### Map

So an HeapObject contains a pointer to a Map, or rather has a function that returns a pointer to Map. I can't see any member map in the HeapObject class.

Lets take a look at when a map is created.

(lldb) br s -f map_test.cc -l 63
Handle<Map> Factory::NewMap(InstanceType type,
int instance_size,
ElementsKind elements_kind,
int inobject_properties) {
HeapObject* result = isolate()->heap()->AllocateRawWithRetryOrFail(Map::kSize, MAP_SPACE);
result->set_map_after_allocation(*meta_map(), SKIP_WRITE_BARRIER);
return handle(InitializeMap(Map::cast(result), type, instance_size,
elements_kind, inobject_properties),
isolate());
}

We can see that the above is calling AllocateRawWithRetryOrFail on the heap instance passing a size of 88 and specifying the MAP_SPACE:

HeapObject* Heap::AllocateRawWithRetryOrFail(int size, AllocationSpace space,
AllocationAlignment alignment) {
AllocationResult alloc;
HeapObject* result = AllocateRawWithLigthRetry(size, space, alignment);
if (result) return result;

isolate()->counters()->gc_last_resort_from_handles()->Increment();
CollectAllAvailableGarbage(GarbageCollectionReason::kLastResort);
{
AlwaysAllocateScope scope(isolate());
alloc = AllocateRaw(size, space, alignment);
}
if (alloc.To(&result)) {
DCHECK(result != exception());
return result;
}
// TODO(1181417): Fix this.
FatalProcessOutOfMemory("CALL_AND_RETRY_LAST");
return nullptr;
}

The default value for alignment is kWordAligned. Reading the docs in the header it says that this function will try to perform an allocation of size 88 in the MAP_SPACE and if it fails a full GC will be performed and the allocation retried. Lets take a look at AllocateRawWithLigthRetry:

AllocationResult alloc = AllocateRaw(size, space, alignment);

AllocateRaw can be found in src/heap/heap-inl.h. There are different paths that will be taken depending on the space parameteter. Since it is MAP_SPACE in our case we will focus on that path:

AllocationResult Heap::AllocateRaw(int size_in_bytes, AllocationSpace space, AllocationAlignment alignment) {
...
HeapObject* object = nullptr;
AllocationResult allocation;
if (OLD_SPACE == space) {
...
} else if (MAP_SPACE == space) {
allocation = map_space_->AllocateRawUnaligned(size_in_bytes);
}
...
}

map_space_ is a private member of Heap (src/heap/heap.h):

MapSpace* map_space_;

AllocateRawUnaligned can be found in src/heap/spaces-inl.h:

AllocationResult PagedSpace::AllocateRawUnaligned( int size_in_bytes, UpdateSkipList update_skip_list) {
if (!EnsureLinearAllocationArea(size_in_bytes)) {
return AllocationResult::Retry(identity());
}

HeapObject* object = AllocateLinearly(size_in_bytes);
MSAN_ALLOCATED_UNINITIALIZED_MEMORY(object->address(), size_in_bytes);
return object;
}

The default value for update_skip_list is UPDATE_SKIP_LIST. So lets take a look at AllocateLinearly:

HeapObject* PagedSpace::AllocateLinearly(int size_in_bytes) {
Address current_top = allocation_info_.top();
Address new_top = current_top + size_in_bytes;
allocation_info_.set_top(new_top);
return HeapObject::FromAddress(current_top);
}

Recall that size_in_bytes in our case is 88.

(lldb) expr current_top
(v8::internal::Address) \$5 = 24847457492680
(lldb) expr new_top
(v8::internal::Address) \$6 = 24847457492768
(lldb) expr new_top - current_top
(unsigned long) \$7 = 88

Notice that first the top is set to the new_top and then the current_top is returned and that will be a pointer to the start of the object in memory (which in this case is of v8::internal::Map which is also of type HeapObject). I've been wondering why Map (and other HeapObject) don't have any member fields and only/mostly getters/setters for the various fields that make up an object. Well the answer is that pointers to instances of for example Map point to the first memory location of the instance. And the getters/setter functions use indexed to read/write to memory locations. The indexes are mostly in the form of enum fields that define the memory layout of the type.

Next, in AllocateRawUnaligned we have the MSAN_ALLOCATED_UNINITIALIZED_MEMORY macro:

MSAN_ALLOCATED_UNINITIALIZED_MEMORY(object->address(), size_in_bytes);

MSAN_ALLOCATED_UNINITIALIZED_MEMORY can be found in src/msan.h and ms stands for Memory Sanitizer and would only be used if V8_US_MEMORY_SANITIZER is defined. The returned object will be used to construct an AllocationResult when returned. Back in AllocateRaw we have:

if (allocation.To(&object)) {
...
OnAllocationEvent(object, size_in_bytes);
}

return allocation;

This will return us in AllocateRawWithLightRetry:

AllocationResult alloc = AllocateRaw(size, space, alignment);
if (alloc.To(&result)) {
DCHECK(result != exception());
return result;
}

This will return us back in AllocateRawWithRetryOrFail:

HeapObject* result = AllocateRawWithLigthRetry(size, space, alignment);
if (result) return result;

And that return will return to NewMap in src/heap/factory.cc:

result->set_map_after_allocation(*meta_map(), SKIP_WRITE_BARRIER);
return handle(InitializeMap(Map::cast(result), type, instance_size,
elements_kind, inobject_properties),
isolate());

InitializeMap:

map->set_instance_type(type);
map->set_prototype(*null_value(), SKIP_WRITE_BARRIER);
map->set_constructor_or_backpointer(*null_value(), SKIP_WRITE_BARRIER);
map->set_instance_size(instance_size);
if (map->IsJSObjectMap()) {
DCHECK(!isolate()->heap()->InReadOnlySpace(map));
map->SetInObjectPropertiesStartInWords(instance_size / kPointerSize - inobject_properties);
DCHECK_EQ(map->GetInObjectProperties(), inobject_properties);
map->set_prototype_validity_cell(*invalid_prototype_validity_cell());
} else {
DCHECK_EQ(inobject_properties, 0);
map->set_inobject_properties_start_or_constructor_function_index(0);
map->set_prototype_validity_cell(Smi::FromInt(Map::kPrototypeChainValid));
}
map->set_dependent_code(DependentCode::cast(*empty_fixed_array()), SKIP_WRITE_BARRIER);
map->set_weak_cell_cache(Smi::kZero);
map->set_raw_transitions(MaybeObject::FromSmi(Smi::kZero));
map->SetInObjectUnusedPropertyFields(inobject_properties);
map->set_instance_descriptors(*empty_descriptor_array());

map->set_visitor_id(Map::GetVisitorId(map));
map->set_bit_field(0);
map->set_bit_field2(Map::IsExtensibleBit::kMask);
int bit_field3 = Map::EnumLengthBits::encode(kInvalidEnumCacheSentinel) |
Map::OwnsDescriptorsBit::encode(true) |
Map::ConstructionCounterBits::encode(Map::kNoSlackTracking);
map->set_bit_field3(bit_field3);
map->set_elements_kind(elements_kind); //HOLEY_ELEMENTS
map->set_new_target_is_base(true);
isolate()->counters()->maps_created()->Increment();
if (FLAG_trace_maps) LOG(isolate(), MapCreate(map));
return map;

Creating a new map (map_test.cc:

i::Handle<i::Map> map = i::Map::Create(asInternal(isolate_), 10);
std::cout << map->instance_type() << '\n';

Map::Create can be found in objects.cc:

Handle<Map> Map::Create(Isolate* isolate, int inobject_properties) {
Handle<Map> copy = Copy(handle(isolate->object_function()->initial_map()), "MapCreate");

So, the first thing that will happen is isolate->object_function() will be called. This is function that is generated by the preprocessor.

// from src/context.h
#define NATIVE_CONTEXT_FIELDS(V)                                               \
...                                                                          \
V(OBJECT_FUNCTION_INDEX, JSFunction, object_function)                        \

// from src/isolate.h
#define NATIVE_CONTEXT_FIELD_ACCESSOR(index, type, name)     \
Handle<type> Isolate::name() {                             \
return Handle<type>(raw_native_context()->name(), this); \
}                                                          \
bool Isolate::is_##name(type* value) {                     \
return raw_native_context()->is_##name(value);           \
}
NATIVE_CONTEXT_FIELDS(NATIVE_CONTEXT_FIELD_ACCESSOR)

object_function() will become:

Handle<JSFunction> Isolate::object_function() {
return Handle<JSFunction>(raw_native_context()->object_function(), this);
}

Lets look closer at JSFunction::initial_map() in in object-inl.h:

Map* JSFunction::initial_map() {
return Map::cast(prototype_or_initial_map());
}

prototype_or_initial_map is generated by a macro:

ACCESSORS_CHECKED(JSFunction, prototype_or_initial_map, Object,
kPrototypeOrInitialMapOffset, map()->has_prototype_slot())

ACCESSORS_CHECKED can be found in src/objects/object-macros.h:

#define ACCESSORS_CHECKED(holder, name, type, offset, condition) \
ACCESSORS_CHECKED2(holder, name, type, offset, condition, condition)

#define ACCESSORS_CHECKED2(holder, name, type, offset, get_condition, \
set_condition)                             \
type* holder::name() const {                                        \
type* value = type::cast(READ_FIELD(this, offset));               \
DCHECK(get_condition);                                            \
return value;                                                     \
}                                                                   \
void holder::set_##name(type* value, WriteBarrierMode mode) {       \
DCHECK(set_condition);                                            \
WRITE_FIELD(this, offset, value);                                 \
CONDITIONAL_WRITE_BARRIER(GetHeap(), this, offset, value, mode);  \
}

#define FIELD_ADDR(p, offset) \
(reinterpret_cast<Address>(p) + offset - kHeapObjectTag)

#define READ_FIELD(p, offset) \
(*reinterpret_cast<Object* const*>(FIELD_ADDR(p, offset)))

The preprocessor will expand prototype_or_initial_map to:

JSFunction* JSFunction::prototype_or_initial_map() const {
JSFunction* value = JSFunction::cast(
(*reinterpret_cast<Object* const*>(
(reinterpret_cast<Address>(this) + kPrototypeOrInitialMapOffset - kHeapObjectTag))))
DCHECK(map()->has_prototype_slot());
return value;
}

Notice that map()->has_prototype_slot()) will be called first which looks like this:

Map* HeapObject::map() const {
return map_word().ToMap();
}

TODO: Add notes about MapWord

MapWord HeapObject::map_word() const {
return MapWord(
reinterpret_cast<uintptr_t>(RELAXED_READ_FIELD(this, kMapOffset)));
}

First thing that will happen is RELAXED_READ_FIELD(this, kMapOffset)

#define RELAXED_READ_FIELD(p, offset)           \
reinterpret_cast<Object*>(base::Relaxed_Load( \
reinterpret_cast<const base::AtomicWord*>(FIELD_ADDR(p, offset))))

#define FIELD_ADDR(p, offset) \
(reinterpret_cast<Address>(p) + offset - kHeapObjectTag)

This will get expanded by the preprocessor to:

reinterpret_cast<Object*>(base::Relaxed_Load(
reinterpret_cast<const base::AtomicWord*>(
(reinterpret_cast<Address>(this) + kMapOffset - kHeapObjectTag)))

src/base/atomicops_internals_portable.h:

inline Atomic8 Relaxed_Load(volatile const Atomic8* ptr) {
return __atomic_load_n(ptr, __ATOMIC_RELAXED);
}

So this will do an atomoic load of the ptr with the memory order of __ATOMIC_RELELAXED.

ACCESSORS_CHECKED also generates a set_prototyp_or_initial_map:

void JSFunction::set_prototype_or_initial_map(JSFunction* value, WriteBarrierMode mode) {
DCHECK(map()->has_prototype_slot());
WRITE_FIELD(this, kPrototypeOrInitialMapOffset, value);
CONDITIONAL_WRITE_BARRIER(GetHeap(), this, kPrototypeOrInitialMapOffset, value, mode);
}

What does WRITE_FIELD do?

#define WRITE_FIELD(p, offset, value)                             \
base::Relaxed_Store(                                            \
reinterpret_cast<base::AtomicWord*>(FIELD_ADDR(p, offset)), \
reinterpret_cast<base::AtomicWord>(value));

Which would expand into:

base::Relaxed_Store(                                            \
reinterpret_cast<base::AtomicWord*>(
(reinterpret_cast<Address>(this) + kPrototypeOrInitialMapOffset - kHeapObjectTag)
reinterpret_cast<base::AtomicWord>(value));

Lets take a look at what instance_type does:

InstanceType Map::instance_type() const {
return static_cast<InstanceType>(READ_UINT16_FIELD(this, kInstanceTypeOffset));
}

To see what the above is doing we can do the same thing in the debugger: Note that I got 11 below from map->kInstanceTypeOffset - i::kHeapObjectTag

(lldb) memory read -f u -c 1 -s 8 `*map + 11`
0x6d4e6609ed4: 585472345729139745
(lldb) expr static_cast<InstanceType>(585472345729139745)
(v8::internal::InstanceType) \$34 = JS_OBJECT_TYPE

Take map->has_non_instance_prototype():

(lldb) br s -n has_non_instance_prototype
(lldb) expr -i 0 -- map->has_non_instance_prototype()

The above command will break in src/objects/map-inl.h:

BIT_FIELD_ACCESSORS(Map, bit_field, has_non_instance_prototype, Map::HasNonInstancePrototypeBit)

// src/objects/object-macros.h
#define BIT_FIELD_ACCESSORS(holder, field, name, BitField)      \
typename BitField::FieldType holder::name() const {           \
return BitField::decode(field());                           \
}                                                             \
void holder::set_##name(typename BitField::FieldType value) { \
set_##field(BitField::update(field(), value));              \
}

The preprocessor will expand that to:

typename Map::HasNonInstancePrototypeBit::FieldType Map::has_non_instance_prototype() const {
return Map::HasNonInstancePrototypeBit::decode(bit_field());
}                                                             \
void holder::set_has_non_instance_prototype(typename BitField::FieldType value) { \
set_bit_field(Map::HasNonInstancePrototypeBit::update(bit_field(), value));              \
}

So where can we find Map::HasNonInstancePrototypeBit?
It is generated by a macro in src/objects/map.h:

// Bit positions for |bit_field|.
#define MAP_BIT_FIELD_FIELDS(V, _)          \
V(HasNonInstancePrototypeBit, bool, 1, _) \
...
DEFINE_BIT_FIELDS(MAP_BIT_FIELD_FIELDS)
#undef MAP_BIT_FIELD_FIELDS

#define DEFINE_BIT_FIELDS(LIST_MACRO) \
DEFINE_BIT_RANGES(LIST_MACRO)       \
LIST_MACRO(DEFINE_BIT_FIELD_TYPE, LIST_MACRO##_Ranges)

#define DEFINE_BIT_RANGES(LIST_MACRO)                               \
struct LIST_MACRO##_Ranges {                                      \
enum { LIST_MACRO(DEFINE_BIT_FIELD_RANGE_TYPE, _) kBitsCount }; \
};

#define DEFINE_BIT_FIELD_RANGE_TYPE(Name, Type, Size, _) \
k##Name##Start, k##Name##End = k##Name##Start + Size - 1,

Alright, lets see what preprocessor expands that to:

struct MAP_BIT_FIELD_FIELDS_Ranges {
enum {
kHasNonInstancePrototypeBitStart,
kHasNonInstancePrototypeBitEnd = kHasNonInstancePrototypeBitStart + 1 - 1,
... // not showing the rest of the entries.
kBitsCount
};
};

So this would create a struct with an enum and it could be accessed using: i::Map::MAP_BIT_FIELD_FIELDS_Ranges::kHasNonInstancePrototypeBitStart The next part of the macro is

LIST_MACRO(DEFINE_BIT_FIELD_TYPE, LIST_MACRO##_Ranges)

#define DEFINE_BIT_FIELD_TYPE(Name, Type, Size, RangesName) \
typedef BitField<Type, RangesName::k##Name##Start, Size> Name;

Which will get expanded to:

typedef BitField<HasNonInstancePrototypeBit, MAP_BIT_FIELD_FIELDS_Ranges::kHasNonInstancePrototypeBitStart, 1> HasNonInstancePrototypeBit;

So this is how HasNonInstancePrototypeBit is declared and notice that it is of type BitField which can be found in src/utils.h:

template<class T, int shift, int size>
class BitField : public BitFieldBase<T, shift, size, uint32_t> { };

template<class T, int shift, int size, class U>
class BitFieldBase {
public:
typedef T FieldType;

Map::HasNonInstancePrototypeBit::decode(bit_field()); first bit_field is called:

byte Map::bit_field() const { return READ_BYTE_FIELD(this, kBitFieldOffset); }

And the result of that is passed to Map::HasNonInstancePrototypeBit::decode:

(lldb) br s -n bit_field
(lldb) expr -i 0 --  map->bit_field()
byte Map::bit_field() const { return READ_BYTE_FIELD(this, kBitFieldOffset); }

So, this is the current Map instance, and we are going to read from.

#define READ_BYTE_FIELD(p, offset) \
(*reinterpret_cast<const byte*>(FIELD_ADDR(p, offset)))

#define FIELD_ADDR(p, offset) \
(reinterpret_cast<Address>(p) + offset - kHeapObjectTag)

Which will get expanded to:

byte Map::bit_field() const {
return *reinterpret_cast<const byte*>(
reinterpret_cast<Address>(this) + kBitFieldOffset - kHeapObjectTag)
}

The instance_size is the instance_size_in_words << kPointerSizeLog2 (3 on my machine):

(lldb) memory read -f x -s 1 -c 1 *map+8
0x24d1cd509ed1: 0x03
(lldb) expr 0x03 << 3
(int) \$2 = 24
(lldb) expr map->instance_size()
(int) \$3 = 24

i::HeapObject::kHeaderSize is 8 on my system which is used in the `DEFINE_FIELD_OFFSET_CONSTANTS:

#define MAP_FIELDS(V)
V(kInstanceSizeInWordsOffset, kUInt8Size)
V(kInObjectPropertiesStartOrConstructorFunctionIndexOffset, kUInt8Size)
...
DEFINE_FIELD_OFFSET_CONSTANTS(HeapObject::kHeaderSize, MAP_FIELDS)

So we can use this information to read the inobject_properties_start_or_constructor_function_index directly from memory using:

(lldb) expr map->inobject_properties_start_or_constructor_function_index()
(lldb) memory read -f x -s 1 -c 1 map+9
error: invalid start address expression.
error: address expression "map+9" evaluation failed
(lldb) memory read -f x -s 1 -c 1 *map+9
0x17b027209ed2: 0x03

Inspect the visitor_id (which is the last of the first byte):

lldb) memory read -f x -s 1 -c 1 *map+10
0x17b027209ed3: 0x15
(lldb) expr (int) 0x15
(int) \$8 = 21
(lldb) expr map->visitor_id()
(v8::internal::VisitorId) \$11 = kVisitJSObjectFast
(lldb) expr (int) \$11
(int) \$12 = 21

Inspect the instance_type (which is part of the second byte):

(lldb) expr map->instance_type()
(v8::internal::InstanceType) \$41 = JS_OBJECT_TYPE
(lldb) expr v8::internal::InstanceType::JS_OBJECT_TYPE
(uint16_t) \$35 = 1057
(lldb) memory read -f x -s 2 -c 1 *map+11
0x17b027209ed4: 0x0421
(lldb) expr (int)0x0421
(int) \$40 = 1057

Notice that instance_type is a short so that will take up 2 bytes

(lldb) expr map->has_non_instance_prototype()
(bool) \$60 = false
(lldb) expr map->is_callable()
(bool) \$46 = false
(lldb) expr map->has_named_interceptor()
(bool) \$51 = false
(lldb) expr map->has_indexed_interceptor()
(bool) \$55 = false
(lldb) expr map->is_undetectable()
(bool) \$56 = false
(lldb) expr map->is_access_check_needed()
(bool) \$57 = false
(lldb) expr map->is_constructor()
(bool) \$58 = false
(lldb) expr map->has_prototype_slot()
(bool) \$59 = false

Verify that the above is correct:

(lldb) expr map->has_non_instance_prototype()
(bool) \$44 = false
(lldb) memory read -f x -s 1 -c 1 *map+13
0x17b027209ed6: 0x00

(lldb) expr map->set_has_non_instance_prototype(true)
(lldb) memory read -f x -s 1 -c 1 *map+13
0x17b027209ed6: 0x01

(lldb) expr map->set_has_prototype_slot(true)
(lldb) memory read -f x -s 1 -c 1 *map+13
0x17b027209ed6: 0x81

Inspect second int field (bit_field2):

(lldb) memory read -f x -s 1 -c 1 *map+14
0x17b027209ed7: 0x19
(lldb) expr map->is_extensible()
(bool) \$78 = true
(lldb) expr -- 0x19 & (1 << 0)
(bool) \$90 = 1

(lldb) expr map->is_prototype_map()
(bool) \$79 = false

(lldb) expr map->is_in_retained_map_list()
(bool) \$80 = false

(lldb) expr map->elements_kind()
(v8::internal::ElementsKind) \$81 = HOLEY_ELEMENTS
(lldb) expr v8::internal::ElementsKind::HOLEY_ELEMENTS
(int) \$133 = 3
(lldb) expr  0x19 >> 3
(int) \$134 = 3

Inspect third int field (bit_field3):

(lldb) memory read -f b -s 4 -c 1 *map+15
0x17b027209ed8: 0b00001000001000000000001111111111
(lldb) memory read -f x -s 4 -c 1 *map+15
0x17b027209ed8: 0x082003ff

So we know that a Map instance is a pointer allocated by the Heap and with a specific size. Fields are accessed using indexes (remember there are no member fields in the Map class). We also know that all HeapObject have a Map. The Map is sometimes referred to as the HiddenClass and sometimes the shape of an object. If two objects have the same properties they would share the same Map. This makes sense and I've see blog post that show this but I'd like to verify this to fully understand it. I'm going to try to match https://v8project.blogspot.com/2017/08/fast-properties.html with the code.

So, lets take a look at adding a property to a JSObject. We start by creating a new Map and then use it to create a new JSObject:

i::Handle<i::Map> map = factory->NewMap(i::JS_OBJECT_TYPE, 32);
i::Handle<i::JSObject> js_object = factory->NewJSObjectFromMap(map);

i::Handle<i::String> prop_name = factory->InternalizeUtf8String("prop_name");
i::Handle<i::String> prop_value = factory->InternalizeUtf8String("prop_value");
i::JSObject::AddProperty(js_object, prop_name, prop_value, i::NONE);

Lets take a closer look at AddProperty and how it interacts with the Map. This function can be found in src/objects.cc:

void JSObject::AddProperty(Handle<JSObject> object, Handle<Name> name,
Handle<Object> value,
PropertyAttributes attributes) {
LookupIterator it(object, name, object, LookupIterator::OWN_SKIP_INTERCEPTOR);
CHECK_NE(LookupIterator::ACCESS_CHECK, it.state());

First we have the LookupIterator constructor (src/lookup.h) but since this is a new property which we know does not exist it will not find any property.

CHECK(AddDataProperty(&it, value, attributes, kThrowOnError,
CERTAINLY_NOT_STORE_FROM_KEYED)
.IsJust());
Handle<JSReceiver> receiver = it->GetStoreTarget<JSReceiver>();
...
it->UpdateProtector();
// Migrate to the most up-to-date map that will be able to store |value|
// under it->name() with |attributes|.
it->PrepareTransitionToDataProperty(receiver, value, attributes, store_mode);
DCHECK_EQ(LookupIterator::TRANSITION, it->state());
it->ApplyTransitionToDataProperty(receiver);

// Write the property value.
it->WriteDataValue(value, true);

PrepareTransitionToDataProperty:

Representation representation = value->OptimalRepresentation();
Handle<FieldType> type = value->OptimalType(isolate, representation);
maybe_map = Map::CopyWithField(map, name, type, attributes, constness,
representation, flag);

Map::CopyWithField:

Descriptor d = Descriptor::DataField(name, index, attributes, constness, representation, wrapped_type);

Lets take a closer look the Decriptor which can be found in src/property.cc:

Descriptor Descriptor::DataField(Handle<Name> key, int field_index,
PropertyAttributes attributes,
PropertyConstness constness,
Representation representation,
MaybeObjectHandle wrapped_field_type) {
DCHECK(wrapped_field_type->IsSmi() || wrapped_field_type->IsWeakHeapObject());
PropertyDetails details(kData, attributes, kField, constness, representation,
field_index);
return Descriptor(key, wrapped_field_type, details);
}

Descriptor is declared in src/property.h and describes the elements in a instance-descriptor array. These are returned when calling map->instance_descriptors(). Let check some of the arguments:

(lldb) job *key
#prop_name
(lldb) expr attributes
(v8::internal::PropertyAttributes) \$27 = NONE
(lldb) expr constness
(v8::internal::PropertyConstness) \$28 = kMutable
(lldb) expr representation
(v8::internal::Representation) \$29 = (kind_ = '\b')

The Descriptor class contains three members:

private:
Handle<Name> key_;
MaybeObjectHandle value_;
PropertyDetails details_;

Lets take a closer look PropertyDetails which only has a single member named value_

uint32_t value_;

It also declares a number of classes the extend BitField, for example:

class KindField : public BitField<PropertyKind, 0, 1> {};
class LocationField : public BitField<PropertyLocation, KindField::kNext, 1> {};
class ConstnessField : public BitField<PropertyConstness, LocationField::kNext, 1> {};
class AttributesField : public BitField<PropertyAttributes, ConstnessField::kNext, 3> {};
class PropertyCellTypeField : public BitField<PropertyCellType, AttributesField::kNext, 2> {};
class DictionaryStorageField : public BitField<uint32_t, PropertyCellTypeField::kNext, 23> {};

// Bit fields for fast objects.
class RepresentationField : public BitField<uint32_t, AttributesField::kNext, 4> {};
class DescriptorPointer : public BitField<uint32_t, RepresentationField::kNext, kDescriptorIndexBitCount> {};
class FieldIndexField : public BitField<uint32_t, DescriptorPointer::kNext, kDescriptorIndexBitCount> {

enum PropertyKind { kData = 0, kAccessor = 1 };
enum PropertyLocation { kField = 0, kDescriptor = 1 };
enum class PropertyConstness { kMutable = 0, kConst = 1 };
enum PropertyAttributes {
NONE = ::v8::None,
READ_ONLY = ::v8::ReadOnly,
DONT_ENUM = ::v8::DontEnum,
DONT_DELETE = ::v8::DontDelete,
ALL_ATTRIBUTES_MASK = READ_ONLY | DONT_ENUM | DONT_DELETE,
SEALED = DONT_DELETE,
FROZEN = SEALED | READ_ONLY,
ABSENT = 64,  // Used in runtime to indicate a property is absent.
// ABSENT can never be stored in or returned from a descriptor's attributes
// bitfield.  It is only used as a return value meaning the attributes of
// a non-existent property.
};
enum class PropertyCellType {
// Meaningful when a property cell does not contain the hole.
kUndefined,     // The PREMONOMORPHIC of property cells.
kConstant,      // Cell has been assigned only once.
kConstantType,  // Cell has been assigned only one type.
kMutable,       // Cell will no longer be tracked as constant.
// Meaningful when a property cell contains the hole.
kUninitialized = kUndefined,  // Cell has never been initialized.
kInvalidated = kConstant,     // Cell has been deleted, invalidated or never
// existed.
// For dictionaries not holding cells.
kNoCell = kMutable,
};

template<class T, int shift, int size>
class BitField : public BitFieldBase<T, shift, size, uint32_t> { };

The Type T of KindField will be PropertyKind, the shift will be 0 , and the size 1. Notice that LocationField is using KindField::kNext as its shift. This is a static class constant of type uint32_t and is defined as:

static const U kNext = kShift + kSize;

So LocationField would get the value from KindField which should be:

class LocationField : public BitField<PropertyLocation, 1, 1> {};

The constructor for PropertyDetails looks like this:

PropertyDetails(PropertyKind kind, PropertyAttributes attributes, PropertyCellType cell_type, int dictionary_index = 0) {
value_ = KindField::encode(kind) | LocationField::encode(kField) |
AttributesField::encode(attributes) |
DictionaryStorageField::encode(dictionary_index) |
PropertyCellTypeField::encode(cell_type);
}

So what does KindField::encode(kind) actualy do then?

(lldb) expr static_cast<uint32_t>(kind())
(uint32_t) \$36 = 0
(lldb) expr static_cast<uint32_t>(kind()) << 0
(uint32_t) \$37 = 0

This value is later returned by calling kind():

PropertyKind kind() const { return KindField::decode(value_); }

So we have all this information about this property, its type (Representation), constness, if it is read-only, enumerable, deletable, sealed, frozen. After that little detour we are back in Descriptor::DataField:

return Descriptor(key, wrapped_field_type, details);

Here we are using the key (name of the property), the wrapped_field_type, and PropertyDetails we created. What is wrapped_field_type again?
If we back up a few frames back into Map::TransitionToDataProperty we can see that the type passed in is taken from the following code:

Representation representation = value->OptimalRepresentation();
Handle<FieldType> type = value->OptimalType(isolate, representation);

So this is only taking the type of the field:

(lldb) expr representation.kind()
(v8::internal::Representation::Kind) \$51 = kHeapObject

This makes sense as the map only deals with the shape of the propery and not the value. Next in Map::CopyWithField we have:

Handle<Map> new_map = Map::CopyAddDescriptor(map, &d, flag);

CopyAddDescriptor does:

Handle<DescriptorArray> descriptors(map->instance_descriptors());

int nof = map->NumberOfOwnDescriptors();
Handle<DescriptorArray> new_descriptors = DescriptorArray::CopyUpTo(descriptors, nof, 1);
new_descriptors->Append(descriptor);

Handle<LayoutDescriptor> new_layout_descriptor =
FLAG_unbox_double_fields
? LayoutDescriptor::New(map, new_descriptors, nof + 1)
: handle(LayoutDescriptor::FastPointerLayout(), map->GetIsolate());

return CopyReplaceDescriptors(map, new_descriptors, new_layout_descriptor,
flag, descriptor->GetKey(), "CopyAddDescriptor",
SIMPLE_PROPERTY_TRANSITION);

Lets take a closer look at LayoutDescriptor

(lldb) expr new_layout_descriptor->Print()
Layout descriptor: <all tagged>

TODO: Take a closer look at LayoutDescritpor

Later when actually adding the value in Object::AddDataProperty:

it->WriteDataValue(value, true);

This call will end up in src/lookup.cc and in our case the path will be the following call:

JSObject::cast(*holder)->WriteToField(descriptor_number(), property_details_, *value);

TODO: Take a closer look at LookupIterator. WriteToField can be found in src/objects-inl.h:

FieldIndex index = FieldIndex::ForDescriptor(map(), descriptor);

FieldIndex::ForDescriptor can be found in src/field-index-inl.h:

inline FieldIndex FieldIndex::ForDescriptor(const Map* map, int descriptor_index) {
PropertyDetails details = map->instance_descriptors()->GetDetails(descriptor_index);
int field_index = details.field_index();
return ForPropertyIndex(map, field_index, details.representation());
}

Notice that this is calling instance_descriptors() on the passed-in map. This as we recall from earlier returns and DescriptorArray (which is a type of WeakFixedArray). A Descriptor array

Our DecsriptorArray only has one entry:

(lldb) expr map->instance_descriptors()->number_of_descriptors()
(int) \$6 = 1
(lldb) expr map->instance_descriptors()->GetKey(0)->Print()
#prop_name
(lldb) expr map->instance_descriptors()->GetFieldIndex(0)
(int) \$11 = 0

We can also use Print on the DescriptorArray:

lldb) expr map->instance_descriptors()->Print()

[0]: #prop_name (data field 0:h, p: 0, attrs: [WEC]) @ Any

In our case we are accessing the PropertyDetails and then getting the field_index which I think tells us where in the object the value for this property is stored. The last call in ForDescriptor is `ForProperty:

inline FieldIndex FieldIndex::ForPropertyIndex(const Map* map,
int property_index,
Representation representation) {
int inobject_properties = map->GetInObjectProperties();
bool is_inobject = property_index < inobject_properties;
int first_inobject_offset;
int offset;
if (is_inobject) {
first_inobject_offset = map->GetInObjectPropertyOffset(0);
offset = map->GetInObjectPropertyOffset(property_index);
} else {
first_inobject_offset = FixedArray::kHeaderSize;
property_index -= inobject_properties;
offset = FixedArray::kHeaderSize + property_index * kPointerSize;
}
Encoding encoding = FieldEncoding(representation);
return FieldIndex(is_inobject, offset, encoding, inobject_properties,
first_inobject_offset);
}

I was expecting inobject_propertis to be 1 here but it is 0:

(lldb) expr inobject_properties
(int) \$14 = 0

Why is that, what am I missing?
These in-object properties are stored directly on the object instance and not do not use the properties array. All get back to an example of this later to clarify this. TODO: Add in-object properties example.

Back in JSObject::WriteToField:

RawFastPropertyAtPut(index, value);
void JSObject::RawFastPropertyAtPut(FieldIndex index, Object* value) {
if (index.is_inobject()) {
int offset = index.offset();
WRITE_FIELD(this, offset, value);
WRITE_BARRIER(GetHeap(), this, offset, value);
} else {
property_array()->set(index.outobject_array_index(), value);
}
}

In our case we know that the index is not inobject()

(lldb) expr index.is_inobject()
(bool) \$18 = false

So, property_array()->set() will be called.

(lldb) expr this
(v8::internal::JSObject *) \$21 = 0x00002c31c6a88b59

JSObject inherits from JSReceiver which is where the property_array() function is declared.

inline PropertyArray* property_array() const;
(lldb) expr property_array()->Print()
0x2c31c6a88bb1: [PropertyArray]
- map: 0x2c31f5603e21 <Map>
- length: 3
- hash: 0
0: 0x2c31f56025a1 <Odd Oddball: uninitialized>
1-2: 0x2c31f56026f1 <undefined>
(lldb) expr index.outobject_array_index()
(int) \$26 = 0
(lldb) expr value->Print()
#prop_value

Looking at the above values printed we should see the property be written to entry 0.

(lldb) expr property_array()->get(0)->Print()
#uninitialized
// after call to set
(lldb) expr property_array()->get(0)->Print()
#prop_value
(lldb) expr map->instance_descriptors()
(v8::internal::DescriptorArray *) \$4 = 0x000039a927082339

So a map has an pointer array of instance of DescriptorArray

(lldb) expr map->GetInObjectProperties()
(int) \$19 = 1

Each Map has int that tells us the number of properties it has. This is the number specified when creating a new Map, for example:

i::Handle<i::Map> map = i::Map::Create(asInternal(isolate_), 1);

But at this stage we don't really have any properties. The value for a property is associated with the actual instance of the Object. What the Map specifies is index of the value for a particualar property.

#### Creating a Map instance

Lets take a look at when a map is created.

(lldb) br s -f map_test.cc -l 63
Handle<Map> Factory::NewMap(InstanceType type,
int instance_size,
ElementsKind elements_kind,
int inobject_properties) {
HeapObject* result = isolate()->heap()->AllocateRawWithRetryOrFail(Map::kSize, MAP_SPACE);
result->set_map_after_allocation(*meta_map(), SKIP_WRITE_BARRIER);
return handle(InitializeMap(Map::cast(result), type, instance_size,
elements_kind, inobject_properties),
isolate());
}

We can see that the above is calling AllocateRawWithRetryOrFail on the heap instance passing a size of 88 and specifying the MAP_SPACE:

HeapObject* Heap::AllocateRawWithRetryOrFail(int size, AllocationSpace space,
AllocationAlignment alignment) {
AllocationResult alloc;
HeapObject* result = AllocateRawWithLigthRetry(size, space, alignment);
if (result) return result;

isolate()->counters()->gc_last_resort_from_handles()->Increment();
CollectAllAvailableGarbage(GarbageCollectionReason::kLastResort);
{
AlwaysAllocateScope scope(isolate());
alloc = AllocateRaw(size, space, alignment);
}
if (alloc.To(&result)) {
DCHECK(result != exception());
return result;
}
// TODO(1181417): Fix this.
FatalProcessOutOfMemory("CALL_AND_RETRY_LAST");
return nullptr;
}

The default value for alignment is kWordAligned. Reading the docs in the header it says that this function will try to perform an allocation of size 88 in the MAP_SPACE and if it fails a full GC will be performed and the allocation retried. Lets take a look at AllocateRawWithLigthRetry:

AllocationResult alloc = AllocateRaw(size, space, alignment);

AllocateRaw can be found in src/heap/heap-inl.h. There are different paths that will be taken depending on the space parameteter. Since it is MAP_SPACE in our case we will focus on that path:

AllocationResult Heap::AllocateRaw(int size_in_bytes, AllocationSpace space, AllocationAlignment alignment) {
...
HeapObject* object = nullptr;
AllocationResult allocation;
if (OLD_SPACE == space) {
...
} else if (MAP_SPACE == space) {
allocation = map_space_->AllocateRawUnaligned(size_in_bytes);
}
...
}

map_space_ is a private member of Heap (src/heap/heap.h):

MapSpace* map_space_;

AllocateRawUnaligned can be found in src/heap/spaces-inl.h:

AllocationResult PagedSpace::AllocateRawUnaligned( int size_in_bytes, UpdateSkipList update_skip_list) {
if (!EnsureLinearAllocationArea(size_in_bytes)) {
return AllocationResult::Retry(identity());
}

HeapObject* object = AllocateLinearly(size_in_bytes);
MSAN_ALLOCATED_UNINITIALIZED_MEMORY(object->address(), size_in_bytes);
return object;
}

The default value for update_skip_list is UPDATE_SKIP_LIST. So lets take a look at AllocateLinearly:

HeapObject* PagedSpace::AllocateLinearly(int size_in_bytes) {
Address current_top = allocation_info_.top();
Address new_top = current_top + size_in_bytes;
allocation_info_.set_top(new_top);
return HeapObject::FromAddress(current_top);
}

Recall that size_in_bytes in our case is 88.

(lldb) expr current_top
(v8::internal::Address) \$5 = 24847457492680
(lldb) expr new_top
(v8::internal::Address) \$6 = 24847457492768
(lldb) expr new_top - current_top
(unsigned long) \$7 = 88

Notice that first the top is set to the new_top and then the current_top is returned and that will be a pointer to the start of the object in memory (which in this case is of v8::internal::Map which is also of type HeapObject). I've been wondering why Map (and other HeapObject) don't have any member fields and only/mostly getters/setters for the various fields that make up an object. Well the answer is that pointers to instances of for example Map point to the first memory location of the instance. And the getters/setter functions use indexed to read/write to memory locations. The indexes are mostly in the form of enum fields that define the memory layout of the type.

Next, in AllocateRawUnaligned we have the MSAN_ALLOCATED_UNINITIALIZED_MEMORY macro:

MSAN_ALLOCATED_UNINITIALIZED_MEMORY(object->address(), size_in_bytes);

MSAN_ALLOCATED_UNINITIALIZED_MEMORY can be found in src/msan.h and ms stands for Memory Sanitizer and would only be used if V8_US_MEMORY_SANITIZER is defined. The returned object will be used to construct an AllocationResult when returned. Back in AllocateRaw we have:

if (allocation.To(&object)) {
...
OnAllocationEvent(object, size_in_bytes);
}

return allocation;

This will return us in AllocateRawWithLightRetry:

AllocationResult alloc = AllocateRaw(size, space, alignment);
if (alloc.To(&result)) {
DCHECK(result != exception());
return result;
}

This will return us back in AllocateRawWithRetryOrFail:

HeapObject* result = AllocateRawWithLigthRetry(size, space, alignment);
if (result) return result;

And that return will return to NewMap in src/heap/factory.cc:

result->set_map_after_allocation(*meta_map(), SKIP_WRITE_BARRIER);
return handle(InitializeMap(Map::cast(result), type, instance_size,
elements_kind, inobject_properties),
isolate());

InitializeMap:

map->set_instance_type(type);
map->set_prototype(*null_value(), SKIP_WRITE_BARRIER);
map->set_constructor_or_backpointer(*null_value(), SKIP_WRITE_BARRIER);
map->set_instance_size(instance_size);
if (map->IsJSObjectMap()) {
DCHECK(!isolate()->heap()->InReadOnlySpace(map));
map->SetInObjectPropertiesStartInWords(instance_size / kPointerSize - inobject_properties);
DCHECK_EQ(map->GetInObjectProperties(), inobject_properties);
map->set_prototype_validity_cell(*invalid_prototype_validity_cell());
} else {
DCHECK_EQ(inobject_properties, 0);
map->set_inobject_properties_start_or_constructor_function_index(0);
map->set_prototype_validity_cell(Smi::FromInt(Map::kPrototypeChainValid));
}
map->set_dependent_code(DependentCode::cast(*empty_fixed_array()), SKIP_WRITE_BARRIER);
map->set_weak_cell_cache(Smi::kZero);
map->set_raw_transitions(MaybeObject::FromSmi(Smi::kZero));
map->SetInObjectUnusedPropertyFields(inobject_properties);
map->set_instance_descriptors(*empty_descriptor_array());

map->set_visitor_id(Map::GetVisitorId(map));
map->set_bit_field(0);
map->set_bit_field2(Map::IsExtensibleBit::kMask);
int bit_field3 = Map::EnumLengthBits::encode(kInvalidEnumCacheSentinel) |
Map::OwnsDescriptorsBit::encode(true) |
Map::ConstructionCounterBits::encode(Map::kNoSlackTracking);
map->set_bit_field3(bit_field3);
map->set_elements_kind(elements_kind); //HOLEY_ELEMENTS
map->set_new_target_is_base(true);
isolate()->counters()->maps_created()->Increment();
if (FLAG_trace_maps) LOG(isolate(), MapCreate(map));
return map;

### Context

Context extends FixedArray (src/context.h). So an instance of this Context is a FixedArray and we can use Get(index) etc to get entries in the array.

### V8_EXPORT

This can be found in quite a few places in v8 source code. For example:

class V8_EXPORT ArrayBuffer : public Object {

What is this?
It is a preprocessor macro which looks like this:

#if V8_HAS_ATTRIBUTE_VISIBILITY && defined(V8_SHARED)
# ifdef BUILDING_V8_SHARED
#  define V8_EXPORT __attribute__ ((visibility("default")))
# else
#  define V8_EXPORT
# endif
#else
# define V8_EXPORT
#endif

So we can see that if V8_HAS_ATTRIBUTE_VISIBILITY, and defined(V8_SHARED), and also if BUILDING_V8_SHARED, V8_EXPORT is set to __attribute__ ((visibility("default")). But in all other cases V8_EXPORT is empty and the preprocessor does not insert anything (nothing will be there come compile time). But what about the __attribute__ ((visibility("default")) what is this?

In the GNU compiler collection (GCC) environment, the term that is used for exporting is visibility. As it applies to functions and variables in a shared object, visibility refers to the ability of other shared objects to call a C/C++ function. Functions with default visibility have a global scope and can be called from other shared objects. Functions with hidden visibility have a local scope and cannot be called from other shared objects.

Visibility can be controlled by using either compiler options or visibility attributes. In your header files, wherever you want an interface or API made public outside the current Dynamic Shared Object (DSO) , place __attribute__ ((visibility ("default"))) in struct, class and function declarations you wish to make public. With -fvisibility=hidden, you are telling GCC that every declaration not explicitly marked with a visibility attribute has a hidden visibility. There is such a flag in build/common.gypi

### ToLocalChecked()

You'll see a few of these calls in the hello_world example:

Local<String> source = String::NewFromUtf8(isolate, js, NewStringType::kNormal).ToLocalChecked();

NewFromUtf8 actually returns a Local wrapped in a MaybeLocal which forces a check to see if the Local<> is empty before using it. NewStringType is an enum which can be kNormalString (k for constant) or kInternalized.

The following is after running the preprocessor (clang -E src/api.cc):

# 5961 "src/api.cc"
Local<String> String::NewFromUtf8(Isolate* isolate,
const char* data,
NewStringType type,
int length) {
MaybeLocal<String> result;
if (length == 0) {
result = String::Empty(isolate);
} else if (length > i::String::kMaxLength) {
result = MaybeLocal<String>();
} else {
i::Isolate* i_isolate = reinterpret_cast<internal::Isolate*>(isolate);
i::VMState<v8::OTHER> __state__((i_isolate));
i::RuntimeCallTimerScope _runtime_timer( i_isolate, &i::RuntimeCallStats::API_String_NewFromUtf8);
LOG(i_isolate, ApiEntryCall("v8::" "String" "::" "NewFromUtf8"));
if (length < 0) length = StringLength(data);
i::Handle<i::String> handle_result = NewString(i_isolate->factory(), static_cast<v8::NewStringType>(type), i::Vector<const char>(data, length)) .ToHandleChecked();
result = Utils::ToLocal(handle_result);
};
return result.FromMaybe(Local<String>());;
}

I was wondering where the Utils::ToLocal was defined but could not find it until I found:

MAKE_TO_LOCAL(ToLocal, String, String)

#define MAKE_TO_LOCAL(Name, From, To)                                       \
Local<v8::To> Utils::Name(v8::internal::Handle<v8::internal::From> obj) {   \
return Convert<v8::internal::From, v8::To>(obj);                          \
}

The above can be found in src/api.h. The same goes for Local<Object>, Local<String> etc.

### Small Integers

Reading through v8.h I came accross // Tag information for Smi Smi stands for small integers.

A pointer is really just a integer that is treated like a memory address. We can use that memory address to get the start of the data located in that memory slot. But we can also just store an normal value like 18 in it. There might be cases where it does not make sense to store a small integer somewhere in the heap and have a pointer to it, but instead store the value directly in the pointer itself. But that only works for small integers so there needs to be away to know if the value we want is stored in the pointer or if we should follow the value stored to the heap to get the value.

A word on a 64 bit machine is 8 bytes (64 bits) and all of the pointers need to be aligned to multiples of 8. So a pointer could be:

1000       = 8
10000      = 16
11000      = 24
100000     = 32
1000000000 = 512

Remember that we are talking about the pointers and not the values store at the memory location they point to. We can see that there are always three bits that are zero in the pointers. So we can use them for something else and just mask them out when using them as pointers.

Tagging involves borrowing one bit of the 32-bit, making it 31-bit and having the leftover bit represent a tag. If the tag is zero then this is a plain value, but if tag is 1 then the pointer must be followed. This does not only have to be for numbers it could also be used for object (I think)

Instead the small integer is represented by the 32 bits plus a pointer to the 64-bit number. V8 needs to know if a value stored in memory represents a 32-bit integer, or if it is really a 64-bit number, in which case it has to follow the pointer to get the complete value. This is where the concept of tagging comes in.

### Properties/Elements

Take the following object:

{ firstname: "Jon", lastname: "Doe' }

The above object has two named properties. Named properties differ from integer indexed which is what you have when you are working with arrays.

Memory layout of JavaScript Object:

Properties                  JavaScript Object               Elements
+-----------+              +-----------------+         +----------------+
|property1  |<------+      | HiddenClass     |  +----->|                |
+-----------+       |      +-----------------+  |      +----------------+
|...        |       +------| Properties      |  |      | element1       |<------+
+-----------+              +-----------------+  |      +----------------+       |
|...        |              | Elements        |--+      | ...            |       |
+-----------+              +-----------------+         +----------------+       |
|propertyN  | <---------------------+                  | elementN       |       |
+-----------+                       |                  +----------------+       |
|                                           |
|                                           |
|                                           |
Named properties:    { firstname: "Jon", lastname: "Doe' } Indexed Properties: {1: "Jon", 2: "Doe"}

We can see that properies and elements are stored in different data structures. Elements are usually implemented as a plain array and the indexes can be used for fast access to the elements. But for the properties this is not the case. Instead there is a mapping between the property names and the index into the properties.

In src/objects/objects.h we can find JSObject:

class JSObject: public JSReceiver {
...
DECL_ACCESSORS(elements, FixedArrayBase)

And looking a the DECL_ACCESSOR macro:

#define DECL_ACCESSORS(name, type)    \
inline type* name() const;          \
inline void set_##name(type* value, \
WriteBarrierMode mode = UPDATE_WRITE_BARRIER);

inline FixedArrayBase* name() const;
inline void set_elements(FixedArrayBase* value, WriteBarrierMode = UPDATE_WRITE_BARRIER)

Notice that JSObject extends JSReceiver which is extended by all types that can have properties defined on them. I think this includes all JSObjects and JSProxy. It is in JSReceiver that the we find the properties array:

DECL_ACCESSORS(raw_properties_or_hash, Object)

Now properties (named properties not elements) can be of different kinds internally. These work just like simple dictionaries from the outside but a dictionary is only used in certain curcumstances at runtime.

Properties                  JSObject                    HiddenClass (Map)
+-----------+              +-----------------+         +----------------+
|property1  |<------+      | HiddenClass     |-------->| bit field1     |
+-----------+       |      +-----------------+         +----------------+
|...        |       +------| Properties      |         | bit field2     |
+-----------+              +-----------------+         +----------------+
|...        |              | Elements        |         | bit field3     |
+-----------+              +-----------------+         +----------------+
|propertyN  |              | property1       |
+-----------+              +-----------------+
| property2       |
+-----------------+
| ...             |
+-----------------+

#### JSObject

Each JSObject has as its first field a pointer to the generated HiddenClass. A hiddenclass contain mappings from property names to indices into the properties data type. When an instance of JSObject is created a Map is passed in. As mentioned earlier JSObject inherits from JSReceiver which inherits from HeapObject

For example,in jsobject_test.cc we first create a new Map using the internal Isolate Factory:

v8::internal::Handle<v8::internal::Map> map = factory->NewMap(v8::internal::JS_OBJECT_TYPE, 24);
v8::internal::Handle<v8::internal::JSObject> js_object = factory->NewJSObjectFromMap(map);
EXPECT_TRUE(js_object->HasFastProperties());

When we call js_object->HasFastProperties() this will delegate to the map instance:

return !map()->is_dictionary_map();

How do you add a property to a JSObject instance? Take a look at jsobject_test.cc for an example.

### Caching

Are ways to optimize polymorphic function calls in dynamic languages, for example JavaScript.

#### Lookup caches

Sending a message to a receiver requires the runtime to find the correct target method using the runtime type of the receiver. A lookup cache maps the type of the receiver/message name pair to methods and stores the most recently used lookup results. The cache is first consulted and if there is a cache miss a normal lookup is performed and the result stored in the cache.

#### Inline caches

Using a lookup cache as described above still takes a considerable amount of time since the cache must be probed for each message. It can be observed that the type of the target does often not vary. If a call to type A is done at a particular call site it is very likely that the next time it is called the type will also be A. The method address looked up by the system lookup routine can be cached and the call instruction can be overwritten. Subsequent calls for the same type can jump directly to the cached method and completely avoid the lookup. The prolog of the called method must verify that the receivers type has not changed and do the lookup if it has changed (the type if incorrect, no longer A for example).

The target methods address is stored in the callers code, or "inline" with the callers code, hence the name "inline cache".

If V8 is able to make a good assumption about the type of object that will be passed to a method, it can bypass the process of figuring out how to access the objects properties, and instead use the stored information from previous lookups to the objects hidden class.

#### Polymorfic Inline cache (PIC)

A polymorfic call site is one where there are many equally likely receiver types (and thus call targets).

• Monomorfic means there is only one receiver type
• Polymorfic a few receiver types
• Megamorfic very many receiver types

This type of caching extends inline caching to not just cache the last lookup, but cache all lookup results for a given polymorfic call site using a specially generated stub. Lets say we have a method that iterates through a list of types and calls a method. If all the types are the same (monomorfic) a PIC acts just like an inline cache. The calls will directly call the target method (with the method prolog followed by the method body). If a different type exists in the list there will be a cache miss in the prolog and the lookup routine called. In normal inline caching this would rebind the call, replacing the call to this types target method. This would happen each time the type changes.

With PIC the cache miss handler will generate a small stub routine and rebinds the call to this stub. The stub will check if the receiver is of a type that it has seen before and branch to the correct targets. Since the type of the target is already known at this point it can directly branch to the target method body without the need for the prolog. If the type has not been seen before it will be added to the stub to handle that type. Eventually the stub will contain all types used and there will be no more cache misses/lookups.

The problem is that we don't have type information so methods cannot be called directly, but instead be looked up. In a static language a virtual table might have been used. In JavaScript there is no inheritance relationship so it is not possible to know a vtable offset ahead of time. What can be done is to observe and learn about the "types" used in the program. When an object is seen it can be stored and the target of that method call can be stored and inlined into that call. Bascially the type will be checked and if that particular type has been seen before the method can just be invoked directly. But how do we check the type in a dynamic language? The answer is hidden classes which allow the VM to quickly check an object against a hidden class.

The inline caching source are located in src/ic.

## --trace-ic

\$ out/x64.debug/d8 --trace-ic --trace-maps class.js

before
[TraceMaps: Normalize from= 0x19a314288b89 to= 0x19a31428aff9 reason= NormalizeAsPrototype ]
[TraceMaps: ReplaceDescriptors from= 0x19a31428aff9 to= 0x19a31428b051 reason= CopyAsPrototype ]
[TraceMaps: InitialMap map= 0x19a31428afa1 SFI= 34_Person ]

[StoreIC in ~Person+65 at class.js:2 (0->.) map=0x19a31428afa1 0x10e68ba83361 <String[4]: name>]
[TraceMaps: Transition from= 0x19a31428afa1 to= 0x19a31428b0a9 name= name ]
[StoreIC in ~Person+102 at class.js:3 (0->.) map=0x19a31428b0a9 0x2beaa25abd89 <String[3]: age>]
[TraceMaps: Transition from= 0x19a31428b0a9 to= 0x19a31428b101 name= age ]
[TraceMaps: SlowToFast from= 0x19a31428b051 to= 0x19a31428b159 reason= OptimizeAsPrototype ]
[StoreIC in ~Person+65 at class.js:2 (.->1) map=0x19a31428afa1 0x10e68ba83361 <String[4]: name>]
[StoreIC in ~Person+102 at class.js:3 (.->1) map=0x19a31428b0a9 0x2beaa25abd89 <String[3]: age>]
[LoadIC in ~+546 at class.js:9 (0->.) map=0x19a31428b101 0x10e68ba83361 <String[4]: name>]
[CallIC in ~+571 at class.js:9 (0->1) map=0x0 0x32f481082231 <String[5]: print>]
Daniel
[LoadIC in ~+642 at class.js:10 (0->.) map=0x19a31428b101 0x2beaa25abd89 <String[3]: age>]
[CallIC in ~+667 at class.js:10 (0->1) map=0x0 0x32f481082231 <String[5]: print>]
41
[LoadIC in ~+738 at class.js:11 (0->.) map=0x19a31428b101 0x10e68ba83361 <String[4]: name>]
[CallIC in ~+763 at class.js:11 (0->1) map=0x0 0x32f481082231 <String[5]: print>]
Tilda
[LoadIC in ~+834 at class.js:12 (0->.) map=0x19a31428b101 0x2beaa25abd89 <String[3]: age>]
[CallIC in ~+859 at class.js:12 (0->1) map=0x0 0x32f481082231 <String[5]: print>]
2
[CallIC in ~+927 at class.js:13 (0->1) map=0x0 0x32f481082231 <String[5]: print>]
after

LoadIC (0->.) means that it has transitioned from unititialized state (0) to pre-monomophic state (.) monomorphic state is specified with a 1. These states can be found in src/ic/ic.cc. What we are doing caching knowledge about the layout of the previously seen object inside the StoreIC/LoadIC calls.

\$ lldb -- out/x64.debug/d8 class.js

#### HeapObject

This class describes heap allocated objects. It is in this class we find information regarding the type of object. This information is contained in v8::internal::Map.

### v8::internal::Map

src/objects/map.h

• bit_field1
• bit_field2
• bit field3 contains information about the number of properties that this Map has, a pointer to an DescriptorArray. The DescriptorArray contains information like the name of the property, and the posistion where the value is stored in the JSObject. I noticed that this information available in src/objects/map.h.

#### DescriptorArray

Can be found in src/objects/descriptor-array.h. This class extends FixedArray and has the following entries:

[0] the number of descriptors it contains
[1] If uninitialized this will be Smi(0) otherwise an enum cache bridge which is a FixedArray of size 2:
[0] enum cache: FixedArray containing all own enumerable keys
[1] either Smi(0) or a pointer to a FixedArray with indices
[2] first key (and internalized String
[3] first descriptor

### Factory

Each Internal Isolate has a Factory which is used to create instances. This is because all handles needs to be allocated using the factory (src/heap/factory.h)

### Objects

All objects extend the abstract class Object (src/objects/objects.h).

### Oddball

This class extends HeapObject and describes null, undefined, true, and false objects.

#### Map

Extends HeapObject and all heap objects have a Map which describes the objects structure. This is where you can find the size of the instance, access to the inobject_properties.

### Compiler pipeline

When a script is compiled all of the top level code is parsed. These are function declarartions (but not the function bodies).

function f1() {       <- top level code
console.log('f1');  <- non top level
}

function f2() {       <- top level code
f1();               <- non top level
console.logg('f2'); <- non top level
}

f2();                 <- top level code
var i = 10;           <- top level code

The non top level code must be pre-parsed to check for syntax errors. The top level code is parsed and compiles by the full-codegen compiler. This compiler does not perform any optimizations and it's only task is to generate machine code as quickly as possible (this is pre turbofan)

Source ------> Parser  --------> Full-codegen ---------> Unoptimized Machine Code

So the whole script is parsed even though we only generated code for the top-level code. The pre-parse (the syntax checking) was not stored in any way. The functions are lazy stubs that when/if the function gets called the function get compiled. This means that the function has to be parsed (again, the first time was the pre-parse remember).

If a function is determined to be hot it will be optimized by one of the two optimizing compilers crankshaft for older parts of JavaScript or Turbofan for Web Assembly (WASM) and some of the newer es6 features.

The first time V8 sees a function it will parse it into an AST but not do any further processing of that tree until that function is used.

+-----> Full-codegen -----> Unoptimized code
/                               \/ /\       \
Parser  ------> AST -------> Cranshaft    -----> Optimized code  |
\                                           /
+-----> Turbofan     -----> Optimized code

Inline Cachine (IC) is done here which also help to gather type information. V8 also has a profiler thread which monitors which functions are hot and should be optimized. This profiling also allows V8 to find out information about types using IC. This type information can then be fed to Crankshaft/Turbofan. The type information is stored as a 8 bit value.

When a function is optimized the unoptimized code cannot be thrown away as it might be needed since JavaScript is highly dynamic the optimzed function migth change and the in that case we fallback to the unoptimzed code. This takes up alot of memory which may be important for low end devices. Also the time spent in parsing (twice) takes time.

The idea with Ignition is to be an bytecode interpreter and to reduce memory consumption, the bytecode is very consice compared to native code which can vary depending on the target platform. The whole source can be parsed and compiled, compared to the current pipeline the has the pre-parse and parse stages mentioned above. So even unused functions will get compiled. The bytecode becomes the source of truth instead of as before the AST.

Source ------> Parser  --------> Ignition-codegen ---------> Bytecode ---------> Turbofan ----> Optimized Code ---+
/\                                                  |
+--------------------------------------------------+

function bajja(a, b, c) {
var d = c - 100;
return a + d * b;
}

var result = bajja(2, 2, 150);
print(result);

\$ ./d8 test.js --ignition  --print_bytecode

[generating bytecode for function: bajja]
Parameter count 4
Frame size 8
14 E> 0x2eef8d9b103e @    0 : 7f                StackCheck
38 S> 0x2eef8d9b103f @    1 : 03 64             LdaSmi [100]   // load 100
38 E> 0x2eef8d9b1041 @    3 : 2b 02 02          Sub a2, [2]    // a2 is the third argument. a2 is an argument register
0x2eef8d9b1044 @    6 : 1f fa             Star r0        // r0 is a register for local variables. We only have one which is d
47 S> 0x2eef8d9b1046 @    8 : 1e 03             Ldar a1        // LoaD accumulator from Register argument a1 which is b
60 E> 0x2eef8d9b1048 @   10 : 2c fa 03          Mul r0, [3]    // multiply that is our local variable in r0
56 E> 0x2eef8d9b104b @   13 : 2a 04 04          Add a0, [4]    // add that to our argument register 0 which is a
65 S> 0x2eef8d9b104e @   16 : 83                Return         // return the value in the accumulator?

### Abstract Syntax Tree (AST)

In src/ast/ast.h. You can print the ast using the --print-ast option for d8.

Lets take the following javascript and look at the ast:

const msg = 'testing';
console.log(msg);
\$ d8 --print-ast simple.js
[generating interpreter code for user-defined function: ]
--- AST ---
FUNC at 0
. KIND 0
. SUSPEND COUNT 0
. NAME ""
. INFERRED NAME ""
. DECLS
. . VARIABLE (0x7ffe5285b0f8) (mode = CONST) "msg"
. BLOCK NOCOMPLETIONS at -1
. . EXPRESSION STATEMENT at 12
. . . INIT at 12
. . . . VAR PROXY context[4] (0x7ffe5285b0f8) (mode = CONST) "msg"
. . . . LITERAL "testing"
. EXPRESSION STATEMENT at 23
. . ASSIGN at -1
. . . VAR PROXY local[0] (0x7ffe5285b330) (mode = TEMPORARY) ".result"
. . . CALL Slot(0)
. . . . PROPERTY Slot(4) at 31
. . . . . VAR PROXY Slot(2) unallocated (0x7ffe5285b3d8) (mode = DYNAMIC_GLOBAL) "console"
. . . . . NAME log
. . . . VAR PROXY context[4] (0x7ffe5285b0f8) (mode = CONST) "msg"
. RETURN at -1
. . VAR PROXY local[0] (0x7ffe5285b330) (mode = TEMPORARY) ".result"

You can find the declaration of EXPRESSION in ast.h.

### Bytecode

Can be found in src/interpreter/bytecodes.h

• StackCheck checks that stack limits are not exceeded to guard against overflow.
• Star Store content in accumulator regiser in register (the operand).
• Ldar LoaD accumulator from Register argument a1 which is b

The registers are not machine registers, apart from the accumlator as I understand it, but would instead be stack allocated.

#### Parsing

Parsing is the parsing of the JavaScript and the generation of the abstract syntax tree. That tree is then visited and bytecode generated from it. This section tries to figure out where in the code these operations are performed.

For example, take the script example.

\$ make run-script
\$ lldb -- run-script
(lldb) br s -n main
(lldb) r

Lets take a look at the following line:

Local<Script> script = Script::Compile(context, source).ToLocalChecked();

This will land us in api.cc

ScriptCompiler::Source script_source(source);
return ScriptCompiler::Compile(context, &script_source);

MaybeLocal<Script> ScriptCompiler::Compile(Local<Context> context, Source* source, CompileOptions options) {
...
auto isolate = context->GetIsolate();
auto maybe = CompileUnboundInternal(isolate, source, options);

CompileUnboundInternal will call GetSharedFunctionInfoForScript (in src/compiler.cc):

result = i::Compiler::GetSharedFunctionInfoForScript(
str, name_obj, line_offset, column_offset, source->resource_options,
source_map_url, isolate->native_context(), NULL, &script_data, options,
i::NOT_NATIVES_CODE);

(lldb) br s -f compiler.cc -l 1259

LanguageMode language_mode = construct_language_mode(FLAG_use_strict);
(lldb) p language_mode
(v8::internal::LanguageMode) \$10 = SLOPPY

LanguageMode can be found in src/globals.h and it is an enum with three values:

enum LanguageMode : uint32_t { SLOPPY, STRICT, LANGUAGE_END };

SLOPPY mode, I assume, is the mode when there is no "use strict";. Remember that this can go inside a function and does not have to be at the top level of the file.

ParseInfo parse_info(script);

There is a unit test that shows how a ParseInfo instance can be created and inspected.

This will call ParseInfo's constructor (in src/parsing/parse-info.cc), and which will call ParseInfo::InitFromIsolate:

DCHECK_NOT_NULL(isolate);
set_hash_seed(isolate->heap()->HashSeed());
set_stack_limit(isolate->stack_guard()->real_climit());
set_unicode_cache(isolate->unicode_cache());
set_runtime_call_stats(isolate->counters()->runtime_call_stats());
set_ast_string_constants(isolate->ast_string_constants());

I was curious about these ast_string_constants:

(lldb) p *ast_string_constants_
(const v8::internal::AstStringConstants) \$58 = {
zone_ = {
allocation_size_ = 1312
segment_bytes_allocated_ = 8192
position_ = 0x0000000105052538 <no value available>
limit_ = 0x0000000105054000 <no value available>
allocator_ = 0x0000000103e00080
segment_head_ = 0x0000000105052000
name_ = 0x0000000101623a70 "../../src/ast/ast-value-factory.h:365"
sealed_ = false
}
string_table_ = {
v8::base::TemplateHashMapImpl<void *, void *, v8::base::HashEqualityThenKeyMatcher<void *, bool (*)(void *, void *)>, v8::base::DefaultAllocationPolicy> = {
map_ = 0x0000000105054000
capacity_ = 64
occupancy_ = 41
match_ = {
match_ = 0x000000010014b260 (libv8.dylib`v8::internal::AstRawString::Compare(void*, void*) at ast-value-factory.cc:122)
}
}
}
hash_seed_ = 500815076
anonymous_function_string_ = 0x0000000105052018
arguments_string_ = 0x0000000105052038
async_string_ = 0x0000000105052058
await_string_ = 0x0000000105052078
boolean_string_ = 0x0000000105052098
constructor_string_ = 0x00000001050520b8
default_string_ = 0x00000001050520d8
done_string_ = 0x00000001050520f8
dot_string_ = 0x0000000105052118
dot_for_string_ = 0x0000000105052138
dot_generator_object_string_ = 0x0000000105052158
dot_iterator_string_ = 0x0000000105052178
dot_result_string_ = 0x0000000105052198
dot_switch_tag_string_ = 0x00000001050521b8
dot_catch_string_ = 0x00000001050521d8
empty_string_ = 0x00000001050521f8
eval_string_ = 0x0000000105052218
function_string_ = 0x0000000105052238
get_space_string_ = 0x0000000105052258
length_string_ = 0x0000000105052278
let_string_ = 0x0000000105052298
name_string_ = 0x00000001050522b8
native_string_ = 0x00000001050522d8
new_target_string_ = 0x00000001050522f8
next_string_ = 0x0000000105052318
number_string_ = 0x0000000105052338
object_string_ = 0x0000000105052358
proto_string_ = 0x0000000105052378
prototype_string_ = 0x0000000105052398
return_string_ = 0x00000001050523b8
set_space_string_ = 0x00000001050523d8
star_default_star_string_ = 0x00000001050523f8
string_string_ = 0x0000000105052418
symbol_string_ = 0x0000000105052438
this_string_ = 0x0000000105052458
this_function_string_ = 0x0000000105052478
throw_string_ = 0x0000000105052498
undefined_string_ = 0x00000001050524b8
use_asm_string_ = 0x00000001050524d8
use_strict_string_ = 0x00000001050524f8
value_string_ = 0x0000000105052518
}

So these are constants that are set on the new ParseInfo instance using the values from the isolate. Not exactly sure what I want with this but I might come back to it later. So, we are back in ParseInfo's constructor:

set_allow_lazy_parsing();
set_toplevel();
set_script(script);

Script is of type v8::internal::Script which can be found in src/object/script.h

Back now in compiler.cc and the GetSharedFunctionInfoForScript function:

Zone compile_zone(isolate->allocator(), ZONE_NAME);

...
if (parse_info->literal() == nullptr && !parsing::ParseProgram(parse_info, isolate))

ParseProgram:

Parser parser(info);
...
FunctionLiteral* result = nullptr;
result = parser.ParseProgram(isolate, info);

parser.ParseProgram:

Handle<String> source(String::cast(info->script()->source()));

(lldb) job *source
"var user1 = new Person('Fletch');\x0avar user2 = new Person('Dr.Rosen');\x0aprint("user1 = " + user1.name);\x0aprint("user2 = " + user2.name);\x0a\x0a"

So here we can see our JavaScript as a String.

std::unique_ptr<Utf16CharacterStream> stream(ScannerStream::For(source));
scanner_.Initialize(stream.get(), info->is_module());
result = DoParseProgram(info);

DoParseProgram:

(lldb) br s -f parser.cc -l 639
...

this->scope()->SetLanguageMode(info->language_mode());
ParseStatementList(body, Token::EOS, &ok);

This call will land in parser-base.h and its ParseStatementList function.

(lldb) br s -f parser-base.h -l 4695

StatementT stat = ParseStatementListItem(CHECK_OK_CUSTOM(Return, kLazyParsingComplete));

result = CompileToplevel(&parse_info, isolate, Handle<SharedFunctionInfo>::null());

This will land in CompileTopelevel (in the same file which is src/compiler.cc):

// Compile the code.
result = CompileUnoptimizedCode(parse_info, shared_info, isolate);

This will land in CompileUnoptimizedCode (in the same file which is src/compiler.cc):

// Prepare and execute compilation of the outer-most function.
std::unique_ptr<CompilationJob> outer_job(
PrepareAndExecuteUnoptimizedCompileJob(parse_info, parse_info->literal(),
shared_info, isolate));

std::unique_ptr<CompilationJob> job(
interpreter::Interpreter::NewCompilationJob(parse_info, literal, isolate));
if (job->PrepareJob() == CompilationJob::SUCCEEDED &&
job->ExecuteJob() == CompilationJob::SUCCEEDED) {
return job;
}

PrepareJobImpl:

CodeGenerator::MakeCodePrologue(parse_info(), compilation_info(),
"interpreter");
return SUCCEEDED;

codegen.cc MakeCodePrologue:

interpreter.cc ExecuteJobImpl:

generator()->GenerateBytecode(stack_limit());

src/interpreter/bytecode-generator.cc

RegisterAllocationScope register_scope(this);

The bytecode is register based (if that is the correct term) and we had an example previously. I'm guessing that this is what this call is about.

VisitDeclarations will iterate over all the declarations in the file which in our case are:

var user1 = new Person('Fletch');
var user2 = new Person('Dr.Rosen');

(lldb) p *variable->raw_name()
(const v8::internal::AstRawString) \$33 = {
= {
next_ = 0x000000010600a280
string_ = 0x000000010600a280
}
literal_bytes_ = (start_ = "user1", length_ = 5)
hash_field_ = 1303438034
is_one_byte_ = true
has_string_ = false
}

// Perform a stack-check before the body.
builder()->StackCheck(info()->literal()->start_position());

So that call will output a stackcheck instruction, like in the example above:

14 E> 0x2eef8d9b103e @    0 : 7f                StackCheck

### Performance

Say you have the expression x + y the full-codegen compiler might produce:

movq rax, x
movq rbx, y
callq RuntimeAdd

If x and y are integers just using the add operation would be much quicker:

movq rax, x
movq rbx, y
add rax, rbx

Recall that functions are optimized so if the compiler has to bail out and unoptimize part of a function then the whole functions will be affected and it will go back to the unoptimized version.

## Bytecode

This section will examine the bytecode for the following JavaScript:

function beve() {
const p = new Promise((resolve, reject) => {
resolve('ok');
});

p.then(msg => {
console.log(msg);
});
}

beve();

\$ d8 --print-bytecode promise.js

First have the main function which does not have a name:

[generating bytecode for function: ]
(The code that generated this can be found in src/objects.cc BytecodeArray::Dissassemble)
Parameter count 1
Frame size 32
// load what ever the FixedArray[4] is in the constant pool into the accumulator.
0x34423e7ac19e @    0 : 09 00             LdaConstant [0]
// store the FixedArray[4] in register r1
0x34423e7ac1a0 @    2 : 1e f9             Star r1
// store zero into the accumulator.
0x34423e7ac1a2 @    4 : 02                LdaZero
// store zero (the contents of the accumulator) into register r2.
0x34423e7ac1a3 @    5 : 1e f8             Star r2
//
0x34423e7ac1a5 @    7 : 1f fe f7          Mov <closure>, r3
0x34423e7ac1a8 @   10 : 53 96 01 f9 03    CallRuntime [DeclareGlobalsForInterpreter], r1-r3
0 E> 0x34423e7ac1ad @   15 : 90                StackCheck
141 S> 0x34423e7ac1ae @   16 : 0a 01 00          LdaGlobal [1], [0]
0x34423e7ac1b1 @   19 : 1e f9             Star r1
141 E> 0x34423e7ac1b3 @   21 : 4f f9 03          CallUndefinedReceiver0 r1, [3]
0x34423e7ac1b6 @   24 : 1e fa             Star r0
148 S> 0x34423e7ac1b8 @   26 : 94                Return

Constant pool (size = 2)
0x34423e7ac149: [FixedArray] in OldSpace
- map = 0x344252182309 <Map(HOLEY_ELEMENTS)>
- length: 2
0: 0x34423e7ac069 <FixedArray[4]>
1: 0x34423e7abf59 <String[4]: beve>

Handler Table (size = 16) Load the global with name in constant pool entry <name_index> into the
// accumulator using FeedBackVector slot <slot> outside of a typeof
• LdaConstant Load the constant at index from the constant pool into the accumulator.
• Star Store the contents of the accumulator register in dst.
• Ldar Load accumulator with value from register src.
• LdaGlobal Load the global with name in constant pool entry idx into the accumulator using FeedBackVector slot outside of a typeof.
• Mov , Store the value of register

You can find the declarations for the these instructions in src/interpreter/interpreter-generator.cc.

## FeedbackVector

Is attached to every function and is responsible for recording and managing all execution feedback, which is information about types enabling. You can find the declaration for this class in src/feedback-vector.h

## BytecodeGenerator

Is currently the only part of V8 that cares about the AST.

## BytecodeGraphBuilder

Produces high-level IR graph based on interpreter bytecodes.

## TurboFan

Is a compiler backend that gets fed a control flow graph and then does instruction selection, register allocation and code generation. The code generation generates

### Execution/Runtime

I'm not sure if V8 follows this exactly but I've heard and read that when the engine comes across a function declaration it only parses and verifies the syntax and saves a ref to the function name. The statements inside the function are not checked at this stage only the syntax of the function declaration (parenthesis, arguments, brackets etc).

### Function methods

The declaration of Function can be found in include/v8.h (just noting this as I've looked for it several times)

### Symbol

The declarations for the Symbol class can be found in v8.h and the internal implementation in src/api/api.cc.

The well known Symbols are generated using macros so you won't find the just by searching using the static function names like 'GetToPrimitive`.

#define WELL_KNOWN_SYMBOLS(V)                 \
V(AsyncIterator, async_iterator)            \
V(HasInstance, has_instance)                \
V(IsConcatSpreadable, is_concat_spreadable) \
V(Iterator, iterator)                       \
V(Match, match)                             \
V(Replace, replace)                         \
V(Search, search)                           \
V(Split, split)                             \
V(ToPrimitive, to_primitive)                \
V(ToStringTag, to_string_tag)               \
V(Unscopables, unscopables)

#define SYMBOL_GETTER(Name, name)                                   \
Local<Symbol> v8::Symbol::Get##Name(Isolate* isolate) {           \
i::Isolate* i_isolate = reinterpret_cast<i::Isolate*>(isolate); \
return Utils::ToLocal(i_isolate->factory()->name##_symbol());   \
}

So GetToPrimitive would become:

Local<Symbol> v8::Symbol::GeToPrimitive(Isolate* isolate) {
i::Isolate* i_isolate = reinterpret_cast<i::Isolate*>(isolate);
return Utils::ToLocal(i_isolate->factory()->to_primitive_symbol());
}

There is an example in symbol-test.cc.

## Builtins

Are JavaScript functions/objects that are provided by V8. These are built using a C++ DSL and are passed through:

CodeStubAssembler -> CodeAssembler -> RawMachineAssembler.

Builtins need to have bytecode generated for them so that they can be run in TurboFan.

src/code-stub-assembler.h

All the builtins are declared in src/builtins/builtins-definitions.h by the BUILTIN_LIST_BASE macro. There are different type of builtins (TF = Turbo Fan):

TFJ JavaScript linkage which means it is callable as a JavaScript function

TFS CodeStub linkage. A builtin with stub linkage can be used to extract common code into a separate code object which can then be used by multiple callers. These is useful because builtins are generated at compile time and included in the V8 snapshot. This means that they are part of every isolate that is created. Being able to share common code for multiple builtins will save space.

TFC CodeStub linkage with custom descriptor

To see how this works in action we first need to disable snapshots. If we don't, we won't be able to set breakpoints as the the heap will be serialized at compile time and deserialized upon startup of v8.

To find the option to disable snapshots use:

\$ gn args --list out.gn/learning --short | more
...
v8_use_snapshot=true
\$ gn args out.gn/learning
v8_use_snapshot=false
\$ gn -C out.gn/learning

After building we should be able to set a break point in bootstrapper.cc and its function Genesis::InitializeGlobal:

(lldb) br s -f bootstrapper.cc -l 2684

Lets take a look at how the JSON object is setup:

Handle<String> name = factory->InternalizeUtf8String("JSON");
Handle<JSObject> json_object = factory->NewJSObject(isolate->object_function(), TENURED);

TENURED means that this object should be allocated directly in the old generation.

JSObject::AddProperty(global, name, json_object, DONT_ENUM);

DONT_ENUM is checked by some builtin functions and if set this object will be ignored by those functions.

SimpleInstallFunction(json_object, "parse", Builtins::kJsonParse, 2, false);

Here we can see that we are installing a function named parse, which takes 2 parameters. You can find the definition in src/builtins/builtins-json.cc. What does the SimpleInstallFunction do?

Lets take console as an example which was created using:

Handle<JSObject> console = factory->NewJSObject(cons, TENURED);
JSObject::AddProperty(global, name, console, DONT_ENUM);
SimpleInstallFunction(console, "debug", Builtins::kConsoleDebug, 1, false,
NONE);

V8_NOINLINE Handle<JSFunction> SimpleInstallFunction(
Handle<JSObject> base,
const char* name,
Builtins::Name call,
int len,
bool adapt,
PropertyAttributes attrs = DONT_ENUM,
BuiltinFunctionId id = kInvalidBuiltinFunctionId) {

So we can see that base is our Handle to a JSObject, and name is "debug". Builtins::Name is Builtins:kConsoleDebug. Where is this defined?
You can find a macro named CPP in src/builtins/builtins-definitions.h:

CPP(ConsoleDebug)

What does this macro expand to?
It is part of the BUILTIN_LIST_BASE macro in builtin-definitions.h We have to look at where BUILTIN_LIST is used which we can find in builtins.cc. In builtins.cc we have an array of BuiltinMetadata which is declared as:

const BuiltinMetadata builtin_metadata[] = {
BUILTIN_LIST(DECL_CPP, DECL_API, DECL_TFJ, DECL_TFC, DECL_TFS, DECL_TFH, DECL_ASM)
};

#define DECL_CPP(Name, ...) { #Name, Builtins::CPP, \
{ FUNCTION_ADDR(Builtin_##Name) }},

Which will expand to the creation of a BuiltinMetadata struct entry in the array. The BuildintMetadata struct looks like this which might help understand what is going on:

struct BuiltinMetadata {
const char* name;
Builtins::Kind kind;
union {
Address cpp_entry;       // For CPP and API builtins.
int8_t parameter_count;  // For TFJ builtins.
} kind_specific_data;
};

So the CPP(ConsoleDebug) will expand to an entry in the array which would look something like this:

{ ConsoleDebug,
Builtins::CPP,
{
reinterpret_cast<v8::internal::Address>(reinterpret_cast<intptr_t>(Builtin_ConsoleDebug))
}
},

The third paramter is the creation on the union which might not be obvious.

Back to the question I'm trying to answer which is:
"Buildtins::Name is is Builtins:kConsoleDebug. Where is this defined?"
For this we have to look at builtins.h and the enum Name:

enum Name : int32_t {
#define DEF_ENUM(Name, ...) k##Name,
BUILTIN_LIST_ALL(DEF_ENUM)
#undef DEF_ENUM
builtin_count
};

This will expand to the complete list of builtins in builtin-definitions.h using the DEF_ENUM macro. So the expansion for ConsoleDebug will look like:

enum Name: int32_t {
...
kDebugConsole,
...
};

So backing up to looking at the arguments to SimpleInstallFunction which are:

SimpleInstallFunction(console, "debug", Builtins::kConsoleDebug, 1, false,
NONE);

V8_NOINLINE Handle<JSFunction> SimpleInstallFunction(
Handle<JSObject> base,
const char* name,
Builtins::Name call,
int len,
bool adapt,
PropertyAttributes attrs = DONT_ENUM,
BuiltinFunctionId id = kInvalidBuiltinFunctionId) {

We know about Builtins::Name, so lets look at len which is one, what is this?
SimpleInstallFunction will call:

Handle<JSFunction> fun =
SimpleCreateFunction(base->GetIsolate(), function_name, call, len, adapt);

len would be used if adapt was true but it is false in our case. This is what it would be used for if adapt was true:

fun->shared()->set_internal_formal_parameter_count(len);

I'm not exactly sure what adapt is referring to here.

PropertyAttributes is not specified so it will get the default value of DONT_ENUM. The last parameter which is of type BuiltinFunctionId is not specified either so the default value of kInvalidBuiltinFunctionId will be used. This is an enum defined in src/objects/objects.h.

This blog provides an example of adding a function to the String object.

\$ out.gn/learning/mksnapshot --print-code > output

You can then see the generated code from this. This will produce a code stub that can be called through C++. Lets update this to have it be called from JavaScript:

Update builtins/builtins-string-get.cc :

TF_BUILTIN(GetStringLength, StringBuiltinsAssembler) {
Node* const str = Parameter(Descriptor::kReceiver);
Return(LoadStringLength(str));
}

We also have to update builtins/builtins-definitions.h:

TFJ(GetStringLength, 0)

And bootstrapper.cc:

SimpleInstallFunction(prototype, "len", Builtins::kGetStringLength, 0, true);

If you now build using 'ninja -C out.gn/learning_v8' you should be able to run d8 and try this out:

d8> const s = 'testing'
undefined
d8> s.len()
7

Now lets take a closer look at the code that is generated for this:

\$ out.gn/learning/mksnapshot --print-code > output

Looking at the output generated I was surprised to see two entries for GetStringLength (I changed the name just to make sure there was not something else generating the second one). Why two?

The following uses Intel Assembly syntax which means that no register/immediate prefixes and the first operand is the destination and the second operand the source.

--- Code ---
kind = BUILTIN
name = BeveStringLength
compiler = turbofan
Instructions (size = 136)
0x1fafde09b3a0     0  55             push rbp
0x1fafde09b3a1     1  4889e5         REX.W movq rbp,rsp                  // movq rsp into rbp

0x1fafde09b3a4     4  56             push rsi                            // push the value of rsi (first parameter) onto the stack
0x1fafde09b3a5     5  57             push rdi                            // push the value of rdi (second parameter) onto the stack
0x1fafde09b3a6     6  50             push rax                            // push the value of rax (accumulator) onto the stack

0x1fafde09b3a7     7  4883ec08       REX.W subq rsp,0x8                  // make room for a 8 byte value on the stack
0x1fafde09b3ab     b  488b4510       REX.W movq rax,[rbp+0x10]           // move the value rpm + 10 to rax
0x1fafde09b3af     f  488b58ff       REX.W movq rbx,[rax-0x1]
0x1fafde09b3b3    13  807b0b80       cmpb [rbx+0xb],0x80                // IsString(object). compare byte to zero
0x1fafde09b3b7    17  0f8350000000   jnc 0x1fafde09b40d  <+0x6d>        // jump it carry flag was not set

0x1fafde09b3bd    1d  488b400f       REX.W movq rax,[rax+0xf]
0x1fafde09b3c1    21  4989e2         REX.W movq r10,rsp
0x1fafde09b3c4    24  4883ec08       REX.W subq rsp,0x8
0x1fafde09b3c8    28  4883e4f0       REX.W andq rsp,0xf0
0x1fafde09b3cc    2c  4c891424       REX.W movq [rsp],r10
0x1fafde09b3d0    30  488945e0       REX.W movq [rbp-0x20],rax
0x1fafde09b3d4    34  48be0000000001000000 REX.W movq rsi,0x100000000
0x1fafde09b3de    3e  48bad9c228dfa8090000 REX.W movq rdx,0x9a8df28c2d9    ;; object: 0x9a8df28c2d9 <String[101]: CAST(LoadObjectField(object, offset, MachineTypeOf<T>::value)) at ../../src/code-stub-assembler.h:432>
0x1fafde09b3e8    48  488bf8         REX.W movq rdi,rax
0x1fafde09b3eb    4b  48b830726d0a01000000 REX.W movq rax,0x10a6d7230    ;; external reference (check_object_type)
0x1fafde09b3f5    55  40f6c40f       testb rsp,0xf
0x1fafde09b3f9    59  7401           jz 0x1fafde09b3fc  <+0x5c>
0x1fafde09b3fb    5b  cc             int3l
0x1fafde09b3fc    5c  ffd0           call rax
0x1fafde09b3fe    5e  488b2424       REX.W movq rsp,[rsp]
0x1fafde09b402    62  488b45e0       REX.W movq rax,[rbp-0x20]
0x1fafde09b406    66  488be5         REX.W movq rsp,rbp
0x1fafde09b409    69  5d             pop rbp
0x1fafde09b40a    6a  c20800         ret 0x8

// this is where we jump to if IsString failed
0x1fafde09b40d    6d  48ba71c228dfa8090000 REX.W movq rdx,0x9a8df28c271    ;; object: 0x9a8df28c271 <String[76]\: CSA_ASSERT failed: IsString(object) [../../src/code-stub-assembler.cc:1498]\n>
0x1fafde09b417    77  e8e4d1feff     call 0x1fafde088600     ;; code: BUILTIN
0x1fafde09b41c    7c  cc             int3l
0x1fafde09b41d    7d  cc             int3l
0x1fafde09b41e    7e  90             nop
0x1fafde09b41f    7f  90             nop

Safepoints (size = 8)

RelocInfo (size = 7)
0x1fafde09b3e0  embedded object  (0x9a8df28c2d9 <String[101]: CAST(LoadObjectField(object, offset, MachineTypeOf<T>::value)) at ../../src/code-stub-assembler.h:432>)
0x1fafde09b3ed  external reference (check_object_type)  (0x10a6d7230)
0x1fafde09b40f  embedded object  (0x9a8df28c271 <String[76]\: CSA_ASSERT failed: IsString(object) [../../src/code-stub-assembler.cc:1498]\n>)
0x1fafde09b418  code target (BUILTIN)  (0x1fafde088600)

--- End code ---

### TF_BUILTIN macro

Is a macro to defining Turbofan (TF) builtins and can be found in builtins/builtins-utils-gen.h

If we take a look at the file src/builtins/builtins-bigint-gen.cc and the following function:

TF_BUILTIN(BigIntToI64, CodeStubAssembler) {
if (!Is64()) {
Unreachable();
return;
}

TNode<Object> value = CAST(Parameter(Descriptor::kArgument));
TNode<Context> context = CAST(Parameter(Descriptor::kContext));
TNode<BigInt> n = ToBigInt(context, value);

TVARIABLE(UintPtrT, var_low);
TVARIABLE(UintPtrT, var_high);

BigIntToRawBytes(n, &var_low, &var_high);
Return(var_low.value());
}

Let's take our GetStringLength example from above and see what this will be expanded to after processing this macro:

\$ clang++ --sysroot=build/linux/debian_sid_amd64-sysroot -isystem=./buildtools/third_party/libc++/trunk/include -isystem=buildtools/third_party/libc++/trunk/include -I. -E src/builtins/builtins-bigint-gen.cc > builtins-bigint-gen.cc.pp
static void Generate_BigIntToI64(compiler::CodeAssemblerState* state);

class BigIntToI64Assembler : public CodeStubAssembler {
public:
using Descriptor = Builtin_BigIntToI64_InterfaceDescriptor;
explicit BigIntToI64Assembler(compiler::CodeAssemblerState* state) : CodeStubAssembler(state) {}
void GenerateBigIntToI64Impl();
Node* Parameter(Descriptor::ParameterIndices index) {
return CodeAssembler::Parameter(static_cast<int>(index));
}
};

void Builtins::Generate_BigIntToI64(compiler::CodeAssemblerState* state) {
BigIntToI64Assembler assembler(state);
state->SetInitialDebugInformation("BigIntToI64", "src/builtins/builtins-bigint-gen.cc", 14);
if (Builtins::KindOf(Builtins::kBigIntToI64) == Builtins::TFJ) {
assembler.PerformStackCheck(assembler.GetJSContextParameter());
}
assembler.GenerateBigIntToI64Impl();
}
void BigIntToI64Assembler::GenerateBigIntToI64Impl() {
if (!Is64()) {
Unreachable();
return;
}

TNode<Object> value = Cast(Parameter(Descriptor::kArgument));
TNode<Context> context = Cast(Parameter(Descriptor::kContext));
TNode<BigInt> n = ToBigInt(context, value);

TVariable<UintPtrT> var_low(this);
TVariable<UintPtrT> var_high(this);

BigIntToRawBytes(n, &var_low, &var_high);
Return(var_low.value());
}

From the resulting class you can see how Parameter can be used from within TF_BUILTIN macro.

## Building V8

You'll need to have checked out the Google V8 sources to you local file system and build it by following the instructions found here.

### Configure v8 build for learning-v8

There is a make target that can generate a build configuration for V8 that is specific to this project. It can be run using the following command:

\$ make configure_v8

Then to compile this configuration:

\$ make compile_v8

### gclient sync

\$ gclient sync

#### Troubleshooting build:

/v8_src/v8/out/x64.release/obj/libv8_monolith.a(eh-frame.o):eh-frame.cc:function v8::internal::EhFrameWriter::WriteEmptyEhFrame(std::__1::basic_ostream<char, std::__1::char_traits<char> >&): error: undefined reference to 'std::__1::basic_ostream<char, std::__1::char_traits<char> >::write(char const*, long)'
clang: error: linker command failed with exit code 1 (use -v to see invocation)

-stdlib=libc++ is llvm's C++ runtime. This runtime has a __1 namespace. I looks like the static library above was compiled with clangs/llvm's libc++ as we are seeing the __1 namespace.

-stdlib=libstdc++ is GNU's C++ runtime

So we can see that the namespace std::__1 is used which we now know is the namespace that libc++ which is clangs libc++ library. I guess we could go about this in two ways, either we can change v8 build of to use glibc++ when compiling so that the symbols are correct when we want to link against it, or we can update our linker (ld) to use libc++.

We need to include the correct libraries to link with during linking, which means specifying:

-stdlib=libc++ -Wl,-L\$(v8_build_dir)

If we look in \$(v8_build_dir) we find libc++.so. We also need to this library to be found at runtime by the dynamic linker using LD_LIBRARY_PATH:

\$ LD_LIBRARY_PATH=../v8_src/v8/out/x64.release/ ./hello-world

Notice that this is using ld from our path. We can tell clang to use a different search path with the -B option:

\$ clang++ --help | grep -- '-B'
-B <dir>                Add <dir> to search path for binaries and object files used implicitly

libgcc_s is GCC low level runtime library. I've been confusing this with glibc++ libraries for some reason but they are not the same.

Running cctest:

\$ out.gn/learning/cctest test-heap-profiler/HeapSnapshotRetainedObjectInfo

To get a list of the available tests:

\$ out.gn/learning/cctest --list

Checking formating/linting:

\$ git cl format

You can then git diff and see the changes.

Running pre-submit checks:

\$ git cl presubmit

Then upload using:

\$ git cl upload

#### Build details

So when we run gn it will generate Ninja build file. GN itself is written in C++ but has a python wrapper around it.

A group in gn is just a collection of other targets which enables them to have a name.

So when we run gn there will be a number of .ninja files generated. If we look in the root of the output directory we find two .ninja files:

build.ninja  toolchain.ninja

By default ninja will look for build.ninja and when we run ninja we usually specify the -C out/dir. If no targets are specified on the command line ninja will execute all outputs unless there is one specified as default. V8 has the following default target:

default all

build all: phony \$
./bytecode_builtins_list_generator \$
./d8 \$
obj/fuzzer_support.stamp \$
./gen-regexp-special-case \$
obj/generate_bytecode_builtins_list.stamp \$
obj/gn_all.stamp \$
obj/json_fuzzer.stamp \$
obj/lib_wasm_fuzzer_common.stamp \$
./mksnapshot \$
obj/multi_return_fuzzer.stamp \$
obj/parser_fuzzer.stamp \$
obj/postmortem-metadata.stamp \$
obj/regexp_builtins_fuzzer.stamp \$
obj/regexp_fuzzer.stamp \$
obj/run_gen-regexp-special-case.stamp \$
obj/run_mksnapshot_default.stamp \$
obj/run_torque.stamp \$
./torque \$
./torque-language-server \$
obj/torque_base.stamp \$
obj/torque_generated_definitions.stamp \$
obj/torque_generated_initializers.stamp \$
obj/torque_ls_base.stamp \$
./libv8.so.TOC \$
obj/v8_archive.stamp \$
...

A phony rule can be used to create an alias for other targets. The \$ in ninja is an escape character so in the case of the all target it escapes the new line, like using \ in a shell script.

Lets take a look at bytecode_builtins_list_generator:

build \$:bytecode_builtins_list_generator: phony ./bytecode_builtins_list_generator

The format of the ninja build statement is:

build outputs: rulename inputs

We are again seeing the \$ ninja escape character but this time it is escaping the colon which would otherwise be interpreted as separating file names. The output in this case is bytecode_builtins_list_generator. And I'm guessing, as I can't find a connection between ./bytecode_builtins_list_generator and

The default target_out_dir in this case is //out/x64.release_gcc/obj. The executable in BUILD.gn which generates this does not specify any output directory so I'm assuming that it the generated .ninja file is place in the target_out_dir in this case where we can find bytecode_builtins_list_generator.ninja This file has a label named:

label_name = bytecode_builtins_list_generator

Hmm, notice that in build.ninja there is the following command:

subninja toolchain.ninja

And in toolchain.ninja we have:

subninja obj/bytecode_builtins_list_generator.ninja

This is what is making ./bytecode_builtins_list_generator available.

\$ ninja -C out/x64.release_gcc/ -t targets all  | grep bytecode_builtins_list_generator
\$ rm out/x64.release_gcc/bytecode_builtins_list_generator
\$ ninja -C out/x64.release_gcc/ bytecode_builtins_list_generator
ninja: Entering directory `out/x64.release_gcc/'
[1/1] LINK ./bytecode_builtins_list_generator

Alright, so I'd like to understand when in the process torque is run to generate classes like TorqueGeneratedStruct:

class Struct : public TorqueGeneratedStruct<Struct, HeapObject> {
./torque \$
./torque-language-server \$
obj/torque_base.stamp \$
obj/torque_generated_definitions.stamp \$
obj/torque_generated_initializers.stamp \$
obj/torque_ls_base.stamp \$

Like before we can find that obj/torque.ninja in included by the subninja command in toolchain.ninja:

subninja obj/torque.ninja

So this is building the executable torque, but it has not been run yet.

\$ gn ls out/x64.release_gcc/ --type=action
//:generate_bytecode_builtins_list
//:postmortem-metadata
//:run_gen-regexp-special-case
//:run_mksnapshot_default
//:run_torque
//:v8_dump_build_config
//src/inspector:protocol_compatibility
//src/inspector:protocol_generated_sources
//tools/debug_helper:gen_heap_constants
//tools/debug_helper:run_mkgrokdump

Notice the run_torque target

\$ gn desc out/x64.release_gcc/ //:run_torque

If we look in toolchain.ninja we have a rule named ___run_torque___build_toolchain_linux_x64__rule

command = python ../../tools/run.py ./torque -o gen/torque-generated -v8-root ../..
src/builtins/array-copywithin.tq
src/builtins/array-every.tq
src/builtins/array-filter.tq
src/builtins/array-find.tq
...

And there is a build that specifies the .h and cc files in gen/torque-generated which has this rule in it if they change.

## Building chromium

When making changes to V8 you might need to verify that your changes have not broken anything in Chromium.

Generate Your Project (gpy) : You'll have to run this once before building:

\$ gclient sync
\$ gclient runhooks

#### Update the code base

\$ git fetch origin master
\$ git co master
\$ git merge origin/master

### Building using GN

\$ gn args out.gn/learning

### Building using Ninja

\$ ninja -C out.gn/learning

Building the tests:

\$ ninja -C out.gn/learning chrome/test:unit_tests

An error I got when building the first time:

traceback (most recent call last):
File "./gyp-mac-tool", line 713, in <module>
sys.exit(main(sys.argv[1:]))
File "./gyp-mac-tool", line 29, in main
exit_code = executor.Dispatch(args)
File "./gyp-mac-tool", line 44, in Dispatch
return getattr(self, method)(*args[1:])
File "./gyp-mac-tool", line 68, in ExecCopyBundleResource
self._CopyStringsFile(source, dest)
File "./gyp-mac-tool", line 134, in _CopyStringsFile
import CoreFoundation
ImportError: No module named CoreFoundation
[6642/20987] CXX obj/base/debug/base.task_annotator.o
[6644/20987] ACTION base_nacl: build newlib plib_9b4f41e4158ebb93a5d28e6734a13e85
ninja: build stopped: subcommand failed.

I was able to get around this by:

\$ pip install -U pyobjc

#### Using a specific version of V8

The instructions below work but it is also possible to create a soft link from chromium/src/v8 to local v8 repository and the build/test.

So, we want to include our updated version of V8 so that we can verify that it builds correctly with our change to V8. While I'm not sure this is the proper way to do it, I was able to update DEPS in src (chromium) and set the v8 entry to git@github.com:danbev/v8.git@064718a8921608eaf9b5eadbb7d734ec04068a87:

"git@github.com:danbev/v8.git@064718a8921608eaf9b5eadbb7d734ec04068a87"

You'll have to run gclient sync after this.

Another way is to not updated the DEPS file, which is a version controlled file, but instead update .gclientrc and add a custom_deps entry:

solutions = [{u'managed': False, u'name': u'src', u'url': u'https://chromium.googlesource.com/chromium/src.git',
u'custom_deps': {
"src/v8": "git@github.com:danbev/v8.git@27a666f9be7ca3959c7372bdeeee14aef2a4b7ba"
}, u'deps_file': u'.DEPS.git', u'safesync_url': u''}]

## Buiding pdfium

You may have to compile this project (in addition to chromium to verify that changes in v8 are not breaking code in pdfium.

### Create/clone the project

\$ mkdir pdfuim_reop
\$ gclient config --unmanaged https://pdfium.googlesource.com/pdfium.git
\$ gclient sync
\$ cd pdfium

### Building

\$ ninja -C out/Default

#### Using a branch of v8

You should be able to update the .gclient file adding a custom_deps entry:

solutions = [
{
"name"        : "pdfium",
"url"         : "https://pdfium.googlesource.com/pdfium.git",
"deps_file"   : "DEPS",
"managed"     : False,
"custom_deps" : {
"v8": "git@github.com:danbev/v8.git@064718a8921608eaf9b5eadbb7d734ec04068a87"
},
},

] cache_dir = None You'll have to run gclient sync after this too.

## Code in this repo

#### hello-world

hello-world is heavily commented and show the usage of a static int being exposed and accessed from JavaScript.

#### instances

instances shows the usage of creating new instances of a C++ class from JavaScript.

#### run-script

run-script is basically the same as instance but reads an external file, script.js and run the script.

#### tests

The test directory contains unit tests for individual classes/concepts in V8 to help understand them.

\$ make

\$ ./hello-world

\$ make clean

## Contributing a change to V8

1. Create a working branch using git new-branch name
2. git cl upload

See Googles contributing-code for more details.

\$ git cl issue

## Debugging

\$ lldb hello-world
(lldb) br s -f hello-world.cc -l 27

There are a number of useful functions in src/objects-printer.cc which can also be used in lldb.

#### Print value of a Local object

(lldb) print _v8_internal_Print_Object(*(v8::internal::Object**)(*init_fn))

#### Print stacktrace

(lldb) p _v8_internal_Print_StackTrace()

#### Creating command aliases in lldb

Create a file named .lldbinit (in your project director or home directory). This file can now be found in v8's tools directory.

### Using d8

This is the source used for the following examples:

\$ cat class.js
function Person(name, age) {
this.name = name;
this.age = age;
}

print("before");
const p = new Person("Daniel", 41);
print(p.name);
print(p.age);
print("after");

### V8_shell startup

What happens when the v8_shell is run?

\$ lldb -- out/x64.debug/d8 --enable-inspector class.js
(lldb) breakpoint set --file d8.cc --line 2662
Breakpoint 1: where = d8`v8::Shell::Main(int, char**) + 96 at d8.cc:2662, address = 0x0000000100015150

First v8::base::debug::EnableInProcessStackDumping() is called followed by some windows specific code guarded by macros. Next is all the options are set using v8::Shell::SetOptions

SetOptions will call v8::V8::SetFlagsFromCommandLine which is found in src/api.cc:

i::FlagList::SetFlagsFromCommandLine(argc, argv, remove_flags);

This function can be found in src/flags.cc. The flags themselves are defined in src/flag-definitions.h

Next a new SourceGroup array is create:

options.isolate_sources = new SourceGroup[options.num_isolates];
SourceGroup* current = options.isolate_sources;
current->Begin(argv, 1);
for (int i = 1; i < argc; i++) {
const char* str = argv[i];

(lldb) p str
(const char *) \$6 = 0x00007fff5fbfed4d "manual.js"

There are then checks performed to see if the args is --isolate or --module, or -e and if not (like in our case)

} else if (strncmp(str, "-", 1) != 0) {
// Not a flag, so it must be a script to execute.
options.script_executed = true;

TODO: I'm not exactly sure what SourceGroups are about but just noting this and will revisit later.

This will take us back int Shell::Main in src/d8.cc

::V8::InitializeICUDefaultLocation(argv[0], options.icu_data_file);

(lldb) p argv[0]
(char *) \$8 = 0x00007fff5fbfed48 "./d8"

See ICU a little more details.

Next the default V8 platform is initialized:

g_platform = i::FLAG_verify_predictable ? new PredictablePlatform() : v8::platform::CreateDefaultPlatform();

v8::platform::CreateDefaultPlatform() will be called in our case.

We are then back in Main and have the following lines:

2685 v8::V8::InitializePlatform(g_platform);
2686 v8::V8::Initialize();

This is very similar to what I've seen in the Node.js startup process.

We did not specify any natives_blob or snapshot_blob as an option on the command line so the defaults will be used:

v8::V8::InitializeExternalStartupData(argv[0]);

back in src/d8.cc line 2918:

Isolate* isolate = Isolate::New(create_params);

this call will bring us into api.cc line 8185:

i::Isolate* isolate = new i::Isolate(false);

So, we are invoking the Isolate constructor (in src/isolate.cc).

isolate->set_snapshot_blob(i::Snapshot::DefaultSnapshotBlob());

api.cc:

isolate->Init(NULL);

compilation_cache_ = new CompilationCache(this);
context_slot_cache_ = new ContextSlotCache();
descriptor_lookup_cache_ = new DescriptorLookupCache();
unicode_cache_ = new UnicodeCache();
inner_pointer_to_code_cache_ = new InnerPointerToCodeCache(this);
global_handles_ = new GlobalHandles(this);
eternal_handles_ = new EternalHandles();
bootstrapper_ = new Bootstrapper(this);
handle_scope_implementer_ = new HandleScopeImplementer(this);
load_stub_cache_ = new StubCache(this, Code::LOAD_IC);
store_stub_cache_ = new StubCache(this, Code::STORE_IC);
materialized_object_store_ = new MaterializedObjectStore(this);
regexp_stack_ = new RegExpStack();
regexp_stack_->isolate_ = this;
date_cache_ = new DateCache();
call_descriptor_data_ =
new CallInterfaceDescriptorData[CallDescriptors::NUMBER_OF_DESCRIPTORS];
access_compiler_data_ = new AccessCompilerData();
cpu_profiler_ = new CpuProfiler(this);
heap_profiler_ = new HeapProfiler(heap());
interpreter_ = new interpreter::Interpreter(this);
compiler_dispatcher_ =
new CompilerDispatcher(this, V8::GetCurrentPlatform(), FLAG_stack_size);

src/builtins/builtins.cc, this is where the builtins are defined. TODO: sort out what these macros do.

In src/v8.cc we have a couple of checks for if the options passed are for a stress_run but since we did not pass in any such flags this code path will be followed which will call RunMain:

result = RunMain(isolate, argc, argv, last_run);

this will end up calling:

options.isolate_sources[0].Execute(isolate);

Which will call SourceGroup::Execute(Isolate* isolate)

// Use all other arguments as names of files to load and run.
HandleScope handle_scope(isolate);
Local<String> file_name = String::NewFromUtf8(isolate, arg, NewStringType::kNormal).ToLocalChecked();
Local<String> source = ReadFile(isolate, arg);
if (source.IsEmpty()) {
printf("Error reading '%s'\n", arg);
Shell::Exit(1);
}
Shell::options.script_executed = true;
if (!Shell::ExecuteString(isolate, source, file_name, false, true)) {
exception_was_thrown = true;
break;
}

ScriptOrigin origin(name);
if (compile_options == ScriptCompiler::kNoCompileOptions) {
ScriptCompiler::Source script_source(source, origin);
return ScriptCompiler::Compile(context, &script_source, compile_options);
}

Which will delegate to ScriptCompiler(Local, Source* source, CompileOptions options):

auto maybe = CompileUnboundInternal(isolate, source, options);

CompileUnboundInternal

result = i::Compiler::GetSharedFunctionInfoForScript(
str, name_obj, line_offset, column_offset, source->resource_options,
source_map_url, isolate->native_context(), NULL, &script_data, options,
i::NOT_NATIVES_CODE);

src/compiler.cc

// Compile the function and add it to the cache.
ParseInfo parse_info(script);
Zone compile_zone(isolate->allocator(), ZONE_NAME);
CompilationInfo info(&compile_zone, &parse_info, Handle<JSFunction>::null());

Back in src/compiler.cc-info.cc:

result = CompileToplevel(&info);

(lldb) job *result
0x17df0df309f1: [SharedFunctionInfo]
- name = 0x1a7f12d82471 <String[0]: >
- formal_parameter_count = 0
- expected_nof_properties = 10
- ast_node_count = 23
- instance class name = #Object

- code = 0x1d8484d3661 <Code: BUILTIN>
- source code = function bajja(a, b, c) {
var d = c - 100;
return a + d * b;
}

var result = bajja(2, 2, 150);
print(result);

- anonymous expression
- function token position = -1
- start position = 0
- end position = 114
- no debug info
- length = 0
- optimized_code_map = 0x1a7f12d82241 <FixedArray[0]>
- feedback_metadata = 0x17df0df30d09: [FeedbackMetadata]
- length: 3
- slot_count: 11
Slot #0 LOAD_GLOBAL_NOT_INSIDE_TYPEOF_IC
Slot #2 kCreateClosure
Slot #3 LOAD_GLOBAL_NOT_INSIDE_TYPEOF_IC
Slot #5 CALL_IC
Slot #7 CALL_IC
Slot #9 LOAD_GLOBAL_NOT_INSIDE_TYPEOF_IC

- bytecode_array = 0x17df0df30c61

Back in d8.cc:

maybe_result = script->Run(realm);

src/api.cc

auto fun = i::Handle<i::JSFunction>::cast(Utils::OpenHandle(this));

(lldb) job *fun
0x17df0df30e01: [Function]
- map = 0x19cfe0003859 [FastProperties]
- prototype = 0x17df0df043b1
- elements = 0x1a7f12d82241 <FixedArray[0]> [FAST_HOLEY_ELEMENTS]
- initial_map =
- shared_info = 0x17df0df309f1 <SharedFunctionInfo>
- name = 0x1a7f12d82471 <String[0]: >
- formal_parameter_count = 0
- context = 0x17df0df03bf9 <FixedArray[245]>
- feedback vector cell = 0x17df0df30ed1 Cell for 0x17df0df30e49 <FixedArray[13]>
- code = 0x1d8484d3661 <Code: BUILTIN>
- properties = 0x1a7f12d82241 <FixedArray[0]> {
#length: 0x2c35a5718089 <AccessorInfo> (const accessor descriptor)
#name: 0x2c35a57180f9 <AccessorInfo> (const accessor descriptor)
#arguments: 0x2c35a5718169 <AccessorInfo> (const accessor descriptor)
#caller: 0x2c35a57181d9 <AccessorInfo> (const accessor descriptor)
#prototype: 0x2c35a5718249 <AccessorInfo> (const accessor descriptor)

}

i::Handle<i::Object> receiver = isolate->global_proxy();
Local<Value> result;
has_pending_exception = !ToLocal<Value>(i::Execution::Call(isolate, fun, receiver, 0, nullptr), &result);

src/execution.cc

### Zone

Taken directly from src/zone/zone.h:

// The Zone supports very fast allocation of small chunks of
// memory. The chunks cannot be deallocated individually, but instead
// the Zone supports deallocating all chunks in one fast
// operation. The Zone is used to hold temporary data structures like
// the abstract syntax tree, which is deallocated after compilation.

\$ ./d8 --help

### d8

(lldb) br s -f d8.cc -l 2935

return v8::Shell::Main(argc, argv);

api.cc:6112
i::ReadNatives();
natives-external.cc

### v8::String::NewFromOneByte

So I was a little confused when I first read this function name and thought it had something to do with the length of the string. But the byte is the type of the chars that make up the string. For example, a one byte char would be reinterpreted as uint8_t:

const char* data

reinterpret_cast<const uint8_t*>(data)

#### Tasks

• gdbinit has been updated. Check if there is something that should be ported to lldbinit

### Invocation walkthrough

This section will go through calling a Script to understand what happens in V8.

I'll be using run-scripts.cc as the example for this.

\$ lldb -- ./run-scripts
(lldb) br s -n main

I'll step through until the following call:

script->Run(context).ToLocalChecked();

So, Script::Run is defined in api.cc First things that happens in this function is a macro:

PREPARE_FOR_EXECUTION_WITH_CONTEXT_IN_RUNTIME_CALL_STATS_SCOPE(
"v8",
"V8.Execute",
context,
Script,
Run,
MaybeLocal<Value>(),
InternalEscapableScope,
true);
TRACE_EVENT_CALL_STATS_SCOPED(isolate, category, name);
PREPARE_FOR_EXECUTION_GENERIC(isolate, context, class_name, function_name, \
bailout_value, HandleScopeClass, do_callback);

So, what does the preprocessor replace this with then:

auto isolate = context.IsEmpty() ? i::Isolate::Current()                               : reinterpret_cast<i::Isolate*>(context->GetIsolate());

I'm skipping TRACE_EVENT_CALL_STATS_SCOPED for now. PREPARE_FOR_EXECUTION_GENERIC will be replaced with:

if (IsExecutionTerminatingCheck(isolate)) {                        \
return bailout_value;                                            \
}                                                                  \
HandleScopeClass handle_scope(isolate);                            \
CallDepthScope<do_callback> call_depth_scope(isolate, context);    \
LOG_API(isolate, class_name, function_name);                       \
ENTER_V8_DO_NOT_USE(isolate);                                      \
bool has_pending_exception = false

auto fun = i::Handle<i::JSFunction>::cast(Utils::OpenHandle(this));

(lldb) job *fun
0x33826912c021: [Function]
- map = 0x1d0656c03599 [FastProperties]
- prototype = 0x338269102e69
- elements = 0x35190d902241 <FixedArray[0]> [FAST_HOLEY_ELEMENTS]
- initial_map =
- shared_info = 0x33826912bc11 <SharedFunctionInfo>
- name = 0x35190d902471 <String[0]: >
- formal_parameter_count = 0
- context = 0x338269102611 <FixedArray[265]>
- feedback vector cell = 0x33826912c139 <Cell value= 0x33826912c069 <FixedArray[24]>>
- code = 0x1319e25fcf21 <Code BUILTIN>
- properties = 0x35190d902241 <FixedArray[0]> {
#length: 0x2e9d97ce68b1 <AccessorInfo> (const accessor descriptor)
#name: 0x2e9d97ce6921 <AccessorInfo> (const accessor descriptor)
#arguments: 0x2e9d97ce6991 <AccessorInfo> (const accessor descriptor)
#caller: 0x2e9d97ce6a01 <AccessorInfo> (const accessor descriptor)
#prototype: 0x2e9d97ce6a71 <AccessorInfo> (const accessor descriptor)
}

The code for i::JSFunction is generated in src/api.h. Lets take a closer look at this.

#define DECLARE_OPEN_HANDLE(From, To) \
static inline v8::internal::Handle<v8::internal::To> \
OpenHandle(const From* that, bool allow_empty_handle = false);

OPEN_HANDLE_LIST(DECLARE_OPEN_HANDLE)

OPEN_HANDLE_LIST looks like this:

#define OPEN_HANDLE_LIST(V)                    \
....
V(Script, JSFunction)                        \

So lets expand this for JSFunction and it should become:

static inline v8::internal::Handle<v8::internal::JSFunction> \
OpenHandle(const Script* that, bool allow_empty_handle = false);

So there will be an function named OpenHandle that will take a const pointer to Script.

A little further down in src/api.h there is another macro which looks like this:

OPEN_HANDLE_LIST(MAKE_OPEN_HANDLE)

MAKE_OPEN_HANDLE:

#define MAKE_OPEN_HANDLE(From, To)
v8::internal::Handle<v8::internal::To> Utils::OpenHandle(
const v8::From* that, bool allow_empty_handle) {
return v8::internal::Handle<v8::internal::To>(
reinterpret_cast<v8::internal::Address*>(const_cast<v8::From*>(that)));
}

And remember that JSFunction is included in the OPEN_HANDLE_LIST so there will be the following in the source after the preprocessor has processed this header: A concrete example would look like this:

v8::internal::Handle<v8::internal::JSFunction> Utils::OpenHandle(
const v8::Script* that, bool allow_empty_handle) {
return v8::internal::Handle<v8::internal::JSFunction>(
reinterpret_cast<v8::internal::Address*>(const_cast<v8::Script*>(that))); }

You can inspect the output of the preprocessor using:

\$ clang++ -I./out/x64.release/gen -I. -I./include -E src/api/api-inl.h > api-inl.output

So where is JSFunction declared? It is defined in objects.h

## Ignition interpreter

User JavaScript also needs to have bytecode generated for them and they also use the C++ DLS and use the CodeStubAssembler -> CodeAssembler -> RawMachineAssembler just like builtins.

## C++ Domain Specific Language (DLS)

#### Build failure

After rebasing I've seen the following issue:

\$ ninja -C out/Debug chrome
ninja: Entering directory `out/Debug'
ninja: error: '../../chrome/renderer/resources/plugins/plugin_delay.html', needed by 'gen/chrome/grit/renderer_resources.h', missing and no known rule to make it

The "solution" was to remove the out directory and rebuild.

### Tasks

To find suitable task you can use label:HelpWanted at bugs.chromium.org.

### OpenHandle

What does this call do:

Utils::OpenHandle(*(source->source_string));

OPEN_HANDLE_LIST(MAKE_OPEN_HANDLE)

Which is a macro defined in src/api.h:

#define MAKE_OPEN_HANDLE(From, To)                                             \
v8::internal::Handle<v8::internal::To> Utils::OpenHandle(                    \
const v8::From* that, bool allow_empty_handle) {                         \
DCHECK(allow_empty_handle || that != NULL);                                \
DCHECK(that == NULL ||                                                     \
(*reinterpret_cast<v8::internal::Object* const*>(that))->Is##To()); \
return v8::internal::Handle<v8::internal::To>(                             \
reinterpret_cast<v8::internal::To**>(const_cast<v8::From*>(that)));    \
}

OPEN_HANDLE_LIST(MAKE_OPEN_HANDLE)

If we take a closer look at the macro is should expand to something like this in our case:

v8::internal::Handle<v8::internal::To> Utils::OpenHandle(const v8:String* that, false) {
DCHECK(allow_empty_handle || that != NULL);                                \
DCHECK(that == NULL ||                                                     \
(*reinterpret_cast<v8::internal::Object* const*>(that))->IsString()); \
return v8::internal::Handle<v8::internal::String>(                             \
reinterpret_cast<v8::internal::String**>(const_cast<v8::String*>(that)));    \
}

So this is returning a new v8::internal::Handle, the constructor is defined in src/handles.h:95.

src/objects.cc Handle WeakFixedArray::Add(Handle maybe_array, 10167 Handle value, 10168 int* assigned_index) { Notice the name of the first parameter maybe_array but it is not of type maybe?

### Context

JavaScript provides a set of builtin functions and objects. These functions and objects can be changed by user code. Each context is separate collection of these objects and functions.

And internal::Context is declared in deps/v8/src/contexts.h and extends FixedArray

class Context: public FixedArray {

A Context can be create by calling:

const v8::HandleScope handle_scope(isolate_);
Handle<Context> context = Context::New(isolate_,
nullptr,
v8::Local<v8::ObjectTemplate>());

Context::New can be found in src/api.cc:6405:

Local<Context> v8::Context::New(
v8::Isolate* external_isolate, v8::ExtensionConfiguration* extensions,
v8::MaybeLocal<ObjectTemplate> global_template,
v8::MaybeLocal<Value> global_object,
DeserializeInternalFieldsCallback internal_fields_deserializer) {
return NewContext(external_isolate, extensions, global_template,
global_object, 0, internal_fields_deserializer);
}

The declaration of this function can be found in include/v8.h:

static Local<Context> New(
Isolate* isolate, ExtensionConfiguration* extensions = NULL,
MaybeLocal<ObjectTemplate> global_template = MaybeLocal<ObjectTemplate>(),
MaybeLocal<Value> global_object = MaybeLocal<Value>(),
DeserializeInternalFieldsCallback internal_fields_deserializer =
DeserializeInternalFieldsCallback());

So we can see the reason why we did not have to specify internal_fields_deserialize. What is ExtensionConfiguration?
This class can be found in include/v8.h and only has two members, a count of the extension names and an array with the names.

If specified these will be installed by Boostrapper::InstallExtensions which will delegate to Genesis::InstallExtensions, both can be found in src/boostrapper.cc. Where are extensions registered?
This is done once per process and called from V8::Initialize():

void Bootstrapper::InitializeOncePerProcess() {
free_buffer_extension_ = new FreeBufferExtension;
v8::RegisterExtension(free_buffer_extension_);
gc_extension_ = new GCExtension(GCFunctionName());
v8::RegisterExtension(gc_extension_);
externalize_string_extension_ = new ExternalizeStringExtension;
v8::RegisterExtension(externalize_string_extension_);
statistics_extension_ = new StatisticsExtension;
v8::RegisterExtension(statistics_extension_);
trigger_failure_extension_ = new TriggerFailureExtension;
v8::RegisterExtension(trigger_failure_extension_);
ignition_statistics_extension_ = new IgnitionStatisticsExtension;
v8::RegisterExtension(ignition_statistics_extension_);
}

The extensions can be found in src/extensions. You register your own extensions and an example of this can be found in test/context_test.cc.

(lldb) br s -f node.cc -l 4439
(lldb) expr context->length()
(int) \$522 = 281

This output was taken

Creating a new Context is done by v8::CreateEnvironment

(lldb) br s -f api.cc -l 6565
InvokeBootstrapper<ObjectType> invoke;
6635    result =
-> 6636        invoke.Invoke(isolate, maybe_proxy, proxy_template, extensions,
6637                      context_snapshot_index, embedder_fields_deserializer);

This will later end up in Snapshot::NewContextFromSnapshot:

Vector<const byte> context_data =
ExtractContextData(blob, static_cast<uint32_t>(context_index));
SnapshotData snapshot_data(context_data);

MaybeHandle<Context> maybe_result = PartialDeserializer::DeserializeContext(
isolate, &snapshot_data, can_rehash, global_proxy,
embedder_fields_deserializer);

So we can see here that the Context is deserialized from the snapshot. What does the Context contain at this stage:

(lldb) expr result->length()
(int) \$650 = 281
(lldb) expr result->Print()
// not inlcuding the complete output

Lets take a look at an entry:

(lldb) expr result->get(0)->Print()
0xc201584331: [Function] in OldSpace
- map = 0xc24c002251 [FastProperties]
- prototype = 0xc201584371
- elements = 0xc2b2882251 <FixedArray[0]> [HOLEY_ELEMENTS]
- initial_map =
- shared_info = 0xc2b2887521 <SharedFunctionInfo>
- name = 0xc2b2882441 <String[0]: >
- formal_parameter_count = -1
- kind = [ NormalFunction ]
- context = 0xc201583a59 <FixedArray[281]>
- code = 0x2df1f9865a61 <Code BUILTIN>
- source code = () {}
- properties = 0xc2b2882251 <FixedArray[0]> {
#length: 0xc2cca83729 <AccessorInfo> (const accessor descriptor)
#name: 0xc2cca83799 <AccessorInfo> (const accessor descriptor)
#arguments: 0xc201587fd1 <AccessorPair> (const accessor descriptor)
#caller: 0xc201587fd1 <AccessorPair> (const accessor descriptor)
#constructor: 0xc201584c29 <JSFunction Function (sfi = 0xc2b28a6fb1)> (const data descriptor)
#apply: 0xc201588079 <JSFunction apply (sfi = 0xc2b28a7051)> (const data descriptor)
#bind: 0xc2015880b9 <JSFunction bind (sfi = 0xc2b28a70f1)> (const data descriptor)
#call: 0xc2015880f9 <JSFunction call (sfi = 0xc2b28a7191)> (const data descriptor)
#toString: 0xc201588139 <JSFunction toString (sfi = 0xc2b28a7231)> (const data descriptor)
0xc2b28bc669 <Symbol: Symbol.hasInstance>: 0xc201588179 <JSFunction [Symbol.hasInstance] (sfi = 0xc2b28a72d1)> (const data descriptor)
}

- feedback vector: not available

So we can see that this is of type [Function] which we can cast using:

(lldb) expr JSFunction::cast(result->get(0))->code()->Print()
0x2df1f9865a61: [Code]
kind = BUILTIN
name = EmptyFunction
(lldb) expr JSFunction::cast(result->closure())->Print()
0xc201584331: [Function] in OldSpace
- map = 0xc24c002251 [FastProperties]
- prototype = 0xc201584371
- elements = 0xc2b2882251 <FixedArray[0]> [HOLEY_ELEMENTS]
- initial_map =
- shared_info = 0xc2b2887521 <SharedFunctionInfo>
- name = 0xc2b2882441 <String[0]: >
- formal_parameter_count = -1
- kind = [ NormalFunction ]
- context = 0xc201583a59 <FixedArray[281]>
- code = 0x2df1f9865a61 <Code BUILTIN>
- source code = () {}
- properties = 0xc2b2882251 <FixedArray[0]> {
#length: 0xc2cca83729 <AccessorInfo> (const accessor descriptor)
#name: 0xc2cca83799 <AccessorInfo> (const accessor descriptor)
#arguments: 0xc201587fd1 <AccessorPair> (const accessor descriptor)
#caller: 0xc201587fd1 <AccessorPair> (const accessor descriptor)
#constructor: 0xc201584c29 <JSFunction Function (sfi = 0xc2b28a6fb1)> (const data descriptor)
#apply: 0xc201588079 <JSFunction apply (sfi = 0xc2b28a7051)> (const data descriptor)
#bind: 0xc2015880b9 <JSFunction bind (sfi = 0xc2b28a70f1)> (const data descriptor)
#call: 0xc2015880f9 <JSFunction call (sfi = 0xc2b28a7191)> (const data descriptor)
#toString: 0xc201588139 <JSFunction toString (sfi = 0xc2b28a7231)> (const data descriptor)
0xc2b28bc669 <Symbol: Symbol.hasInstance>: 0xc201588179 <JSFunction [Symbol.hasInstance] (sfi = 0xc2b28a72d1)> (const data descriptor)
}

- feedback vector: not available

So this is the JSFunction associated with the deserialized context. Not sure what this is about as looking at the source code it looks like an empty function. A function can also be set on the context so I'm guessing that this give access to the function of a context once set. Where is function set, well it is probably deserialized but we can see it be used in deps/v8/src/bootstrapper.cc:

{
Handle<JSFunction> function = SimpleCreateFunction(isolate, factory->empty_string(), Builtins::kAsyncFunctionAwaitCaught, 2, false);
native_context->set_async_function_await_caught(*function);
}
​```console
(lldb) expr isolate()->builtins()->builtin_handle(Builtins::Name::kAsyncFunctionAwaitCaught)->Print()

Context::Scope is a RAII class used to Enter/Exit a context. Lets take a closer look at Enter:

void Context::Enter() {
i::Handle<i::Context> env = Utils::OpenHandle(this);
i::Isolate* isolate = env->GetIsolate();
ENTER_V8_NO_SCRIPT_NO_EXCEPTION(isolate);
i::HandleScopeImplementer* impl = isolate->handle_scope_implementer();
impl->EnterContext(env);
impl->SaveContext(isolate->context());
isolate->set_context(*env);
}

So the current context is saved and then the this context env is set as the current on the isolate. EnterContext will push the passed-in context (deps/v8/src/api.cc):

void HandleScopeImplementer::EnterContext(Handle<Context> context) {
entered_contexts_.push_back(*context);
}
...
DetachableVector<Context*> entered_contexts_;
DetachableVector is a delegate/adaptor with some additonaly features on a std::vector.
Handle<Context> context1 = NewContext(isolate);
Handle<Context> context2 = NewContext(isolate);
Context::Scope context_scope1(context1);        // entered_contexts_ [context1], saved_contexts_[isolateContext]
Context::Scope context_scope2(context2);        // entered_contexts_ [context1, context2], saved_contexts[isolateContext, context1]

Now, SaveContext is using the current context, not this context (env) and pushing that to the end of the saved_contexts_ vector. We can look at this as we entered context_scope2 from context_scope1:

And Exit looks like:

void Context::Exit() {
i::Handle<i::Context> env = Utils::OpenHandle(this);
i::Isolate* isolate = env->GetIsolate();
ENTER_V8_NO_SCRIPT_NO_EXCEPTION(isolate);
i::HandleScopeImplementer* impl = isolate->handle_scope_implementer();
if (!Utils::ApiCheck(impl->LastEnteredContextWas(env),
"v8::Context::Exit()",
"Cannot exit non-entered context")) {
return;
}
impl->LeaveContext();
isolate->set_context(impl->RestoreContext());
}

#### EmbedderData

A context can have embedder data set on it. Like decsribed above a Context is internally A FixedArray. SetEmbedderData in Context is implemented in src/api.cc:

const char* location = "v8::Context::SetEmbedderData()";
i::Handle<i::FixedArray> data = EmbedderDataFor(this, index, true, location);
i::Handle<i::FixedArray> data(env->embedder_data());

location is only used for logging and we can ignore it for now. EmbedderDataFor:

i::Handle<i::Context> env = Utils::OpenHandle(context);
...
i::Handle<i::FixedArray> data(env->embedder_data());

We can find embedder_data in src/contexts-inl.h

#define NATIVE_CONTEXT_FIELD_ACCESSORS(index, type, name) \
inline void set_##name(type* value);                    \
inline bool is_##name(type* value) const;               \
inline type* name() const;
NATIVE_CONTEXT_FIELDS(NATIVE_CONTEXT_FIELD_ACCESSORS)

And NATIVE_CONTEXT_FIELDS in context.h:

#define NATIVE_CONTEXT_FIELDS(V)                                               \
V(GLOBAL_PROXY_INDEX, JSObject, global_proxy_object)                         \
V(EMBEDDER_DATA_INDEX, FixedArray, embedder_data)                            \
...

#define NATIVE_CONTEXT_FIELD_ACCESSORS(index, type, name) \
void Context::set_##name(type* value) {                 \
DCHECK(IsNativeContext());                            \
set(index, value);                                    \
}                                                       \
bool Context::is_##name(type* value) const {            \
DCHECK(IsNativeContext());                            \
return type::cast(get(index)) == value;               \
}                                                       \
type* Context::name() const {                           \
DCHECK(IsNativeContext());                            \
return type::cast(get(index));                        \
}
NATIVE_CONTEXT_FIELDS(NATIVE_CONTEXT_FIELD_ACCESSORS)
#undef NATIVE_CONTEXT_FIELD_ACCESSORS

So the preprocessor would expand this to:

FixedArray embedder_data() const;

void Context::set_embedder_data(FixedArray value) {
DCHECK(IsNativeContext());
set(EMBEDDER_DATA_INDEX, value);
}

bool Context::is_embedder_data(FixedArray value) const {
DCHECK(IsNativeContext());
return FixedArray::cast(get(EMBEDDER_DATA_INDEX)) == value;
}

FixedArray Context::embedder_data() const {
DCHECK(IsNativeContext());
return FixedArray::cast(get(EMBEDDER_DATA_INDEX));
}

We can take a look at the initial data:

lldb) expr data->Print()
0x2fac3e896439: [FixedArray] in OldSpace
- map = 0x2fac9de82341 <Map(HOLEY_ELEMENTS)>
- length: 3
0-2: 0x2fac1cb822e1 <undefined>
(lldb) expr data->length()
(int) \$5 = 3

And after setting:

(lldb) expr data->Print()
0x2fac3e896439: [FixedArray] in OldSpace
- map = 0x2fac9de82341 <Map(HOLEY_ELEMENTS)>
- length: 3
0: 0x2fac20c866e1 <String[7]: embdata>
1-2: 0x2fac1cb822e1 <undefined>

(lldb) expr v8::internal::String::cast(data->get(0))->Print()
"embdata"

This was taken while debugging ContextTest::EmbedderData.

### ENTER_V8_FOR_NEW_CONTEXT

This macro is used in CreateEnvironment (src/api.cc) and the call in this function looks like this:

ENTER_V8_FOR_NEW_CONTEXT(isolate);

### Factory::NewMap

This section will take a look at the following call:

i::Handle<i::Map> map = factory->NewMap(i::JS_OBJECT_TYPE, 24);

Lets take a closer look at this function which can be found in src/factory.cc:

Handle<Map> Factory::NewMap(InstanceType type, int instance_size,
ElementsKind elements_kind,
int inobject_properties) {
CALL_HEAP_FUNCTION(
isolate(),
isolate()->heap()->AllocateMap(type, instance_size, elements_kind,
inobject_properties),
Map);
}

If we take a look at factory.h we can see the default values for elements_kind and inobject_properties:

Handle<Map> NewMap(InstanceType type, int instance_size,
ElementsKind elements_kind = TERMINAL_FAST_ELEMENTS_KIND,
int inobject_properties = 0);

If we expand the CALL_HEAP_FUNCTION macro we will get:

AllocationResult __allocation__ = isolate()->heap()->AllocateMap(type,
instance_size,
elements_kind,
inobject_properties),
Object* __object__ = nullptr;
RETURN_OBJECT_UNLESS_RETRY(isolate(), Map)
/* Two GCs before panicking.  In newspace will almost always succeed. */
for (int __i__ = 0; __i__ < 2; __i__++) {
(isolate())->heap()->CollectGarbage(
__allocation__.RetrySpace(),
GarbageCollectionReason::kAllocationFailure);
__allocation__ = FUNCTION_CALL;
RETURN_OBJECT_UNLESS_RETRY(isolate, Map)
}
(isolate())->counters()->gc_last_resort_from_handles()->Increment();
(isolate())->heap()->CollectAllAvailableGarbage(
GarbageCollectionReason::kLastResort);
{
AlwaysAllocateScope __scope__(isolate());
t __allocation__ = isolate()->heap()->AllocateMap(type,
instance_size,
elements_kind,
inobject_properties),
}
RETURN_OBJECT_UNLESS_RETRY(isolate, Map)
/* TODO(1181417): Fix this. */
v8::internal::Heap::FatalProcessOutOfMemory("CALL_AND_RETRY_LAST", true);
return Handle<Map>();

So, lets take a look at isolate()->heap()->AllocateMap in 'src/heap/heap.cc':

HeapObject* result = nullptr;
AllocationResult allocation = AllocateRaw(Map::kSize, MAP_SPACE);

AllocateRaw can be found in src/heap/heap-inl.h:

bool large_object = size_in_bytes > kMaxRegularHeapObjectSize;
HeapObject* object = nullptr;
AllocationResult allocation;
if (NEW_SPACE == space) {
if (large_object) {
space = LO_SPACE;
} else {
allocation = new_space_->AllocateRaw(size_in_bytes, alignment);
if (allocation.To(&object)) {
OnAllocationEvent(object, size_in_bytes);
}
return allocation;
}
}
} else if (MAP_SPACE == space) {
allocation = map_space_->AllocateRawUnaligned(size_in_bytes);
}
(lldb) expr large_object
(bool) \$3 = false
(lldb) expr size_in_bytes
(int) \$5 = 80
(lldb) expr map_space_
(v8::internal::MapSpace *) \$6 = 0x0000000104700f60

AllocateRawUnaligned can be found in src/heap/spaces-inl.h

HeapObject* object = AllocateLinearly(size_in_bytes);

### v8::internal::Object

Is an abstract super class for all classes in the object hierarch and both Smi and HeapObject are subclasses of Object so there are no data members in object only functions. For example:

bool IsObject() const { return true; }
INLINE(bool IsSmi() const
INLINE(bool IsLayoutDescriptor() const
INLINE(bool IsHeapObject() const
INLINE(bool IsPrimitive() const
INLINE(bool IsNumber() const
INLINE(bool IsNumeric() const
INLINE(bool IsAbstractCode() const
INLINE(bool IsAccessCheckNeeded() const
INLINE(bool IsArrayList() const
INLINE(bool IsBigInt() const
INLINE(bool IsUndefined() const
INLINE(bool IsNull() const
INLINE(bool IsTheHole() const
INLINE(bool IsException() const
INLINE(bool IsUninitialized() const
INLINE(bool IsTrue() const
INLINE(bool IsFalse() const
...

### v8::internal::Smi

Extends v8::internal::Object and are not allocated on the heap. There are no members as the pointer itself is used to store the information.

In our case the calling v8::Isolate::New which is done by the test fixture:

virtual void SetUp() {
isolate_ = v8::Isolate::New(create_params_);
}

This will call:

Isolate* Isolate::New(const Isolate::CreateParams& params) {
Isolate* isolate = Allocate();
Initialize(isolate, params);
return isolate;
}

In Isolate::Initialize we'll call i::Snapshot::Initialize(i_isolate):

if (params.entry_hook || !i::Snapshot::Initialize(i_isolate)) {
...

Which will call:

bool success = isolate->Init(&deserializer);

Before this call all the roots are uninitialized. Reading this blog it says that the Isolate class contains a roots table. It looks to me that the Heap contains this data structure but perhaps that is what they meant.

(lldb) bt 3
* thread #1, queue = 'com.apple.main-thread', stop reason = step over
* frame #0: 0x0000000101584f43 libv8.dylib`v8::internal::StartupDeserializer::DeserializeInto(this=0x00007ffeefbfe200, isolate=0x000000010481cc00) at startup-deserializer.cc:39
frame #1: 0x0000000101028bb6 libv8.dylib`v8::internal::Isolate::Init(this=0x000000010481cc00, des=0x00007ffeefbfe200) at isolate.cc:3036
frame #2: 0x000000010157c682 libv8.dylib`v8::internal::Snapshot::Initialize(isolate=0x000000010481cc00) at snapshot-common.cc:54

In startup-deserializer.cc we can find StartupDeserializer::DeserializeInto:

DisallowHeapAllocation no_gc;
isolate->heap()->IterateSmiRoots(this);
isolate->heap()->IterateStrongRoots(this, VISIT_ONLY_STRONG);

After If we take a look in src/roots.h we can find the read-only roots in Heap. If we take the 10 value, which is:

V(String, empty_string, empty_string)                                        \

we can then inspect this value:

(lldb) expr roots_[9]
(v8::internal::Object *) \$32 = 0x0000152d30b82851
(lldb) expr roots_[9]->IsString()
(bool) \$30 = true
(lldb) expr roots_[9]->Print()
#

So this entry is a pointer to objects on the managed heap which have been deserialized from the snapshot.

The heap class has a lot of members that are initialized during construction by the body of the constructor looks like this:

{
// Ensure old_generation_size_ is a multiple of kPageSize.
DCHECK_EQ(0, max_old_generation_size_ & (Page::kPageSize - 1));

memset(roots_, 0, sizeof(roots_[0]) * kRootListLength);
set_native_contexts_list(nullptr);
set_allocation_sites_list(Smi::kZero);
set_encountered_weak_collections(Smi::kZero);
// Put a dummy entry in the remembered pages so we can find the list the
// minidump even if there are no real unmapped pages.
RememberUnmappedPage(nullptr, false);
}

We can see that roots_ is filled with 0 values. We can inspect roots_ using:

(lldb) expr roots_
(lldb) expr RootListIndex::kRootListLength
(int) \$16 = 509

Now they are all 0 at this stage, so when will this array get populated?
These will happen in Isolate::Init:

heap_.SetUp()
if (!create_heap_objects) des->DeserializeInto(this);

void StartupDeserializer::DeserializeInto(Isolate* isolate) {
-> 17    Initialize(isolate);
startup-deserializer.cc:37

isolate->heap()->IterateSmiRoots(this);

This will delegate to ConfigureHeapDefaults() which will call Heap::ConfigureHeap:

enum RootListIndex {
kFreeSpaceMapRootIndex,
kOnePointerFillerMapRootIndex,
...
}
(lldb) expr heap->RootListIndex::kFreeSpaceMapRootIndex
(int) \$3 = 0
(lldb) expr heap->RootListIndex::kOnePointerFillerMapRootIndex
(int) \$4 = 1

### MemoryChunk

Found in src/heap/spaces.h an instace of a MemoryChunk represents a region in memory that is owned by a specific space.

### Embedded builtins

In the blog post explains how the builtins are embedded into the executable in to the .TEXT section which is readonly and therefore can be shared amoung multiple processes. We know that builtins are compiled and stored in the snapshot but now it seems that the are instead placed in to out.gn/learning/gen/embedded.cc and the combined with the object files from the compile to produce the libv8.dylib. V8 has a configuration option named v8_enable_embedded_builtins which which case embedded.cc will be added to the list of sources. This is done in BUILD.gn and the v8_snapshot target. If v8_enable_embedded_builtins is false then src/snapshot/embedded-empty.cc will be included instead. Both of these files have the following functions:

const uint8_t* DefaultEmbeddedBlob()
uint32_t DefaultEmbeddedBlobSize()

#ifdef V8_MULTI_SNAPSHOTS
const uint8_t* TrustedEmbeddedBlob()
uint32_t TrustedEmbeddedBlobSize()
#endif

These functions are used by isolate.cc and declared extern:

extern const uint8_t* DefaultEmbeddedBlob();
extern uint32_t DefaultEmbeddedBlobSize();

And the usage of DefaultEmbeddedBlob can be see in Isolate::Isolate where is sets the embedded blob:

SetEmbeddedBlob(DefaultEmbeddedBlob(), DefaultEmbeddedBlobSize());

Lets set a break point there and see if this is empty of not.

(lldb) expr v8_embedded_blob_size_
(uint32_t) \$0 = 4021088

So we can see that we are not using the empty one. Isolate::SetEmbeddedBlob

We can see in src/snapshot/deserializer.cc (line 552) we have a check for the embedded_blob():

CHECK_NOT_NULL(isolate->embedded_blob());
EmbeddedData d = EmbeddedData::FromBlob();
Address address = d.InstructionStartOfBuiltin(builtin_index);

EmbeddedData can be found in src/snapshot/snapshot.h` and the implementation can be found in snapshot-common.cc.

Address EmbeddedData::InstructionStartOfBuiltin(int i) const {
const struct Metadata* metadata = Metadata();
const uint8_t* result = RawData() + metadata[i].instructions_offset;
return reinterpret_cast<Address>(result);
}
(lldb) expr *metadata
(const v8::internal::EmbeddedData::Metadata) \$7 = (instructions_offset = 0, instructions_length = 1464)
struct Metadata {
// Blob layout information.
uint32_t instructions_offset;
uint32_t instructions_length;
};
(lldb) expr *this
(v8::internal::EmbeddedData) \$10 = (data_ = "\xffffffdc\xffffffc0\xffffff88'"y[\xffffffd6", size_ = 4021088)
(lldb) expr metadata[i]
(const v8::internal::EmbeddedData::Metadata) \$8 = (instructions_offset = 0, instructions_length = 1464)

So, is it possible for us to verify that this information is in the .text section?

(lldb) expr result
(const uint8_t *) \$13 = 0x0000000101b14ee0 "UH\x89�jH\x83�(H\x89U�H�\x16H\x89}�H�u�H�E�H\x89U�H\x83�
(lldb) image lookup --address 0x0000000101b14ee0 --verbose
Address: libv8.dylib[0x00000000019cdee0] (libv8.dylib.__TEXT.__text + 27054464)
Summary: libv8.dylib`v8_Default_embedded_blob_ + 7072
Module: file = "/Users/danielbevenius/work/google/javascript/v8/out.gn/learning/libv8.dylib", arch = "x86_64"
Symbol: id = {0x0004b596}, range = [0x0000000101b13340-0x0000000101ee8ea0), name="v8_Default_embedded_blob_"

So what we have is a pointer to the .text segment which is returned:

(lldb) memory read -f x -s 1 -c 13 0x0000000101b14ee0
0x101b14ee0: 0x55 0x48 0x89 0xe5 0x6a 0x18 0x48 0x83
0x101b14ee8: 0xec 0x28 0x48 0x89 0x55

And we can compare this with out.gn/learning/gen/embedded.cc:

V8_EMBEDDED_TEXT_HEADER(v8_Default_embedded_blob_)
__asm__(
...
".byte 0x55,0x48,0x89,0xe5,0x6a,0x18,0x48,0x83,0xec,0x28,0x48,0x89,0x55\n"
...
);

The macro V8_EMBEDDED_TEXT_HEADER can be found src/snapshot/macros.h:

#define V8_EMBEDDED_TEXT_HEADER(LABEL)         \
__asm__(V8_ASM_DECLARE(#LABEL)               \
".csect " #LABEL "[DS]\n"            \
#LABEL ":\n"                         \
".llong ." #LABEL ", TOC[tc0], 0\n"  \
V8_ASM_TEXT_SECTION                  \
"." #LABEL ":\n");

define V8_ASM_DECLARE(NAME) ".private_extern " V8_ASM_MANGLE_LABEL NAME "\n"
#define V8_ASM_MANGLE_LABEL "_"
#define V8_ASM_TEXT_SECTION ".csect .text[PR]\n"

And would be expanded by the preprocessor into:

__asm__(".private_extern " _ v8_Default_embedded_blob_ "\n"
".csect " v8_Default_embedded_blob_ "[DS]\n"
v8_Default_embedded_blob_ ":\n"
".llong ." v8_Default_embedded_blob_ ", TOC[tc0], 0\n"
".csect .text[PR]\n"
"." v8_Default_embedded_blob_ ":\n");
__asm__(
...
".byte 0x55,0x48,0x89,0xe5,0x6a,0x18,0x48,0x83,0xec,0x28,0x48,0x89,0x55\n"
...
);

Back in src/snapshot/deserialzer.cc we are on this line:

Address address = d.InstructionStartOfBuiltin(builtin_index);
CHECK_NE(kNullAddress, address);
if (RelocInfo::OffHeapTargetIsCodedSpecially()) {
// is false in our case so skipping the code here
} else {
MaybeObject* o = reinterpret_cast<MaybeObject*>(address);
UnalignedCopy(current, &o);
current++;
}
break;

### print-code

\$ ./d8 -print-bytecode  -print-code sample.js
[generated bytecode for function:  (0x2a180824ffbd <SharedFunctionInfo>)]
Parameter count 1
Register count 5
Frame size 40
0x2a1808250066 @    0 : 12 00             LdaConstant [0]
0x2a1808250068 @    2 : 26 f9             Star r2
0x2a180825006a @    4 : 27 fe f8          Mov <closure>, r3
0x2a180825006d @    7 : 61 32 01 f9 02    CallRuntime [DeclareGlobals], r2-r3
0x2a1808250072 @   12 : 0b                LdaZero
0x2a1808250073 @   13 : 26 fa             Star r1
0x2a1808250075 @   15 : 0d                LdaUndefined
0x2a1808250076 @   16 : 26 fb             Star r0
0x2a1808250078 @   18 : 00 0c 10 27       LdaSmi.Wide [10000]
0x2a180825007c @   22 : 69 fa 00          TestLessThan r1, [0]
0x2a180825007f @   25 : 9a 1c             JumpIfFalse [28] (0x2a180825009b @ 53)
0x2a1808250081 @   27 : a7                StackCheck
0x2a1808250082 @   28 : 13 01 01          LdaGlobal [1], [1]
0x2a1808250085 @   31 : 26 f9             Star r2
0x2a1808250087 @   33 : 0c 02             LdaSmi [2]
0x2a1808250089 @   35 : 26 f7             Star r4
0x2a180825008b @   37 : 5e f9 fa f7 03    CallUndefinedReceiver2 r2, r1, r4, [3]
0x2a1808250090 @   42 : 26 fb             Star r0
0x2a1808250092 @   44 : 25 fa             Ldar r1
0x2a1808250094 @   46 : 4c 05             Inc [5]
0x2a1808250096 @   48 : 26 fa             Star r1
0x2a1808250098 @   50 : 8a 20 00          JumpLoop [32], [0] (0x2a1808250078 @ 18)
0x2a180825009b @   53 : 25 fb             Ldar r0
0x2a180825009d @   55 : ab                Return
Constant pool (size = 2)
0x2a1808250035: [FixedArray] in OldSpace
- map: 0x2a18080404b1 <Map>
- length: 2
0: 0x2a180824ffe5 <FixedArray[2]>
1: 0x2a180824ff61 <String[#9]: something>
Handler Table (size = 0)
Source Position Table (size = 0)
[generated bytecode for function: something (0x2a180824fff5 <SharedFunctionInfo something>)]
Parameter count 3
Register count 0
Frame size 0
0x2a18082501ba @    0 : 25 02             Ldar a1
0x2a18082501bc @    2 : 34 03 00          Add a0, [0]
0x2a18082501bf @    5 : ab                Return
Constant pool (size = 0)
Handler Table (size = 0)
Source Position Table (size = 0)
--- Raw source ---
function something(x, y) {
return x + y
}
for (let i = 0; i < 10000; i++) {
something(i, 2);
}

--- Optimized code ---
optimization_id = 0
source_position = 0
kind = OPTIMIZED_FUNCTION
stack_slots = 14
compiler = turbofan
address = 0x108400082ae1

Instructions (size = 536)
0x108400082b20     0  488d1df9ffffff REX.W leaq rbx,[rip+0xfffffff9]
0x108400082b27     7  483bd9         REX.W cmpq rbx,rcx
0x108400082b2a     a  7418           jz 0x108400082b44  <+0x24>
0x108400082b2c     c  48ba6800000000000000 REX.W movq rdx,0x68
0x108400082b36    16  49bae0938c724b560000 REX.W movq r10,0x564b728c93e0  (Abort)    ;; off heap target
0x108400082b40    20  41ffd2         call r10
0x108400082b43    23  cc             int3l
0x108400082b44    24  8b59d0         movl rbx,[rcx-0x30]
0x108400082b47    27  4903dd         REX.W addq rbx,r13
0x108400082b4a    2a  f6430701       testb [rbx+0x7],0x1
0x108400082b4e    2e  740d           jz 0x108400082b5d  <+0x3d>
0x108400082b50    30  49bae0f781724b560000 REX.W movq r10,0x564b7281f7e0  (CompileLazyDeoptimizedCode)    ;; off heap target
0x108400082b5a    3a  41ffe2         jmp r10
0x108400082b5d    3d  55             push rbp
0x108400082b5e    3e  4889e5         REX.W movq rbp,rsp
0x108400082b61    41  56             push rsi
0x108400082b62    42  57             push rdi
0x108400082b63    43  48ba4200000000000000 REX.W movq rdx,0x42
0x108400082b6d    4d  4c8b15c4ffffff REX.W movq r10,[rip+0xffffffc4]
0x108400082b74    54  41ffd2         call r10
0x108400082b77    57  cc             int3l
0x108400082b78    58  4883ec18       REX.W subq rsp,0x18
0x108400082b7c    5c  488975a0       REX.W movq [rbp-0x60],rsi
0x108400082b80    60  488b4dd0       REX.W movq rcx,[rbp-0x30]
0x108400082b84    64  f6c101         testb rcx,0x1
0x108400082b87    67  0f8557010000   jnz 0x108400082ce4  <+0x1c4>
0x108400082b8d    6d  81f9204e0000   cmpl rcx,0x4e20
0x108400082b93    73  0f8c0b000000   jl 0x108400082ba4  <+0x84>
0x108400082b99    79  488b45d8       REX.W movq rax,[rbp-0x28]
0x108400082b9d    7d  488be5         REX.W movq rsp,rbp
0x108400082ba0    80  5d             pop rbp
0x108400082ba1    81  c20800         ret 0x8
0x108400082ba4    84  493b6560       REX.W cmpq rsp,[r13+0x60] (external value (StackGuard::address_of_jslimit()))
0x108400082ba8    88  0f8669000000   jna 0x108400082c17  <+0xf7>
0x108400082bae    8e  488bf9         REX.W movq rdi,rcx
0x108400082bb1    91  d1ff           sarl rdi, 1
0x108400082bb3    93  4c8bc7         REX.W movq r8,rdi
0x108400082bb6    96  4183c002       addl r8,0x2
0x108400082bba    9a  0f8030010000   jo 0x108400082cf0  <+0x1d0>
0x108400082bc0    a0  83c701         addl rdi,0x1
0x108400082bc3    a3  0f8033010000   jo 0x108400082cfc  <+0x1dc>
0x108400082bc9    a9  e921000000     jmp 0x108400082bef  <+0xcf>
0x108400082bce    ae  6690           nop
0x108400082bd0    b0  488bcf         REX.W movq rcx,rdi
0x108400082bd3    b3  83c102         addl rcx,0x2
0x108400082bd6    b6  0f802c010000   jo 0x108400082d08  <+0x1e8>
0x108400082bdc    bc  4c8bc7         REX.W movq r8,rdi
0x108400082bdf    bf  4183c001       addl r8,0x1
0x108400082be3    c3  0f802b010000   jo 0x108400082d14  <+0x1f4>
0x108400082be9    c9  498bf8         REX.W movq rdi,r8
0x108400082bec    cc  4c8bc1         REX.W movq r8,rcx
0x108400082bef    cf  81ff10270000   cmpl rdi,0x2710
0x108400082bf5    d5  0f8d0b000000   jge 0x108400082c06  <+0xe6>
0x108400082bfb    db  493b6560       REX.W cmpq rsp,[r13+0x60] (external value (StackGuard::address_of_jslimit()))
0x108400082bff    df  77cf           ja 0x108400082bd0  <+0xb0>
0x108400082c01    e1  e943000000     jmp 0x108400082c49  <+0x129>
0x108400082c06    e6  498bc8         REX.W movq rcx,r8
0x108400082c09    e9  4103c8         addl rcx,r8
0x108400082c0c    ec  0f8061000000   jo 0x108400082c73  <+0x153>
0x108400082c12    f2  488bc1         REX.W movq rax,rcx
0x108400082c15    f5  eb86           jmp 0x108400082b9d  <+0x7d>
0x108400082c17    f7  33c0           xorl rax,rax
0x108400082c19    f9  48bef50c240884100000 REX.W movq rsi,0x108408240cf5    ;; object: 0x108408240cf5 <NativeContext[261]>
0x108400082c23   103  48bb101206724b560000 REX.W movq rbx,0x564b72061210    ;; external reference (Runtime::StackGuard)
0x108400082c2d   10d  488bf8         REX.W movq rdi,rax
0x108400082c30   110  4c8bc6         REX.W movq r8,rsi
0x108400082c33   113  49ba2089a3724b560000 REX.W movq r10,0x564b72a38920  (CEntry_Return1_DontSaveFPRegs_ArgvOnStack_NoBuiltinExit)    ;; off heap target
0x108400082c3d   11d  41ffd2         call r10
0x108400082c40   120  488b4dd0       REX.W movq rcx,[rbp-0x30]
0x108400082c44   124  e965ffffff     jmp 0x108400082bae  <+0x8e>
0x108400082c49   129  48897da8       REX.W movq [rbp-0x58],rdi
0x108400082c4d   12d  488b1dd1ffffff REX.W movq rbx,[rip+0xffffffd1]
0x108400082c54   134  33c0           xorl rax,rax
0x108400082c56   136  48bef50c240884100000 REX.W movq rsi,0x108408240cf5    ;; object: 0x108408240cf5 <NativeContext[261]>
0x108400082c60   140  4c8b15ceffffff REX.W movq r10,[rip+0xffffffce]
0x108400082c67   147  41ffd2         call r10
0x108400082c6a   14a  488b7da8       REX.W movq rdi,[rbp-0x58]
0x108400082c6e   14e  e95dffffff     jmp 0x108400082bd0  <+0xb0>
0x108400082c73   153  48b968ea2f744b560000 REX.W movq rcx,0x564b742fea68    ;; external reference (Heap::NewSpaceAllocationTopAddress())
0x108400082c7d   15d  488b39         REX.W movq rdi,[rcx]
0x108400082c80   160  4c8d4f0c       REX.W leaq r9,[rdi+0xc]
0x108400082c84   164  4c8945b0       REX.W movq [rbp-0x50],r8
0x108400082c88   168  49bb70ea2f744b560000 REX.W movq r11,0x564b742fea70    ;; external reference (Heap::NewSpaceAllocationLimitAddress())
0x108400082c92   172  4d390b         REX.W cmpq [r11],r9
0x108400082c95   175  0f8721000000   ja 0x108400082cbc  <+0x19c>
0x108400082c9b   17b  ba0c000000     movl rdx,0xc
0x108400082ca0   180  49ba200282724b560000 REX.W movq r10,0x564b72820220  (AllocateRegularInYoungGeneration)    ;; off heap target
0x108400082caa   18a  41ffd2         call r10
0x108400082cad   18d  488d78ff       REX.W leaq rdi,[rax-0x1]
0x108400082cb1   191  488b0dbdffffff REX.W movq rcx,[rip+0xffffffbd]
0x108400082cb8   198  4c8b45b0       REX.W movq r8,[rbp-0x50]
0x108400082cbc   19c  4c8d4f0c       REX.W leaq r9,[rdi+0xc]
0x108400082cc0   1a0  4c8909         REX.W movq [rcx],r9
0x108400082cc3   1a3  488d4f01       REX.W leaq rcx,[rdi+0x1]
0x108400082cc7   1a7  498bbd40010000 REX.W movq rdi,[r13+0x140] (root (heap_number_map))
0x108400082cce   1ae  8979ff         movl [rcx-0x1],rdi
0x108400082cd1   1b1  c4c1032ac0     vcvtlsi2sd xmm0,xmm15,r8
0x108400082cd6   1b6  c5fb114103     vmovsd [rcx+0x3],xmm0
0x108400082cdb   1bb  488bc1         REX.W movq rax,rcx
0x108400082cde   1be  e9bafeffff     jmp 0x108400082b9d  <+0x7d>
0x108400082ce3   1c3  90             nop
0x108400082ce4   1c4  49c7c500000000 REX.W movq r13,0x0
0x108400082ceb   1cb  e850f30300     call 0x1084000c2040     ;; eager deoptimization bailout
0x108400082cf0   1d0  49c7c501000000 REX.W movq r13,0x1
0x108400082cf7   1d7  e844f30300     call 0x1084000c2040     ;; eager deoptimization bailout
0x108400082cfc   1dc  49c7c502000000 REX.W movq r13,0x2
0x108400082d03   1e3  e838f30300     call 0x1084000c2040     ;; eager deoptimization bailout
0x108400082d08   1e8  49c7c503000000 REX.W movq r13,0x3
0x108400082d0f   1ef  e82cf30300     call 0x1084000c2040     ;; eager deoptimization bailout
0x108400082d14   1f4  49c7c504000000 REX.W movq r13,0x4
0x108400082d1b   1fb  e820f30300     call 0x1084000c2040     ;; eager deoptimization bailout
0x108400082d20   200  49c7c505000000 REX.W movq r13,0x5
0x108400082d27   207  e814f30700     call 0x108400102040     ;; lazy deoptimization bailout
0x108400082d2c   20c  49c7c506000000 REX.W movq r13,0x6
0x108400082d33   213  e808f30700     call 0x108400102040     ;; lazy deoptimization bailout

Source positions:
pc offset  position
f7         0

Inlined functions (count = 1)
0x10840824fff5 <SharedFunctionInfo something>

Deoptimization Input Data (deopt points = 7)
index  bytecode-offset    pc
0               22    NA
1                2    NA
2               46    NA
3                2    NA
4               46    NA
5               27   120
6               27   14a

Safepoints (size = 50)
0x108400082c40     120   200  10000010000000 (sp -> fp)       5
0x108400082c6a     14a   20c  10000000000000 (sp -> fp)       6
0x108400082cad     18d    NA  00000000000000 (sp -> fp)  <none>

RelocInfo (size = 34)
0x108400082b38  off heap target
0x108400082b52  off heap target
0x108400082c1b  full embedded object  (0x108408240cf5 <NativeContext[261]>)
0x108400082c25  external reference (Runtime::StackGuard)  (0x564b72061210)
0x108400082c35  off heap target
0x108400082c58  full embedded object  (0x108408240cf5 <NativeContext[261]>)
0x108400082c75  external reference (Heap::NewSpaceAllocationTopAddress())  (0x564b742fea68)
0x108400082c8a  external reference (Heap::NewSpaceAllocationLimitAddress())  (0x564b742fea70)
0x108400082ca2  off heap target
0x108400082cec  runtime entry  (eager deoptimization bailout)
0x108400082cf8  runtime entry  (eager deoptimization bailout)
0x108400082d04  runtime entry  (eager deoptimization bailout)
0x108400082d10  runtime entry  (eager deoptimization bailout)
0x108400082d1c  runtime entry  (eager deoptimization bailout)
0x108400082d28  runtime entry  (lazy deoptimization bailout)
0x108400082d34  runtime entry  (lazy deoptimization bailout)

--- End code ---
\$

### Building Google Test

\$ mkdir lib
\$ mkdir deps ; cd deps
\$ git clone git@github.com:google/googletest.git
\$ cd googletest/googletest
\$ /usr/bin/clang++ --std=c++14 -Iinclude -I. -pthread -c src/gtest-all.cc
\$ ar -rv libgtest-linux.a gtest-all.o
\$ cp libgtest-linux.a ../../../../lib/gtest

Linking issue:

./lib/gtest/libgtest-linux.a(gtest-all.o):gtest-all.cc:function testing::internal::BoolFromGTestEnv(char const*, bool): error: undefined reference to 'std::__cxx11::basic_string<char, std::char_traits<char>, std::allocator<char> >::c_str() const'
\$ nm lib/gtest/libgtest-linux.a | grep basic_string | c++filt
....

There are a lot of symbols listed above but the point is that in the object file of libgtest-linux.a these symbols were compiled in. Now, when we compile v8 and the tests we are using -std=c++14 and we have to use the same when compiling gtest. Lets try that. Just adding that does not help in this case. We need to check which c++ headers are being used:

\$ /usr/bin/clang++ -print-search-dirs
programs: =/usr/bin:/usr/bin/../lib/gcc/x86_64-redhat-linux/9/../../../../x86_64-redhat-linux/bin
libraries: =/usr/lib64/clang/9.0.0:
/usr/bin/../lib/gcc/x86_64-redhat-linux/9:
/usr/bin/../lib/gcc/x86_64-redhat-linux/9/../../../../lib64:
/usr/bin/../lib64:
/lib/../lib64:
/usr/lib/../lib64:
/usr/bin/../lib/gcc/x86_64-redhat-linux/9/../../..:
/usr/bin/../lib:
/lib:/usr/lib
\$

Lets search for the string header and inspect the namespace in that header:

\$ find /usr/ -name string
/usr/include/c++/9/debug/string
/usr/include/c++/9/experimental/string
/usr/include/c++/9/string
/usr/src/debug/gcc-9.2.1-1.fc31.x86_64/obj-x86_64-redhat-linux/x86_64-redhat-linux/libstdc++-v3/include/string
\$ vi /usr/include/c++/9/string

So this looks alright and thinking about this a little more I've been bitten by the linking with different libc++ symbols issue (again). When we compile using Make we are using the c++ headers that are shipped with v8 (clang libc++). Take the string header for example in v8/buildtools/third_party/libc++/trunk/include/string which is from clang's c++ library which does not use namespaces (__11 or __14 etc).

But when I compiled gtest did not specify the istystem include path and the default would be used adding symbols with __11 into them. When the linker tries to find these symbols it fails as it does not have any such symbols in the libraries that it searches.

Create a simple test linking with the standard build of gtest to see if that compiles and runs:

\$ /usr/bin/clang++ -std=c++14 -I./deps/googletest/googletest/include  -L\$PWD/lib -g -O0 -o test/simple_test test/main.cc test/simple.cc lib/libgtest.a -lpthread

That worked and does not segfault.

But when I run the version that is built using the makefile I get:

lldb) target create "./test/persistent-object_test"
Current executable set to './test/persistent-object_test' (x86_64).
(lldb) r
Process 1024232 launched: '/home/danielbevenius/work/google/learning-v8/test/persistent-object_test' (x86_64)
warning: (x86_64) /lib64/libgcc_s.so.1 unsupported DW_FORM values: 0x1f20 0x1f21

[ FATAL ] Process 1024232 stopped
* thread #1, name = 'persistent-obje', stop reason = signal SIGSEGV: invalid address (fault address: 0x33363658)
frame #0: 0x00007ffff7c0a7b0 libc.so.6`__GI___libc_free + 32
libc.so.6`__GI___libc_free:
->  0x7ffff7c0a7b0 <+32>: mov    rax, qword ptr [rdi - 0x8]
0x7ffff7c0a7b4 <+36>: lea    rsi, [rdi - 0x10]
0x7ffff7c0a7b8 <+40>: test   al, 0x2
0x7ffff7c0a7ba <+42>: jne    0x7ffff7c0a7f0            ; <+96>
(lldb) bt
* thread #1, name = 'persistent-obje', stop reason = signal SIGSEGV: invalid address (fault address: 0x33363658)
* frame #0: 0x00007ffff7c0a7b0 libc.so.6`__GI___libc_free + 32
frame #1: 0x000000000042bb58 persistent-object_test`std::__1::basic_stringbuf<char, std::__1::char_traits<char>, std::__1::allocator<char> >::~basic_stringbuf(this=0x000000000046e908) at iosfwd:130:32
frame #2: 0x000000000042ba4f persistent-object_test`std::__1::basic_stringstream<char, std::__1::char_traits<char>, std::__1::allocator<char> >::~basic_stringstream(this=0x000000000046e8f0, vtt=0x000000000044db28) at iosfwd:139:32
frame #3: 0x0000000000420176 persistent-object_test`std::__1::basic_stringstream<char, std::__1::char_traits<char>, std::__1::allocator<char> >::~basic_stringstream(this=0x000000000046e8f0) at iosfwd:139:32
frame #4: 0x000000000042bacc persistent-object_test`std::__1::basic_stringstream<char, std::__1::char_traits<char>, std::__1::allocator<char> >::~basic_stringstream(this=0x000000000046e8f0) at iosfwd:139:32
frame #5: 0x0000000000427f4e persistent-object_test`testing::internal::scoped_ptr<std::__1::basic_stringstream<char, std::__1::char_traits<char>, std::__1::allocator<char> > >::reset(this=0x00007fffffffcee8, p=0x0000000000000000) at gtest-port.h:1216:9
frame #6: 0x0000000000427ee9 persistent-object_test`testing::internal::scoped_ptr<std::__1::basic_stringstream<char, std::__1::char_traits<char>, std::__1::allocator<char> > >::~scoped_ptr(this=0x00007fffffffcee8) at gtest-port.h:1201:19
frame #7: 0x000000000041f265 persistent-object_test`testing::Message::~Message(this=0x00007fffffffcee8) at gtest-message.h:89:18
frame #8: 0x00000000004235ec persistent-object_test`std::__1::basic_string<char, std::__1::char_traits<char>, std::__1::allocator<char> > testing::internal::StreamableToString<int>(streamable=0x00007fffffffcf9c) at gtest-message.h:247:3
frame #9: 0x000000000040d2bd persistent-object_test`testing::internal::FormatFileLocation(file="/home/danielbevenius/work/google/learning-v8/deps/googletest/googletest/src/gtest-internal-inl.h", line=663) at gtest-port.cc:946:28
frame #10: 0x000000000041b7e2 persistent-object_test`testing::internal::GTestLog::GTestLog(this=0x00007fffffffd060, severity=GTEST_FATAL, file="/home/danielbevenius/work/google/learning-v8/deps/googletest/googletest/src/gtest-internal-inl.h", line=663) at gtest-port.cc:972:18
frame #11: 0x000000000042242c persistent-object_test`testing::internal::UnitTestImpl::AddTestInfo(this=0x000000000046e480, set_up_tc=(persistent-object_test`testing::Test::SetUpTestCase() at gtest.h:427), tear_down_tc=(persistent-object_test`testing::Test::TearDownTestCase() at gtest.h:435), test_info=0x000000000046e320)(), void (*)(), testing::TestInfo*) at gtest-internal-inl.h:663:7
frame #12: 0x000000000040d04f persistent-object_test`testing::internal::MakeAndRegisterTestInfo(test_case_name="Persistent", name="object", type_param=0x0000000000000000, value_param=0x0000000000000000, code_location=<unavailable>, fixture_class_id=0x000000000046d748, set_up_tc=(persistent-object_test`testing::Test::SetUpTestCase() at gtest.h:427), tear_down_tc=(persistent-object_test`testing::Test::TearDownTestCase() at gtest.h:435), factory=0x000000000046e300)(), void (*)(), testing::internal::TestFactoryBase*) at gtest.cc:2599:22
frame #13: 0x00000000004048b8 persistent-object_test`::__cxx_global_var_init() at persistent-object_test.cc:5:1
frame #14: 0x00000000004048e9 persistent-object_test`_GLOBAL__sub_I_persistent_object_test.cc at persistent-object_test.cc:0
frame #15: 0x00000000004497a5 persistent-object_test`__libc_csu_init + 69
frame #16: 0x00007ffff7ba512e libc.so.6`__libc_start_main + 126
frame #17: 0x0000000000404eba persistent-object_test`_start + 42

### Google test (gtest) linking issue

This issue came up when linking a unit test with gtest:

/usr/bin/ld: ./lib/gtest/libgtest-linux.a(gtest-all.o): in function `testing::internal::BoolFromGTestEnv(char const*, bool)':
/home/danielbevenius/work/google/learning-v8/deps/googletest/googletest/src/gtest-port.cc:1259: undefined reference to `std::__1::basic_string<char, std::__1::char_traits<char>, std::__1::allocator<char> >::~basic_string()'

So this indicated that the object files in libgtest-linux.a where infact using headers from libc++ and not libstc++. This was a really stupig mistake on my part, I'd not specified the output file explicitly (-o) so this was getting added into the current working directory, but the file included in the archive was taken from within deps/googltest/googletest/ directory which was old and compiled using libc++.

### Peristent cast-function-type

This issue was seen in Node.js when compiling with GCC. It can also been see if building V8 using GCC and also enabling -Wcast-function-type in BUILD.gn:

"-Wcast-function-type",

There are unit tests in V8 that also produce this warning, for example test/cctest/test-global-handles.cc: Original:

g++ -MMD -MF obj/test/cctest/cctest_sources/test-global-handles.o.d -DV8_INTL_SUPPORT -DUSE_UDEV -DUSE_AURA=1 -DUSE_GLIB=1 -DUSE_NSS_CERTS=1 -DUSE_X11=1 -D_FILE_OFFSET_BITS=64 -D_LARGEFILE_SOURCE -D_LARGEFILE64_SOURCE -D__STDC_CONSTANT_MACROS -D__STDC_FORMAT_MACROS -DCR_SYSROOT_HASH=9c905c99558f10e19cc878b5dca1d4bd58c607ae -D_DEBUG -DDYNAMIC_ANNOTATIONS_ENABLED=1 -DENABLE_DISASSEMBLER -DV8_TYPED_ARRAY_MAX_SIZE_IN_HEAP=64 -DENABLE_GDB_JIT_INTERFACE -DENABLE_MINOR_MC -DOBJECT_PRINT -DV8_TRACE_MAPS -DV8_ENABLE_ALLOCATION_TIMEOUT -DV8_ENABLE_FORCE_SLOW_PATH -DV8_ENABLE_DOUBLE_CONST_STORE_CHECK -DV8_INTL_SUPPORT -DENABLE_HANDLE_ZAPPING -DV8_SNAPSHOT_NATIVE_CODE_COUNTERS -DV8_CONCURRENT_MARKING -DV8_ENABLE_LAZY_SOURCE_POSITIONS -DV8_CHECK_MICROTASKS_SCOPES_CONSISTENCY -DV8_EMBEDDED_BUILTINS -DV8_WIN64_UNWINDING_INFO -DV8_ENABLE_REGEXP_INTERPRETER_THREADED_DISPATCH -DV8_SNAPSHOT_COMPRESSION -DV8_ENABLE_CHECKS -DV8_COMPRESS_POINTERS -DV8_31BIT_SMIS_ON_64BIT_ARCH -DV8_DEPRECATION_WARNINGS -DV8_IMMINENT_DEPRECATION_WARNINGS -DV8_TARGET_ARCH_X64 -DV8_HAVE_TARGET_OS -DV8_TARGET_OS_LINUX -DDEBUG -DDISABLE_UNTRUSTED_CODE_MITIGATIONS -DV8_ENABLE_CHECKS -DV8_COMPRESS_POINTERS -DV8_31BIT_SMIS_ON_64BIT_ARCH -DV8_DEPRECATION_WARNINGS -DV8_IMMINENT_DEPRECATION_WARNINGS -DU_USING_ICU_NAMESPACE=0 -DU_ENABLE_DYLOAD=0 -DUSE_CHROMIUM_ICU=1 -DU_STATIC_IMPLEMENTATION -DICU_UTIL_DATA_IMPL=ICU_UTIL_DATA_FILE -DUCHAR_TYPE=uint16_t -I../.. -Igen -I../../include -Igen/include -I../.. -Igen -I../../third_party/icu/source/common -I../../third_party/icu/source/i18n -I../../include -I../../tools/debug_helper -fno-strict-aliasing --param=ssp-buffer-size=4 -fstack-protector -funwind-tables -fPIC -pipe -B../../third_party/binutils/Linux_x64/Release/bin -pthread -m64 -march=x86-64 -Wno-builtin-macro-redefined -D__DATE__= -D__TIME__= -D__TIMESTAMP__= -Wall -Wno-unused-local-typedefs -Wno-maybe-uninitialized -Wno-deprecated-declarations -Wno-comments -Wno-packed-not-aligned -Wno-missing-field-initializers -Wno-unused-parameter -fno-omit-frame-pointer -g2 -Wno-strict-overflow -Wno-return-type -Wcast-function-type -O3 -fno-ident -fdata-sections -ffunction-sections -fvisibility=default -std=gnu++14 -Wno-narrowing -Wno-class-memaccess -fno-exceptions -fno-rtti --sysroot=../../build/linux/debian_sid_amd64-sysroot -c ../../test/cctest/test-global-handles.cc -o obj/test/cctest/cctest_sources/test-global-handles.o
In file included from ../../include/v8-inspector.h:14,
from ../../src/execution/isolate.h:15,
from ../../src/api/api.h:10,
from ../../src/api/api-inl.h:8,
from ../../test/cctest/test-global-handles.cc:28:
../../include/v8.h: In instantiation of ‘void v8::PersistentBase<T>::SetWeak(P*, typename v8::WeakCallbackInfo<P>::Callback, v8::WeakCallbackType) [with P = v8::Global<v8::Object>; T = v8::Object; typename v8::WeakCallbackInfo<P>::Callback = void (*)(const v8::WeakCallbackInfo<v8::Global<v8::Object> >&)]’:
../../test/cctest/test-global-handles.cc:292:47:   required from here
../../include/v8.h:10750:16: warning: cast between incompatible function types from ‘v8::WeakCallbackInfo<v8::Global<v8::Object> >::Callback’ {aka ‘void (*)(const v8::WeakCallbackInfo<v8::Global<v8::Object> >&)’} to ‘Callback’ {aka ‘void (*)(const v8::WeakCallbackInfo<void>&)’} [-Wcast-function-type]
10750 |                reinterpret_cast<Callback>(callback), type);
|                ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
../../include/v8.h: In instantiation of ‘void v8::PersistentBase<T>::SetWeak(P*, typename v8::WeakCallbackInfo<P>::Callback, v8::WeakCallbackType) [with P = v8::internal::{anonymous}::FlagAndGlobal; T = v8::Object; typename v8::WeakCallbackInfo<P>::Callback = void (*)(const v8::WeakCallbackInfo<v8::internal::{anonymous}::FlagAndGlobal>&)]’:
../../test/cctest/test-global-handles.cc:493:53:   required from here
../../include/v8.h:10750:16: warning: cast between incompatible function types from ‘v8::WeakCallbackInfo<v8::internal::{anonymous}::FlagAndGlobal>::Callback’ {aka ‘void (*)(const v8::WeakCallbackInfo<v8::internal::{anonymous}::FlagAndGlobal>&)’} to ‘Callback’ {aka ‘void (*)(const v8::WeakCallbackInfo<void>&)’} [-Wcast-function-type]

Formatted for git commit message:

g++ -MMD -MF obj/test/cctest/cctest_sources/test-global-handles.o.d
...
In file included from ../../include/v8-inspector.h:14,
from ../../src/execution/isolate.h:15,
from ../../src/api/api.h:10,
from ../../src/api/api-inl.h:8,
from ../../test/cctest/test-global-handles.cc:28:
../../include/v8.h:
In instantiation of ‘void v8::PersistentBase<T>::SetWeak(
P*,
typename v8::WeakCallbackInfo<P>::Callback,
v8::WeakCallbackType)
[with
P = v8::Global<v8::Object>;
T = v8::Object;
typename v8::WeakCallbackInfo<P>::Callback =
void (*)(const v8::WeakCallbackInfo<v8::Global<v8::Object> >&)
]’:
../../test/cctest/test-global-handles.cc:292:47:   required from here
../../include/v8.h:10750:16: warning:
cast between incompatible function types from
‘v8::WeakCallbackInfo<v8::Global<v8::Object> >::Callback’ {aka
‘void (*)(const v8::WeakCallbackInfo<v8::Global<v8::Object> >&)’} to
‘Callback’ {aka ‘void (*)(const v8::WeakCallbackInfo<void>&)’}
[-Wcast-function-type]
10750 |                reinterpret_cast<Callback>(callback), type);
|                ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

This commit suggests adding a pragma specifically for GCC to suppress this warning. The motivation for this is that there were quite a few of these warnings in the Node.js build, but these have been suppressed by adding a similar pragma but around the include of v8.h [1].

\$
In file included from persistent-obj.cc:8:
/home/danielbevenius/work/google/v8_src/v8/include/v8.h: In instantiation of ‘void v8::PersistentBase<T>::SetWeak(P*, typename v8::WeakCallbackInfo<P>::Callback, v8::WeakCallbackType) [with P = Something; T = v8::Object; typename v8::WeakCallbackInfo<P>::Callback = void (*)(const v8::WeakCallbackInfo<Something>&)]’:

persistent-obj.cc:57:38:   required from here
/home/danielbevenius/work/google/v8_src/v8/include/v8.h:10750:16: warning: cast between incompatible function types from ‘v8::WeakCallbackInfo<Something>::Callback’ {aka ‘void (*)(const v8::WeakCallbackInfo<Something>&)’} to ‘Callback’ {aka ‘void (*)(const v8::WeakCallbackInfo<void>&)’} [-Wcast-function-type]
10750 |                reinterpret_cast<Callback>(callback), type);
|                ^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

Currently, we have added a pragma to avoid this warning in node.js but we'd like to add this in v8 and closer to the actual code that is causing it. In node we have to set the praga on the header.

template <class T>
template <typename P>
V8_INLINE void PersistentBase<T>::SetWeak(
P* parameter,
typename WeakCallbackInfo<P>::Callback callback,
WeakCallbackType type) {
typedef typename WeakCallbackInfo<void>::Callback Callback;
V8::MakeWeak(reinterpret_cast<internal::Address*>(this->val_), parameter,
reinterpret_cast<Callback>(callback), type);
}

Notice the second parameter is typename WeakCallbackInfo<P>::Callback which is a typedef:

typedef void (*Callback)(const WeakCallbackInfo<T>& data);

This is a function declaration for Callback which is a function that takes a reference to a const WeakCallbackInfo and returns void. So we could define it like this:

void WeakCallback(const v8::WeakCallbackInfo<Something>& data) {
Something* obj = data.GetParameter();
std::cout << "in make weak callback..." << '\n';
}

And the trying to cast it into:

typedef typename v8::WeakCallbackInfo<void>::Callback Callback;
Callback cb = reinterpret_cast<Callback>(WeakCallback);

This is done as V8::MakeWeak has the following signature:

void V8::MakeWeak(i::Address* location, void* parameter,
WeakCallbackInfo<void>::Callback weak_callback,
WeakCallbackType type) {
i::GlobalHandles::MakeWeak(location, parameter, weak_callback, type);
}

### gdb warnings

warning: Could not find DWO CU obj/v8_compiler/common-node-cache.dwo(0x42b8adb87d74d56b) referenced by CU at offset 0x206f7 [in module /home/danielbevenius/work/google/learning-v8/hello-world]

This can be worked around by specifying the --cd argument to gdb:

\$ gdb --cd=/home/danielbevenius/work/google/v8_src/v8/out/x64.release --args /home/danielbevenius/work/google/learning-v8/hello-world

### Building with g++

Update args.gn to include:

is_clang = false

Next I got the following error when trying to compile:

\$ ninja -v -C out/x64.release/ obj/test/cctest/cctest_sources/test-global-handles.o
ux/debian_sid_amd64-sysroot -fexceptions -frtti -c ../../src/torque/instance-type-generator.cc -o obj/torque_base/instance-type-generator.o
In file included from /usr/include/c++/9/bits/stl_algobase.h:59,
from /usr/include/c++/9/memory:62,
from ../../src/torque/implementation-visitor.h:8,
from ../../src/torque/instance-type-generator.cc:5:
/usr/include/c++/9/x86_64-redhat-linux/bits/c++config.h:3:10: fatal error: bits/wordsize.h: No such file or directory
3 | #include <bits/wordsize.h>
|          ^~~~~~~~~~~~~~~~~
compilation terminated.
ninja: build stopped: subcommand failed.
\$ export CPATH=/usr/include
third_party/binutils/Linux_x64/Release/bin/ld.gold: error: cannot open /usr/lib64/libatomic.so.1.2.0: No such file or directory
\$ sudo dnf install -y libatomic

I still got an error because of a warning but I'm trying to build using:

treat_warnings_as_errors = false

Lets see how that works out. I also had to use gnus linker by disableing gold:

use_gold = false

### CodeStubAssembler

This history of this is that JavaScript builtins used be written in assembly which gave very good performance but made porting V8 to different architectures more difficult as these builtins had to have specific implementations for each supported architecture, so it dit not scale very well. With the addition of features to the JavaScript specifications having to support new features meant having to implement them for all platforms which made it difficult to keep up and deliver these new features.

The goal is to have the perfomance of handcoded assembly but not have to write it for every platform. So a portable assembly language was build on top of Tubofans backend. This is an API that generates Turbofan's machine-level IR. This IR can be used by Turbofan to produce very good machine code on all platforms. So one "only" has to implement one component/function/feature (not sure what to call this) and then it can be made available to all platforms. They no longer have to maintain all that handwritten assembly.

Just to be clear CSA is a C++ API that is used to generate IR which is then compiled in to machine code for the target instruction set architectur.

### Torque

Torque is a DLS language to avoid having to use the CodeStubAssembler directly (it is still used behind the scene). This language is statically typed, garbage collected, and compatible with JavaScript.

The JavaScript standard library was implemented in V8 previously using hand written assembly. But as we mentioned in the previous section this did not scale.

It could have been written in JavaScript too, and I think this was done in the past but this has some issues as builtins would need warmup time to become optimized, there were also issues with monkey-patching and exposing VM internals unintentionally.

Is torque run a build time, I'm thinking yes as it would have to generate the c++ code.

There is a main function in torque.cc which will be built into an executable

\$ ./out/x64.release_gcc/torque --help
Unexpected command-line argument "--help", expected a .tq file.

The files that are processed by torque are defined in BUILD.gc in the torque_files section. There is also a template named run_torque. I've noticed that this template and others in GN use the script tools/run.py. This is apperently because GN can only execute scripts at the moment and what this script does is use python to create a subprocess with the passed in argument:

\$ gn help action

And a template is way to reuse code in GN.

There is a make target that shows what is generated by torque:

\$ make torque-example

This will create a directory in the current directory named gen/torque-generated. Notice that this directory contains c++ headers and sources.

It take torque-example.tq as input. For this file the following header will be generated:

#ifndef V8_GEN_TORQUE_GENERATED_TORQUE_EXAMPLE_TQ_H_
#define V8_GEN_TORQUE_GENERATED_TORQUE_EXAMPLE_TQ_H_

#include "src/builtins/builtins-promise.h"
#include "src/compiler/code-assembler.h"
#include "src/codegen/code-stub-assembler.h"
#include "src/utils/utils.h"
#include "torque-generated/field-offsets-tq.h"
#include "torque-generated/csa-types-tq.h"

namespace v8 {
namespace internal {

void HelloWorld_0(compiler::CodeAssemblerState* state_);

}  // namespace internal
}  // namespace v8

#endif  // V8_GEN_TORQUE_GENERATED_TORQUE_EXAMPLE_TQ_H_

This is only to show the generated files and make it clear that torque will generate these file which will then be compiled during the v8 build. So, lets try copying example-torque.tq to v8/src/builtins directory.

\$ cp torque-example.tq ../v8_src/v8/src/builtins/

This is not enough to get it included in the build, we have to update BUILD.gn and add this file to the torque_files list. After running the build we can see that there is a file named src/builtins/torque-example-tq-csa.h generated along with a .cc.

To understand how this works I'm going to use https://v8.dev/docs/torque-builtins as a starting point:

transitioning javascript builtin
MathIs42(js-implicit context: NativeContext, receiver: JSAny)(x: JSAny): Boolean {
const number: Number = ToNumber_Inline(x);
typeswitch (number) {
case (smi: Smi): {
return smi == 42 ? True : False;
}
case (heapNumber: HeapNumber): {
return Convert<float64>(heapNumber) == 42 ? True : False;
}
}
}

This has been updated to work with the latest V8 version.

Next, we need to update src/init/bootstrappers.cc to add/install this function on the math object:

SimpleInstallFunction(isolate_, math, "is42", Builtins::kMathIs42, 1, true);

After this we need to rebuild v8:

\$ env CPATH=/usr/include ninja -v -C out/x64.release_gcc
\$ d8
d8> Math.is42(42)
true
d8> Math.is42(2)
false

If we look at the generated code that Torque has produced in out/x64.release_gcc/gen/torque-generated/src/builtins/math-tq-csa.cc (we can run it through the preprocessor using):

\$ clang++ --sysroot=build/linux/debian_sid_amd64-sysroot -isystem=./buildtools/third_party/libc++/trunk/include -isystem=buildtools/third_party/libc++/trunk/include -I. -E out/x64.release_gcc/gen/torque-generated/src/builtins/math-tq-csa.cc > math.cc.pp

If we open math.cc.pp and search for Is42 we can find:

class MathIs42Assembler : public CodeStubAssembler {
public:
using Descriptor = Builtin_MathIs42_InterfaceDescriptor;
explicit MathIs42Assembler(compiler::CodeAssemblerState* state) : CodeStubAssembler(state) {}
void GenerateMathIs42Impl();
Node* Parameter(Descriptor::ParameterIndices index) {
return CodeAssembler::Parameter(static_cast<int>(index));
}
};

void Builtins::Generate_MathIs42(compiler::CodeAssemblerState* state) {
MathIs42Assembler assembler(state);
state->SetInitialDebugInformation("MathIs42", "out/x64.release_gcc/gen/torque-generated/src/builtins/math-tq-csa.cc", 2121);
if (Builtins::KindOf(Builtins::kMathIs42) == Builtins::TFJ) {
assembler.PerformStackCheck(assembler.GetJSContextParameter());
}
assembler.GenerateMathIs42Impl();
}

void MathIs42Assembler::GenerateMathIs42Impl() {
...

So this is what gets generated by the Torque compiler and what we see above is CodeStubAssemble class.

If we take a look in out/x64.release_gcc/gen/torque-generated/builtin-definitions-tq.h we can find the following line that has been generated:

TFJ(MathIs42, 1, kReceiver, kX) \

Now, there is a section about the TF_BUILTIN macro, and it will create function declarations, and function and class definitions:

Now, in src/builtins/builtins.h we have the following macros:

class Builtins {
public:

enum Name : int32_t {
#define DEF_ENUM(Name, ...) k##Name,
BUILTIN_LIST(DEF_ENUM, DEF_ENUM, DEF_ENUM, DEF_ENUM, DEF_ENUM, DEF_ENUM,
DEF_ENUM)
#undef DEF_ENUM
...
}

#define DECLARE_TF(Name, ...) \
static void Generate_##Name(compiler::CodeAssemblerState* state);

BUILTIN_LIST(IGNORE_BUILTIN, DECLARE_TF, DECLARE_TF, DECLARE_TF, DECLARE_TF,
IGNORE_BUILTIN, DECLARE_ASM)

And BUILTINS_LIST is declared in src/builtins/builtins-definitions.h and this file includes:

#include "torque-generated/builtin-definitions-tq.h"

#define BUILTIN_LIST(CPP, TFJ, TFC, TFS, TFH, BCH, ASM)  \
BUILTIN_LIST_BASE(CPP, TFJ, TFC, TFS, TFH, ASM)        \
BUILTIN_LIST_FROM_TORQUE(CPP, TFJ, TFC, TFS, TFH, ASM) \
BUILTIN_LIST_INTL(CPP, TFJ, TFS)                       \
BUILTIN_LIST_BYTECODE_HANDLERS(BCH)

Notice BUILTIN_LIST_FROM_TORQUE, this is how our MathIs42 gets included from builtin-definitions-tq.h. This is in turn included by builtins.h.

If we take a look at the this header after it has gone through the preprocessor we can see what has been generated for MathIs42:

\$ clang++ --sysroot=build/linux/debian_sid_amd64-sysroot -isystem=./buildtools/third_party/libc++/trunk/include -isystem=buildtools/third_party/libc++/trunk/include -I. -I./out/x64.release_gcc/gen/ -E src/builtins/builtins.h > builtins.h.pp

First MathIs42 will be come a member in the Name enum of the Builtins class:

class Builtins {
public:

enum Name : int32_t {
...
kMathIs42,
};

static void Generate_MathIs42(compiler::CodeAssemblerState* state);

We should also take a look in src/builtins/builtins-descriptors.h as the BUILTIN_LIST is used there two and specifically to our current example there is a DEFINE_TFJ_INTERFACE_DESCRIPTOR macro used:

BUILTIN_LIST(IGNORE_BUILTIN, DEFINE_TFJ_INTERFACE_DESCRIPTOR,
DEFINE_TFC_INTERFACE_DESCRIPTOR, DEFINE_TFS_INTERFACE_DESCRIPTOR,
DEFINE_TFH_INTERFACE_DESCRIPTOR, IGNORE_BUILTIN,
DEFINE_ASM_INTERFACE_DESCRIPTOR)

#define DEFINE_TFJ_INTERFACE_DESCRIPTOR(Name, Argc, ...)                \
struct Builtin_##Name##_InterfaceDescriptor {                         \
enum ParameterIndices {                                             \
kJSTarget = compiler::CodeAssembler::kTargetParameterIndex,       \
##__VA_ARGS__,                                                    \
kJSNewTarget,                                                     \
kJSActualArgumentsCount,                                          \
kContext,                                                         \
kParameterCount,                                                  \
};                                                                  \
};

So the above will generate the following code but this time for builtins.cc:

\$ clang++ --sysroot=build/linux/debian_sid_amd64-sysroot -isystem=./buildtools/third_party/libc++/trunk/include -isystem=buildtools/third_party/libc++/trunk/include -I. -I./out/x64.release_gcc/gen/ -E src/builtins/builtins.cc > builtins.cc.pp
struct Builtin_MathIs42_InterfaceDescriptor {
enum ParameterIndices {
kJSTarget = compiler::CodeAssembler::kTargetParameterIndex,
kReceiver,
kX,
kJSNewTarget,
kJSActualArgumentsCount,
kContext,
kParameterCount,
};

const BuiltinMetadata builtin_metadata[] = {
...
{"MathIs42", Builtins::TFJ, {1, 0}}
...
};

BuiltinMetadata is a struct defined in builtins.cc and in our case the name is passed, then the type, and the last struct is specifying the number of parameters and the last 0 is unused as far as I can tell and only there make it different from the constructor that takes an Address parameter.

So, where is Generate_MathIs42 used:

void SetupIsolateDelegate::SetupBuiltinsInternal(Isolate* isolate) {
Code code;
...
code = BuildWithCodeStubAssemblerJS(isolate, index, &Builtins::Generate_MathIs42, 1, "MathIs42");
AddBuiltin(builtins, index++, code);
...

BuildWithCodeStubAssemblerJS can be found in src/builtins/setup-builtins-internal.cc

Code BuildWithCodeStubAssemblerJS(Isolate* isolate, int32_t builtin_index,
CodeAssemblerGenerator generator, int argc,
const char* name) {
Zone zone(isolate->allocator(), ZONE_NAME);
const int argc_with_recv = (argc == kDontAdaptArgumentsSentinel) ? 0 : argc + 1;
compiler::CodeAssemblerState state(
isolate, &zone, argc_with_recv, Code::BUILTIN, name,
PoisoningMitigationLevel::kDontPoison, builtin_index);
generator(&state);
Handle<Code> code = compiler::CodeAssembler::GenerateCode(
&state, BuiltinAssemblerOptions(isolate, builtin_index));
return *code;

Lets add a conditional break point so that we can stop in this function when MathIs42 is passed in:

(gdb) br setup-builtins-internal.cc:161
(gdb) cond 1 ((int)strcmp(name, "MathIs42")) == 0

We can see that we first create a new CodeAssemblerState, which we say previously was that type that the Generate_MathIs42 function takes. TODO: look into this class a litte more. After this generator will be called with the newly created state passed in:

(gdb) p generator
\$8 = (v8::internal::(anonymous namespace)::CodeAssemblerGenerator) 0x5619fd61b66e <v8::internal::Builtins::Generate_MathIs42(v8::internal::compiler::CodeAssemblerState*)>

TODO: Take a closer look at generate and how that code works. After generate returns we will have the following call:

generator(&state);
Handle<Code> code = compiler::CodeAssembler::GenerateCode(
&state, BuiltinAssemblerOptions(isolate, builtin_index));
return *code;

Then next thing that will happen is the code returned will be added to the builtins by calling SetupIsolateDelegate::AddBuiltin:

void SetupIsolateDelegate::AddBuiltin(Builtins* builtins, int index, Code code) {
builtins->set_builtin(index, code);
}

set_builtins can be found in src/builtins/builtins.cc` and looks like this:

void Builtins::set_builtin(int index, Code builtin) {
isolate_->heap()->set_builtin(index, builtin);
}

And Heap::set_builtin does:

void Heap::set_builtin(int index, Code builtin) {
isolate()->builtins_table()[index] = builtin.ptr();
}

So this is how the builtins_table is populated.

And when is SetupBuiltinsInternal called?
It is called from SetupIsolateDelegat::SetupBuiltins which is called from Isolate::Init.

Just to recap before I loose track of what is going on...We have math.tq, which is the torque source file. This is parsed by the torque compiler/parser and it will generate c++ headers and source files, one of which will be a CodeStubAssembler class for our MathI42 function. It will also generate the "torque-generated/builtin-definitions-tq.h. After this has happened the sources need to be compiled into object files. After that if a snapshot is configured to be created, mksnapshot will create a new Isolate and in that process the MathIs42 builtin will get added. Then a context will be created and saved. The snapshot can then be deserialized into an Isoalte as some later point.

Alright, so we have seen what gets generated for the function MathIs42 but how does this get "hooked" but to enable us to call Math.is42(11)?

In bootstrapper.cc we can see a number of lines:

SimpleInstallFunction(isolate_, math, "trunc", Builtins::kMathTrunc, 1, true);

And we are going to add a line like the following:

SimpleInstallFunction(isolate_, math, "is42", Builtins::kMathIs42, 1, true);

The signature for SimpleInstallFunction looks like this

V8_NOINLINE Handle<JSFunction> SimpleInstallFunction(
Isolate* isolate, Handle<JSObject> base, const char* name,
Builtins::Name call, int len, bool adapt,
PropertyAttributes attrs = DONT_ENUM) {
Handle<String> internalized_name = isolate->factory()->InternalizeUtf8String(name);
Handle<JSFunction> fun = SimpleCreateFunction(isolate, internalized_name, call, len, adapt);
JSObject::AddProperty(isolate, base, internalized_name, fun, attrs);
return fun;
}

So we see that the function is added as a property to the Math object. Notice that we also have to add kMathIs42 to the Builtins class which is now part of the builtins_table_ array which we went through above.

#### Transitioning/Transient

In torgue source files we can sometimes see types declared as transient, and functions that have a transitioning specifier. In V8 HeapObjects can change at runtime (I think an example of this would be deleting an element in an array which would transition it to a different type of array HoleyElementArray or something like that. TODO: verify and explain this). And a function that calls JavaScript which cause such a transition is marked with transitioning.

#### Callables

Are like functions is js/c++ but have some additional capabilities and there are several different types of callables:

macro callables

These correspond to generated CodeStubAssebler C++ that will be inlined at the callsite.

builtin callables

These will become V8 builtins with info added to builtin-definitions.h (via the include of torque-generated/builtin-definitions-tq.h). There is only one copy of this and this will be a call instead of being inlined as is the case with macros.

runtime callables

intrinsic callables

#### Explicit parameters

macros and builtins can have parameters. For example:

@export
macro HelloWorld1(msg: JSAny) {
Print(msg);
}

And we can call this from another macro like this:

@export
macro HelloWorld() {
HelloWorld1('Hello World');
}

#### Implicit parameters

In the previous section we showed explicit parameters but we can also have implicit parameters:

@export
macro HelloWorld2(implicit msg: JSAny)() {
Print(msg);
}
@export
macro HelloWorld() {
const msg = 'Hello implicit';
HelloWorld2();
}

### Troubleshooting

Compilation error when including `src/objects/objects-inl.h:

/home/danielbevenius/work/google/v8_src/v8/src/objects/object-macros.h:263:14: error: no declaration matches ‘bool v8::internal::HeapObject::IsJSCollator() const’

Does this need i18n perhaps?

\$ gn args --list out/x64.release_gcc | grep i18n
v8_enable_i18n_support
usr/bin/ld: /tmp/ccJOrUMl.o: in function `v8::internal::MaybeHandle<v8::internal::Object>::Check() const':
/home/danielbevenius/work/google/v8_src/v8/src/handles/maybe-handles.h:44: undefined reference to `V8_Fatal(char const*, ...)'
collect2: error: ld returned 1 exit status

V8_Fatal is referenced but not defined in v8_monolith.a:

\$ nm libv8_monolith.a | grep V8_Fatal | c++filt
...
U V8_Fatal(char const*, int, char const*, ...)

And I thought it might be defined in libv8_libbase.a but it is the same there. Actually, I was looking at the wrong symbol. This was not from the logging.o object file. If we look at it we find:

v8_libbase/logging.o:
...
0000000000000000 T V8_Fatal(char const*, int, char const*, ...)

In out/x64.release/obj/logging.o we can find it defined:

\$ nm -C  libv8_libbase.a | grep -A 50 logging.o | grep V8_Fatal
0000000000000000 T V8_Fatal(char const*, int, char const*, ...)

T means that the symbol is in the text section. So if the linker is able to find libv8_libbase.a it should be able to resolve this.

So we need to make sure the linker can find the directory where the libraries are located ('-Wl,-Ldir'), and also that it will include the library ('-Wl,-llibname')

With this in place I can see that the linker can open the archive:

attempt to open /home/danielbevenius/work/google/v8_src/v8/out/x64.release_gcc/obj/libv8_libbase.so failed
attempt to open /home/danielbevenius/work/google/v8_src/v8/out/x64.release_gcc/obj/libv8_libbase.a succeeded
/home/danielbevenius/work/google/v8_src/v8/out/x64.release_gcc/obj/libv8_libbase.a

But I'm still getting the same linking error. If we look closer at the error message we can see that it is maybe-handles.h that is complaining. Could it be that the order is incorrect when linking. libv8_libbase.a needs to come after libv8_monolith Something I noticed is that even though the library libv8_libbase.a is found it does not look like the linker actually reads the object files. I can see that it does this for libv8_monolith.a:

(/home/danielbevenius/work/google/v8_src/v8/out/x64.release_gcc/obj/libv8_monolith.a)common-node-cache.o

Hmm, actually looking at the signature of the function it is V8_Fatal(char const*, ...) and not char const*, int, char const*, ...)

For a debug build it will be:

void V8_Fatal(const char* file, int line, const char* format, ...);

And else

void V8_Fatal(const char* format, ...);

So it looks like I need to set debug to false. With this the V8_Fatal symbol in logging.o is:

\$ nm -C out/x64.release_gcc/obj/v8_libbase/logging.o | grep V8_Fatal
0000000000000000 T V8_Fatal(char const*, ...)

### V8 Build artifacts

What is actually build when you specify v8_monolithic: When this type is chosen the build cannot be a component build, there is an assert for this. In this case a static library build:

if (v8_monolithic) {
# A component build is not monolithic.
assert(!is_component_build)

# Using external startup data would produce separate files.
assert(!v8_use_external_startup_data)
v8_static_library("v8_monolith") {
deps = [
":v8",
":v8_libbase",
":v8_libplatform",
":v8_libsampler",
"//build/win:default_exe_manifest",
]

configs = [ ":internal_config" ]
}
}

Notice that the builtin function is called static_library so is a template that can be found in gni/v8.gni

v8_static_library: This will use source_set instead of creating a static library when compiling. When set to false, the object files that would be included in the linker command. The can speed up the build as the creation of the static libraries is skipped. But this does not really help when linking to v8 externally as from this project.

is_component_build: This will compile targets declared as components as shared libraries. All the v8_components in BUILD.gn will be built as .so files in the output director (not the obj directory which is the case for static libraries).

So the only two options are the v8_monolith or is_component_build where it might be an advantage of being able to build a single component and not have to rebuild the whole monolith at times.

### wee8

libwee8 can be produced which is a library which only supports WebAssembly and does not support JavaScript.

\$ ninja -C out/wee8 wee8

### V8 Internal Isolate

src/execution/isolate.h is where you can find the v8::internal::Isolate.

class V8_EXPORT_PRIVATE Isolate final : private HiddenFactory {

And HiddenFactory is just to allow Isolate to inherit privately from Factory which can be found in src/heap/factory.h.

### Startup Walk through

This section will walk through the start up on V8 by using the hello_world example in this project:

\$ LD_LIBRARY_PATH=../v8_src/v8/out/x64.release_gcc/ lldb ./hello-world
(lldb) br s -n main
Breakpoint 1: where = hello-world`main + 25 at hello-world.cc:41:38, address = 0x0000000000402821
V8::InitializeExternalStartupData(argv[0]);

This call will land in api.cc which will just delegate the call to and internal (internal namespace that is). If you try to step into this function you will just land on the next line in hello_world. This is because we compiled v8 without external start up data so this function will be empty:

\$ objdump -Cd out/x64.release_gcc/obj/v8_base_without_compiler/startup-data-util.o
Disassembly of section .text._ZN2v88internal37InitializeExternalStartupDataFromFileEPKc:

0000000000000000 <v8::internal::InitializeExternalStartupDataFromFile(char const*)>:
0:    c3                       retq

Next, we have:

std::unique_ptr<Platform> platform = platform::NewDefaultPlatform();

This will land in src/libplatform/default-platform.cc which will create a new DefaultPlatform.

Isolate* isolate = Isolate::New(create_params);

This will call Allocate:

Isolate* isolate = Allocate();
Isolate* Isolate::Allocate() {
return reinterpret_cast<Isolate*>(i::Isolate::New());
}

Remember that the internal Isolate can be found in src/execution/isolate.h. In src/execution/isolate.cc we find Isolate::New

Isolate* Isolate::New(IsolateAllocationMode mode) {
std::unique_ptr<IsolateAllocator> isolate_allocator = std::make_unique<IsolateAllocator>(mode);
void* isolate_ptr = isolate_allocator->isolate_memory();
Isolate* isolate = new (isolate_ptr) Isolate(std::move(isolate_allocator));

So we first create an IsolateAllocator instance which will allocate memory for a single Isolate instance. This is then passed into the Isolate constructor, notice the usage of new here, this is just a normal heap allocation.

The default new operator has been deleted and an override provided that takes a void pointer, which is just returned:

void* operator new(size_t, void* ptr) { return ptr; }
void* operator new(size_t) = delete;
void operator delete(void*) = delete;

In this case it just returns the memory allocateed by isolate-memory(). The reason for doing this is that using the new operator not only invokes the new operator but the compiler will also add a call the types constructor passing in the address of the allocated memory.

Isolate::Isolate(std::unique_ptr<i::IsolateAllocator> isolate_allocator)
: isolate_data_(this),
isolate_allocator_(std::move(isolate_allocator)),
id_(isolate_counter.fetch_add(1, std::memory_order_relaxed)),
allocator_(FLAG_trace_zone_stats
? new VerboseAccountingAllocator(&heap_, 256 * KB)
: new AccountingAllocator()),
builtins_(this),
rail_mode_(PERFORMANCE_ANIMATION),
code_event_dispatcher_(new CodeEventDispatcher()),
jitless_(FLAG_jitless),
#if V8_SFI_HAS_UNIQUE_ID
next_unique_sfi_id_(0),
#endif
cancelable_task_manager_(new CancelableTaskManager()) {

Notice that isolate_data_ will be populated by calling the constructor which takes an pointer to an Isolate.

class IsolateData final {
public:
explicit IsolateData(Isolate* isolate) : stack_guard_(isolate) {}

Back in Isolate's constructor we have:

#define ISOLATE_INIT_LIST(V)                                                   \
/* Assembler state. */                                                       \
V(FatalErrorCallback, exception_behavior, nullptr)                           \
...

#define ISOLATE_INIT_EXECUTE(type, name, initial_value) \
name##_ = (initial_value);
ISOLATE_INIT_LIST(ISOLATE_INIT_EXECUTE)
#undef ISOLATE_INIT_EXECUTE

So lets expand the first entry to understand what is going on:

exception_behavior_ = (nullptr);
oom_behavior_ = (nullptr);
event_logger_ = (nullptr);
allow_code_gen_callback_ = (nullptr);
modify_code_gen_callback_ = (nullptr);
allow_wasm_code_gen_callback_ = (nullptr);
wasm_module_callback_ = (&NoExtension);
wasm_instance_callback_ = (&NoExtension);
wasm_streaming_callback_ = (nullptr);
wasm_threads_enabled_callback_ = (nullptr);
wasm_load_source_map_callback_ = (nullptr);
relocatable_top_ = (nullptr);
string_stream_debug_object_cache_ = (nullptr);
string_stream_current_security_token_ = (Object());
api_external_references_ = (nullptr);
external_reference_map_ = (nullptr);
root_index_map_ = (nullptr);
default_microtask_queue_ = (nullptr);
turbo_statistics_ = (nullptr);
code_tracer_ = (nullptr);
per_isolate_assert_data_ = (0xFFFFFFFFu);
promise_reject_callback_ = (nullptr);
snapshot_blob_ = (nullptr);
code_and_metadata_size_ = (0);
bytecode_and_metadata_size_ = (0);
external_script_source_size_ = (0);
is_profiling_ = (false);
num_cpu_profilers_ = (0);
formatting_stack_trace_ = (false);
debug_execution_mode_ = (DebugInfo::kBreakpoints);
code_coverage_mode_ = (debug::CoverageMode::kBestEffort);
type_profile_mode_ = (debug::TypeProfileMode::kNone);
last_stack_frame_info_id_ = (0);
last_console_context_id_ = (0);
inspector_ = (nullptr);
next_v8_call_is_safe_for_termination_ = (false);
only_terminate_in_safe_scope_ = (false);
detailed_source_positions_for_profiling_ = (FLAG_detailed_line_info);
embedder_wrapper_type_index_ = (-1);
embedder_wrapper_object_index_ = (-1);

So all of the entries in this list will become private members of the Isolate class after the preprocessor is finished. There will also be public assessor to get and set these initial values values (which is the last entry in the ISOLATE_INIT_LIST above.

Back in isolate.cc constructor we have:

#define ISOLATE_INIT_ARRAY_EXECUTE(type, name, length) \
memset(name##_, 0, sizeof(type) * length);
ISOLATE_INIT_ARRAY_LIST(ISOLATE_INIT_ARRAY_EXECUTE)
#undef ISOLATE_INIT_ARRAY_EXECUTE
#define ISOLATE_INIT_ARRAY_LIST(V)                                             \
/* SerializerDeserializer state. */                                          \
V(int32_t, jsregexp_static_offsets_vector, kJSRegexpStaticOffsetsVectorSize) \
...

InitializeDefaultEmbeddedBlob();
MicrotaskQueue::SetUpDefaultMicrotaskQueue(this);

After that we have created a new Isolate, we were in this function call:

Isolate* isolate = new (isolate_ptr) Isolate(std::move(isolate_allocator));

After this we will be back in api.cc:

Initialize(isolate, params);
void Isolate::Initialize(Isolate* isolate,
const v8::Isolate::CreateParams& params) {

We are not using any external snapshot data so the following will be false:

if (params.snapshot_blob != nullptr) {
i_isolate->set_snapshot_blob(params.snapshot_blob);
} else {
i_isolate->set_snapshot_blob(i::Snapshot::DefaultSnapshotBlob());
(gdb) p snapshot_blob_
\$7 = (const v8::StartupData *) 0x0
(gdb) n
(gdb) p i_isolate->snapshot_blob_
\$8 = (const v8::StartupData *) 0x7ff92d7d6cf0 <v8::internal::blob>

snapshot_blob_ is also one of the members that was set up with ISOLATE_INIT_LIST. So we are setting up the Isolate instance for creation.

Isolate::Scope isolate_scope(isolate);
if (!i::Snapshot::Initialize(i_isolate)) {

In src/snapshot/snapshot-common.cc we find

bool Snapshot::Initialize(Isolate* isolate) {
...
const v8::StartupData* blob = isolate->snapshot_blob();
Vector<const byte> startup_data = ExtractStartupData(blob);
Vector<const byte> read_only_data = ExtractReadOnlyData(blob);
SnapshotData startup_snapshot_data(MaybeDecompress(startup_data));
SnapshotData read_only_snapshot_data(MaybeDecompress(read_only_data));
StartupDeserializer startup_deserializer(&startup_snapshot_data);
ReadOnlyDeserializer read_only_deserializer(&read_only_snapshot_data);
startup_deserializer.SetRehashability(ExtractRehashability(blob));
read_only_deserializer.SetRehashability(ExtractRehashability(blob));

bool success = isolate->InitWithSnapshot(&read_only_deserializer, &startup_deserializer);

So we get the blob and create deserializers for it which are then passed to isolate->InitWithSnapshot which delegated to Isolate::Init. The blob will have be create previously using mksnapshot (more on this can be found later).

This will use a FOR_EACH_ISOLATE_ADDRESS_NAME macro to assign to the isolate_addresses_ field:

isolate_addresses_[IsolateAddressId::kHandlerAddress] = reinterpret_cast<Address>(handler_address());
isolate_addresses_[IsolateAddressId::kCEntryFPAddress] = reinterpret_cast<Address>(c_entry_fp_address());
isolate_addresses_[IsolateAddressId::kCFunctionAddress] = reinterpret_cast<Address>(c_function_address());
isolate_addresses_[IsolateAddressId::kContextAddress] = reinterpret_cast<Address>(context_address());
isolate_addresses_[IsolateAddressId::kPendingExceptionAddress] = reinterpret_cast<Address>(pending_exception_address());
isolate_addresses_[IsolateAddressId::kPendingHandlerContextAddress] = reinterpret_cast<Address>(pending_handler_context_address());
isolate_addresses_[IsolateAddressId::kPendingHandlerEntrypointAddress] = reinterpret_cast<Address>(pending_handler_entrypoint_address());
isolate_addresses_[IsolateAddressId::kPendingHandlerConstantPoolAddress] = reinterpret_cast<Address>(pending_handler_constant_pool_address());
isolate_addresses_[IsolateAddressId::kPendingHandlerFPAddress] = reinterpret_cast<Address>(pending_handler_fp_address());
isolate_addresses_[IsolateAddressId::kPendingHandlerSPAddress] = reinterpret_cast<Address>(pending_handler_sp_address());
isolate_addresses_[IsolateAddressId::kExternalCaughtExceptionAddress] = reinterpret_cast<Address>(external_caught_exception_address());
isolate_addresses_[IsolateAddressId::kJSEntrySPAddress] = reinterpret_cast<Address>(js_entry_sp_address());

After this we have a number of members that are assigned to:

compilation_cache_ = new CompilationCache(this);
descriptor_lookup_cache_ = new DescriptorLookupCache();
inner_pointer_to_code_cache_ = new InnerPointerToCodeCache(this);
global_handles_ = new GlobalHandles(this);
eternal_handles_ = new EternalHandles();
bootstrapper_ = new Bootstrapper(this);
handle_scope_implementer_ = new HandleScopeImplementer(this);
load_stub_cache_ = new StubCache(this);
store_stub_cache_ = new StubCache(this);
materialized_object_store_ = new MaterializedObjectStore(this);
regexp_stack_ = new RegExpStack();
regexp_stack_->isolate_ = this;
date_cache_ = new DateCache();
heap_profiler_ = new HeapProfiler(heap());
interpreter_ = new interpreter::Interpreter(this);
compiler_dispatcher_ =
new CompilerDispatcher(this, V8::GetCurrentPlatform(), FLAG_stack_size);

After this we have:

isolate_data_.external_reference_table()->Init(this);

This will land in src/codegen/external-reference-table.cc where we have:

void ExternalReferenceTable::Init(Isolate* isolate) {
int index = 0;
Add(kNullAddress, &index);
AddReferences(isolate, &index);
AddBuiltins(&index);
AddRuntimeFunctions(&index);
AddIsolateAddresses(isolate, &index);
AddAccessors(&index);
AddStubCache(isolate, &index);
AddNativeCodeStatsCounters(isolate, &index);
is_initialized_ = static_cast<uint32_t>(true);

CHECK_EQ(kSize, index);
}

void ExternalReferenceTable::Add(Address address, int* index) {
ref_addr_[(*index)++] = address;
}

Address ref_addr_[kSize];

Now, lets take a look at AddReferences:

Add(ExternalReference::abort_with_reason().address(), index);

What are ExternalReferences?
They represent c++ addresses used in generated code.

After that we have AddBuiltins:

static const Address c_builtins[] = {
(reinterpret_cast<v8::internal::Address>(&Builtin_HandleApiCall)),
...

Address Builtin_HandleApiCall(int argc, Address* args, Isolate* isolate);

I can see that the function declaration is in external-reference.h but the implementation is not there. Instead this is defined in src/builtins/builtins-api.cc:

BUILTIN(HandleApiCall) {
(will expand to:)

V8_WARN_UNUSED_RESULT static Object Builtin_Impl_HandleApiCall(
BuiltinArguments args, Isolate* isolate);

V8_NOINLINE static Address Builtin_Impl_Stats_HandleApiCall(
int args_length, Address* args_object, Isolate* isolate) {
BuiltinArguments args(args_length, args_object);
RuntimeCallTimerScope timer(isolate,
RuntimeCallCounterId::kBuiltin_HandleApiCall);
TRACE_EVENT0(TRACE_DISABLED_BY_DEFAULT("v8.runtime"), "V8.Builtin_HandleApiCall");
return CONVERT
}
V8_WARN_UNUSED_RESULT Address Builtin_HandleApiCall(
int args_length, Address* args_object, Isolate* isolate) {
DCHECK(isolate->context().is_null() || isolate->context().IsContext());
if (V8_UNLIKELY(TracingFlags::is_runtime_stats_enabled())) {
return Builtin_Impl_Stats_HandleApiCall(args_length, args_object, isolate);
}
BuiltinArguments args(args_length, args_object);
return CONVERT_OBJECT(Builtin_Impl_HandleApiCall(args, isolate));
}

V8_WARN_UNUSED_RESULT static Object Builtin_Impl_HandleApiCall(
BuiltinArguments args, Isolate* isolate) {
HandleScope scope(isolate);
Handle<JSFunction> function = args.target();
Handle<Object> receiver = args.receiver();
Handle<HeapObject> new_target = args.new_target();
Handle<FunctionTemplateInfo> fun_data(function->shared().get_api_func_data(),
isolate);
if (new_target->IsJSReceiver()) {
RETURN_RESULT_OR_FAILURE(
isolate, HandleApiCallHelper<true>(isolate, function, new_target,
fun_data, receiver, args));
} else {
RETURN_RESULT_OR_FAILURE(
isolate, HandleApiCallHelper<false>(isolate, function, new_target,
fun_data, receiver, args));
}
}

The BUILTIN macro can be found in src/builtins/builtins-utils.h:

#define BUILTIN(name)                                                       \
V8_WARN_UNUSED_RESULT static Object Builtin_Impl_##name(                  \
BuiltinArguments args, Isolate* isolate);
if (setup_delegate_ == nullptr) {
setup_delegate_ = new SetupIsolateDelegate(create_heap_objects);
}

if (!setup_delegate_->SetupHeap(&heap_)) {
V8::FatalProcessOutOfMemory(this, "heap object creation");
return false;
}

This does nothing in the current code path and the code comment says that the heap will be deserialized from the snapshot and true will be returned.

InitializeThreadLocal();
startup_deserializer->DeserializeInto(this);
DisallowHeapAllocation no_gc;
isolate->heap()->IterateSmiRoots(this);
isolate->heap()->IterateStrongRoots(this, VISIT_FOR_SERIALIZATION);
Iterate(isolate, this);
isolate->heap()->IterateWeakRoots(this, VISIT_FOR_SERIALIZATION);
DeserializeDeferredObjects();
RestoreExternalReferenceRedirectors(accessor_infos());
RestoreExternalReferenceRedirectors(call_handler_infos());

In heap.cc we find IterateSmiRootswhich takes a pointer to aRootVistor`. RootVisitor is used for visiting and modifying (optionally) the pointers contains in roots. This is used in garbage collection and also in serializing and deserializing snapshots.

### Roots

RootVistor:

class RootVisitor {
public:
virtual void VisitRootPointers(Root root, const char* description,
FullObjectSlot start, FullObjectSlot end) = 0;

virtual void VisitRootPointer(Root root, const char* description,
FullObjectSlot p) {
VisitRootPointers(root, description, p, p + 1);
}

static const char* RootName(Root root);

Root is an enum in src/object/visitors.h. This enum is generated by a macro and expands to:

enum class Root {
kStringTable,
kExternalStringsTable,
kReadOnlyRootList,
kStrongRootList,
kSmiRootList,
kBootstrapper,
kTop,
kRelocatable,
kDebug,
kCompilationCache,
kHandleScope,
kBuiltins,
kGlobalHandles,
kEternalHandles,
kThreadManager,
kStrongRoots,
kExtensions,
kCodeFlusher,
kPartialSnapshotCache,
kReadOnlyObjectCache,
kWeakCollections,
kWrapperTracing,
kUnknown,
kNumberOfRoots
};

These can be displayed using:

\$ ./test/roots_test --gtest_filter=RootsTest.visitor_roots

Just to keep things clear for myself here, these visitor roots are only used for GC and serialization/deserialization (at least I think so) and should not be confused with the RootIndex enum in src/roots/roots.h.

Lets set a break point in mksnapshot and see if we can find where one of the above Root enum elements is used to make it a little more clear what these are used for.

\$ lldb ../v8_src/v8/out/x64.debug/mksnapshot
(lldb) target create "../v8_src/v8/out/x64.debug/mksnapshot"
Current executable set to '../v8_src/v8/out/x64.debug/mksnapshot' (x86_64).
(lldb) br s -n main
Breakpoint 1: where = mksnapshot`main + 42, address = 0x00000000009303ca
(lldb) r

What this does is that it creates an V8 environment (Platform, Isolate, Context) and then saves it to a file, either a binary file on disk but it can also save it to a .cc file that can be used in programs in which case the binary is a byte array. It does this in much the same way as the hello-world example create a platform and then initializes it, and the creates and initalizes a new Isolate. After the Isolate a new Context will be create using the Isolate. If there was an embedded-src flag passed to mksnaphot it will be run.

StartupSerializer will use the Root enum elements for example and the deserializer will use the same enum elements.

Adding a script to a snapshot:

\$ gdb ../v8_src/v8/out/x64.release_gcc/mksnapshot --embedded-src="\$PWD/embed.js"

TODO: Look into CreateOffHeapTrampolines.

So the VisitRootPointers function takes one of these Root's and visits all those roots. In our case the first Root to be visited is Heap::IterateSmiRoots:

void Heap::IterateSmiRoots(RootVisitor* v) {
ExecutionAccess access(isolate());
v->VisitRootPointers(Root::kSmiRootList, nullptr,
roots_table().smi_roots_begin(),
roots_table().smi_roots_end());
v->Synchronize(VisitorSynchronization::kSmiRootList);
}

And here we can see that it is using Root::kSmiRootList, and passing nullptr for the description argument (I wonder what this is used for?). Next, comes the start and end arguments.

(lldb) p roots_table().smi_roots_begin()
(v8::internal::FullObjectSlot) \$5 = {
v8::internal::SlotBase<v8::internal::FullObjectSlot, unsigned long, 8> = (ptr_ = 50680614097760)
}

We can list all the values of roots_table using:

(lldb) expr -A -- roots_table()

In src/snapshot/deserializer.cc we can find VisitRootPointers:

void Deserializer::VisitRootPointers(Root root, const char* description,
FullObjectSlot start, FullObjectSlot end)
ReadData(FullMaybeObjectSlot(start), FullMaybeObjectSlot(end),
SnapshotSpace::kNew, kNullAddress);

Notice that description is never used. ReadDatais in the same source file:

The class SnapshotByteSource has a data member that is initialized upon construction from a const char* or a Vector. Where is this done?
This was done back in Snapshot::Initialize:

const v8::StartupData* blob = isolate->snapshot_blob();
Vector<const byte> startup_data = ExtractStartupData(blob);
Vector<const byte> read_only_data = ExtractReadOnlyData(blob);
SnapshotData startup_snapshot_data(MaybeDecompress(startup_data));
SnapshotData read_only_snapshot_data(MaybeDecompress(read_only_data));
StartupDeserializer startup_deserializer(&startup_snapshot_data);
(lldb) expr *this
(v8::internal::SnapshotByteSource) \$30 = (data_ = "`\x04", length_ = 125752, position_ = 1)

All the roots in a heap are declared in src/roots/roots.h. You can access the roots using RootsTable via the Isolate using isolate_data->roots() or by using isolate->roots_table. The roots_ field is an array of Address elements:

class RootsTable {
public:
static constexpr size_t kEntriesCount = static_cast<size_t>(RootIndex::kRootListLength);
...
private:
Address roots_[kEntriesCount];
static const char* root_names_[kEntriesCount];

RootIndex is generated by a macro

enum class RootIndex : uint16_t {

The complete enum can be displayed using:

\$ ./test/roots_test --gtest_filter=RootsTest.list_root_index

Lets take a look at an entry:

(lldb) p roots_[(uint16_t)RootIndex::kError_string]
(v8::internal::Address) \$1 = 42318447256121

Now, there are functions in factory which can be used to retrieve these addresses, like factory->Error_string():

(lldb) expr *isolate->factory()->Error_string()
(v8::internal::String) \$9 = {
v8::internal::TorqueGeneratedString<v8::internal::String, v8::internal::Name> = {
v8::internal::Name = {
v8::internal::TorqueGeneratedName<v8::internal::Name, v8::internal::PrimitiveHeapObject> = {
v8::internal::PrimitiveHeapObject = {
v8::internal::TorqueGeneratedPrimitiveHeapObject<v8::internal::PrimitiveHeapObject, v8::internal::HeapObject> = {
v8::internal::HeapObject = {
v8::internal::Object = {
v8::internal::TaggedImpl<v8::internal::HeapObjectReferenceType::STRONG, unsigned long> = (ptr_ = 42318447256121)
}
}
}
}
}
}
}
}
(lldb) expr \$9.length()
(int32_t) \$10 = 5
(lldb) expr \$9.Print()
#Error

These accessor functions declarations are generated by the ROOT_LIST(ROOT_ACCESSOR)) macros:

#define ROOT_ACCESSOR(Type, name, CamelName) inline Handle<Type> name();
ROOT_LIST(ROOT_ACCESSOR)
#undef ROOT_ACCESSOR

And the definitions can be found in src/heap/factory-inl.h and look like this The implementations then look like this:

String ReadOnlyRoots::Error_string() const {
return  String::unchecked_cast(Object(at(RootIndex::kError_string)));
}

Handle<String> ReadOnlyRoots::Error_string_handle() const {
return Handle<String>(&at(RootIndex::kError_string));
}

The unit test roots_test shows and example of this.

This shows the usage of root entries but where are the roots added to this array. roots_ is a member of IsolateData in src/execution/isolate-data.h:

RootsTable roots_;

We can inspect the roots_ content by using the interal Isolate:

(lldb) f
frame #0: 0x00007ffff6261cdf libv8.so`v8::Isolate::Initialize(isolate=0x00000eb900000000, params=0x00007fffffffd0d0) at api.cc:8269:31
8266    void Isolate::Initialize(Isolate* isolate,
8267                             const v8::Isolate::CreateParams& params) {

(lldb) expr i_isolate->isolate_data_.roots_
(v8::internal::RootsTable) \$5 = {
roots_ = {
[0] = 0
[1] = 0
[2] = 0

So we can see that the roots are intially zero:ed out. And the type of roots_ is an array of Address's.

frame #3: 0x00007ffff6c33d58 libv8.so`v8::internal::Deserializer::VisitRootPointers(this=0x00007fffffffcce0, root=kReadOnlyRootList, description=0x0000000000000000, start=FullObjectSlot @ 0x00007fffffffc530, end=FullObjectSlot @ 0x00007fffffffc528) at deserializer.cc:94:11
frame #4: 0x00007ffff6b6212f libv8.so`v8::internal::ReadOnlyRoots::Iterate(this=0x00007fffffffc5c8, visitor=0x00007fffffffcce0) at roots.cc:21:29
frame #5: 0x00007ffff6c46fee libv8.so`v8::internal::ReadOnlyDeserializer::DeserializeInto(this=0x00007fffffffcce0, isolate=0x00000f7500000000) at read-only-deserializer.cc:41:18
frame #6: 0x00007ffff66af631 libv8.so`v8::internal::ReadOnlyHeap::DeseralizeIntoIsolate(this=0x000000000049afb0, isolate=0x00000f7500000000, des=0x00007fffffffcce0) at read-only-heap.cc:85:23
frame #7: 0x00007ffff66af5de libv8.so`v8::internal::ReadOnlyHeap::SetUp(isolate=0x00000f7500000000, des=0x00007fffffffcce0) at read-only-heap.cc:78:53

This will land us in roots.cc ReadOnlyRoots::Iterate(RootVisitor* visitor):

void ReadOnlyRoots::Iterate(RootVisitor* visitor) {
visitor->VisitRootPointers(Root::kReadOnlyRootList, nullptr,
FullObjectSlot(read_only_roots_),
FullObjectSlot(&read_only_roots_[kEntriesCount]));
visitor->Synchronize(VisitorSynchronization::kReadOnlyRootList);
}

Deserializer::VisitRootPointers calls Deserializer::ReadData and the roots_ array is still zero:ed out when we enter this function.

void Deserializer::VisitRootPointers(Root root, const char* description,
FullObjectSlot start, FullObjectSlot end) {
ReadData(FullMaybeObjectSlot(start), FullMaybeObjectSlot(end),
SnapshotSpace::kNew, kNullAddress);

Notice that we called VisitRootPointer and pased in Root:kReadOnlyRootList, nullptr (the description), and start and end addresses as FullObjectSlots. The signature of VisitRootPointers looks like this:

virtual void VisitRootPointers(Root root, const char* description,
FullObjectSlot start, FullObjectSlot end)

In our case we are using the address of read_only_roots_ from src/roots/roots.h and the end is found by using the static member of ReadOnlyRoots::kEntrysCount.

The switch statement in ReadData is generated by macros so lets take a look at an expanded snippet to understand what is going on:

template <typename TSlot>
bool Deserializer::ReadData(TSlot current, TSlot limit,
SnapshotSpace source_space,
Address current_object_address) {
Isolate* const isolate = isolate_;
...
while (current < limit) {
byte data = source_.Get();

So current is the start address of the read_only_list and limit the end. source_ is a member of ReadOnlyDeserializer and is of type SnapshotByteSource.

source_ got populated back in Snapshot::Initialize(internal_isolate):

const v8::StartupData* blob = isolate->snapshot_blob();
Vector<const byte> read_only_data = ExtractReadOnlyData(blob);
ReadOnlyDeserializer read_only_deserializer(&read_only_snapshot_data);

And ReadOnlyDeserializer extends Deserialier (src/snapshot/deserializer.h) which has a constructor that sets the source_ member to data->Payload(). So source_ is will be pointer to an instance of SnapshotByteSource which can be found in src/snapshot-source-sink.h:

class SnapshotByteSource final {
public:
SnapshotByteSource(const char* data, int length)
: data_(reinterpret_cast<const byte*>(data)),
length_(length),
position_(0) {}

byte Get() {
return data_[position_++];
}
...
private:
const byte* data_;
int length_;
int posistion_;

Alright, so we are calling source_.Get() which we can see returns the current entry from the byte array data_ and increment the position. So with that in mind lets take closer look at the switch statment:

while (current < limit) {
byte data = source_.Get();
switch (data) {
case kNewObject + static_cast<int>(SnapshotSpace::kNew):
current = ReadDataCase<TSlot, kNewObject, SnapshotSpace::kNew>(isolate, current, current_object_address, data, write_barrier_needed);
break;
case kNewObject + static_cast<int>(SnapshotSpace::kOld):
[[clang::fallthrough]];
case kNewObject + static_cast<int>(SnapshotSpace::kCode):
[[clang::fallthrough]];
case kNewObject + static_cast<int>(SnapshotSpace::kMap):
static_assert((static_cast<int>(SnapshotSpace::kMap) & ~kSpaceMask) == 0, "(static_cast<int>(SnapshotSpace::kMap) & ~kSpaceMask) == 0");
[[clang::fallthrough]];
...

We can see that switch statement will assign the passed-in current with a new instance of ReadDataCase.

current = ReadDataCase<TSlot, kNewObject, SnapshotSpace::kNew>(isolate,
current, current_object_address, data, write_barrier_needed);

Notice that kNewObject is the type of SerializerDeserliazer::Bytecode that is to be read (I think), this enum can be found in src/snapshot/serializer-common.h. TSlot I think stands for the "Type of Slot", which in our case is a FullMaybyObjectSlot.

HeapObject heap_object;
if (bytecode == kNewObject) {
heap_object = ReadObject(space);

ReadObject is also in deserializer.cc :

Address address = allocator()->Allocate(space, size);
HeapObject obj = HeapObject::FromAddress(address);
isolate_->heap()->OnAllocationEvent(obj, size);

Alright, lets set a watch point on the roots_ array to see when the first entry
is populated and try to figure this out that way:
```console
(lldb) watch set variable  isolate->isolate_data_.roots_.roots_[0]
Watchpoint created: Watchpoint 5: addr = 0xf7500000080 size = 8 state = enabled type = w
declare @ '/home/danielbevenius/work/google/v8_src/v8/src/heap/read-only-heap.cc:28'
watchpoint spec = 'isolate->isolate_data_.roots_.roots_[0]'
new value: 0
(lldb) r

Watchpoint 5 hit:
old value: 0
new value: 16995320070433
Process 1687448 stopped
* thread #1, name = 'hello-world', stop reason = watchpoint 5
frame #0: 0x00007ffff664e5b1 libv8.so`v8::internal::FullMaybeObjectSlot::store(this=0x00007fffffffc3b0, value=MaybeObject @ 0x00007fffffffc370) const at slots-inl.h:74:1
71
72      void FullMaybeObjectSlot::store(MaybeObject value) const {
73        *location() = value.ptr();
-> 74      }
75

We can verify that location actually contains the address of roots_[0]:

(lldb) expr -f hex -- this->ptr_
(v8::internal::Address) \$164 = 0x00000f7500000080
(lldb) expr -f hex -- &this->isolate_->isolate_data_.roots_.roots_[0]
(v8::internal::Address *) \$171 = 0x00000f7500000080

(lldb) expr -f hex -- value.ptr()
(unsigned long) \$184 = 0x00000f7508040121
(lldb) expr -f hex -- isolate_->isolate_data_.roots_.roots_[0]
(v8::internal::Address) \$183 = 0x00000f7508040121

The first entry is free_space_map.

(lldb) expr v8::internal::Map::unchecked_cast(v8::internal::Object(value->ptr()))
(v8::internal::Map) \$185 = {
v8::internal::HeapObject = {
v8::internal::Object = {
v8::internal::TaggedImpl<v8::internal::HeapObjectReferenceType::STRONG, unsigned long> = (ptr_ = 16995320070433)
}
}

Next, we will go through the while loop again:

(lldb) expr -f hex -- isolate_->isolate_data_.roots_.roots_[1]
(v8::internal::Address) \$191 = 0x0000000000000000
(lldb) expr -f hex -- &isolate_->isolate_data_.roots_.roots_[1]
(v8::internal::Address *) \$192 = 0x00000f7500000088
(lldb) expr -f hex -- location()
(v8::internal::SlotBase<v8::internal::FullMaybeObjectSlot, unsigned long, 8>::TData *) \$194 = 0x00000f7500000088

Notice that in Deserializer::Write we have:

dest.store(value);
return dest + 1;

And it's current value is:

(v8::internal::Address) \$197 = 0x00000f7500000088

Which is the same address as roots_[1] that we just wrote to.

If we know the type that an Address points to we can use the Type::cast(Object obj) to cast it into a pointer of that type. I think this works will all types.

(lldb) expr -A -f hex  -- v8::internal::Oddball::cast(v8::internal::Object(isolate_->isolate_data_.roots_.roots_[4]))
(v8::internal::Oddball) \$258 = {
v8::internal::TorqueGeneratedOddball<v8::internal::Oddball, v8::internal::PrimitiveHeapObject> = {
v8::internal::PrimitiveHeapObject = {
v8::internal::TorqueGeneratedPrimitiveHeapObject<v8::internal::PrimitiveHeapObject, v8::internal::HeapObject> = {
v8::internal::HeapObject = {
v8::internal::Object = {
v8::internal::TaggedImpl<v8::internal::HeapObjectReferenceType::STRONG, unsigned long> = (ptr_ = 0x00000f750804030d)
}
}
}
}
}
}

You can also just cast it to an object and try printing it:

(lldb) expr -A -f hex  -- v8::internal::Object(isolate_->isolate_data_.roots_.roots_[4]).Print()
#undefined

This is actually the Oddball UndefinedValue so it makes sense in this case I think. With this value in the roots_ array we can use the function ReadOnlyRoots::undefined_value():

(lldb) expr v8::internal::ReadOnlyRoots(&isolate_->heap_).undefined_value()
(v8::internal::Oddball) \$265 = {
v8::internal::TorqueGeneratedOddball<v8::internal::Oddball, v8::internal::PrimitiveHeapObject> = {
v8::internal::PrimitiveHeapObject = {
v8::internal::TorqueGeneratedPrimitiveHeapObject<v8::internal::PrimitiveHeapObject, v8::internal::HeapObject> = {
v8::internal::HeapObject = {
v8::internal::Object = {
v8::internal::TaggedImpl<v8::internal::HeapObjectReferenceType::STRONG, unsigned long> = (ptr_ = 16995320070925)
}
}
}
}
}
}

So how are these roots used, take the above undefined_value for example?
Well most things (perhaps all) that are needed go via the Factory which the internal Isolate is a type of. In factory we can find:

Handle<Oddball> Factory::undefined_value() {
return Handle<Oddball>(&isolate()->roots_table()[RootIndex::kUndefinedValue]);
}

Notice that this is basically what we did in the debugger before but here it is wrapped in Handle so that it can be tracked by the GC.

The unit test isolate_test explores the internal isolate and has example of usages of the above mentioned methods.

InitwithSnapshot will call Isolate::Init:

bool Isolate::Init(ReadOnlyDeserializer* read_only_deserializer,
StartupDeserializer* startup_deserializer) {

#define ASSIGN_ELEMENT(CamelName, hacker_name)                  \
isolate_addresses_[IsolateAddressId::k##CamelName##Address] = \
reinterpret_cast<Address>(hacker_name##_address());
FOR_EACH_ISOLATE_ADDRESS_NAME(ASSIGN_ELEMENT)
#undef ASSIGN_ELEMENT
Address isolate_addresses_[kIsolateAddressCount + 1] = {};
(gdb) p isolate_addresses_
\$16 = {0 <repeats 13 times>}

Lets take a look at the expanded code in Isolate::Init:

\$ clang++ -I./out/x64.release/gen -I. -I./include -E src/execution/isolate.cc > output
isolate_addresses_[IsolateAddressId::kHandlerAddress] = reinterpret_cast<Address>(handler_address());
isolate_addresses_[IsolateAddressId::kCEntryFPAddress] = reinterpret_cast<Address>(c_entry_fp_address());
isolate_addresses_[IsolateAddressId::kCFunctionAddress] = reinterpret_cast<Address>(c_function_address());
isolate_addresses_[IsolateAddressId::kContextAddress] = reinterpret_cast<Address>(context_address());
isolate_addresses_[IsolateAddressId::kPendingExceptionAddress] = reinterpret_cast<Address>(pending_exception_address());
isolate_addresses_[IsolateAddressId::kPendingHandlerContextAddress] = reinterpret_cast<Address>(pending_handler_context_address());
isolate_addresses_[IsolateAddressId::kPendingHandlerEntrypointAddress] = reinterpret_cast<Address>(pending_handler_entrypoint_address());
isolate_addresses_[IsolateAddressId::kPendingHandlerConstantPoolAddress] = reinterpret_cast<Address>(pending_handler_constant_pool_address());
isolate_addresses_[IsolateAddressId::kPendingHandlerFPAddress] = reinterpret_cast<Address>(pending_handler_fp_address());
isolate_addresses_[IsolateAddressId::kPendingHandlerSPAddress] = reinterpret_cast<Address>(pending_handler_sp_address());
isolate_addresses_[IsolateAddressId::kExternalCaughtExceptionAddress] = reinterpret_cast<Address>(external_caught_exception_address());
isolate_addresses_[IsolateAddressId::kJSEntrySPAddress] = reinterpret_cast<Address>(js_entry_sp_address());

Then functions, like handler_address() are implemented as:

inline Address* handler_address() { return &thread_local_top()->handler_; }
(gdb) x/x isolate_addresses_[0]
0x1a3500003240:    0x00000000

At this point in the program we have only set the entries to point contain the addresses specified in ThreadLocalTop, At the time there are initialized the will mostly be initialized to kNullAddress:

static const Address kNullAddress = 0;

And notice that the functions above return pointers so later these pointers can be updated to point to something. What/when does this happen? Lets continue and find out...

Back in Isolate::Init we have:

compilation_cache_ = new CompilationCache(this);
descriptor_lookup_cache_ = new DescriptorLookupCache();
inner_pointer_to_code_cache_ = new InnerPointerToCodeCache(this);
global_handles_ = new GlobalHandles(this);
eternal_handles_ = new EternalHandles();
bootstrapper_ = new Bootstrapper(this);
handle_scope_implementer_ = new HandleScopeImplementer(this);
load_stub_cache_ = new StubCache(this);
store_stub_cache_ = new StubCache(this);
materialized_object_store_ = new MaterializedObjectStore(this);
regexp_stack_ = new RegExpStack();
regexp_stack_->isolate_ = this;
date_cache_ = new DateCache();
heap_profiler_ = new HeapProfiler(heap());
interpreter_ = new interpreter::Interpreter(this);

compiler_dispatcher_ =
new CompilerDispatcher(this, V8::GetCurrentPlatform(), FLAG_stack_size);

// SetUp the object heap.
DCHECK(!heap_.HasBeenSetUp());
heap_.SetUp();

...
InitializeThreadLocal();

Lets take a look at InitializeThreadLocal

void Isolate::InitializeThreadLocal() {
thread_local_top()->Initialize(this);
clear_pending_exception();
clear_pending_message();
clear_scheduled_exception();
}
void Isolate::clear_pending_exception() {
DCHECK(!thread_local_top()->pending_exception_.IsException(this));
thread_local_top()->pending_exception_ = ReadOnlyRoots(this).the_hole_value();
}

ReadOnlyRoots

#define ROOT_ACCESSOR(Type, name, CamelName) \
V8_INLINE class Type name() const;         \
V8_INLINE Handle<Type> name##_handle() const;

READ_ONLY_ROOT_LIST(ROOT_ACCESSOR)
#undef ROOT_ACCESSOR

This will expand to a number of function declarations that looks like this:

\$ clang++ -I./out/x64.release/gen -I. -I./include -E src/roots/roots.h > output
inline __attribute__((always_inline)) class Map free_space_map() const;
inline __attribute__((always_inline)) Handle<Map> free_space_map_handle() const;

The Map class is what all HeapObject use to describe their structure. Notice that there is also a Handle declared. These are generated by a macro in roots-inl.h:

Map ReadOnlyRoots::free_space_map() const {
((void) 0);
return Map::unchecked_cast(Object(at(RootIndex::kFreeSpaceMap)));
}

Handle<Map> ReadOnlyRoots::free_space_map_handle() const {
((void) 0);
return Handle<Map>(&at(RootIndex::kFreeSpaceMap));
}

Notice that this is using the RootIndex enum that was mentioned earlier:

return Map::unchecked_cast(Object(at(RootIndex::kFreeSpaceMap)));

In object/map.h there is the following line:

DECL_CAST(Map)

Which can be found in objects/object-macros.h:

#define DECL_CAST(Type)                                 \
V8_INLINE static Type cast(Object object);            \
V8_INLINE static Type unchecked_cast(Object object) { \
return bit_cast<Type>(object);                      \
}

This will expand to something like

static Map cast(Object object);
static Map unchecked_cast(Object object) {
return bit_cast<Map>(object);
}

And the Object part is the Object contructor that takes an Address:

explicit constexpr Object(Address ptr) : TaggedImpl(ptr) {}

That leaves the at function which is a private function in ReadOnlyRoots:

V8_INLINE Address& at(RootIndex root_index) const;

So we are now back in Isolate::Init after the call to InitializeThreadLocal we have:

setup_delegate_->SetupBuiltins(this);

In the following line in api.cc, where does i::OBJECT_TEMPLATE_INFO_TYPE come from:

i::Handle<i::Struct> struct_obj = isolate->factory()->NewStruct(
i::OBJECT_TEMPLATE_INFO_TYPE, i::AllocationType::kOld);

### InstanceType

The enum InstanceType is defined in src/objects/instance-type.h:

#include "torque-generated/instance-types-tq.h"

enum InstanceType : uint16_t {
...
#define MAKE_TORQUE_INSTANCE_TYPE(TYPE, value) TYPE = value,
TORQUE_ASSIGNED_INSTANCE_TYPES(MAKE_TORQUE_INSTANCE_TYPE)
#undef MAKE_TORQUE_INSTANCE_TYPE
...
};

And in gen/torque-generated/instance-types-tq.h we can find:

#define TORQUE_ASSIGNED_INSTANCE_TYPES(V) \
...
V(OBJECT_TEMPLATE_INFO_TYPE, 79) \
...

There is list in src/objects/objects-definitions.h:

#define STRUCT_LIST_GENERATOR_BASE(V, _)                                      \
...
V(_, OBJECT_TEMPLATE_INFO_TYPE, ObjectTemplateInfo, object_template_info)   \
...
template <typename Impl>
Handle<Struct> FactoryBase<Impl>::NewStruct(InstanceType type,
AllocationType allocation) {
Map map = Map::GetInstanceTypeMap(read_only_roots(), type);

If we look in Map::GetInstanceTypeMap in map.cc we find:

Map map;
switch (type) {
#define MAKE_CASE(TYPE, Name, name) \
case TYPE:                        \
map = roots.name##_map();       \
break;
STRUCT_LIST(MAKE_CASE)
#undef MAKE_CASE

Now, we know that our type is:

(gdb) p type
\$1 = v8::internal::OBJECT_TEMPLATE_INFO_TYPE
map = roots.object_template_info_map();       \

And we can inspect the output of the preprocessor of roots.cc and find:

Map ReadOnlyRoots::object_template_info_map() const {
((void) 0);
return Map::unchecked_cast(Object(at(RootIndex::kObjectTemplateInfoMap)));
}

And this is something we have seen before.

One things I ran into was wanting to print the InstanceType using the overloaded << operator which is defined for the InstanceType in objects.cc.

std::ostream& operator<<(std::ostream& os, InstanceType instance_type) {
switch (instance_type) {
#define WRITE_TYPE(TYPE) \
case TYPE:             \
return os << #TYPE;
INSTANCE_TYPE_LIST(WRITE_TYPE)
#undef WRITE_TYPE
}
UNREACHABLE();
}

The code I'm using is the followig:

i::InstanceType type = map.instance_type();
std::cout << "object_template_info_map type: " << type << '\n';

This will cause the UNREACHABLE() function to be called and a Fatal error thrown. But note that the following line works:

std::cout << "object_template_info_map type: " << v8::internal::OBJECT_TEMPLATE_INFO_TYPE << '\n';

And prints

object_template_info_map type: OBJECT_TEMPLATE_INFO_TYPE

In the switch/case block above the case for this value is:

case OBJECT_TEMPLATE_INFO_TYPE:
return os << "OBJECT_TEMPLATE_INFO_TYPE"

When map.instance_type() is called, it returns a value of 1023 but the value of OBJECT_TEMPLATE_INFO_TYPE is:

OBJECT_TEMPLATE_INFO_TYPE = 79

And we can confirm this using:

std::cout << "object_template_info_map type: " << static_cast<uint16_t>(v8::internal::OBJECT_TEMPLATE_INFO_TYPE) << '\n';

Which will print:

object_template_info_map type: 79

### Context creation

When we create a new context using:

Local<ObjectTemplate> global = ObjectTemplate::New(isolate_);
Local<Context> context = Context::New(isolate_, nullptr, global);

The Context class in include/v8.h declares New as follows:

static Local<Context> New(Isolate* isolate,
ExtensionConfiguration* extensions = nullptr,
MaybeLocal<ObjectTemplate> global_template = MaybeLocal<ObjectTemplate>(),
MaybeLocal<Value> global_object = MaybeLocal<Value>(),
DeserializeInternalFieldsCallback internal_fields_deserializer = DeserializeInternalFieldsCallback(),
MicrotaskQueue* microtask_queue = nullptr);

When a step into Context::New(isolate_, nullptr, global) this will first break in the constructor of DeserializeInternalFieldsCallback in v8.h which has default values for the callback function and data_args (both are nullptr). After that gdb will break in MaybeLocal and setting val_ to nullptr. Next it will break in Local::operator* for the value of global which is then passed to the MaybeLocalv8::ObjectTemplate constructor. After those break points the break point will be in api.cc and v8::Context::New. New will call NewContext in api.cc.

There will be some checks and logging/tracing and then a call to CreateEnvironment:

i::Handle<i::Context> env = CreateEnvironment<i::Context>(
isolate,
extensions,
global_template,
global_object,
context_snapshot_index,
embedder_fields_deserializer,
microtask_queue);

The first line in CreateEnironment is:

ENTER_V8_FOR_NEW_CONTEXT(isolate);

Which is a macro defined in api.cc

i::VMState<v8::OTHER> __state__((isolate)); \
i::DisallowExceptions __no_exceptions__((isolate))

So the first break point we break on will be the execution/vm-state-inl.h and VMState's constructor:

template <StateTag Tag>
VMState<Tag>::VMState(Isolate* isolate)
: isolate_(isolate), previous_tag_(isolate->current_vm_state()) {
isolate_->set_current_vm_state(Tag);
}

In gdb you'll see this:

(gdb) s
v8::internal::VMState<(v8::StateTag)5>::VMState (isolate=0x372500000000, this=<synthetic pointer>) at ../../src/api/api.cc:6005
6005          context_snapshot_index, embedder_fields_deserializer, microtask_queue);
(gdb) s
v8::internal::Isolate::current_vm_state (this=0x372500000000) at ../../src/execution/isolate.h:1072
1072      THREAD_LOCAL_TOP_ACCESSOR(StateTag, current_vm_state)

Notice that VMState's constructor sets its previous_tag_ to isolate->current_vm_state() which is generated by the macro THREAD_LOCAL_TOP_ACCESSOR. The next break point will be:

#0  v8::internal::PerIsolateAssertScopeDebugOnly<(v8::internal::PerIsolateAssertType)5, false>::PerIsolateAssertScopeDebugOnly (
isolate=0x372500000000, this=0x7ffc7b51b500) at ../../src/common/assert-scope.h:107
107      explicit PerIsolateAssertScopeDebugOnly(Isolate* isolate)

We can find that DisallowExceptions is defined in src/common/assert-scope.h as:

using DisallowExceptions =
PerIsolateAssertScopeDebugOnly<NO_EXCEPTION_ASSERT, false>;

After all that we can start to look at the code in CreateEnvironment.

// Create the environment.
InvokeBootstrapper<ObjectType> invoke;
result = invoke.Invoke(isolate, maybe_proxy, proxy_template, extensions,
context_snapshot_index, embedder_fields_deserializer,
microtask_queue);

template <typename ObjectType>
struct InvokeBootstrapper;

template <>
struct InvokeBootstrapper<i::Context> {
i::Handle<i::Context> Invoke(
i::Isolate* isolate, i::MaybeHandle<i::JSGlobalProxy> maybe_global_proxy,
v8::Local<v8::ObjectTemplate> global_proxy_template,
v8::ExtensionConfiguration* extensions, size_t context_snapshot_index,
v8::DeserializeInternalFieldsCallback embedder_fields_deserializer,
v8::MicrotaskQueue* microtask_queue) {
return isolate->bootstrapper()->CreateEnvironment(
maybe_global_proxy, global_proxy_template, extensions,
context_snapshot_index, embedder_fields_deserializer, microtask_queue);
}
};

Bootstrapper can be found in src/init/bootstrapper.cc:

HandleScope scope(isolate_);
Handle<Context> env;
{
Genesis genesis(isolate_, maybe_global_proxy, global_proxy_template,
context_snapshot_index, embedder_fields_deserializer,
microtask_queue);
env = genesis.result();
if (env.is_null() || !InstallExtensions(env, extensions)) {
return Handle<Context>();
}
}

Notice that the break point will be in the HandleScope constructor. Then a new instance of Genesis is created which performs some actions in its constructor.

global_proxy = isolate->factory()->NewUninitializedJSGlobalProxy(instance_size);

This will land in factory.cc:

Handle<Map> map = NewMap(JS_GLOBAL_PROXY_TYPE, size);

size will be 16 in this case. NewMap is declared in factory.h which has default values for its parameters:

Handle<Map> NewMap(InstanceType type, int instance_size,
ElementsKind elements_kind = TERMINAL_FAST_ELEMENTS_KIND,
int inobject_properties = 0);

In Factory::InitializeMap we have the following check:

DCHECK_EQ(map.GetInObjectProperties(), inobject_properties);

Remember that I called Context::New with the following arguments:

Local<ObjectTemplate> global = ObjectTemplate::New(isolate_);
Local<Context> context = Context::New(isolate_, nullptr, global);

### TaggedImpl

Has a single private member which is declared as:

StorageType ptr_;

An instance can be created using:

i::TaggedImpl<i::HeapObjectReferenceType::STRONG, i::Address>  tagged{};

Storage type can also be Tagged_t which is defined in globals.h:

using Tagged_t = uint32_t;

It looks like it can be a different value when using pointer compression.

### Object (internal)

This class extends TaggedImpl:

class Object : public TaggedImpl<HeapObjectReferenceType::STRONG, Address> {

An Object can be created using the default constructor, or by passing in an Address which will delegate to TaggedImpl constructors. Object itself does not have any members (apart from ptr_ which is inherited from TaggedImpl that is). So if we create an Object on the stack this is like a pointer/reference to an object:

+------+
|Object|
|------|
|ptr_  |---->
+------+

Now, ptr_ is a TaggedImpl so it would be a Smi in which case it would just contains the value directly, for example a small integer:

+------+
|Object|
|------|
|  18  |
+------+

### Handle

A Handle is similar to a Object and ObjectSlot in that it also contains an Address member (called location_ and declared in HandleBase), but with the difference is that Handles can be relocated by the garbage collector.

### NewContext

When we create a new context using:

const v8::Local<v8::ObjectTemplate> obt = v8::Local<v8::ObjectTemplate>();
v8::Handle<v8::Context> context = v8::Context::New(isolate_, nullptr, obt);

The above is using the static function New declared in include/v8.h

static Local<Context> New(
Isolate* isolate,
ExtensionConfiguration* extensions = nullptr,
MaybeLocal<ObjectTemplate> global_template = MaybeLocal<ObjectTemplate>(),
MaybeLocal<Value> global_object = MaybeLocal<Value>(),
DeserializeInternalFieldsCallback internal_fields_deserializer = DeserializeInternalFieldsCallback(),
MicrotaskQueue* microtask_queue = nullptr);

The implementation for this function can be found in src/api/api.cc How does a Local become a MaybeLocal in this above case?
This is because MaybeLocal has a constructor that takes a Local<S> and this will be casted into the val_ member of the MaybeLocal instance.

TODO

### What is the difference between a Local and a Handle?

Currently, the torque generator will generate Print functions that look like the following:

template <>
void TorqueGeneratedEnumCache<EnumCache, Struct>::EnumCachePrint(std::ostream& os) {
this->PrintHeader(os, "TorqueGeneratedEnumCache");
os << "\n - keys: " << Brief(this->keys());
os << "\n - indices: " << Brief(this->indices());
os << "\n";
}

Notice the last line where the newline character is printed as a string. This would just be a char instead '\n'.

There are a number of things that need to happen only once upon startup for each process. These things are placed in V8::InitializeOncePerProcessImpl which can be found in src/init/v8.cc. This is called by v8::V8::Initialize().

CpuFeatures::Probe(false);
ElementsAccessor::InitializeOncePerProcess();
Bootstrapper::InitializeOncePerProcess();
CallDescriptors::InitializeOncePerProcess();
wasm::WasmEngine::InitializeOncePerProcess();

ElementsAccessor populates the accessor_array with Elements listed in ELEMENTS_LIST. TODO: take a closer look at Elements.

v8::Isolate::Initialize will set up the heap.

i_isolate->heap()->ConfigureHeap(params.constraints);

It is when we create an new Context that Genesis is created. This will call Snapshot::NewContextFromSnapshot. So the context is read from the StartupData* blob with ExtractContextData(blob).

What is the global proxy?

### Builtins runtime error

Builtins is a member of Isolate and an instance is created by the Isolate constructor. We can inspect the value of initialized_ and that it is false:

(gdb) p *this->builtins()
\$3 = {static kNoBuiltinId = -1, static kFirstWideBytecodeHandler = 1248, static kFirstExtraWideBytecodeHandler = 1398,
static kLastBytecodeHandlerPlusOne = 1548, static kAllBuiltinsAreIsolateIndependent = true, isolate_ = 0x0, initialized_ = false,
js_entry_handler_offset_ = 0}

The above is printed form Isolate's constructor and it is not changes in the contructor.

This is very strange, while I though that the initialized_ was being updated it now looks like there might be two instances, one with has this value as false and the other as true. And also one has a nullptr as the isolate and the other as an actual value. For example, when I run the hello-world example:

\$4 = (v8::internal::Builtins *) 0x33b20000a248
(gdb) p &builtins_
\$5 = (v8::internal::Builtins *) 0x33b20000a248

Notice that these are poiting to the same location in memory.

(gdb) p &builtins_
\$1 = (v8::internal::Builtins *) 0x25210000a248
(gdb) p builtins()
\$2 = (v8::internal::Builtins *) 0x25210000a228

Alright, so after looking into this closer I noticed that I was including internal headers in the test itself. When I include src/builtins/builtins.h I will get an implementation of isolate->builtins() in the object file which is in the shared library libv8.so, but the field is part of object file that is part of the cctest. This will be a different method and not the method that is in libv8_v8.so shared library.

As I'm only interested in exploring v8 internals and my goal is only for each unit test to verify my understanding I've statically linked those object files needed, like builtins.o and code.o to the test.

Fatal error in ../../src/snapshot/read-only-deserializer.cc, line 35
# Debug check failed: !isolate->builtins()->is_initialized().
#
#
#
#FailureMessage Object: 0x7ffed92ceb20
==== C stack trace ===============================

/home/danielbevenius/work/google/v8_src/v8/out/x64.release_gcc/libv8_libbase.so(v8::base::debug::StackTrace::StackTrace()+0x1d) [0x7fabe6c348c1]
/home/danielbevenius/work/google/v8_src/v8/out/x64.release_gcc/libv8_libplatform.so(+0x652d9) [0x7fabe6cac2d9]
/home/danielbevenius/work/google/v8_src/v8/out/x64.release_gcc/libv8_libbase.so(V8_Fatal(char const*, int, char const*, ...)+0x172) [0x7fabe6c2416d]
/home/danielbevenius/work/google/v8_src/v8/out/x64.release_gcc/libv8_libbase.so(v8::base::SetPrintStackTrace(void (*)())+0) [0x7fabe6c23de0]
/home/danielbevenius/work/google/v8_src/v8/out/x64.release_gcc/libv8_libbase.so(V8_Dcheck(char const*, int, char const*)+0x2d) [0x7fabe6c241b1]
/home/danielbevenius/work/google/v8_src/v8/out/x64.release_gcc/libv8.so(v8::internal::ReadOnlyDeserializer::DeserializeInto(v8::internal::Isolate*)+0x192) [0x7fabe977c468]
/home/danielbevenius/work/google/v8_src/v8/out/x64.release_gcc/libv8.so(v8::internal::ReadOnlyHeap::DeseralizeIntoIsolate(v8::internal::Isolate*, v8::internal::ReadOnlyDeserializer*)+0x4f) [0x7fabe91e5a7d]
/home/danielbevenius/work/google/v8_src/v8/out/x64.release_gcc/libv8.so(v8::internal::ReadOnlyHeap::SetUp(v8::internal::Isolate*, v8::internal::ReadOnlyDeserializer*)+0x66) [0x7fabe91e5a2a]
/home/danielbevenius/work/google/v8_src/v8/out/x64.release_gcc/libv8.so(v8::internal::Isolate::Init(v8::internal::ReadOnlyDeserializer*, v8::internal::StartupDeserializer*)+0x70b) [0x7fabe90633bb]
/home/danielbevenius/work/google/v8_src/v8/out/x64.release_gcc/libv8.so(v8::internal::Isolate::InitWithSnapshot(v8::internal::ReadOnlyDeserializer*, v8::internal::StartupDeserializer*)+0x7b) [0x7fabe906299f]
/home/danielbevenius/work/google/v8_src/v8/out/x64.release_gcc/libv8.so(v8::internal::Snapshot::Initialize(v8::internal::Isolate*)+0x1e9) [0x7fabe978d941]
/home/danielbevenius/work/google/v8_src/v8/out/x64.release_gcc/libv8.so(v8::Isolate::Initialize(v8::Isolate*, v8::Isolate::CreateParams const&)+0x33d) [0x7fabe8d999e3]
/home/danielbevenius/work/google/v8_src/v8/out/x64.release_gcc/libv8.so(v8::Isolate::New(v8::Isolate::CreateParams const&)+0x28) [0x7fabe8d99b66]
./test/builtins_test() [0x4135a2]
./test/builtins_test() [0x43a1b7]
./test/builtins_test() [0x434c99]
./test/builtins_test() [0x41a3a7]
./test/builtins_test() [0x41aafb]
./test/builtins_test() [0x41b085]
./test/builtins_test() [0x4238e0]
./test/builtins_test() [0x43b1aa]
./test/builtins_test() [0x435773]
./test/builtins_test() [0x422836]
./test/builtins_test() [0x412ea4]
./test/builtins_test() [0x412e3d]
/lib64/libc.so.6(__libc_start_main+0xf3) [0x7fabe66b31a3]
./test/builtins_test() [0x412d5e]
Illegal instruction (core dumped)

The issue here is that I'm including the header in the test, which means that code will be in the object code of the test, while the implementation part will be in the linked dynamic library which is why these are pointing to different areas in memory. The one retreived by the function call will use the

### Goma

I've goma referenced in a number of places so just makeing a note of what it is here: Goma is googles internal distributed compile service.

### WebAssembly

This section is going to take a closer look at how wasm works in V8.

We can use a wasm module like this:

const buffer = fixtures.readSync('add.wasm');
const module = new WebAssembly.Module(buffer);
const instance = new WebAssembly.Instance(module);
instance.exports.add(3, 4);

Where is the WebAssembly object setup? We have sen previously that objects and function are added in src/init/bootstrapper.cc and for Wasm there is a function named Genisis::InstallSpecialObjects which calls:

WasmJs::Install(isolate, true);

This call will land in src/wasm/wasm-js.cc where we can find:

void WasmJs::Install(Isolate* isolate, bool exposed_on_global_object) {
...
Handle<String> name = v8_str(isolate, "WebAssembly")
...
NewFunctionArgs args = NewFunctionArgs::ForFunctionWithoutCode(
name, isolate->strict_function_map(), LanguageMode::kStrict);
Handle<JSFunction> cons = factory->NewFunction(args);
JSFunction::SetPrototype(cons, isolate->initial_object_prototype());
Handle<JSObject> webassembly =
factory->NewJSObject(cons, AllocationType::kOld);
JSObject::AddProperty(isolate, webassembly, factory->to_string_tag_symbol(),
name, ro_attributes);

InstallFunc(isolate, webassembly, "compile", WebAssemblyCompile, 1);
InstallFunc(isolate, webassembly, "validate", WebAssemblyValidate, 1);
InstallFunc(isolate, webassembly, "instantiate", WebAssemblyInstantiate, 1);
...
Handle<JSFunction> module_constructor =
InstallConstructorFunc(isolate, webassembly, "Module", WebAssemblyModule);
...
}

And all the rest of the functions that are available on the WebAssembly object are setup in the same function.

(lldb) br s -name Genesis::InstallSpecialObjects

Now, lets also set a break point in WebAssemblyModule:

(lldb) br s -n WebAssemblyModule
(lldb) r
v8::Isolate* isolate = args.GetIsolate();
i::Isolate* i_isolate = reinterpret_cast<i::Isolate*>(isolate);
if (i_isolate->wasm_module_callback()(args)) return;

Notice the wasm_module_callback() function which is a function that is setup on the internal Isolate in src/execution/isolate.h:

#define ISOLATE_INIT_LIST(V)                                                   \
...
V(ExtensionCallback, wasm_module_callback, &NoExtension)                     \
V(ExtensionCallback, wasm_instance_callback, &NoExtension)                   \
V(WasmStreamingCallback, wasm_streaming_callback, nullptr)                   \
V(WasmThreadsEnabledCallback, wasm_threads_enabled_callback, nullptr)        \
V(WasmLoadSourceMapCallback, wasm_load_source_map_callback, nullptr)

#define GLOBAL_ACCESSOR(type, name, initialvalue)                \
inline type name() const {                                     \
DCHECK(OFFSET_OF(Isolate, name##_) == name##_debug_offset_); \
return name##_;                                              \
}                                                              \
inline void set_##name(type value) {                           \
DCHECK(OFFSET_OF(Isolate, name##_) == name##_debug_offset_); \
name##_ = value;                                             \
}
ISOLATE_INIT_LIST(GLOBAL_ACCESSOR)
#undef GLOBAL_ACCESSOR

So this would be expanded by the preprocessor into:

inline ExtensionCallback wasm_module_callback() const {
((void) 0);
return wasm_module_callback_;
}
inline void set_wasm_module_callback(ExtensionCallback value) {
((void) 0);
wasm_module_callback_ = value;
}

Also notice that if wasm_module_callback() return true the WebAssemblyModule fuction will return and no further processing of the instructions in that function will be done. NoExtension is a function that looks like this:

bool NoExtension(const v8::FunctionCallbackInfo<v8::Value>&) { return false; }

And is set as the default function for module/instance callbacks.

Looking a little further we can see checks for WASM Threads support (TODO: take a look at this). And then we have:

module_obj = i_isolate->wasm_engine()->SyncCompile(
i_isolate, enabled_features, &thrower, bytes);

SyncCompile can be found in src/wasm/wasm-engine.cc and will call DecodeWasmModule which can be found in src/wasm/module-decoder.cc.

ModuleResult result = DecodeWasmModule(enabled, bytes.start(), bytes.end(),
false, kWasmOrigin,
isolate->counters(), allocator());
ModuleResult DecodeWasmModule(const WasmFeatures& enabled,
const byte* module_start, const byte* module_end,
bool verify_functions, ModuleOrigin origin,
Counters* counters,
AccountingAllocator* allocator) {
...
ModuleDecoderImpl decoder(enabled, module_start, module_end, origin);
return decoder.DecodeModule(counters, allocator, verify_functions);

DecodeModuleHeader:

uint32_t magic_word = consume_u32("wasm magic");

This will land in src/wasm/decoder.h consume_little_endian(name):

A wasm module has the following preamble:

magic nr: 0x6d736100
version: 0x1

These can be found as a constant in src/wasm/wasm-constants.h:

constexpr uint32_t kWasmMagic = 0x6d736100;
constexpr uint32_t kWasmVersion = 0x01;

After the DecodeModuleHeader the code will iterate of the sections (type, import, function, table, memory, global, export, start, element, code, data, custom). For each section DecodeSection will be called:

DecodeSection(section_iter.section_code(), section_iter.payload(),
offset, verify_functions);

There is an enum named SectionCode in src/wasm/wasm-constants.h which contains the various sections which is used in switch statement in DecodeSection . Depending on the section_code there are DecodeSection methods that will be called. In our case section_code is:

(lldb) expr section_code
(v8::internal::wasm::SectionCode) \$5 = kTypeSectionCode

And this will match the kTypeSectionCode and DecodeTypeSection will be called.

ValueType can be found in src/wasm/value-type.h and there are types for each of the currently supported types:

constexpr ValueType kWasmI32 = ValueType(ValueType::kI32);
constexpr ValueType kWasmI64 = ValueType(ValueType::kI64);
constexpr ValueType kWasmF32 = ValueType(ValueType::kF32);
constexpr ValueType kWasmF64 = ValueType(ValueType::kF64);
constexpr ValueType kWasmAnyRef = ValueType(ValueType::kAnyRef);
constexpr ValueType kWasmExnRef = ValueType(ValueType::kExnRef);
constexpr ValueType kWasmFuncRef = ValueType(ValueType::kFuncRef);
constexpr ValueType kWasmNullRef = ValueType(ValueType::kNullRef);
constexpr ValueType kWasmS128 = ValueType(ValueType::kS128);
constexpr ValueType kWasmStmt = ValueType(ValueType::kStmt);
constexpr ValueType kWasmBottom = ValueType(ValueType::kBottom);

FunctionSig is declared with a using statement in value-type.h:

using FunctionSig = Signature<ValueType>;

We can find Signature in src/codegen/signature.h:

template <typename T>
class Signature : public ZoneObject {
public:
constexpr Signature(size_t return_count, size_t parameter_count,
const T* reps)
: return_count_(return_count),
parameter_count_(parameter_count),
reps_(reps) {}

The return count can be zero, one (or greater if multi-value return types are enabled). The parameter count also makes sense, but reps is not clear to me what that represents.

(lldb) fr v
(v8::internal::Signature<v8::internal::wasm::ValueType> *) this = 0x0000555555583950
(size_t) return_count = 1
(size_t) parameter_count = 2
(const v8::internal::wasm::ValueType *) reps = 0x0000555555583948

Before the call to Signatures construtor we have:

// FunctionSig stores the return types first.
ValueType* buffer = zone->NewArray<ValueType>(param_count + return_count);
uint32_t b = 0;
for (uint32_t i = 0; i < return_count; ++i) buffer[b++] = returns[i];
for (uint32_t i = 0; i < param_count; ++i) buffer[b++] = params[i];

return new (zone) FunctionSig(return_count, param_count, buffer);

So reps_ contains the return (re?) and the params (ps?).

After the DecodeWasmModule has returned in SyncCompile we will have a ModuleResult. This will be compiled to NativeModule:

ModuleResult result =
DecodeWasmModule(enabled, bytes.start(), bytes.end(), false, kWasmOrigin,
isolate->counters(), allocator());
Handle<FixedArray> export_wrappers;
std::shared_ptr<NativeModule> native_module =
CompileToNativeModule(isolate, enabled, thrower,
std::move(result).value(), bytes, &export_wrappers);

CompileToNativeModule can be found in module-compiler.cc

TODO: CompileNativeModule...

There is an example in wasm_test.cc.

### ExtensionCallback

Is a typedef defined in include/v8.h:

typedef bool (*ExtensionCallback)(const FunctionCallbackInfo<Value>&);

### JSEntry

TODO: This section should describe the functions calls below.

* frame #0: 0x00007ffff79a52e4 libv8.so`v8::(anonymous namespace)::WebAssemblyModule(v8::FunctionCallbackInfo<v8::Value> const&) [inlined] v8::FunctionCallbackInfo<v8::Value>::GetIsolate(this=0x00007fffffffc9a0) const at v8.h:11204:40
frame #1: 0x00007ffff79a52e4 libv8.so`v8::(anonymous namespace)::WebAssemblyModule(args=0x00007fffffffc9a0) at wasm-js.cc:638
frame #2: 0x00007ffff6fe9e92 libv8.so`v8::internal::FunctionCallbackArguments::Call(this=0x00007fffffffca40, handler=CallHandlerInfo @ 0x00007fffffffc998) at api-arguments-inl.h:158:3
frame #3: 0x00007ffff6fe7c42 libv8.so`v8::internal::MaybeHandle<v8::internal::Object> v8::internal::(anonymous namespace)::HandleApiCallHelper<true>(isolate=<unavailable>, function=Handle<v8::internal::HeapObject> @ 0x00007fffffffca20, new_target=<unavailable>, fun_data=<unavailable>, receiver=<unavailable>, args=BuiltinArguments @ 0x00007fffffffcae0) at builtins-api.cc:111:36
frame #4: 0x00007ffff6fe67d4 libv8.so`v8::internal::Builtin_Impl_HandleApiCall(args=BuiltinArguments @ 0x00007fffffffcb20, isolate=0x00000f8700000000) at builtins-api.cc:137:5
frame #5: 0x00007ffff6fe6319 libv8.so`v8::internal::Builtin_HandleApiCall(args_length=6, args_object=0x00007fffffffcc10, isolate=0x00000f8700000000) at builtins-api.cc:129:1
frame #6: 0x00007ffff6b2c23f libv8.so`Builtins_CEntry_Return1_DontSaveFPRegs_ArgvOnStack_BuiltinExit + 63
frame #7: 0x00007ffff68fde25 libv8.so`Builtins_JSBuiltinsConstructStub + 101
frame #8: 0x00007ffff6daf46d libv8.so`Builtins_ConstructHandler + 1485
frame #9: 0x00007ffff690e1d5 libv8.so`Builtins_InterpreterEntryTrampoline + 213
frame #10: 0x00007ffff6904b5a libv8.so`Builtins_JSEntryTrampoline + 90
frame #11: 0x00007ffff6904938 libv8.so`Builtins_JSEntry + 120
frame #12: 0x00007ffff716ba0c libv8.so`v8::internal::(anonymous namespace)::Invoke(v8::internal::Isolate*, v8::internal::(anonymous namespace)::InvokeParams const&) [inlined] v8::internal::GeneratedCode<unsigned long, unsigned long, unsigned long, unsigned long, unsigned long, long, unsigned long**>::Call(this=<unavailable>, args=17072495001600, args=<unavailable>, args=17072631376141, args=17072630006049, args=<unavailable>, args=<unavailable>) at simulator.h:142:12
frame #13: 0x00007ffff716ba01 libv8.so`v8::internal::(anonymous namespace)::Invoke(isolate=<unavailable>, params=0x00007fffffffcf50)::InvokeParams const&) at execution.cc:367
frame #14: 0x00007ffff716aa10 libv8.so`v8::internal::Execution::Call(isolate=0x00000f8700000000, callable=<unavailable>, receiver=<unavailable>, argc=<unavailable>, argv=<unavailable>) at execution.cc:461:10

### CustomArguments

Subclasses of CustomArguments, like PropertyCallbackArguments and FunctionCallabackArguments are used for setting up and accessing values on the stack, and also the subclasses provide methods to call various things like CallNamedSetter for PropertyCallbackArguments and Call for FunctionCallbackArguments.

#### FunctionCallbackArguments

class FunctionCallbackArguments
: public CustomArguments<FunctionCallbackInfo<Value> > {
FunctionCallbackArguments(internal::Isolate* isolate, internal::Object data,
internal::HeapObject callee,
internal::Object holder,
internal::HeapObject new_target,
internal::Address* argv, int argc);

This class is in the namespace v8::internal so I'm curious why the explicit namespace is used here?

#### BuiltinArguments

This class extends JavaScriptArguments

class BuiltinArguments : public JavaScriptArguments {
public:
BuiltinArguments(int length, Address* arguments)
: Arguments(length, arguments) {

static constexpr int kNewTargetOffset = 0;
static constexpr int kTargetOffset = 1;
static constexpr int kArgcOffset = 2;
static constexpr int kPaddingOffset = 3;

static constexpr int kNumExtraArgs = 4;
static constexpr int kNumExtraArgsWithReceiver = 5;

JavaScriptArguments is declared in src/common/global.h`:

using JavaScriptArguments = Arguments<ArgumentsType::kJS>;

Arguments can be found in src/execution/arguments.hand is templated with the a type of ArgumentsType (in src/common/globals.h):

enum class ArgumentsType {
kRuntime,
kJS,
};

An instance of Arguments only has a length which is the number of arguments, and an Address pointer which points to the first argument. The functions it provides allows for getting/setting specific arguments and handling various types (like Handle<S>, smi, etc). It also overloads the operator[] allowing to specify an index and getting back an Object to that argument. In BuiltinArguments the constants specify the index's and provides functions to get them:

inline Handle<Object> receiver() const;
inline Handle<JSFunction> target() const;
inline Handle<HeapObject> new_target() const;

### NativeContext

Can be found in src/objects/contexts.h and has the following definition:

class NativeContext : public Context {
public:

DECL_PRIMITIVE_ACCESSORS(microtask_queue, MicrotaskQueue*)

V8_EXPORT_PRIVATE void AddOptimizedCode(Code code);
void SetOptimizedCodeListHead(Object head);
Object OptimizedCodeListHead();
void SetDeoptimizedCodeListHead(Object head);
Object DeoptimizedCodeListHead();
inline OSROptimizedCodeCache GetOSROptimizedCodeCache();
void ResetErrorsThrown();
void IncrementErrorsThrown();
int GetErrorsThrown();

src/parsing/parser.h we can find:

class V8_EXPORT_PRIVATE Parser : public NON_EXPORTED_BASE(ParserBase<Parser>) {
...
enum CompletionKind {
kNormalCompletion,
kThrowCompletion,
kAbruptCompletion
};

But I can't find any usages of this enum?

#### Internal fields/methods

When you see something like [[Notation]] you can think of this as a field in an object that is not exposed to JavaScript user code but internal to the JavaScript engine. These can also be used for internal methods.

Author: Danbev
Source Code: https://github.com/danbev/learning-v8
License:

1594871040

## Exploring the three different types of analytics Descriptive, Predictive, Prescriptive

The best data scientist or data analyst from others is their ability to identify the kind of analytics that can be leveraged to benefit the business — at an optimum. There are three dominant types of analytics –Descriptive, Predictive and Prescriptive analytics. Each of these analytic types offers a different insight.

# Descriptive Analysis

Descriptive statistics are simply the summarizing statistic that quantitatively describes or summarizes features from a collection of information, also we can say coefficients that summarize a given data set.

## Types of Descriptive Statistics

• measures of central tendency
• measures of spread

# measures of central tendency

## Mean

The mean is a descriptive statistic that looks at the average value of a data set.

let’s see the example on the data set using python.

import pandas as pd
import numpy as np

df = pd.read_csv('Bengaluru_House_Data.csv')
df.head(3)

Dataset

Now see the mean of this all numerical columns.

df.mean()

Mean

## Median

In the median, we first need to reorganize our data set in ascending order. Then the median is the value that coincides with the middle of the data set.

Let’s see the example

df.median()

Median

#analytics #statistics #data-science #predictive-analytics #data analysis

1618209540

## Measuring Crop Health Using Deep Learning – Notes From Tiger Analytics

Agrochemical companies manufacture a range of offerings for yield maximisation, pest resistance, hardiness, water quality and availability and other challenges facing farmers. These companies need to measure the efficacy of their products in real-world conditions, not just controlled experimental environments. Single-crop farms are divided into plots and a specific intervention performed in each. For example, hybrid seeds are sown in one plot while another is treated with fertilisers, and so on. The relative performance of each treatment is assessed by tracking the plants’ health in the plot where that treatment was administered.

#featured #deep learning solution #tiger analytics #tiger analytics deep learning #tiger analytics deep learning solution #tiger analytics machine learning #tiger analytics ml #tiger analytics ml-powered digital twin

1659727800

## Hangfire en ASP.NET Core 3.1

En este artículo, aprendamos sobre Hangfire en ASP.NET Core 3.1 y cómo integrarlo con sus aplicaciones principales. Una tarea de programación común a la que nos enfrentamos regularmente es ejecutar trabajos en segundo plano. Y ejecutar estos trabajos correctamente sin estropear su código no es una tarea fácil, pero tampoco es difícil. Solía ​​trabajar con los servicios de Windows para programar varias tareas dentro de mi aplicación C#. Luego, me encontré con esta biblioteca casi increíble: Hangfire, y nunca me fui.

## Trabajos en segundo plano en ASP.NET Core

Básicamente, los trabajos en segundo plano son aquellos métodos o funciones que pueden tardar mucho tiempo en ejecutarse (cantidad de tiempo desconocida). Estos trabajos, si se ejecutan en el subproceso principal de nuestra aplicación, pueden o no bloquear la interacción del usuario y puede parecer que nuestra aplicación .NET Core se ha bloqueado y no responde. Esto es bastante crítico para las aplicaciones orientadas al cliente. Por lo tanto, tenemos trabajos en segundo plano, similares a los subprocesos múltiples, estos trabajos se ejecutan en otro subproceso, lo que hace que nuestra aplicación parezca bastante asíncrona.

También deberíamos tener la posibilidad de programarlos en un futuro cercano para que esté completamente automatizado. La vida de un desarrollador sería muy dura sin estas increíbles posibilidades.

## ¿Qué es Hangfire?

Hangfire es una biblioteca de código abierto que permite a los desarrolladores programar eventos en segundo plano con la mayor facilidad. Es una biblioteca altamente flexible que ofrece varias funciones necesarias para hacer que la tarea de programación de trabajos sea pan comido. Hangfire en ASP.NET Core es la única biblioteca que no puede perderse.

## Integración de Hangfire en ASP.NET Core 3.1

Para este tutorial, tengamos un escenario específico para que podamos explicar Hangfire y su potencial completo. Digamos que estamos desarrollando una API que se encarga de enviar correos al Usuario para diferentes escenarios. Tiene más sentido explicar Hangfire de esta manera. Hangfire es una de las bibliotecas más fáciles de adaptar, pero también muy poderosa. Es uno de los paquetes que ayuda por completo a crear aplicaciones de forma asíncrona y desacoplada.

Como mencioné anteriormente, Hangfire usa una base de datos para almacenar los datos del trabajo. Usaremos la base de datos del servidor MSSQL en esta demostración. Hangfire crea automáticamente las tablas requeridas durante la primera ejecución.

## Configuración del proyecto ASP.NET Core

Comenzaremos creando un nuevo proyecto ASP.NET Core con la plantilla API seleccionada. Ahora cree un controlador de API vacío. Llamémoslo HangfireController. Estoy usando Visual Studio 2019 Community como mi IDE y POSTMAN para probar las API.

### Instalación de los paquetes Hangfire

Instalando el único paquete que necesitarías para configurar Hangfire.

Install-Package Hangfire

### Configuración de Hangfire

Una vez que haya instalado el paquete, ahora estamos listos para configurarlo para que sea compatible con nuestra aplicación ASP.NET Core API. Este es un paso bastante sencillo, además, una vez que instale el paquete, se le mostrará un Léame rápido que le muestra el paso para completar la configuración.

Navigate to Startup.cs / ConfigureServices so that it looks like the below code snippet.
public void ConfigureServices(IServiceCollection services)
{
services.AddHangfire(x => x.UseSqlServerStorage("<connection string>"));
services.AddHangfireServer();
services.AddControllers();
}

Explicación.
Línea #3 Agrega el servicio Hangfire a nuestra aplicación. También hemos mencionado el almacenamiento que se utilizará, el servidor MSSQL, junto con la cadena/nombre de conexión.
La línea n.º 4 en realidad enciende el servidor Hangfire, que es responsable del procesamiento de trabajos.

Una vez hecho esto, vayamos al método Configurar y agregue la siguiente línea.

app.UseHangfireDashboard("/mydashboard");

Explicación.
Lo que hace esta línea es que nos permite acceder al panel de hangfire en nuestra aplicación ASP.NET Core. El tablero estará disponible yendo a /URL de mi tablero. Iniciemos la aplicación.

### Esquema de la base de datos Hangfire

Cuando inicia su aplicación ASP.NET Core por el momento, Hangfire verifica si tiene un esquema de Hangfire asociado disponible en su base de datos. Si no, creará un montón de tablas para ti. Así es como se vería su base de datos.

### Panel de Hangfire

Después de cargar la aplicación, vaya a <localhost>/mydashboard. Podrá ver el panel de control de Hangfire.

Desde el tablero podrás monitorear los trabajos y sus estados. También le permite activar manualmente los trabajos disponibles. Esta es la característica ÚNICA que diferencia a Hangfire de otros programadores. Tablero incorporado. ¿Cuan genial es eso? La captura de pantalla anterior es la de la descripción general del panel. Exploremos también las otras pestañas.

#### Pestaña de trabajos.

Todos los trabajos que están disponibles en el almacén de datos (nuestro servidor MSSQL) se enumerarán aquí. Obtendrá una idea completa del estado de cada trabajo (En cola, Exitoso, Procesando, Fallido, etc.) en esta pantalla.

#### Pestaña Reintentos.

Los trabajos tienden a fallar de vez en cuando debido a factores externos. En nuestro caso, nuestra api intenta enviar un correo al usuario, pero hay un problema de conexión interna, lo que hace que el trabajo no se ejecute. Cuando falla un trabajo, Hangfire continúa intentándolo hasta que pasa. (configurable)

#### Pestaña de trabajos recurrentes.

¿Qué sucede si necesita enviar por correo el uso de su factura mensualmente? Esta es la característica principal de Hangfire, trabajos recurrentes. Esta pestaña le permite monitorear todos los trabajos configurados.

#### Pestaña Servidores.

Recuerde, al configurar Hangfire en la clase Startup.cs, lo hemos mencionado. services.AddHangfireServer().. Esta es la pestaña donde muestra todos los Hangfire Server activos. Estos servidores son responsables de procesar los trabajos. Digamos que no ha agregado los servicios. AddHangfireServer() en la clase de inicio, aún podría agregar trabajos Hangfire a la base de datos, pero no se ejecutarán hasta que inicie un servidor Hangfire.

### Protección del panel Hangfire

Esta es una característica bastante obvia. Dado que el tablero puede exponer datos muy confidenciales como nombres de métodos, valores de parámetros, ID de correo electrónico, es muy importante que protejamos/restringamos este punto final. Hangfire, listo para usar, hace que el tablero sea seguro al permitir solo solicitudes locales. Sin embargo, puede cambiar esto implementando su propia versión de IDashboardAuthorizationFilter . Si ya implementó la Autorización en su API, puede implementarla para Hangfire. Consulte estos pasos para asegurar el tablero.

## Tipos de trabajo en Hangfire

Los trabajos en segundo plano en ASP.NET Core (o digamos cualquier tecnología) pueden ser de muchos tipos según los requisitos. Repasemos los tipos de trabajo disponibles con Hangfire con la implementación adecuada y la explicación en nuestro proyecto ASP.NET Core API. Vamos a codificar.

### Despedir y olvidar trabajos

Los trabajos de disparar y olvidar se ejecutan  solo una vez  y casi  inmediatamente  después de la creación. Crearemos nuestro primer trabajo de fondo. Abre el controlador Hangfire que habíamos creado. Crearemos un punto final POST que dé la bienvenida a un usuario con un correo electrónico (idealmente). Añade estos códigos.

[HttpPost]
[Route("welcome")]
public IActionResult Welcome(string userName)
{
var jobId = BackgroundJob.Enqueue(() => SendWelcomeMail(userName));
return Ok(\$"Job Id {jobId} Completed. Welcome Mail Sent!");
}

public void SendWelcomeMail(string userName)
{
//Logic to Mail the user
Console.WriteLine(\$"Welcome to our application, {userName}");
}

Explicación.
La línea #5 almacena JobId en una variable. Puede ver que en realidad estamos agregando un trabajo en segundo plano representado por una función ficticia SendWelcomeMail. El JobId se vuelve a publicar más tarde en el Panel de control de Hangfire. Cree la aplicación y ejecútela. Vamos a probarlo con Postman.

Tenga en cuenta la URL y cómo estoy pasando el nombre de usuario al controlador. Una vez que lo ejecute, obtendrá nuestra respuesta requerida. “Id. de trabajo 2 completado. ¡Correo de bienvenida enviado!”. Ahora veamos el tablero de Hangfire.

En la pestaña Correcto, puede ver el recuento de trabajos completados. También puede ver los detalles de cada trabajo, similar a la captura de pantalla anterior. Todos los parámetros y nombres de funciones se exponen aquí. ¿Quiere volver a ejecutar este trabajo con los mismos parámetros? Presiona el botón Volver a poner en cola. Vuelve a agregar su trabajo en la cola para que Hangfire lo procese. Sucede casi de inmediato.

### Trabajos retrasados

Ahora, qué pasa si queremos enviar un correo a un usuario, no inmediatamente, sino después de 10 minutos. En tales casos, utilizamos trabajos retrasados. Veamos su implementación, después de lo cual lo explicaré en detalle. En el mismo controlador, agregue estas líneas de código. Es bastante similar a la variante anterior, pero le introducimos un factor de retraso.

[HttpPost]
[Route("delayedWelcome")]
public IActionResult DelayedWelcome(string userName)
{
var jobId = BackgroundJob.Schedule(() => SendDelayedWelcomeMail(userName),TimeSpan.FromMinutes(2));
return Ok(\$"Job Id {jobId} Completed. Delayed Welcome Mail Sent!");
}

public void SendDelayedWelcomeMail(string userName)
{
//Logic to Mail the user
Console.WriteLine(\$"Welcome to our application, {userName}");
}

Explicación.
La línea #5 programó el trabajo en un período de tiempo definido, en nuestro caso son 2 minutos. Eso significa que nuestro trabajo se ejecutará 2 minutos después de que Postman haya llamado a la acción. Abramos Postman de nuevo y probemos.

Puede ver que recibimos la respuesta esperada de Postman. Ahora. vuelva rápidamente al Panel de control de Hangfire y haga clic en la pestaña Trabajos/programados. Diría que el trabajo se ejecutará en un minuto. Ahí estás para. Ha creado su primer trabajo programado usando Hangfire con facilidad.

### trabajos recurrentes

Nuestro Cliente tiene una suscripción a nuestro servicio. Obviamente, tendríamos que enviarle un recordatorio sobre el pago o la factura en sí. Esto llama la necesidad de un trabajo recurrente, donde puedo enviar correos electrónicos a mis clientes mensualmente. Esto es compatible con Hangfire mediante el programa CRON.
¿Qué es CRON? CRON es una utilidad basada en el tiempo que puede definir intervalos de tiempo. Veamos cómo lograr tal requisito.

[HttpPost]
[Route("invoice")]
public IActionResult Invoice(string userName)
{
RecurringJob.AddOrUpdate(() => SendInvoiceMail(userName), Cron.Monthly);
return Ok(\$"Recurring Job Scheduled. Invoice will be mailed Monthly for {userName}!");
}

public void SendInvoiceMail(string userName)
{
//Logic to Mail the user
Console.WriteLine(\$"Here is your invoice, {userName}");
}

La línea #5 establece claramente que estamos tratando de agregar/actualizar un trabajo recurrente, que llama a una función tantas veces como lo define el esquema CRON. Aquí enviaremos la factura al cliente mensualmente el primer día de cada mes. Ejecutemos la aplicación y cambiemos a Postman. Estoy ejecutando este código el 24 de mayo de 2020. Según nuestro requisito, este trabajo debe despedirse el 1 de junio de 2020, que es dentro de 7 días. Vamos a ver.

Entonces, esto funcionó. Pasemos a Hangfire Dashboard y vayamos a la pestaña Trabajos recurrentes.

¡Perfecto! Funciona como excepción. Puede pasar por varios esquemas CRON aquí que pueden coincidir con sus requisitos. Aquí hay una pequeña documentación agradable para comprender cómo se usan varias expresiones CRON.

### Continuaciones

Este es un escenario más complicado. Permítanme tratar de mantenerlo muy simple. Un usuario decide darse de baja de su servicio. Después de que confirme su acción (tal vez haciendo clic en el botón para cancelar la suscripción), nosotros (la aplicación) tenemos que cancelar la suscripción del sistema y enviarle un correo de confirmación después de eso también. Entonces, el primer trabajo es realmente cancelar la suscripción del usuario. El segundo trabajo es enviar un correo confirmando la acción. El segundo trabajo debe ejecutarse solo después de que el primer trabajo se haya completado correctamente. Obtener el escenario?

[HttpPost]
[Route("unsubscribe")]
public IActionResult Unsubscribe(string userName)
{
var jobId = BackgroundJob.Enqueue(() => UnsubscribeUser(userName));
BackgroundJob.ContinueJobWith(jobId, () => Console.WriteLine(\$"Sent Confirmation Mail to {userName}"));
return Ok(\$"Unsubscribed");
}

public void UnsubscribeUser(string userName)
{
//Logic to Unsubscribe the user
Console.WriteLine(\$"Unsubscribed {userName}");
}

Explicación.
Línea #5 El primer trabajo que realmente contiene lógica para eliminar la suscripción del usuario.
Línea #6 Nuestro segundo trabajo que continuará después de que se ejecute el primer trabajo. Esto se hace pasando el Id. de trabajo del trabajo principal a los trabajos secundarios.

Iniciemos la aplicación y vayamos a Postman.

Ahora, vaya al Tablero y verifique el trabajo exitoso. Verá 2 nuevos trabajos ejecutados en el orden exacto que queríamos. Eso es todo por este tutorial. Espero que tengan claro estos conceptos y les resulte fácil integrar Hangfire en las aplicaciones ASP.NET Core.

## Resumen

En esta guía detallada, hemos repasado los conceptos de trabajos en segundo plano, características e implementación de Hangfire en aplicaciones ASP.NET Core y varios tipos de trabajos en Hangfire. El código fuente utilizado para demostrar este tutorial está publicado en GitHub. Te dejo el enlace a continuación para que lo consultes. ¿Tienes experiencia con Hangfire? ¿Tienes alguna consulta/sugerencia? Siéntase libre de dejar a continuación en la sección de comentarios. ¡Feliz codificación!

1666004249

## Magento Ecommerce SEO Best Practices

Running a business online? Well, I have come across many of you who bend back and forth trying to up their game by hiring a relevant Magento development company and further following the best SEO practices. Fortunately, we are living in an era where you can find a plethora of methods or ways to enhance their SEO procedures. The following post acts as a perfect guide that can assist you in enhancing your SEO tactics/strategies and help you to up your game.

Why is there a need for SEO for eCommerce? 1
How is SEO beneficial for your eCommerce Store? 2
#1 Generate Sustainable Traffic 2
#2 Drives Brand Awareness 3
#3 Amazing Customer Experience 3
#4 Free 3
#5 Capturing the Long Tail Keywords 4

Magento Ecommerce SEO Best Practices 4
#1 Duplicate Content 6
#2 Keeping your store Up-to-Date 7
#3 Enhance the Website Speed 7
#4 Check the Magento SEO URLs 8
#5 Optimize Product Images 9
Final Thoughts 9

## Why is there a need for SEO for eCommerce?

Do you think that SEO is a mere method of producing a high amount of traffic? Well, to be precise SEO is way more than you think. Striving hard to compete in today’s insanely tricky and competitive world is a bit kind of a challenge, especially after the COVID pandemic. So what exactly is SEO? Well, it is short-term known for Search Engine Optimization. The process of increasing traffic visiting a website by gaining a higher position in comparison to the previous one. Originally, SEO was supposed to attract as many visitors as possible.

Now, whenever you try surfing the internet to look for specific information, I am sure you must come across several options, some of which are the best while others are not in the Search Engine Result Pages (SERPs). In other words, the high position of the website means more possibility of visitors visiting and becoming your regular customers. Further, I would like to mention the pros of considering SEO for your eCommerce store.

We are residing in an era where there’s a race for increasing visitors, traffic and revenue and an organic search can be pretty much of help here.

## How is SEO beneficial for your eCommerce Store?

Even today, Search Engine Optimization is overlooked as a highly crucial aspect of eCommerce business marketing strategy. However, here below I would like to mention several benefits offered by SEO. Read Away!

## #1 Generate Sustainable Traffic

One of the obvious benefits of considering SEO is generating a sustainable amount of traffic. There are several methods available such as paid social media, and search engine ads that can certainly assist in driving tons and tons of visitors in an extremely short span of time. You see, maintaining such an impressive amount of traffic is tricky and all the paid methods are pretty expensive. I mean here you have to keep paying the ad provider again and again. And over time, you might have to pay more to drive volume with the increase in competition.

In fact, hereby incorporating the best SEO strategies, you will be able to create a more sustainable level of traffic. You see, most SEO investments tend to happen right at the beginning of the process and can certainly offer long-lasting results. At the same time, it is extremely important to keep the content well up to date and the website keeps on running smoothly. Learn more regaring content marketing.

## #2 Drives Brand Awareness

In today’s scenario, making people well-aware of your brand is very important and SEO offers a great amount of help in doing so. In fact, it turns out to be the sure-shot way for low-cost brand awareness. I mean if your website gets to appear on the very first page of Google, there is a 100% chance for people looking for a particular product ending up stumbling on your website and even buying the product.

Such kinds of rankings can also turn out to be endorsements which do visitors click on and keep the brand in mind while making the final decision. Without a doubt, top ranking is one of the most powerful positions to be in and unlike your competitors you aren’t falling short here.

## #3 Amazing Customer Experience

When you end up ranking on the top of the SERPs, it becomes pretty easy for customers to visit your store. Also, this without a doubt increases the buying chances. In fact, according to several stats, almost all the users don’t even bother looking at the websites that are listed on the second page of Google. So ranking on the first page of Google turns out to be a must.

Now tell me something: do you remember URLs? Of course, not! What we generally do is we simply google things and then view websites or stores ranking on the first page of the search result. Not to mention if the website is already ranked on the first page it means that it is the best in terms of navigation, content quality, high-quality images, and whatnot! As a result, an amazing customer experience can be expected here.

#4 Free
The next advantage of considering SEO for your eCommerce store is that it is available for free. Unlike PPC ads or social ads or search engine ads, you don’t have to pay whether it might work wonders for you or not. All you have to do is follow some of the best SEO practices that earn you a great source of traffic without the requirement of paying any kind of upfront costs. Though you may not spend extravagantly on SEO, you can hire a team of SEO experts at a reasonable price who carry an immense amount of experience ranking eCommerce stores by boosting search engine rankings.

## #5 Capturing the Long Tail Keywords

Another crucial advantage of considering SEO for your eCommerce store is that it captures the long-tail keyword. You see 15% of search engine queries are new and unique and a long tail keyword strategy is the implication of these queries within the content and presents it seamlessly that it successfully covers at a higher rate.

Although, eCommerce sites are typically well-structured in such a way that they do end up targeting those long-term searches. For example, first, you look for clothing rather than women’s clothing, then dresses, jumpsuits, pants, jeans, tops, t-shirts, shirts and whatnot! Similarly, an eCommerce store follows the same path, so if you have the keyword “women dresses” Jeans for Women” then the end user can directly land up on your site. Here all you have to do is opt for a robust and scalable SEO strategy.

I can simply go on and on when it comes to the benefits of eCommerce SEO such as building trust, increasing sales, expanding remarketing audiences, increasing site usability, fast loading speed, etc. eCommerce SEO is a growing trend and not making the most of it means you might have a lot to lose. Further, I would like to mention some of the best Magento eCommerce SEO practices to take into account.

## Magento Ecommerce SEO Best Practices

When we use the word eCommerce, Magento is something that automatically comes to your mind. Why so? Because Magento and eCommerce are like chocolate and peanut butter, they can make incredible taste when merged. In fact, there are a plethora of reasons such as power, security and customizability why Magento is a go-to platform for retailers planning to strengthen their online presence. Now I am sure you must have come across the term Magento SEO. Well, it is a set of SEO adjustments that are unique and never heard of before. In fact, Magento turns out to be more like a blessing in disguise for SEO as it incorporates some of the most amazing features such as robots.txt file, sitemap.xml, etc.

To come up with a strong technical foundation you need:
● Great URL Structure
● Meta information
● Headings
● Faceted Navigation
● Crawling and Indexing
● Site Speed
● HTTPS

In order to rank your Magento store well, especially through the organic search results, there are certain aspects you must take into consideration. Yes, I am talking about the three pillars:

1. Technology – A strong technical foundation of the website can certainly assist search engines in finding and understanding your site as soon and as effectively as possible.
2. Relevance – Is your content relevant to the search query? For that, you have to make sure that you end up creating content that’s useful and satisfying for the end users.
3. Authority – Try to build trust by adding as many links as you can to your website.

It may quite interest you to know that doing SEO for a typical website is far easier than doing that of an eCommerce store featuring hundreds and thousands of page listings or product listings. Fret not, here down below I would like to mention some of the most intimidating SEO tips that must be taken into account for the betterment of your eCommerce store.

### #1 Duplicate Content

What exactly is duplicate content? Now I am sure you must have seen similar content over the internet. I mean two websites having the same heading, title, paras, images basically everything seems to be extremely identical. Can you spot which one is original and which one is copied? Now what happens is when multiple versions are similar to each other, it becomes way difficult for search engines to distinguish between the two. And that’s the reason why search engines rarely tend to display the duplicate pages in the search engine rankings. You must be wondering whether the duplication can harm SEO. Well, of course, it does and in many ways!

One of the obvious ways is that duplicate content can result in high penalties leading to harming your page rankings and organic traffic. You see search engines in such cases tend to determine which version is more relatable to the query of the audience and then give a specific rank. Though there is no denying the fact that duplicate content can severely dilute link equity and credibility.

I have come across many of you who have this question, can this be visible to the naked eyes? Well, not really because duplication is hidden in the code of the site so you need software to check things precisely. Best practices to combat duplicate content are:

● 301 redirect
● Make use of Meta Robot Tags
● Make relevant changes in Meta Title Tags
● Use Canonical tag
● Eliminate pages

Mainly duplicate content issues occur in pages such as product filtering, product sorting, pagination, the same product in different categories, variation of a similar product and so forth.

### #2 Keeping your store Up-to-Date

Another crucial tip to take into account is keeping your Magento store up to date. Now since you have already developed an intimidating Magento store but not keeping it up-to-date means you won’t get desired results and keep your customers hooked for a long period of time. Of course, Magento development is very crucial but what’s more crucial is to maintain the website. Here’s how!

● Analyze website performance – You have to keep examining the overall performance of the website day in and day out. Fortunately, there are a wide range of magento tools available that may assist you well in analyzing the website. So that you can beware of negative clicks, visits, bounce rate, search queries and whatnot!

● Website speed – With an increasingly short attention span of users, website owners these days must keep severe track of the speed of the website. If the website doesn’t load within three seconds then your customers are more likely to shift to your competitors.

● Regular updates – Fresh and relevant information are favored by all and your end users are certainly not an exception here. So try rewriting your website at regular intervals to keep your users stay relevant and on top of Google.

Here you do have a choice. You can either update things manually through a system upgrade or else seek assistance from a relevant Magento development company which offers seamless maintenance.

### #3 Enhance the Website Speed

The next step that needs to be taken into consideration is enhancing the website speed. The slow loading speed can be quite discouraging and tiresome. Now, first of all, let us understand why this happens in the first place. One of the obvious reasons for slow loading speed include not meeting the system requirements, making use of inappropriate extensions, MySQL, NGINX, and PHP configurations not optimized, disabling caching, use of slow hardware and whatnot!

Further, I would like to mention a few ways through which you can speed up your Magento store.

● Update regularly – When a different version is released then you need to know that it is astronomical. And the same goes for every other technology available. You see developers in the Magento community tend to strive extremely hard to make the latest version secure, robust and scalable to a great extent. So don’t miss out on the big update, you never know it can be way more useful.
● Optimize your database – Databases tend to store data in one location. Now what happens when the data is poorly optimized, it takes way longer to server requests. As a result, this surely reflects in performance.
● Enable Magento Cache Management – Now let’s take a situation where you are sending an invite to around 1000 people. Now when you do it manually, it takes a hell lot of time and effort. How about sending bulk emails too?
○ Create a copy of your site in the local cache
○ Magento returns the copy instead of recreating a new site

Also, make this a regular habit of the site audit. Right from adding the relevant amount of pages to getting notified if the website speed gets slow make use of the website audit tool to identify relevant issues such as broken links, SSL errors, lack of mobile optimization and whatnot!

### #4 Check the Magento SEO URLs

Another interesting tip to take into account is keeping tabs on Magento SEO URLs and seeing whether they are SEO-friendly or not. One of the most amazing features offered by Magento was that it enabled the end users to edit their product URLs freely. Yes, in other words, it is extremely easy to make relevant changes to all the links, especially the ones which are in regard to the product categories, and CMS pages. In other words, you no longer have to worry about 440 errors or missing content here.

Some of the best and most common examples to consider:
● website.com/category/
● website.com/category/sub-category/
● website.com/category-sub-category/product-name/

### #5 Optimize Product Images

Another crucial step to take into account is to optimize product images. By doing so you can conduct better search rankings. Now you must be wondering what image optimization is. Well, it is all about reducing the file size of your image and all this happens without sacrificing quality. Here’s how you can do so!

● Name image descriptively – You will be listing hundreds and thousands of products so don’t keep the default names given by the camera. Try to incorporate relevant keywords so that when the crawler goes through your file names, it finds them relevant. Take a deep look at the website analytics and relevant keyword patterns and then make crucial decisions here.

● Choosing image dimensions – Now since you are creating an eCommerce store, of course, you have to show the product from different angles. For example, the back, the front, the interiors, engines and whatnot! In addition, do not forget to add a relevant description so that potential users end up landing on your website.

● Reduce the file size – As mentioned earlier, the attention span is pretty much less and your eCommerce store not loading in a span of 3 seconds means you are losing out on your potential customers. It may also interest you to know that Google uses page load time as one of the crucial ranking factors.

And that’s all for now!

#### Final Thoughts

Though SEO is one of the most conventional and traditional approaches, there are numerous new and quick options such as paid ads, social media ads, and emails, that can offer immediate returns. However, on the contrary, investing or hiring a reliable SEO agency might not provide immediate returns but it certainly can be a slow yet sustainable path to achieve growth in the long run. Take certain aspects such as keyword selection, content creation, and tech SEO in mind and do try investing in opportunities that are within your reach.

It doesn’t matter whether you are a techie or a non-techie, but you have to be realistic knowing that SEO strategy won’t be an overnight success – it may take weeks, months and even a year but have faith that one day your eCommerce store will be found on the top search rankings. Stay motivated, and keep going because that’s the only way we move forward.

I hope you did find the following post meaningful. If so feel free to share this among your peers and do help us in spreading the word.

Original Source: [HERE]
