Spring Boot 2.3.1 Available Now
On behalf of the team and everyone that has contributed, I’m happy to announce that Spring Boot 2.3.1 has been released and is now available from repo.spring.io and Maven Central.
This release includes 127 bug fixes, enhancements, documentation improvements, and dependency upgrades. Thanks to all those who have contributed with issue reports and pull requests.
How can you help?
If you’re interested in helping out, check out the “ideal for contribution” tag in the issue repository. If you have general questions, please ask on stackoverflow.com using the spring-boot tag or chat with the community on Gitter.
#spring-boot #java #developer
What is GEEK
Buddha Community
1653475560
A Pure PHP Implementation Of The MessagePack Serialization Format
msgpack.php
A pure PHP implementation of the MessagePack serialization format.
Features
- Fully compliant with the latest MessagePack specification
- Supports streaming unpacking
- Supports unsigned 64-bit integers handling
- Supports object serialization
- Fully tested
- Relatively fast
Installation
The recommended way to install the library is through Composer:
composer require rybakit/msgpack
Usage
Packing
To pack values you can either use an instance of a Packer:
$packer = new Packer();
$packed = $packer->pack($value);
or call a static method on the MessagePack class:
$packed = MessagePack::pack($value);
In the examples above, the method pack automatically packs a value depending on its type. However, not all PHP types can be uniquely translated to MessagePack types. For example, the MessagePack format defines map and array types, which are represented by a single array type in PHP. By default, the packer will pack a PHP array as a MessagePack array if it has sequential numeric keys, starting from 0 and as a MessagePack map otherwise:
$mpArr1 = $packer->pack([1, 2]); // MP array [1, 2]
$mpArr2 = $packer->pack([0 => 1, 1 => 2]); // MP array [1, 2]
$mpMap1 = $packer->pack([0 => 1, 2 => 3]); // MP map {0: 1, 2: 3}
$mpMap2 = $packer->pack([1 => 2, 2 => 3]); // MP map {1: 2, 2: 3}
$mpMap3 = $packer->pack(['a' => 1, 'b' => 2]); // MP map {a: 1, b: 2}
However, sometimes you need to pack a sequential array as a MessagePack map. To do this, use the packMap method:
$mpMap = $packer->packMap([1, 2]); // {0: 1, 1: 2}
Here is a list of type-specific packing methods:
$packer->packNil(); // MP nil
$packer->packBool(true); // MP bool
$packer->packInt(42); // MP int
$packer->packFloat(M_PI); // MP float (32 or 64)
$packer->packFloat32(M_PI); // MP float 32
$packer->packFloat64(M_PI); // MP float 64
$packer->packStr('foo'); // MP str
$packer->packBin("\x80"); // MP bin
$packer->packArray([1, 2]); // MP array
$packer->packMap(['a' => 1]); // MP map
$packer->packExt(1, "\xaa"); // MP ext
Check the "Custom types" section below on how to pack custom types.
Packing options
The Packer object supports a number of bitmask-based options for fine-tuning the packing process (defaults are in bold):
| Name | Description |
|---|---|
FORCE_STR | Forces PHP strings to be packed as MessagePack UTF-8 strings |
FORCE_BIN | Forces PHP strings to be packed as MessagePack binary data |
DETECT_STR_BIN | Detects MessagePack str/bin type automatically |
FORCE_ARR | Forces PHP arrays to be packed as MessagePack arrays |
FORCE_MAP | Forces PHP arrays to be packed as MessagePack maps |
DETECT_ARR_MAP | Detects MessagePack array/map type automatically |
FORCE_FLOAT32 | Forces PHP floats to be packed as 32-bits MessagePack floats |
FORCE_FLOAT64 | Forces PHP floats to be packed as 64-bits MessagePack floats |
The type detection mode (
DETECT_STR_BIN/DETECT_ARR_MAP) adds some overhead which can be noticed when you pack large (16- and 32-bit) arrays or strings. However, if you know the value type in advance (for example, you only work with UTF-8 strings or/and associative arrays), you can eliminate this overhead by forcing the packer to use the appropriate type, which will save it from running the auto-detection routine. Another option is to explicitly specify the value type. The library provides 2 auxiliary classes for this,MapandBin. Check the "Custom types" section below for details.
Examples:
// detect str/bin type and pack PHP 64-bit floats (doubles) to MP 32-bit floats
$packer = new Packer(PackOptions::DETECT_STR_BIN | PackOptions::FORCE_FLOAT32);
// these will throw MessagePack\Exception\InvalidOptionException
$packer = new Packer(PackOptions::FORCE_STR | PackOptions::FORCE_BIN);
$packer = new Packer(PackOptions::FORCE_FLOAT32 | PackOptions::FORCE_FLOAT64);
Unpacking
To unpack data you can either use an instance of a BufferUnpacker:
$unpacker = new BufferUnpacker();
$unpacker->reset($packed);
$value = $unpacker->unpack();
or call a static method on the MessagePack class:
$value = MessagePack::unpack($packed);
If the packed data is received in chunks (e.g. when reading from a stream), use the tryUnpack method, which attempts to unpack data and returns an array of unpacked messages (if any) instead of throwing an InsufficientDataException:
while ($chunk = ...) {
$unpacker->append($chunk);
if ($messages = $unpacker->tryUnpack()) {
return $messages;
}
}
If you want to unpack from a specific position in a buffer, use seek:
$unpacker->seek(42); // set position equal to 42 bytes
$unpacker->seek(-8); // set position to 8 bytes before the end of the buffer
To skip bytes from the current position, use skip:
$unpacker->skip(10); // set position to 10 bytes ahead of the current position
To get the number of remaining (unread) bytes in the buffer:
$unreadBytesCount = $unpacker->getRemainingCount();
To check whether the buffer has unread data:
$hasUnreadBytes = $unpacker->hasRemaining();
If needed, you can remove already read data from the buffer by calling:
$releasedBytesCount = $unpacker->release();
With the read method you can read raw (packed) data:
$packedData = $unpacker->read(2); // read 2 bytes
Besides the above methods BufferUnpacker provides type-specific unpacking methods, namely:
$unpacker->unpackNil(); // PHP null
$unpacker->unpackBool(); // PHP bool
$unpacker->unpackInt(); // PHP int
$unpacker->unpackFloat(); // PHP float
$unpacker->unpackStr(); // PHP UTF-8 string
$unpacker->unpackBin(); // PHP binary string
$unpacker->unpackArray(); // PHP sequential array
$unpacker->unpackMap(); // PHP associative array
$unpacker->unpackExt(); // PHP MessagePack\Type\Ext object
Unpacking options
The BufferUnpacker object supports a number of bitmask-based options for fine-tuning the unpacking process (defaults are in bold):
| Name | Description |
|---|---|
BIGINT_AS_STR | Converts overflowed integers to strings [1] |
BIGINT_AS_GMP | Converts overflowed integers to GMP objects [2] |
BIGINT_AS_DEC | Converts overflowed integers to Decimal\Decimal objects [3] |
1. The binary MessagePack format has unsigned 64-bit as its largest integer data type, but PHP does not support such integers, which means that an overflow can occur during unpacking.
2. Make sure the GMP extension is enabled.
3. Make sure the Decimal extension is enabled.
Examples:
$packedUint64 = "\xcf"."\xff\xff\xff\xff"."\xff\xff\xff\xff";
$unpacker = new BufferUnpacker($packedUint64);
var_dump($unpacker->unpack()); // string(20) "18446744073709551615"
$unpacker = new BufferUnpacker($packedUint64, UnpackOptions::BIGINT_AS_GMP);
var_dump($unpacker->unpack()); // object(GMP) {...}
$unpacker = new BufferUnpacker($packedUint64, UnpackOptions::BIGINT_AS_DEC);
var_dump($unpacker->unpack()); // object(Decimal\Decimal) {...}
Custom types
In addition to the basic types, the library provides functionality to serialize and deserialize arbitrary types. This can be done in several ways, depending on your use case. Let's take a look at them.
Type objects
If you need to serialize an instance of one of your classes into one of the basic MessagePack types, the best way to do this is to implement the CanBePacked interface in the class. A good example of such a class is the Map type class that comes with the library. This type is useful when you want to explicitly specify that a given PHP array should be packed as a MessagePack map without triggering an automatic type detection routine:
$packer = new Packer();
$packedMap = $packer->pack(new Map([1, 2, 3]));
$packedArray = $packer->pack([1, 2, 3]);
More type examples can be found in the src/Type directory.
Type transformers
As with type objects, type transformers are only responsible for serializing values. They should be used when you need to serialize a value that does not implement the CanBePacked interface. Examples of such values could be instances of built-in or third-party classes that you don't own, or non-objects such as resources.
A transformer class must implement the CanPack interface. To use a transformer, it must first be registered in the packer. Here is an example of how to serialize PHP streams into the MessagePack bin format type using one of the supplied transformers, StreamTransformer:
$packer = new Packer(null, [new StreamTransformer()]);
$packedBin = $packer->pack(fopen('/path/to/file', 'r+'));
More type transformer examples can be found in the src/TypeTransformer directory.
Extensions
In contrast to the cases described above, extensions are intended to handle extension types and are responsible for both serialization and deserialization of values (types).
An extension class must implement the Extension interface. To use an extension, it must first be registered in the packer and the unpacker.
The MessagePack specification divides extension types into two groups: predefined and application-specific. Currently, there is only one predefined type in the specification, Timestamp.
Timestamp
The Timestamp extension type is a predefined type. Support for this type in the library is done through the TimestampExtension class. This class is responsible for handling Timestamp objects, which represent the number of seconds and optional adjustment in nanoseconds:
$timestampExtension = new TimestampExtension();
$packer = new Packer();
$packer = $packer->extendWith($timestampExtension);
$unpacker = new BufferUnpacker();
$unpacker = $unpacker->extendWith($timestampExtension);
$packedTimestamp = $packer->pack(Timestamp::now());
$timestamp = $unpacker->reset($packedTimestamp)->unpack();
$seconds = $timestamp->getSeconds();
$nanoseconds = $timestamp->getNanoseconds();
When using the MessagePack class, the Timestamp extension is already registered:
$packedTimestamp = MessagePack::pack(Timestamp::now());
$timestamp = MessagePack::unpack($packedTimestamp);
Application-specific extensions
In addition, the format can be extended with your own types. For example, to make the built-in PHP DateTime objects first-class citizens in your code, you can create a corresponding extension, as shown in the example. Please note, that custom extensions have to be registered with a unique extension ID (an integer from 0 to 127).
More extension examples can be found in the examples/MessagePack directory.
To learn more about how extension types can be useful, check out this article.
Exceptions
If an error occurs during packing/unpacking, a PackingFailedException or an UnpackingFailedException will be thrown, respectively. In addition, an InsufficientDataException can be thrown during unpacking.
An InvalidOptionException will be thrown in case an invalid option (or a combination of mutually exclusive options) is used.
Tests
Run tests as follows:
vendor/bin/phpunit
Also, if you already have Docker installed, you can run the tests in a docker container. First, create a container:
./dockerfile.sh | docker build -t msgpack -
The command above will create a container named msgpack with PHP 8.1 runtime. You may change the default runtime by defining the PHP_IMAGE environment variable:
PHP_IMAGE='php:8.0-cli' ./dockerfile.sh | docker build -t msgpack -
See a list of various images here.
Then run the unit tests:
docker run --rm -v $PWD:/msgpack -w /msgpack msgpack
Fuzzing
To ensure that the unpacking works correctly with malformed/semi-malformed data, you can use a testing technique called Fuzzing. The library ships with a help file (target) for PHP-Fuzzer and can be used as follows:
php-fuzzer fuzz tests/fuzz_buffer_unpacker.php
Performance
To check performance, run:
php -n -dzend_extension=opcache.so \
-dpcre.jit=1 -dopcache.enable=1 -dopcache.enable_cli=1 \
tests/bench.php
Example output
Filter: MessagePack\Tests\Perf\Filter\ListFilter
Rounds: 3
Iterations: 100000
=============================================
Test/Target Packer BufferUnpacker
---------------------------------------------
nil .................. 0.0030 ........ 0.0139
false ................ 0.0037 ........ 0.0144
true ................. 0.0040 ........ 0.0137
7-bit uint #1 ........ 0.0052 ........ 0.0120
7-bit uint #2 ........ 0.0059 ........ 0.0114
7-bit uint #3 ........ 0.0061 ........ 0.0119
5-bit sint #1 ........ 0.0067 ........ 0.0126
5-bit sint #2 ........ 0.0064 ........ 0.0132
5-bit sint #3 ........ 0.0066 ........ 0.0135
8-bit uint #1 ........ 0.0078 ........ 0.0200
8-bit uint #2 ........ 0.0077 ........ 0.0212
8-bit uint #3 ........ 0.0086 ........ 0.0203
16-bit uint #1 ....... 0.0111 ........ 0.0271
16-bit uint #2 ....... 0.0115 ........ 0.0260
16-bit uint #3 ....... 0.0103 ........ 0.0273
32-bit uint #1 ....... 0.0116 ........ 0.0326
32-bit uint #2 ....... 0.0118 ........ 0.0332
32-bit uint #3 ....... 0.0127 ........ 0.0325
64-bit uint #1 ....... 0.0140 ........ 0.0277
64-bit uint #2 ....... 0.0134 ........ 0.0294
64-bit uint #3 ....... 0.0134 ........ 0.0281
8-bit int #1 ......... 0.0086 ........ 0.0241
8-bit int #2 ......... 0.0089 ........ 0.0225
8-bit int #3 ......... 0.0085 ........ 0.0229
16-bit int #1 ........ 0.0118 ........ 0.0280
16-bit int #2 ........ 0.0121 ........ 0.0270
16-bit int #3 ........ 0.0109 ........ 0.0274
32-bit int #1 ........ 0.0128 ........ 0.0346
32-bit int #2 ........ 0.0118 ........ 0.0339
32-bit int #3 ........ 0.0135 ........ 0.0368
64-bit int #1 ........ 0.0138 ........ 0.0276
64-bit int #2 ........ 0.0132 ........ 0.0286
64-bit int #3 ........ 0.0137 ........ 0.0274
64-bit int #4 ........ 0.0180 ........ 0.0285
64-bit float #1 ...... 0.0134 ........ 0.0284
64-bit float #2 ...... 0.0125 ........ 0.0275
64-bit float #3 ...... 0.0126 ........ 0.0283
fix string #1 ........ 0.0035 ........ 0.0133
fix string #2 ........ 0.0094 ........ 0.0216
fix string #3 ........ 0.0094 ........ 0.0222
fix string #4 ........ 0.0091 ........ 0.0241
8-bit string #1 ...... 0.0122 ........ 0.0301
8-bit string #2 ...... 0.0118 ........ 0.0304
8-bit string #3 ...... 0.0119 ........ 0.0315
16-bit string #1 ..... 0.0150 ........ 0.0388
16-bit string #2 ..... 0.1545 ........ 0.1665
32-bit string ........ 0.1570 ........ 0.1756
wide char string #1 .. 0.0091 ........ 0.0236
wide char string #2 .. 0.0122 ........ 0.0313
8-bit binary #1 ...... 0.0100 ........ 0.0302
8-bit binary #2 ...... 0.0123 ........ 0.0324
8-bit binary #3 ...... 0.0126 ........ 0.0327
16-bit binary ........ 0.0168 ........ 0.0372
32-bit binary ........ 0.1588 ........ 0.1754
fix array #1 ......... 0.0042 ........ 0.0131
fix array #2 ......... 0.0294 ........ 0.0367
fix array #3 ......... 0.0412 ........ 0.0472
16-bit array #1 ...... 0.1378 ........ 0.1596
16-bit array #2 ........... S ............. S
32-bit array .............. S ............. S
complex array ........ 0.1865 ........ 0.2283
fix map #1 ........... 0.0725 ........ 0.1048
fix map #2 ........... 0.0319 ........ 0.0405
fix map #3 ........... 0.0356 ........ 0.0665
fix map #4 ........... 0.0465 ........ 0.0497
16-bit map #1 ........ 0.2540 ........ 0.3028
16-bit map #2 ............. S ............. S
32-bit map ................ S ............. S
complex map .......... 0.2372 ........ 0.2710
fixext 1 ............. 0.0283 ........ 0.0358
fixext 2 ............. 0.0291 ........ 0.0371
fixext 4 ............. 0.0302 ........ 0.0355
fixext 8 ............. 0.0288 ........ 0.0384
fixext 16 ............ 0.0293 ........ 0.0359
8-bit ext ............ 0.0302 ........ 0.0439
16-bit ext ........... 0.0334 ........ 0.0499
32-bit ext ........... 0.1845 ........ 0.1888
32-bit timestamp #1 .. 0.0337 ........ 0.0547
32-bit timestamp #2 .. 0.0335 ........ 0.0560
64-bit timestamp #1 .. 0.0371 ........ 0.0575
64-bit timestamp #2 .. 0.0374 ........ 0.0542
64-bit timestamp #3 .. 0.0356 ........ 0.0533
96-bit timestamp #1 .. 0.0362 ........ 0.0699
96-bit timestamp #2 .. 0.0381 ........ 0.0701
96-bit timestamp #3 .. 0.0367 ........ 0.0687
=============================================
Total 2.7618 4.0820
Skipped 4 4
Failed 0 0
Ignored 0 0
With JIT:
php -n -dzend_extension=opcache.so \
-dpcre.jit=1 -dopcache.jit_buffer_size=64M -dopcache.jit=tracing -dopcache.enable=1 -dopcache.enable_cli=1 \
tests/bench.php
Example output
Filter: MessagePack\Tests\Perf\Filter\ListFilter
Rounds: 3
Iterations: 100000
=============================================
Test/Target Packer BufferUnpacker
---------------------------------------------
nil .................. 0.0005 ........ 0.0054
false ................ 0.0004 ........ 0.0059
true ................. 0.0004 ........ 0.0059
7-bit uint #1 ........ 0.0010 ........ 0.0047
7-bit uint #2 ........ 0.0010 ........ 0.0046
7-bit uint #3 ........ 0.0010 ........ 0.0046
5-bit sint #1 ........ 0.0025 ........ 0.0046
5-bit sint #2 ........ 0.0023 ........ 0.0046
5-bit sint #3 ........ 0.0024 ........ 0.0045
8-bit uint #1 ........ 0.0043 ........ 0.0081
8-bit uint #2 ........ 0.0043 ........ 0.0079
8-bit uint #3 ........ 0.0041 ........ 0.0080
16-bit uint #1 ....... 0.0064 ........ 0.0095
16-bit uint #2 ....... 0.0064 ........ 0.0091
16-bit uint #3 ....... 0.0064 ........ 0.0094
32-bit uint #1 ....... 0.0085 ........ 0.0114
32-bit uint #2 ....... 0.0077 ........ 0.0122
32-bit uint #3 ....... 0.0077 ........ 0.0120
64-bit uint #1 ....... 0.0085 ........ 0.0159
64-bit uint #2 ....... 0.0086 ........ 0.0157
64-bit uint #3 ....... 0.0086 ........ 0.0158
8-bit int #1 ......... 0.0042 ........ 0.0080
8-bit int #2 ......... 0.0042 ........ 0.0080
8-bit int #3 ......... 0.0042 ........ 0.0081
16-bit int #1 ........ 0.0065 ........ 0.0095
16-bit int #2 ........ 0.0065 ........ 0.0090
16-bit int #3 ........ 0.0056 ........ 0.0085
32-bit int #1 ........ 0.0067 ........ 0.0107
32-bit int #2 ........ 0.0066 ........ 0.0106
32-bit int #3 ........ 0.0063 ........ 0.0104
64-bit int #1 ........ 0.0072 ........ 0.0162
64-bit int #2 ........ 0.0073 ........ 0.0174
64-bit int #3 ........ 0.0072 ........ 0.0164
64-bit int #4 ........ 0.0077 ........ 0.0161
64-bit float #1 ...... 0.0053 ........ 0.0135
64-bit float #2 ...... 0.0053 ........ 0.0135
64-bit float #3 ...... 0.0052 ........ 0.0135
fix string #1 ....... -0.0002 ........ 0.0044
fix string #2 ........ 0.0035 ........ 0.0067
fix string #3 ........ 0.0035 ........ 0.0077
fix string #4 ........ 0.0033 ........ 0.0078
8-bit string #1 ...... 0.0059 ........ 0.0110
8-bit string #2 ...... 0.0063 ........ 0.0121
8-bit string #3 ...... 0.0064 ........ 0.0124
16-bit string #1 ..... 0.0099 ........ 0.0146
16-bit string #2 ..... 0.1522 ........ 0.1474
32-bit string ........ 0.1511 ........ 0.1483
wide char string #1 .. 0.0039 ........ 0.0084
wide char string #2 .. 0.0073 ........ 0.0123
8-bit binary #1 ...... 0.0040 ........ 0.0112
8-bit binary #2 ...... 0.0075 ........ 0.0123
8-bit binary #3 ...... 0.0077 ........ 0.0129
16-bit binary ........ 0.0096 ........ 0.0145
32-bit binary ........ 0.1535 ........ 0.1479
fix array #1 ......... 0.0008 ........ 0.0061
fix array #2 ......... 0.0121 ........ 0.0165
fix array #3 ......... 0.0193 ........ 0.0222
16-bit array #1 ...... 0.0607 ........ 0.0479
16-bit array #2 ........... S ............. S
32-bit array .............. S ............. S
complex array ........ 0.0749 ........ 0.0824
fix map #1 ........... 0.0329 ........ 0.0431
fix map #2 ........... 0.0161 ........ 0.0189
fix map #3 ........... 0.0205 ........ 0.0262
fix map #4 ........... 0.0252 ........ 0.0205
16-bit map #1 ........ 0.1016 ........ 0.0927
16-bit map #2 ............. S ............. S
32-bit map ................ S ............. S
complex map .......... 0.1096 ........ 0.1030
fixext 1 ............. 0.0157 ........ 0.0161
fixext 2 ............. 0.0175 ........ 0.0183
fixext 4 ............. 0.0156 ........ 0.0185
fixext 8 ............. 0.0163 ........ 0.0184
fixext 16 ............ 0.0164 ........ 0.0182
8-bit ext ............ 0.0158 ........ 0.0207
16-bit ext ........... 0.0203 ........ 0.0219
32-bit ext ........... 0.1614 ........ 0.1539
32-bit timestamp #1 .. 0.0195 ........ 0.0249
32-bit timestamp #2 .. 0.0188 ........ 0.0260
64-bit timestamp #1 .. 0.0207 ........ 0.0281
64-bit timestamp #2 .. 0.0212 ........ 0.0291
64-bit timestamp #3 .. 0.0207 ........ 0.0295
96-bit timestamp #1 .. 0.0222 ........ 0.0358
96-bit timestamp #2 .. 0.0228 ........ 0.0353
96-bit timestamp #3 .. 0.0210 ........ 0.0319
=============================================
Total 1.6432 1.9674
Skipped 4 4
Failed 0 0
Ignored 0 0
You may change default benchmark settings by defining the following environment variables:
| Name | Default |
|---|---|
| MP_BENCH_TARGETS | pure_p,pure_u, see a list of available targets |
| MP_BENCH_ITERATIONS | 100_000 |
| MP_BENCH_DURATION | not set |
| MP_BENCH_ROUNDS | 3 |
| MP_BENCH_TESTS | -@slow, see a list of available tests |
For example:
export MP_BENCH_TARGETS=pure_p
export MP_BENCH_ITERATIONS=1000000
export MP_BENCH_ROUNDS=5
# a comma separated list of test names
export MP_BENCH_TESTS='complex array, complex map'
# or a group name
# export MP_BENCH_TESTS='-@slow' // @pecl_comp
# or a regexp
# export MP_BENCH_TESTS='/complex (array|map)/'
Another example, benchmarking both the library and the PECL extension:
MP_BENCH_TARGETS=pure_p,pure_u,pecl_p,pecl_u \
php -n -dextension=msgpack.so -dzend_extension=opcache.so \
-dpcre.jit=1 -dopcache.enable=1 -dopcache.enable_cli=1 \
tests/bench.php
Example output
Filter: MessagePack\Tests\Perf\Filter\ListFilter
Rounds: 3
Iterations: 100000
===========================================================================
Test/Target Packer BufferUnpacker msgpack_pack msgpack_unpack
---------------------------------------------------------------------------
nil .................. 0.0031 ........ 0.0141 ...... 0.0055 ........ 0.0064
false ................ 0.0039 ........ 0.0154 ...... 0.0056 ........ 0.0053
true ................. 0.0038 ........ 0.0139 ...... 0.0056 ........ 0.0044
7-bit uint #1 ........ 0.0061 ........ 0.0110 ...... 0.0059 ........ 0.0046
7-bit uint #2 ........ 0.0065 ........ 0.0119 ...... 0.0042 ........ 0.0029
7-bit uint #3 ........ 0.0054 ........ 0.0117 ...... 0.0045 ........ 0.0025
5-bit sint #1 ........ 0.0047 ........ 0.0103 ...... 0.0038 ........ 0.0022
5-bit sint #2 ........ 0.0048 ........ 0.0117 ...... 0.0038 ........ 0.0022
5-bit sint #3 ........ 0.0046 ........ 0.0102 ...... 0.0038 ........ 0.0023
8-bit uint #1 ........ 0.0063 ........ 0.0174 ...... 0.0039 ........ 0.0031
8-bit uint #2 ........ 0.0063 ........ 0.0167 ...... 0.0040 ........ 0.0029
8-bit uint #3 ........ 0.0063 ........ 0.0168 ...... 0.0039 ........ 0.0030
16-bit uint #1 ....... 0.0092 ........ 0.0222 ...... 0.0049 ........ 0.0030
16-bit uint #2 ....... 0.0096 ........ 0.0227 ...... 0.0042 ........ 0.0046
16-bit uint #3 ....... 0.0123 ........ 0.0274 ...... 0.0059 ........ 0.0051
32-bit uint #1 ....... 0.0136 ........ 0.0331 ...... 0.0060 ........ 0.0048
32-bit uint #2 ....... 0.0130 ........ 0.0336 ...... 0.0070 ........ 0.0048
32-bit uint #3 ....... 0.0127 ........ 0.0329 ...... 0.0051 ........ 0.0048
64-bit uint #1 ....... 0.0126 ........ 0.0268 ...... 0.0055 ........ 0.0049
64-bit uint #2 ....... 0.0135 ........ 0.0281 ...... 0.0052 ........ 0.0046
64-bit uint #3 ....... 0.0131 ........ 0.0274 ...... 0.0069 ........ 0.0044
8-bit int #1 ......... 0.0077 ........ 0.0236 ...... 0.0058 ........ 0.0044
8-bit int #2 ......... 0.0087 ........ 0.0244 ...... 0.0058 ........ 0.0048
8-bit int #3 ......... 0.0084 ........ 0.0241 ...... 0.0055 ........ 0.0049
16-bit int #1 ........ 0.0112 ........ 0.0271 ...... 0.0048 ........ 0.0045
16-bit int #2 ........ 0.0124 ........ 0.0292 ...... 0.0057 ........ 0.0049
16-bit int #3 ........ 0.0118 ........ 0.0270 ...... 0.0058 ........ 0.0050
32-bit int #1 ........ 0.0137 ........ 0.0366 ...... 0.0058 ........ 0.0051
32-bit int #2 ........ 0.0133 ........ 0.0366 ...... 0.0056 ........ 0.0049
32-bit int #3 ........ 0.0129 ........ 0.0350 ...... 0.0052 ........ 0.0048
64-bit int #1 ........ 0.0145 ........ 0.0254 ...... 0.0034 ........ 0.0025
64-bit int #2 ........ 0.0097 ........ 0.0214 ...... 0.0034 ........ 0.0025
64-bit int #3 ........ 0.0096 ........ 0.0287 ...... 0.0059 ........ 0.0050
64-bit int #4 ........ 0.0143 ........ 0.0277 ...... 0.0059 ........ 0.0046
64-bit float #1 ...... 0.0134 ........ 0.0281 ...... 0.0057 ........ 0.0052
64-bit float #2 ...... 0.0141 ........ 0.0281 ...... 0.0057 ........ 0.0050
64-bit float #3 ...... 0.0144 ........ 0.0282 ...... 0.0057 ........ 0.0050
fix string #1 ........ 0.0036 ........ 0.0143 ...... 0.0066 ........ 0.0053
fix string #2 ........ 0.0107 ........ 0.0222 ...... 0.0065 ........ 0.0068
fix string #3 ........ 0.0116 ........ 0.0245 ...... 0.0063 ........ 0.0069
fix string #4 ........ 0.0105 ........ 0.0253 ...... 0.0083 ........ 0.0077
8-bit string #1 ...... 0.0126 ........ 0.0318 ...... 0.0075 ........ 0.0088
8-bit string #2 ...... 0.0121 ........ 0.0295 ...... 0.0076 ........ 0.0086
8-bit string #3 ...... 0.0125 ........ 0.0293 ...... 0.0130 ........ 0.0093
16-bit string #1 ..... 0.0159 ........ 0.0368 ...... 0.0117 ........ 0.0086
16-bit string #2 ..... 0.1547 ........ 0.1686 ...... 0.1516 ........ 0.1373
32-bit string ........ 0.1558 ........ 0.1729 ...... 0.1511 ........ 0.1396
wide char string #1 .. 0.0098 ........ 0.0237 ...... 0.0066 ........ 0.0065
wide char string #2 .. 0.0128 ........ 0.0291 ...... 0.0061 ........ 0.0082
8-bit binary #1 ........... I ............. I ........... F ............. I
8-bit binary #2 ........... I ............. I ........... F ............. I
8-bit binary #3 ........... I ............. I ........... F ............. I
16-bit binary ............. I ............. I ........... F ............. I
32-bit binary ............. I ............. I ........... F ............. I
fix array #1 ......... 0.0040 ........ 0.0129 ...... 0.0120 ........ 0.0058
fix array #2 ......... 0.0279 ........ 0.0390 ...... 0.0143 ........ 0.0165
fix array #3 ......... 0.0415 ........ 0.0463 ...... 0.0162 ........ 0.0187
16-bit array #1 ...... 0.1349 ........ 0.1628 ...... 0.0334 ........ 0.0341
16-bit array #2 ........... S ............. S ........... S ............. S
32-bit array .............. S ............. S ........... S ............. S
complex array ............. I ............. I ........... F ............. F
fix map #1 ................ I ............. I ........... F ............. I
fix map #2 ........... 0.0345 ........ 0.0391 ...... 0.0143 ........ 0.0168
fix map #3 ................ I ............. I ........... F ............. I
fix map #4 ........... 0.0459 ........ 0.0473 ...... 0.0151 ........ 0.0163
16-bit map #1 ........ 0.2518 ........ 0.2962 ...... 0.0400 ........ 0.0490
16-bit map #2 ............. S ............. S ........... S ............. S
32-bit map ................ S ............. S ........... S ............. S
complex map .......... 0.2380 ........ 0.2682 ...... 0.0545 ........ 0.0579
fixext 1 .................. I ............. I ........... F ............. F
fixext 2 .................. I ............. I ........... F ............. F
fixext 4 .................. I ............. I ........... F ............. F
fixext 8 .................. I ............. I ........... F ............. F
fixext 16 ................. I ............. I ........... F ............. F
8-bit ext ................. I ............. I ........... F ............. F
16-bit ext ................ I ............. I ........... F ............. F
32-bit ext ................ I ............. I ........... F ............. F
32-bit timestamp #1 ....... I ............. I ........... F ............. F
32-bit timestamp #2 ....... I ............. I ........... F ............. F
64-bit timestamp #1 ....... I ............. I ........... F ............. F
64-bit timestamp #2 ....... I ............. I ........... F ............. F
64-bit timestamp #3 ....... I ............. I ........... F ............. F
96-bit timestamp #1 ....... I ............. I ........... F ............. F
96-bit timestamp #2 ....... I ............. I ........... F ............. F
96-bit timestamp #3 ....... I ............. I ........... F ............. F
===========================================================================
Total 1.5625 2.3866 0.7735 0.7243
Skipped 4 4 4 4
Failed 0 0 24 17
Ignored 24 24 0 7
With JIT:
MP_BENCH_TARGETS=pure_p,pure_u,pecl_p,pecl_u \
php -n -dextension=msgpack.so -dzend_extension=opcache.so \
-dpcre.jit=1 -dopcache.jit_buffer_size=64M -dopcache.jit=tracing -dopcache.enable=1 -dopcache.enable_cli=1 \
tests/bench.php
Example output
Filter: MessagePack\Tests\Perf\Filter\ListFilter
Rounds: 3
Iterations: 100000
===========================================================================
Test/Target Packer BufferUnpacker msgpack_pack msgpack_unpack
---------------------------------------------------------------------------
nil .................. 0.0001 ........ 0.0052 ...... 0.0053 ........ 0.0042
false ................ 0.0007 ........ 0.0060 ...... 0.0057 ........ 0.0043
true ................. 0.0008 ........ 0.0060 ...... 0.0056 ........ 0.0041
7-bit uint #1 ........ 0.0031 ........ 0.0046 ...... 0.0062 ........ 0.0041
7-bit uint #2 ........ 0.0021 ........ 0.0043 ...... 0.0062 ........ 0.0041
7-bit uint #3 ........ 0.0022 ........ 0.0044 ...... 0.0061 ........ 0.0040
5-bit sint #1 ........ 0.0030 ........ 0.0048 ...... 0.0062 ........ 0.0040
5-bit sint #2 ........ 0.0032 ........ 0.0046 ...... 0.0062 ........ 0.0040
5-bit sint #3 ........ 0.0031 ........ 0.0046 ...... 0.0062 ........ 0.0040
8-bit uint #1 ........ 0.0054 ........ 0.0079 ...... 0.0062 ........ 0.0050
8-bit uint #2 ........ 0.0051 ........ 0.0079 ...... 0.0064 ........ 0.0044
8-bit uint #3 ........ 0.0051 ........ 0.0082 ...... 0.0062 ........ 0.0044
16-bit uint #1 ....... 0.0077 ........ 0.0094 ...... 0.0065 ........ 0.0045
16-bit uint #2 ....... 0.0077 ........ 0.0094 ...... 0.0063 ........ 0.0045
16-bit uint #3 ....... 0.0077 ........ 0.0095 ...... 0.0064 ........ 0.0047
32-bit uint #1 ....... 0.0088 ........ 0.0119 ...... 0.0063 ........ 0.0043
32-bit uint #2 ....... 0.0089 ........ 0.0117 ...... 0.0062 ........ 0.0039
32-bit uint #3 ....... 0.0089 ........ 0.0118 ...... 0.0063 ........ 0.0044
64-bit uint #1 ....... 0.0097 ........ 0.0155 ...... 0.0063 ........ 0.0045
64-bit uint #2 ....... 0.0095 ........ 0.0153 ...... 0.0061 ........ 0.0045
64-bit uint #3 ....... 0.0096 ........ 0.0156 ...... 0.0063 ........ 0.0047
8-bit int #1 ......... 0.0053 ........ 0.0083 ...... 0.0062 ........ 0.0044
8-bit int #2 ......... 0.0052 ........ 0.0080 ...... 0.0062 ........ 0.0044
8-bit int #3 ......... 0.0052 ........ 0.0080 ...... 0.0062 ........ 0.0043
16-bit int #1 ........ 0.0089 ........ 0.0097 ...... 0.0069 ........ 0.0046
16-bit int #2 ........ 0.0075 ........ 0.0093 ...... 0.0063 ........ 0.0043
16-bit int #3 ........ 0.0075 ........ 0.0094 ...... 0.0062 ........ 0.0046
32-bit int #1 ........ 0.0086 ........ 0.0122 ...... 0.0063 ........ 0.0044
32-bit int #2 ........ 0.0087 ........ 0.0120 ...... 0.0066 ........ 0.0046
32-bit int #3 ........ 0.0086 ........ 0.0121 ...... 0.0060 ........ 0.0044
64-bit int #1 ........ 0.0096 ........ 0.0149 ...... 0.0060 ........ 0.0045
64-bit int #2 ........ 0.0096 ........ 0.0157 ...... 0.0062 ........ 0.0044
64-bit int #3 ........ 0.0096 ........ 0.0160 ...... 0.0063 ........ 0.0046
64-bit int #4 ........ 0.0097 ........ 0.0157 ...... 0.0061 ........ 0.0044
64-bit float #1 ...... 0.0079 ........ 0.0153 ...... 0.0056 ........ 0.0044
64-bit float #2 ...... 0.0079 ........ 0.0152 ...... 0.0057 ........ 0.0045
64-bit float #3 ...... 0.0079 ........ 0.0155 ...... 0.0057 ........ 0.0044
fix string #1 ........ 0.0010 ........ 0.0045 ...... 0.0071 ........ 0.0044
fix string #2 ........ 0.0048 ........ 0.0075 ...... 0.0070 ........ 0.0060
fix string #3 ........ 0.0048 ........ 0.0086 ...... 0.0068 ........ 0.0060
fix string #4 ........ 0.0050 ........ 0.0088 ...... 0.0070 ........ 0.0059
8-bit string #1 ...... 0.0081 ........ 0.0129 ...... 0.0069 ........ 0.0062
8-bit string #2 ...... 0.0086 ........ 0.0128 ...... 0.0069 ........ 0.0065
8-bit string #3 ...... 0.0086 ........ 0.0126 ...... 0.0115 ........ 0.0065
16-bit string #1 ..... 0.0105 ........ 0.0137 ...... 0.0128 ........ 0.0068
16-bit string #2 ..... 0.1510 ........ 0.1486 ...... 0.1526 ........ 0.1391
32-bit string ........ 0.1517 ........ 0.1475 ...... 0.1504 ........ 0.1370
wide char string #1 .. 0.0044 ........ 0.0085 ...... 0.0067 ........ 0.0057
wide char string #2 .. 0.0081 ........ 0.0125 ...... 0.0069 ........ 0.0063
8-bit binary #1 ........... I ............. I ........... F ............. I
8-bit binary #2 ........... I ............. I ........... F ............. I
8-bit binary #3 ........... I ............. I ........... F ............. I
16-bit binary ............. I ............. I ........... F ............. I
32-bit binary ............. I ............. I ........... F ............. I
fix array #1 ......... 0.0014 ........ 0.0059 ...... 0.0132 ........ 0.0055
fix array #2 ......... 0.0146 ........ 0.0156 ...... 0.0155 ........ 0.0148
fix array #3 ......... 0.0211 ........ 0.0229 ...... 0.0179 ........ 0.0180
16-bit array #1 ...... 0.0673 ........ 0.0498 ...... 0.0343 ........ 0.0388
16-bit array #2 ........... S ............. S ........... S ............. S
32-bit array .............. S ............. S ........... S ............. S
complex array ............. I ............. I ........... F ............. F
fix map #1 ................ I ............. I ........... F ............. I
fix map #2 ........... 0.0148 ........ 0.0180 ...... 0.0156 ........ 0.0179
fix map #3 ................ I ............. I ........... F ............. I
fix map #4 ........... 0.0252 ........ 0.0201 ...... 0.0214 ........ 0.0167
16-bit map #1 ........ 0.1027 ........ 0.0836 ...... 0.0388 ........ 0.0510
16-bit map #2 ............. S ............. S ........... S ............. S
32-bit map ................ S ............. S ........... S ............. S
complex map .......... 0.1104 ........ 0.1010 ...... 0.0556 ........ 0.0602
fixext 1 .................. I ............. I ........... F ............. F
fixext 2 .................. I ............. I ........... F ............. F
fixext 4 .................. I ............. I ........... F ............. F
fixext 8 .................. I ............. I ........... F ............. F
fixext 16 ................. I ............. I ........... F ............. F
8-bit ext ................. I ............. I ........... F ............. F
16-bit ext ................ I ............. I ........... F ............. F
32-bit ext ................ I ............. I ........... F ............. F
32-bit timestamp #1 ....... I ............. I ........... F ............. F
32-bit timestamp #2 ....... I ............. I ........... F ............. F
64-bit timestamp #1 ....... I ............. I ........... F ............. F
64-bit timestamp #2 ....... I ............. I ........... F ............. F
64-bit timestamp #3 ....... I ............. I ........... F ............. F
96-bit timestamp #1 ....... I ............. I ........... F ............. F
96-bit timestamp #2 ....... I ............. I ........... F ............. F
96-bit timestamp #3 ....... I ............. I ........... F ............. F
===========================================================================
Total 0.9642 1.0909 0.8224 0.7213
Skipped 4 4 4 4
Failed 0 0 24 17
Ignored 24 24 0 7
Note that the msgpack extension (v2.1.2) doesn't support ext, bin and UTF-8 str types.
License
The library is released under the MIT License. See the bundled LICENSE file for details.
Author: rybakit
Source Code: https://github.com/rybakit/msgpack.php
License: MIT License
1654075127
Enhance Amazon Aurora Read/Write Capability with ShardingSphere-JDBC
1. Introduction
Amazon Aurora is a relational database management system (RDBMS) developed by AWS(Amazon Web Services). Aurora gives you the performance and availability of commercial-grade databases with full MySQL and PostgreSQL compatibility. In terms of high performance, Aurora MySQL and Aurora PostgreSQL have shown an increase in throughput of up to 5X over stock MySQL and 3X over stock PostgreSQL respectively on similar hardware. In terms of scalability, Aurora achieves enhancements and innovations in storage and computing, horizontal and vertical functions.
Aurora supports up to 128TB of storage capacity and supports dynamic scaling of storage layer in units of 10GB. In terms of computing, Aurora supports scalable configurations for multiple read replicas. Each region can have an additional 15 Aurora replicas. In addition, Aurora provides multi-primary architecture to support four read/write nodes. Its Serverless architecture allows vertical scaling and reduces typical latency to under a second, while the Global Database enables a single database cluster to span multiple AWS Regions in low latency.
Aurora already provides great scalability with the growth of user data volume. Can it handle more data and support more concurrent access? You may consider using sharding to support the configuration of multiple underlying Aurora clusters. To this end, a series of blogs, including this one, provides you with a reference in choosing between Proxy and JDBC for sharding.
1.1 Why sharding is needed
AWS Aurora offers a single relational database. Primary-secondary, multi-primary, and global database, and other forms of hosting architecture can satisfy various architectural scenarios above. However, Aurora doesn’t provide direct support for sharding scenarios, and sharding has a variety of forms, such as vertical and horizontal forms. If we want to further increase data capacity, some problems have to be solved, such as cross-node database Join, associated query, distributed transactions, SQL sorting, page turning, function calculation, database global primary key, capacity planning, and secondary capacity expansion after sharding.
1.2 Sharding methods
It is generally accepted that when the capacity of a MySQL table is less than 10 million, the time spent on queries is optimal because at this time the height of its BTREE index is between 3 and 5. Data sharding can reduce the amount of data in a single table and distribute the read and write loads to different data nodes at the same time. Data sharding can be divided into vertical sharding and horizontal sharding.
1. Advantages of vertical sharding
- Address the coupling of business system and make clearer.
- Implement hierarchical management, maintenance, monitoring, and expansion to data of different businesses, like micro-service governance.
- In high concurrency scenarios, vertical sharding removes the bottleneck of IO, database connections, and hardware resources on a single machine to some extent.
2. Disadvantages of vertical sharding
- After splitting the library,
Joincan only be implemented by interface aggregation, which will increase the complexity of development. - After splitting the library, it is complex to process distributed transactions.
- There is a large amount of data on a single table and horizontal sharding is required.
3. Advantages of horizontal sharding
- There is no such performance bottleneck as a large amount of data on a single database and high concurrency, and it increases system stability and load capacity.
- The business modules do not need to be split due to minor modification on the application client.
4. Disadvantages of horizontal sharding
- Transaction consistency across shards is hard to be guaranteed;
- The performance of associated query in cross-library
Joinis poor. - It’s difficult to scale the data many times and maintenance is a big workload.
Based on the analysis above, and the available studis on popular sharding middleware, we selected ShardingSphere, an open source product, combined with Amazon Aurora to introduce how the combination of these two products meets various forms of sharding and how to solve the problems brought by sharding.
ShardingSphere is an open source ecosystem including a set of distributed database middleware solutions, including 3 independent products, Sharding-JDBC, Sharding-Proxy & Sharding-Sidecar.
2. ShardingSphere introduction:
The characteristics of Sharding-JDBC are:
- With the client end connecting directly to the database, it provides service in the form of jar and requires no extra deployment and dependence.
- It can be considered as an enhanced JDBC driver, which is fully compatible with JDBC and all kinds of ORM frameworks.
- Applicable in any ORM framework based on JDBC, such as JPA, Hibernate, Mybatis, Spring JDBC Template or direct use of JDBC.
- Support any third-party database connection pool, such as DBCP, C3P0, BoneCP, Druid, HikariCP;
- Support any kind of JDBC standard database: MySQL, Oracle, SQLServer, PostgreSQL and any databases accessible to JDBC.
- Sharding-JDBC adopts decentralized architecture, applicable to high-performance light-weight OLTP application developed with Java
Hybrid Structure Integrating Sharding-JDBC and Applications
Sharding-JDBC’s core concepts
Data node: The smallest unit of a data slice, consisting of a data source name and a data table, such as ds_0.product_order_0.
Actual table: The physical table that really exists in the horizontal sharding database, such as product order tables: product_order_0, product_order_1, and product_order_2.
Logic table: The logical name of the horizontal sharding databases (tables) with the same schema. For instance, the logic table of the order product_order_0, product_order_1, and product_order_2 is product_order.
Binding table: It refers to the primary table and the joiner table with the same sharding rules. For example, product_order table and product_order_item are sharded by order_id, so they are binding tables with each other. Cartesian product correlation will not appear in the multi-tables correlating query, so the query efficiency will increase greatly.
Broadcast table: It refers to tables that exist in all sharding database sources. The schema and data must consist in each database. It can be applied to the small data volume that needs to correlate with big data tables to query, dictionary table and configuration table for example.
3. Testing ShardingSphere-JDBC
3.1 Example project
Download the example project code locally. In order to ensure the stability of the test code, we choose shardingsphere-example-4.0.0 version.
git clone https://github.com/apache/shardingsphere-example.git
Project description：
shardingsphere-example
├── example-core
│ ├── config-utility
│ ├── example-api
│ ├── example-raw-jdbc
│ ├── example-spring-jpa #spring+jpa integration-based entity，repository
│ └── example-spring-mybatis
├── sharding-jdbc-example
│ ├── sharding-example
│ │ ├── sharding-raw-jdbc-example
│ │ ├── sharding-spring-boot-jpa-example #integration-based sharding-jdbc functions
│ │ ├── sharding-spring-boot-mybatis-example
│ │ ├── sharding-spring-namespace-jpa-example
│ │ └── sharding-spring-namespace-mybatis-example
│ ├── orchestration-example
│ │ ├── orchestration-raw-jdbc-example
│ │ ├── orchestration-spring-boot-example #integration-based sharding-jdbc governance function
│ │ └── orchestration-spring-namespace-example
│ ├── transaction-example
│ │ ├── transaction-2pc-xa-example #sharding-jdbc sample of two-phase commit for a distributed transaction
│ │ └──transaction-base-seata-example #sharding-jdbc distributed transaction seata sample
│ ├── other-feature-example
│ │ ├── hint-example
│ │ └── encrypt-example
├── sharding-proxy-example
│ └── sharding-proxy-boot-mybatis-example
└── src/resources
└── manual_schema.sql
Configuration file description:
application-master-slave.properties #read/write splitting profile
application-sharding-databases-tables.properties #sharding profile
application-sharding-databases.properties #library split profile only
application-sharding-master-slave.properties #sharding and read/write splitting profile
application-sharding-tables.properties #table split profile
application.properties #spring boot profile
Code logic description:
The following is the entry class of the Spring Boot application below. Execute it to run the project.
The execution logic of demo is as follows:
3.2 Verifying read/write splitting
As business grows, the write and read requests can be split to different database nodes to effectively promote the processing capability of the entire database cluster. Aurora uses a reader/writer endpoint to meet users' requirements to write and read with strong consistency, and a read-only endpoint to meet the requirements to read without strong consistency. Aurora's read and write latency is within single-digit milliseconds, much lower than MySQL's binlog-based logical replication, so there's a lot of loads that can be directed to a read-only endpoint.
Through the one primary and multiple secondary configuration, query requests can be evenly distributed to multiple data replicas, which further improves the processing capability of the system. Read/write splitting can improve the throughput and availability of system, but it can also lead to data inconsistency. Aurora provides a primary/secondary architecture in a fully managed form, but applications on the upper-layer still need to manage multiple data sources when interacting with Aurora, routing SQL requests to different nodes based on the read/write type of SQL statements and certain routing policies.
ShardingSphere-JDBC provides read/write splitting features and it is integrated with application programs so that the complex configuration between application programs and database clusters can be separated from application programs. Developers can manage the Shard through configuration files and combine it with ORM frameworks such as Spring JPA and Mybatis to completely separate the duplicated logic from the code, which greatly improves the ability to maintain code and reduces the coupling between code and database.
3.2.1 Setting up the database environment
Create a set of Aurora MySQL read/write splitting clusters. The model is db.r5.2xlarge. Each set of clusters has one write node and two read nodes.
3.2.2 Configuring Sharding-JDBC
application.properties spring boot Master profile description:
You need to replace the green ones with your own environment configuration.
# Jpa automatically creates and drops data tables based on entities
spring.jpa.properties.hibernate.hbm2ddl.auto=create-drop
spring.jpa.properties.hibernate.dialect=org.hibernate.dialect.MySQL5Dialect
spring.jpa.properties.hibernate.show_sql=true
#spring.profiles.active=sharding-databases
#spring.profiles.active=sharding-tables
#spring.profiles.active=sharding-databases-tables
#Activate master-slave configuration item so that sharding-jdbc can use master-slave profile
spring.profiles.active=master-slave
#spring.profiles.active=sharding-master-slave
application-master-slave.properties sharding-jdbc profile description:
spring.shardingsphere.datasource.names=ds_master,ds_slave_0,ds_slave_1
# data souce-master
spring.shardingsphere.datasource.ds_master.driver-class-name=com.mysql.jdbc.Driver
spring.shardingsphere.datasource.ds_master.password=Your master DB password
spring.shardingsphere.datasource.ds_master.type=com.zaxxer.hikari.HikariDataSource
spring.shardingsphere.datasource.ds_master.jdbc-url=Your primary DB data sourceurl spring.shardingsphere.datasource.ds_master.username=Your primary DB username
# data source-slave
spring.shardingsphere.datasource.ds_slave_0.driver-class-name=com.mysql.jdbc.Driver
spring.shardingsphere.datasource.ds_slave_0.password= Your slave DB password
spring.shardingsphere.datasource.ds_slave_0.type=com.zaxxer.hikari.HikariDataSource
spring.shardingsphere.datasource.ds_slave_0.jdbc-url=Your slave DB data source url
spring.shardingsphere.datasource.ds_slave_0.username= Your slave DB username
# data source-slave
spring.shardingsphere.datasource.ds_slave_1.driver-class-name=com.mysql.jdbc.Driver
spring.shardingsphere.datasource.ds_slave_1.password= Your slave DB password
spring.shardingsphere.datasource.ds_slave_1.type=com.zaxxer.hikari.HikariDataSource
spring.shardingsphere.datasource.ds_slave_1.jdbc-url= Your slave DB data source url
spring.shardingsphere.datasource.ds_slave_1.username= Your slave DB username
# Routing Policy Configuration
spring.shardingsphere.masterslave.load-balance-algorithm-type=round_robin
spring.shardingsphere.masterslave.name=ds_ms
spring.shardingsphere.masterslave.master-data-source-name=ds_master
spring.shardingsphere.masterslave.slave-data-source-names=ds_slave_0,ds_slave_1
# sharding-jdbc configures the information storage mode
spring.shardingsphere.mode.type=Memory
# start shardingsphere log，and you can see the conversion from logical SQL to actual SQL from the print
spring.shardingsphere.props.sql.show=true
3.2.3 Test and verification process description
- Test environment data initialization: Spring JPA initialization automatically creates tables for testing.
- Write data to the master instance
As shown in the ShardingSphere-SQL log figure below, the write SQL is executed on the ds_master data source.
- Data query operations are performed on the slave library.
As shown in the ShardingSphere-SQL log figure below, the read SQL is executed on the ds_slave data source in the form of polling.
[INFO ] 2022-04-02 19:43:39,376 --main-- [ShardingSphere-SQL] Rule Type: master-slave
[INFO ] 2022-04-02 19:43:39,376 --main-- [ShardingSphere-SQL] SQL: select orderentit0_.order_id as order_id1_1_, orderentit0_.address_id as address_2_1_,
orderentit0_.status as status3_1_, orderentit0_.user_id as user_id4_1_ from t_order orderentit0_ ::: DataSources: ds_slave_0
---------------------------- Print OrderItem Data -------------------
Hibernate: select orderiteme1_.order_item_id as order_it1_2_, orderiteme1_.order_id as order_id2_2_, orderiteme1_.status as status3_2_, orderiteme1_.user_id
as user_id4_2_ from t_order orderentit0_ cross join t_order_item orderiteme1_ where orderentit0_.order_id=orderiteme1_.order_id
[INFO ] 2022-04-02 19:43:40,898 --main-- [ShardingSphere-SQL] Rule Type: master-slave
[INFO ] 2022-04-02 19:43:40,898 --main-- [ShardingSphere-SQL] SQL: select orderiteme1_.order_item_id as order_it1_2_, orderiteme1_.order_id as order_id2_2_, orderiteme1_.status as status3_2_,
orderiteme1_.user_id as user_id4_2_ from t_order orderentit0_ cross join t_order_item orderiteme1_ where orderentit0_.order_id=orderiteme1_.order_id ::: DataSources: ds_slave_1
Note: As shown in the figure below, if there are both reads and writes in a transaction, Sharding-JDBC routes both read and write operations to the master library. If the read/write requests are not in the same transaction, the corresponding read requests are distributed to different read nodes according to the routing policy.
@Override
@Transactional // When a transaction is started, both read and write in the transaction go through the master library. When closed, read goes through the slave library and write goes through the master library
public void processSuccess() throws SQLException {
System.out.println("-------------- Process Success Begin ---------------");
List<Long> orderIds = insertData();
printData();
deleteData(orderIds);
printData();
System.out.println("-------------- Process Success Finish --------------");
}
3.2.4 Verifying Aurora failover scenario
The Aurora database environment adopts the configuration described in Section 2.2.1.
3.2.4.1 Verification process description
- Start the
Spring-Bootproject
2. Perform a failover on Aurora’s console
3. Execute the Rest API request
4. Repeatedly execute POST (http://localhost:8088/save-user) until the call to the API failed to write to Aurora and eventually recovered successfully.
5. The following figure shows the process of executing code failover. It takes about 37 seconds from the time when the latest SQL write is successfully performed to the time when the next SQL write is successfully performed. That is, the application can be automatically recovered from Aurora failover, and the recovery time is about 37 seconds.
3.3 Testing table sharding-only function
3.3.1 Configuring Sharding-JDBC
application.properties spring boot master profile description
# Jpa automatically creates and drops data tables based on entities
spring.jpa.properties.hibernate.hbm2ddl.auto=create-drop
spring.jpa.properties.hibernate.dialect=org.hibernate.dialect.MySQL5Dialect
spring.jpa.properties.hibernate.show_sql=true
#spring.profiles.active=sharding-databases
#Activate sharding-tables configuration items
#spring.profiles.active=sharding-tables
#spring.profiles.active=sharding-databases-tables
# spring.profiles.active=master-slave
#spring.profiles.active=sharding-master-slave
application-sharding-tables.properties sharding-jdbc profile description
## configure primary-key policy
spring.shardingsphere.sharding.tables.t_order.key-generator.column=order_id
spring.shardingsphere.sharding.tables.t_order.key-generator.type=SNOWFLAKE
spring.shardingsphere.sharding.tables.t_order.key-generator.props.worker.id=123
spring.shardingsphere.sharding.tables.t_order_item.actual-data-nodes=ds.t_order_item_$->{0..1}
spring.shardingsphere.sharding.tables.t_order_item.table-strategy.inline.sharding-column=order_id
spring.shardingsphere.sharding.tables.t_order_item.table-strategy.inline.algorithm-expression=t_order_item_$->{order_id % 2}
spring.shardingsphere.sharding.tables.t_order_item.key-generator.column=order_item_id
spring.shardingsphere.sharding.tables.t_order_item.key-generator.type=SNOWFLAKE
spring.shardingsphere.sharding.tables.t_order_item.key-generator.props.worker.id=123
# configure the binding relation of t_order and t_order_item
spring.shardingsphere.sharding.binding-tables[0]=t_order,t_order_item
# configure broadcast tables
spring.shardingsphere.sharding.broadcast-tables=t_address
# sharding-jdbc mode
spring.shardingsphere.mode.type=Memory
# start shardingsphere log
spring.shardingsphere.props.sql.show=true
3.3.2 Test and verification process description
1. DDL operation
JPA automatically creates tables for testing. When Sharding-JDBC routing rules are configured, the client executes DDL, and Sharding-JDBC automatically creates corresponding tables according to the table splitting rules. If t_address is a broadcast table, create a t_address because there is only one master instance. Two physical tables t_order_0 and t_order_1 will be created when creating t_order.
2. Write operation
As shown in the figure below, Logic SQL inserts a record into t_order. When Sharding-JDBC is executed, data will be distributed to t_order_0 and t_order_1 according to the table splitting rules.
When t_order and t_order_item are bound, the records associated with order_item and order are placed on the same physical table.
3. Read operation
As shown in the figure below, perform the join query operations to order and order_item under the binding table, and the physical shard is precisely located based on the binding relationship.
The join query operations on order and order_item under the unbound table will traverse all shards.
3.4 Testing database sharding-only function
3.4.1 Setting up the database environment
Create two instances on Aurora: ds_0 and ds_1
When the sharding-spring-boot-jpa-example project is started, tables t_order, t_order_item，t_address will be created on two Aurora instances.
3.4.2 Configuring Sharding-JDBC
application.properties springboot master profile description
# Jpa automatically creates and drops data tables based on entities
spring.jpa.properties.hibernate.hbm2ddl.auto=create
spring.jpa.properties.hibernate.dialect=org.hibernate.dialect.MySQL5Dialect
spring.jpa.properties.hibernate.show_sql=true
# Activate sharding-databases configuration items
spring.profiles.active=sharding-databases
#spring.profiles.active=sharding-tables
#spring.profiles.active=sharding-databases-tables
#spring.profiles.active=master-slave
#spring.profiles.active=sharding-master-slave
application-sharding-databases.properties sharding-jdbc profile description
spring.shardingsphere.datasource.names=ds_0,ds_1
# ds_0
spring.shardingsphere.datasource.ds_0.type=com.zaxxer.hikari.HikariDataSource
spring.shardingsphere.datasource.ds_0.driver-class-name=com.mysql.jdbc.Driver
spring.shardingsphere.datasource.ds_0.jdbc-url= spring.shardingsphere.datasource.ds_0.username=
spring.shardingsphere.datasource.ds_0.password=
# ds_1
spring.shardingsphere.datasource.ds_1.type=com.zaxxer.hikari.HikariDataSource
spring.shardingsphere.datasource.ds_1.driver-class-name=com.mysql.jdbc.Driver
spring.shardingsphere.datasource.ds_1.jdbc-url=
spring.shardingsphere.datasource.ds_1.username=
spring.shardingsphere.datasource.ds_1.password=
spring.shardingsphere.sharding.default-database-strategy.inline.sharding-column=user_id
spring.shardingsphere.sharding.default-database-strategy.inline.algorithm-expression=ds_$->{user_id % 2}
spring.shardingsphere.sharding.binding-tables=t_order,t_order_item
spring.shardingsphere.sharding.broadcast-tables=t_address
spring.shardingsphere.sharding.default-data-source-name=ds_0
spring.shardingsphere.sharding.tables.t_order.actual-data-nodes=ds_$->{0..1}.t_order
spring.shardingsphere.sharding.tables.t_order.key-generator.column=order_id
spring.shardingsphere.sharding.tables.t_order.key-generator.type=SNOWFLAKE
spring.shardingsphere.sharding.tables.t_order.key-generator.props.worker.id=123
spring.shardingsphere.sharding.tables.t_order_item.actual-data-nodes=ds_$->{0..1}.t_order_item
spring.shardingsphere.sharding.tables.t_order_item.key-generator.column=order_item_id
spring.shardingsphere.sharding.tables.t_order_item.key-generator.type=SNOWFLAKE
spring.shardingsphere.sharding.tables.t_order_item.key-generator.props.worker.id=123
# sharding-jdbc mode
spring.shardingsphere.mode.type=Memory
# start shardingsphere log
spring.shardingsphere.props.sql.show=true
3.4.3 Test and verification process description
1. DDL operation
JPA automatically creates tables for testing. When Sharding-JDBC’s library splitting and routing rules are configured, the client executes DDL, and Sharding-JDBC will automatically create corresponding tables according to table splitting rules. If t_address is a broadcast table, physical tables will be created on ds_0 and ds_1. The three tables, t_address, t_order and t_order_item will be created on ds_0 and ds_1 respectively.
2. Write operation
For the broadcast table t_address, each record written will also be written to the t_address tables of ds_0 and ds_1.
The tables t_order and t_order_item of the slave library are written on the table in the corresponding instance according to the slave library field and routing policy.
3. Read operation
Query order is routed to the corresponding Aurora instance according to the routing rules of the slave library .
Query Address. Since address is a broadcast table, an instance of address will be randomly selected and queried from the nodes used.
As shown in the figure below, perform the join query operations to order and order_item under the binding table, and the physical shard is precisely located based on the binding relationship.
3.5 Verifying sharding function
3.5.1 Setting up the database environment
As shown in the figure below, create two instances on Aurora: ds_0 and ds_1
When the sharding-spring-boot-jpa-example project is started, physical tables t_order_01, t_order_02, t_order_item_01，and t_order_item_02 and global table t_address will be created on two Aurora instances.
3.5.2 Configuring Sharding-JDBC
application.properties springboot master profile description
# Jpa automatically creates and drops data tables based on entities
spring.jpa.properties.hibernate.hbm2ddl.auto=create
spring.jpa.properties.hibernate.dialect=org.hibernate.dialect.MySQL5Dialect
spring.jpa.properties.hibernate.show_sql=true
# Activate sharding-databases-tables configuration items
#spring.profiles.active=sharding-databases
#spring.profiles.active=sharding-tables
spring.profiles.active=sharding-databases-tables
#spring.profiles.active=master-slave
#spring.profiles.active=sharding-master-slave
application-sharding-databases.properties sharding-jdbc profile description
spring.shardingsphere.datasource.names=ds_0,ds_1
# ds_0
spring.shardingsphere.datasource.ds_0.type=com.zaxxer.hikari.HikariDataSource
spring.shardingsphere.datasource.ds_0.driver-class-name=com.mysql.jdbc.Driver
spring.shardingsphere.datasource.ds_0.jdbc-url= 306/dev?useSSL=false&characterEncoding=utf-8
spring.shardingsphere.datasource.ds_0.username=
spring.shardingsphere.datasource.ds_0.password=
spring.shardingsphere.datasource.ds_0.max-active=16
# ds_1
spring.shardingsphere.datasource.ds_1.type=com.zaxxer.hikari.HikariDataSource
spring.shardingsphere.datasource.ds_1.driver-class-name=com.mysql.jdbc.Driver
spring.shardingsphere.datasource.ds_1.jdbc-url=
spring.shardingsphere.datasource.ds_1.username=
spring.shardingsphere.datasource.ds_1.password=
spring.shardingsphere.datasource.ds_1.max-active=16
# default library splitting policy
spring.shardingsphere.sharding.default-database-strategy.inline.sharding-column=user_id
spring.shardingsphere.sharding.default-database-strategy.inline.algorithm-expression=ds_$->{user_id % 2}
spring.shardingsphere.sharding.binding-tables=t_order,t_order_item
spring.shardingsphere.sharding.broadcast-tables=t_address
# Tables that do not meet the library splitting policy are placed on ds_0
spring.shardingsphere.sharding.default-data-source-name=ds_0
# t_order table splitting policy
spring.shardingsphere.sharding.tables.t_order.actual-data-nodes=ds_$->{0..1}.t_order_$->{0..1}
spring.shardingsphere.sharding.tables.t_order.table-strategy.inline.sharding-column=order_id
spring.shardingsphere.sharding.tables.t_order.table-strategy.inline.algorithm-expression=t_order_$->{order_id % 2}
spring.shardingsphere.sharding.tables.t_order.key-generator.column=order_id
spring.shardingsphere.sharding.tables.t_order.key-generator.type=SNOWFLAKE
spring.shardingsphere.sharding.tables.t_order.key-generator.props.worker.id=123
# t_order_item table splitting policy
spring.shardingsphere.sharding.tables.t_order_item.actual-data-nodes=ds_$->{0..1}.t_order_item_$->{0..1}
spring.shardingsphere.sharding.tables.t_order_item.table-strategy.inline.sharding-column=order_id
spring.shardingsphere.sharding.tables.t_order_item.table-strategy.inline.algorithm-expression=t_order_item_$->{order_id % 2}
spring.shardingsphere.sharding.tables.t_order_item.key-generator.column=order_item_id
spring.shardingsphere.sharding.tables.t_order_item.key-generator.type=SNOWFLAKE
spring.shardingsphere.sharding.tables.t_order_item.key-generator.props.worker.id=123
# sharding-jdbc mdoe
spring.shardingsphere.mode.type=Memory
# start shardingsphere log
spring.shardingsphere.props.sql.show=true
3.5.3 Test and verification process description
1. DDL operation
JPA automatically creates tables for testing. When Sharding-JDBC’s sharding and routing rules are configured, the client executes DDL, and Sharding-JDBC will automatically create corresponding tables according to table splitting rules. If t_address is a broadcast table, t_address will be created on both ds_0 and ds_1. The three tables, t_address, t_order and t_order_item will be created on ds_0 and ds_1 respectively.
2. Write operation
For the broadcast table t_address, each record written will also be written to the t_address tables of ds_0 and ds_1.
The tables t_order and t_order_item of the sub-library are written to the table on the corresponding instance according to the slave library field and routing policy.
3. Read operation
The read operation is similar to the library split function verification described in section2.4.3.
3.6 Testing database sharding, table sharding and read/write splitting function
3.6.1 Setting up the database environment
The following figure shows the physical table of the created database instance.
3.6.2 Configuring Sharding-JDBC
application.properties spring boot master profile description
# Jpa automatically creates and drops data tables based on entities
spring.jpa.properties.hibernate.hbm2ddl.auto=create
spring.jpa.properties.hibernate.dialect=org.hibernate.dialect.MySQL5Dialect
spring.jpa.properties.hibernate.show_sql=true
# activate sharding-databases-tables configuration items
#spring.profiles.active=sharding-databases
#spring.profiles.active=sharding-tables
#spring.profiles.active=sharding-databases-tables
#spring.profiles.active=master-slave
spring.profiles.active=sharding-master-slave
application-sharding-master-slave.properties sharding-jdbc profile description
The url, name and password of the database need to be changed to your own database parameters.
spring.shardingsphere.datasource.names=ds_master_0,ds_master_1,ds_master_0_slave_0,ds_master_0_slave_1,ds_master_1_slave_0,ds_master_1_slave_1
spring.shardingsphere.datasource.ds_master_0.type=com.zaxxer.hikari.HikariDataSource
spring.shardingsphere.datasource.ds_master_0.driver-class-name=com.mysql.jdbc.Driver
spring.shardingsphere.datasource.ds_master_0.jdbc-url= spring.shardingsphere.datasource.ds_master_0.username=
spring.shardingsphere.datasource.ds_master_0.password=
spring.shardingsphere.datasource.ds_master_0.max-active=16
spring.shardingsphere.datasource.ds_master_0_slave_0.type=com.zaxxer.hikari.HikariDataSource
spring.shardingsphere.datasource.ds_master_0_slave_0.driver-class-name=com.mysql.jdbc.Driver
spring.shardingsphere.datasource.ds_master_0_slave_0.jdbc-url= spring.shardingsphere.datasource.ds_master_0_slave_0.username=
spring.shardingsphere.datasource.ds_master_0_slave_0.password=
spring.shardingsphere.datasource.ds_master_0_slave_0.max-active=16
spring.shardingsphere.datasource.ds_master_0_slave_1.type=com.zaxxer.hikari.HikariDataSource
spring.shardingsphere.datasource.ds_master_0_slave_1.driver-class-name=com.mysql.jdbc.Driver
spring.shardingsphere.datasource.ds_master_0_slave_1.jdbc-url= spring.shardingsphere.datasource.ds_master_0_slave_1.username=
spring.shardingsphere.datasource.ds_master_0_slave_1.password=
spring.shardingsphere.datasource.ds_master_0_slave_1.max-active=16
spring.shardingsphere.datasource.ds_master_1.type=com.zaxxer.hikari.HikariDataSource
spring.shardingsphere.datasource.ds_master_1.driver-class-name=com.mysql.jdbc.Driver
spring.shardingsphere.datasource.ds_master_1.jdbc-url=
spring.shardingsphere.datasource.ds_master_1.username=
spring.shardingsphere.datasource.ds_master_1.password=
spring.shardingsphere.datasource.ds_master_1.max-active=16
spring.shardingsphere.datasource.ds_master_1_slave_0.type=com.zaxxer.hikari.HikariDataSource
spring.shardingsphere.datasource.ds_master_1_slave_0.driver-class-name=com.mysql.jdbc.Driver
spring.shardingsphere.datasource.ds_master_1_slave_0.jdbc-url=
spring.shardingsphere.datasource.ds_master_1_slave_0.username=
spring.shardingsphere.datasource.ds_master_1_slave_0.password=
spring.shardingsphere.datasource.ds_master_1_slave_0.max-active=16
spring.shardingsphere.datasource.ds_master_1_slave_1.type=com.zaxxer.hikari.HikariDataSource
spring.shardingsphere.datasource.ds_master_1_slave_1.driver-class-name=com.mysql.jdbc.Driver
spring.shardingsphere.datasource.ds_master_1_slave_1.jdbc-url= spring.shardingsphere.datasource.ds_master_1_slave_1.username=admin
spring.shardingsphere.datasource.ds_master_1_slave_1.password=
spring.shardingsphere.datasource.ds_master_1_slave_1.max-active=16
spring.shardingsphere.sharding.default-database-strategy.inline.sharding-column=user_id
spring.shardingsphere.sharding.default-database-strategy.inline.algorithm-expression=ds_$->{user_id % 2}
spring.shardingsphere.sharding.binding-tables=t_order,t_order_item
spring.shardingsphere.sharding.broadcast-tables=t_address
spring.shardingsphere.sharding.default-data-source-name=ds_master_0
spring.shardingsphere.sharding.tables.t_order.actual-data-nodes=ds_$->{0..1}.t_order_$->{0..1}
spring.shardingsphere.sharding.tables.t_order.table-strategy.inline.sharding-column=order_id
spring.shardingsphere.sharding.tables.t_order.table-strategy.inline.algorithm-expression=t_order_$->{order_id % 2}
spring.shardingsphere.sharding.tables.t_order.key-generator.column=order_id
spring.shardingsphere.sharding.tables.t_order.key-generator.type=SNOWFLAKE
spring.shardingsphere.sharding.tables.t_order.key-generator.props.worker.id=123
spring.shardingsphere.sharding.tables.t_order_item.actual-data-nodes=ds_$->{0..1}.t_order_item_$->{0..1}
spring.shardingsphere.sharding.tables.t_order_item.table-strategy.inline.sharding-column=order_id
spring.shardingsphere.sharding.tables.t_order_item.table-strategy.inline.algorithm-expression=t_order_item_$->{order_id % 2}
spring.shardingsphere.sharding.tables.t_order_item.key-generator.column=order_item_id
spring.shardingsphere.sharding.tables.t_order_item.key-generator.type=SNOWFLAKE
spring.shardingsphere.sharding.tables.t_order_item.key-generator.props.worker.id=123
# master/slave data source and slave data source configuration
spring.shardingsphere.sharding.master-slave-rules.ds_0.master-data-source-name=ds_master_0
spring.shardingsphere.sharding.master-slave-rules.ds_0.slave-data-source-names=ds_master_0_slave_0, ds_master_0_slave_1
spring.shardingsphere.sharding.master-slave-rules.ds_1.master-data-source-name=ds_master_1
spring.shardingsphere.sharding.master-slave-rules.ds_1.slave-data-source-names=ds_master_1_slave_0, ds_master_1_slave_1
# sharding-jdbc mode
spring.shardingsphere.mode.type=Memory
# start shardingsphere log
spring.shardingsphere.props.sql.show=true
3.6.3 Test and verification process description
1. DDL operation
JPA automatically creates tables for testing. When Sharding-JDBC’s library splitting and routing rules are configured, the client executes DDL, and Sharding-JDBC will automatically create corresponding tables according to table splitting rules. If t_address is a broadcast table, t_address will be created on both ds_0 and ds_1. The three tables, t_address, t_order and t_order_item will be created on ds_0 and ds_1 respectively.
2. Write operation
For the broadcast table t_address, each record written will also be written to the t_address tables of ds_0 and ds_1.
The tables t_order and t_order_item of the slave library are written to the table on the corresponding instance according to the slave library field and routing policy.
3. Read operation
The join query operations on order and order_item under the binding table are shown below.
3. Conclusion
As an open source product focusing on database enhancement, ShardingSphere is pretty good in terms of its community activitiy, product maturity and documentation richness.
Among its products, ShardingSphere-JDBC is a sharding solution based on the client-side, which supports all sharding scenarios. And there’s no need to introduce an intermediate layer like Proxy, so the complexity of operation and maintenance is reduced. Its latency is theoretically lower than Proxy due to the lack of intermediate layer. In addition, ShardingSphere-JDBC can support a variety of relational databases based on SQL standards such as MySQL/PostgreSQL/Oracle/SQL Server, etc.
However, due to the integration of Sharding-JDBC with the application program, it only supports Java language for now, and is strongly dependent on the application programs. Nevertheless, Sharding-JDBC separates all sharding configuration from the application program, which brings relatively small changes when switching to other middleware.
In conclusion, Sharding-JDBC is a good choice if you use a Java-based system and have to to interconnect with different relational databases — and don’t want to bother with introducing an intermediate layer.
Author
Sun Jinhua
A senior solution architect at AWS, Sun is responsible for the design and consult on cloud architecture. for providing customers with cloud-related design and consulting services. Before joining AWS, he ran his own business, specializing in building e-commerce platforms and designing the overall architecture for e-commerce platforms of automotive companies. He worked in a global leading communication equipment company as a senior engineer, responsible for the development and architecture design of multiple subsystems of LTE equipment system. He has rich experience in architecture design with high concurrency and high availability system, microservice architecture design, database, middleware, IOT etc.
1642390128
파이썬 코딩 무료 강의 - 이미지 처리, 얼굴 인식을 통한 캐릭터 씌우기를 해보아요
파이썬 코딩 무료 강의 (활용편6) - 이미지 처리, 얼굴 인식을 통한 캐릭터 씌우기를 해보아요
파이썬 무료 강의 (활용편6 - 이미지 처리)입니다.
OpenCV 를 이용한 다양한 이미지 처리 기법과 재미있는 프로젝트를 진행합니다.
누구나 볼 수 있도록 쉽고 재미있게 제작하였습니다. ^^
[소개]
(0:00:00) 0.Intro
(0:00:31) 1.소개
(0:02:18) 2.활용편 6 이미지 처리 소개
[OpenCV 전반전]
(0:04:36) 3.환경설정
(0:08:41) 4.이미지 출력
(0:21:51) 5.동영상 출력 #1 파일
(0:29:58) 6.동영상 출력 #2 카메라
(0:34:23) 7.도형 그리기 #1 빈 스케치북
(0:39:49) 8.도형 그리기 #2 영역 색칠
(0:42:26) 9.도형 그리기 #3 직선
(0:51:23) 10.도형 그리기 #4 원
(0:55:09) 11.도형 그리기 #5 사각형
(0:58:32) 12.도형 그리기 #6 다각형
(1:09:23) 13.텍스트 #1 기본
(1:17:45) 14.텍스트 #2 한글 우회
(1:24:14) 15.파일 저장 #1 이미지
(1:29:27) 16.파일 저장 #2 동영상
(1:39:29) 17.크기 조정
(1:50:16) 18.이미지 자르기
(1:57:03) 19.이미지 대칭
(2:01:46) 20.이미지 회전
(2:06:07) 21.이미지 변형 - 흑백
(2:11:25) 22.이미지 변형 - 흐림
(2:18:03) 23.이미지 변형 - 원근 #1
(2:27:45) 24.이미지 변형 - 원근 #2
[반자동 문서 스캐너 프로젝트]
(2:32:50) 25.미니 프로젝트 1 - #1 마우스 이벤트 등록
(2:42:06) 26.미니 프로젝트 1 - #2 기본 코드 완성
(2:49:54) 27.미니 프로젝트 1 - #3 지점 선 긋기
(2:55:24) 28.미니 프로젝트 1 - #4 실시간 선 긋기
[OpenCV 후반전]
(3:01:52) 29.이미지 변형 - 이진화 #1 Trackbar
(3:14:37) 30.이미지 변형 - 이진화 #2 임계값
(3:20:26) 31.이미지 변형 - 이진화 #3 Adaptive Threshold
(3:28:34) 32.이미지 변형 - 이진화 #4 오츠 알고리즘
(3:32:22) 33.이미지 변환 - 팽창
(3:41:10) 34.이미지 변환 - 침식
(3:45:56) 35.이미지 변환 - 열림 & 닫힘
(3:54:10) 36.이미지 검출 - 경계선
(4:05:08) 37.이미지 검출 - 윤곽선 #1 기본
(4:15:26) 38.이미지 검출 - 윤곽선 #2 찾기 모드
(4:20:46) 39.이미지 검출 - 윤곽선 #3 면적
[카드 검출 & 분류기 프로젝트]
(4:27:42) 40.미니프로젝트 2
[퀴즈]
(4:31:57) 41.퀴즈
[얼굴인식 프로젝트]
(4:41:25) 42.환경설정 및 기본 코드 정리
(4:54:48) 43.눈과 코 인식하여 도형 그리기
(5:10:42) 44.그림판 이미지 씌우기
(5:20:52) 45.캐릭터 이미지 씌우기
(5:33:10) 46.보충설명
(5:40:53) 47.마치며 (학습 참고 자료)
(5:42:18) 48.Outro
[학습자료]
수업에 필요한 이미지, 동영상 자료 링크입니다.
고양이 이미지 : https://pixabay.com/images/id-2083492/
크기 : 640 x 390
파일명 : img.jpg
고양이 동영상 : https://www.pexels.com/video/7515833/
크기 : SD (360 x 640)
파일명 : video.mp4
신문 이미지 : https://pixabay.com/images/id-350376/
크기 : 1280 x 853
파일명 : newspaper.jpg
카드 이미지 1 : https://pixabay.com/images/id-682332/
크기 : 1280 x 1019
파일명 : poker.jpg
책 이미지 : https://www.pexels.com/photo/1029807/
크기 : Small (640 x 853)
파일명 : book.jpg
눈사람 이미지 : https://pixabay.com/images/id-1300089/
크기 : 1280 x 904
파일명 : snowman.png
카드 이미지 2 : https://pixabay.com/images/id-161404/
크기 : 640 x 408
파일명 : card.png
퀴즈용 동영상 : https://www.pexels.com/video/3121459/
크기 : HD (1280 x 720)
파일명 : city.mp4
프로젝트용 동영상 : https://www.pexels.com/video/3256542/
크기 : Full HD (1920 x 1080)
파일명 : face_video.mp4
프로젝트용 캐릭터 이미지 : https://www.freepik.com/free-vector/cute-animal-masks-video-chat-application-effect-filters-set_6380101.htm
파일명 : right_eye.png (100 x 100), left_eye.png (100 x 100), nose.png (300 x 100)
무료 이미지 편집 도구 : https://pixlr.com/kr/
(Pixlr E -Advanced Editor)
#python #opencv
1677907260
Chatgpt-api: Node.js client for the official ChatGPT API
ChatGPT API
Node.js client for the official ChatGPT API.
Intro
This package is a Node.js wrapper around ChatGPT by OpenAI. TS batteries included. ✨
Updates
March 1, 2023
The official OpenAI chat completions API has been released, and it is now the default for this package! 🔥
| Method | Free? | Robust? | Quality? |
|---|---|---|---|
ChatGPTAPI | ❌ No | ✅ Yes | ✅️ Real ChatGPT models |
ChatGPTUnofficialProxyAPI | ✅ Yes | ☑️ Maybe | ✅ Real ChatGPT |
Note: We strongly recommend using ChatGPTAPI since it uses the officially supported API from OpenAI. We may remove support for ChatGPTUnofficialProxyAPI in a future release.
ChatGPTAPI- Uses thegpt-3.5-turbo-0301model with the official OpenAI chat completions API (official, robust approach, but it's not free)ChatGPTUnofficialProxyAPI- Uses an unofficial proxy server to access ChatGPT's backend API in a way that circumvents Cloudflare (uses the real ChatGPT and is pretty lightweight, but relies on a third-party server and is rate-limited)
CLI
To run the CLI, you'll need an OpenAI API key:
export OPENAI_API_KEY="sk-TODO"
npx chatgpt "your prompt here"By default, the response is streamed to stdout, the results are stored in a local config file, and every invocation starts a new conversation. You can use -c to continue the previous conversation and --no-stream to disable streaming.
Under the hood, the CLI uses ChatGPTAPI with text-davinci-003 to mimic ChatGPT.
Usage:
$ chatgpt <prompt>
Commands:
<prompt> Ask ChatGPT a question
rm-cache Clears the local message cache
ls-cache Prints the local message cache path
For more info, run any command with the `--help` flag:
$ chatgpt --help
$ chatgpt rm-cache --help
$ chatgpt ls-cache --help
Options:
-c, --continue Continue last conversation (default: false)
-d, --debug Enables debug logging (default: false)
-s, --stream Streams the response (default: true)
-s, --store Enables the local message cache (default: true)
-t, --timeout Timeout in milliseconds
-k, --apiKey OpenAI API key
-n, --conversationName Unique name for the conversation
-h, --help Display this message
-v, --version Display version number
Install
npm install chatgptMake sure you're using node >= 18 so fetch is available (or node >= 14 if you install a fetch polyfill).
Usage
To use this module from Node.js, you need to pick between two methods:
| Method | Free? | Robust? | Quality? |
|---|---|---|---|
ChatGPTAPI | ❌ No | ✅ Yes | ✅️ Real ChatGPT models |
ChatGPTUnofficialProxyAPI | ✅ Yes | ☑️ Maybe | ✅ Real ChatGPT |
ChatGPTAPI - Uses the gpt-3.5-turbo-0301 model with the official OpenAI chat completions API (official, robust approach, but it's not free). You can override the model, completion params, and system message to fully customize your assistant.
ChatGPTUnofficialProxyAPI - Uses an unofficial proxy server to access ChatGPT's backend API in a way that circumvents Cloudflare (uses the real ChatGPT and is pretty lightweight, but relies on a third-party server and is rate-limited)
Both approaches have very similar APIs, so it should be simple to swap between them.
Note: We strongly recommend using ChatGPTAPI since it uses the officially supported API from OpenAI. We may remove support for ChatGPTUnofficialProxyAPI in a future release.
Usage - ChatGPTAPI
Sign up for an OpenAI API key and store it in your environment.
import { ChatGPTAPI } from 'chatgpt'
async function example() {
const api = new ChatGPTAPI({
apiKey: process.env.OPENAI_API_KEY
})
const res = await api.sendMessage('Hello World!')
console.log(res.text)
}You can override the default model (gpt-3.5-turbo-0301) and any OpenAI chat completion params using completionParams:
const api = new ChatGPTAPI({
apiKey: process.env.OPENAI_API_KEY,
completionParams: {
temperature: 0.5,
top_p: 0.8
}
})If you want to track the conversation, you'll need to pass the parentMessageId like this:
const api = new ChatGPTAPI({ apiKey: process.env.OPENAI_API_KEY })
// send a message and wait for the response
let res = await api.sendMessage('What is OpenAI?')
console.log(res.text)
// send a follow-up
res = await api.sendMessage('Can you expand on that?', {
parentMessageId: res.id
})
console.log(res.text)
// send another follow-up
res = await api.sendMessage('What were we talking about?', {
parentMessageId: res.id
})
console.log(res.text)You can add streaming via the onProgress handler:
const res = await api.sendMessage('Write a 500 word essay on frogs.', {
// print the partial response as the AI is "typing"
onProgress: (partialResponse) => console.log(partialResponse.text)
})
// print the full text at the end
console.log(res.text)You can add a timeout using the timeoutMs option:
// timeout after 2 minutes (which will also abort the underlying HTTP request)
const response = await api.sendMessage(
'write me a really really long essay on frogs',
{
timeoutMs: 2 * 60 * 1000
}
)If you want to see more info about what's actually being sent to OpenAI's chat completions API, set the debug: true option in the ChatGPTAPI constructor:
const api = new ChatGPTAPI({
apiKey: process.env.OPENAI_API_KEY,
debug: true
})We default to a basic systemMessage. You can override this in either the ChatGPTAPI constructor or sendMessage:
const res = await api.sendMessage('what is the answer to the universe?', {
systemMessage: `You are ChatGPT, a large language model trained by OpenAI. You answer as concisely as possible for each responseIf you are generating a list, do not have too many items.
Current date: ${new Date().toISOString()}\n\n`
})Note that we automatically handle appending the previous messages to the prompt and attempt to optimize for the available tokens (which defaults to 4096).
Usage in CommonJS (Dynamic import)
async function example() {
// To use ESM in CommonJS, you can use a dynamic import
const { ChatGPTAPI } = await import('chatgpt')
const api = new ChatGPTAPI({ apiKey: process.env.OPENAI_API_KEY })
const res = await api.sendMessage('Hello World!')
console.log(res.text)
}Usage - ChatGPTUnofficialProxyAPI
The API for ChatGPTUnofficialProxyAPI is almost exactly the same. You just need to provide a ChatGPT accessToken instead of an OpenAI API key.
import { ChatGPTUnofficialProxyAPI } from 'chatgpt'
async function example() {
const api = new ChatGPTUnofficialProxyAPI({
accessToken: process.env.OPENAI_ACCESS_TOKEN
})
const res = await api.sendMessage('Hello World!')
console.log(res.text)
}See demos/demo-reverse-proxy for a full example:
npx tsx demos/demo-reverse-proxy.tsChatGPTUnofficialProxyAPI messages also contain a conversationid in addition to parentMessageId, since the ChatGPT webapp can't reference messages across
Reverse Proxy
You can override the reverse proxy by passing apiReverseProxyUrl:
const api = new ChatGPTUnofficialProxyAPI({
accessToken: process.env.OPENAI_ACCESS_TOKEN,
apiReverseProxyUrl: 'https://your-example-server.com/api/conversation'
})Known reverse proxies run by community members include:
| Reverse Proxy URL | Author | Rate Limits | Last Checked |
|---|---|---|---|
https://chat.duti.tech/api/conversation | @acheong08 | 120 req/min by IP | 2/19/2023 |
https://gpt.pawan.krd/backend-api/conversation | @PawanOsman | ? | 2/19/2023 |
Note: info on how the reverse proxies work is not being published at this time in order to prevent OpenAI from disabling access.
Access Token
To use ChatGPTUnofficialProxyAPI, you'll need an OpenAI access token from the ChatGPT webapp. To do this, you can use any of the following methods which take an email and password and return an access token:
- Node.js libs
- Python libs
These libraries work with email + password accounts (e.g., they do not support accounts where you auth via Microsoft / Google).
Alternatively, you can manually get an accessToken by logging in to the ChatGPT webapp and then opening https://chat.openai.com/api/auth/session, which will return a JSON object containing your accessToken string.
Access tokens last for days.
Note: using a reverse proxy will expose your access token to a third-party. There shouldn't be any adverse effects possible from this, but please consider the risks before using this method.
Docs
See the auto-generated docs for more info on methods and parameters.
Demos
Most of the demos use ChatGPTAPI. It should be pretty easy to convert them to use ChatGPTUnofficialProxyAPI if you'd rather use that approach. The only thing that needs to change is how you initialize the api with an accessToken instead of an apiKey.
To run the included demos:
- clone repo
- install node deps
- set
OPENAI_API_KEYin .env
A basic demo is included for testing purposes:
npx tsx demos/demo.tsA demo showing on progress handler:
npx tsx demos/demo-on-progress.tsThe on progress demo uses the optional onProgress parameter to sendMessage to receive intermediary results as ChatGPT is "typing".
npx tsx demos/demo-conversation.tsA persistence demo shows how to store messages in Redis for persistence:
npx tsx demos/demo-persistence.tsAny keyv adaptor is supported for persistence, and there are overrides if you'd like to use a different way of storing / retrieving messages.
Note that persisting message is required for remembering the context of previous conversations beyond the scope of the current Node.js process, since by default, we only store messages in memory. Here's an external demo of using a completely custom database solution to persist messages.
Note: Persistence is handled automatically when using ChatGPTUnofficialProxyAPI because it is connecting indirectly to ChatGPT.
Projects
All of these awesome projects are built using the chatgpt package. 🤯
- Twitter Bot powered by ChatGPT ✨
- Mention @ChatGPTBot on Twitter with your prompt to try it out
- ChatGPT API Server - API server for this package with support for multiple OpenAI accounts, proxies, and load-balancing requests between accounts.
- ChatGPT Prompts - A collection of 140+ of the best ChatGPT prompts from the community.
- Lovelines.xyz
- Chrome Extension (demo)
- VSCode Extension #1 (demo, updated version, marketplace)
- VSCode Extension #2 (marketplace)
- VSCode Extension #3 (marketplace)
- VSCode Extension #4 (marketplace)
- Raycast Extension #1 (demo)
- Raycast Extension #2
- Telegram Bot #1
- Telegram Bot #2
- Telegram Bot #3 (group privacy mode, ID-based auth)
- Telegram Bot #4 (queue system, ID-based chat thread)
- Deno Telegram Bot
- Go Telegram Bot
- Telegram Bot for YouTube Summaries
- GitHub ProBot
- Discord Bot #1
- Discord Bot #2
- Discord Bot #3
- Discord Bot #4 (selfbot)
- Discord Bot #5
- Discord Bot #6 (Shakespeare bot)
- WeChat Bot #1
- WeChat Bot #2
- WeChat Bot #3 (
- WeChat Bot #4
- WeChat Bot #5
- QQ Bot (plugin for Yunzai-bot)
- QQ Bot (plugin for KiviBot)
- QQ Bot (oicq)
- QQ Bot (oicq + RabbitMQ)
- QQ Bot (go-cqhttp)
- EXM smart contracts
- Flutter ChatGPT API
- Carik Bot
- Github Action for reviewing PRs
- WhatsApp Bot #1 (DALL-E + Whisper support 💪)
- WhatsApp Bot #2
- WhatsApp Bot #3 (multi-user support)
- WhatsApp Bot #4 (schedule periodic messages)
- WhatsApp Bot #5 (RaspberryPi + ngrok + Twilio)
- WhatsApp Bot #6 (Session and chat history storage with MongoStore)
- Matrix Bot
- Rental Cover Letter Generator
- Assistant CLI
- Teams Bot
- Askai
- TalkGPT
- ChatGPT With Voice
- iOS Shortcut
- Slack Bot #1
- Slack Bot #2 (with queueing mechanism)
- Slack Bot #3
- Slack Bot #4 ( Serverless AWS Lambda )
- Electron Bot
- Kodyfire CLI
- Twitch Bot
- Continuous Conversation
- Figma plugin
- NestJS server
- NestJS ChatGPT Starter Boilerplate
- Wordsmith: Add-in for Microsoft Word
- QuizGPT: Create Kahoot quizzes with ChatGPT
- openai-chatgpt: Talk to ChatGPT from the terminal
- Clippy the Saleforce chatbot ClippyJS joke bot
- ai-assistant Chat assistant
- Feishu Bot
- DomainGPT: Discover available domain names
- AI Poem Generator
- Next.js ChatGPT With Firebase
- ai-commit – GPT-3 Commit Message Generator
If you create a cool integration, feel free to open a PR and add it to the list.
Compatibility
- This package is ESM-only.
- This package supports
node >= 14. - This module assumes that
fetchis installed. - If you want to build a website using
chatgpt, we recommend using it only from your backend API
Credits
- Huge thanks to @waylaidwanderer, @abacaj, @wong2, @simon300000, @RomanHotsiy, @ElijahPepe, and all the other contributors 💪
- The original browser version was inspired by this Go module by Daniel Gross
- OpenAI for creating ChatGPT 🔥
Previous Updates
Feb 19, 2023
We now provide three ways of accessing the unofficial ChatGPT API, all of which have tradeoffs:
| Method | Free? | Robust? | Quality? |
|---|---|---|---|
ChatGPTAPI | ❌ No | ✅ Yes | ☑️ Mimics ChatGPT |
ChatGPTUnofficialProxyAPI | ✅ Yes | ☑️ Maybe | ✅ Real ChatGPT |
ChatGPTAPIBrowser (v3) | ✅ Yes | ❌ No | ✅ Real ChatGPT |
Note: I recommend that you use either ChatGPTAPI or ChatGPTUnofficialProxyAPI.
ChatGPTAPI- Usestext-davinci-003to mimic ChatGPT via the official OpenAI completions API (most robust approach, but it's not free and doesn't use a model fine-tuned for chat)ChatGPTUnofficialProxyAPI- Uses an unofficial proxy server to access ChatGPT's backend API in a way that circumvents Cloudflare (uses the real ChatGPT and is pretty lightweight, but relies on a third-party server and is rate-limited)ChatGPTAPIBrowser- (deprecated; v3.5.1 of this package) Uses Puppeteer to access the official ChatGPT webapp (uses the real ChatGPT, but very flaky, heavyweight, and error prone)
Feb 5, 2023
OpenAI has disabled the leaked chat model we were previously using, so we're now defaulting to text-davinci-003, which is not free.
We've found several other hidden, fine-tuned chat models, but OpenAI keeps disabling them, so we're searching for alternative workarounds.
Feb 1, 2023
This package no longer requires any browser hacks – it is now using the official OpenAI completions API with a leaked model that ChatGPT uses under the hood. 🔥
import { ChatGPTAPI } from 'chatgpt'
const api = new ChatGPTAPI({
apiKey: process.env.OPENAI_API_KEY
})
const res = await api.sendMessage('Hello World!')
console.log(res.text)Please upgrade to chatgpt@latest (at least v4.0.0). The updated version is significantly more lightweight and robust compared with previous versions. You also don't have to worry about IP issues or rate limiting.
Huge shoutout to @waylaidwanderer for discovering the leaked chat model!
If you run into any issues, we do have a pretty active Discord with a bunch of ChatGPT hackers from the Node.js & Python communities.
Lastly, please consider starring this repo and following me on twitter to help support the project.
Thanks && cheers, Travis
Download Details:
Author: Transitive-bullshit
Source Code: https://github.com/transitive-bullshit/chatgpt-api
License: MIT license
1669952228
Dijkstra's Algorithm Explained with Examples
In this tutorial, you'll learn: What is Dijkstra's Algorithm and how Dijkstra's algorithm works with the help of visual guides.
You can use algorithms in programming to solve specific problems through a set of precise instructions or procedures.
Dijkstra's algorithm is one of many graph algorithms you'll come across. It is used to find the shortest path from a fixed node to all other nodes in a graph.
There are different representations of Dijkstra's algorithm. You can either find the shortest path between two nodes, or the shortest path from a fixed node to the rest of the nodes in a graph.
In this article, you'll learn how Dijkstra's algorithm works with the help of visual guides.
How Does Dijkstra’s Algorithm Work?
Before we dive into more detailed visual examples, you need to understand how Dijkstra's algorithm works.
Although the theoretical explanation may seem a bit abstract, it'll help you understand the practical aspect better.
In a given graph containing different nodes, we are required to get the shortest path from a given node to the rest of the nodes.
These nodes can represent any object like the names of cities, letters, and so on.
Between each node is a number denoting the distance between two nodes, as you can see in the image below:
We usually work with two arrays – one for visited nodes, and another for unvisited nodes. You'll learn more about the arrays in the next section.
When a node is visited, the algorithm calculates how long it took to get to the node and stores the distance. If a shorter path to a node is found, the initial value assigned for the distance is updated.
Note that a node cannot be visited twice.
The algorithm runs recursively until all the nodes have been visited.
Dijkstra's Algorithm Example
In this section, we'll take a look at a practical example that shows how Dijkstra's algorithm works.
Here's the graph we'll be working with:
We'll use the table below to put down the visited nodes and their distance from the fixed node:
| NODE | SHORTEST DISTANCE FROM FIXED NODE |
|---|---|
| A | ∞ |
| B | ∞ |
| C | ∞ |
| D | ∞ |
| E | ∞ |
Visited nodes = []
Unvisited nodes = [A,B,C,D,E]
Above, we have a table showing each node and the shortest distance from the that node to the fixed node. We are yet to choose the fixed node.
Note that the distance for each node in the table is currently denoted as infinity (∞). This is because we don't know the shortest distance yet.
We also have two arrays – visited and unvisited. Whenever a node is visited, it is added to the visited nodes array.
Let's get started!
To simplify things, I'll break the process down into iterations. You'll see what happens in each step with the aid of diagrams.
Iteration #1
The first iteration might seem confusing, but that's totally fine. Once we start repeating the process in each iteration, you'll have a clearer picture of how the algorithm works.
Step #1 - Pick an unvisited node
We'll choose A as the fixed node. So we'll find the shortest distance from A to every other node in the graph.
We're going to give A a distance of 0 because it is the initial node. So the table would look like this:
| NODE | SHORTEST DISTANCE FROM FIXED NODE |
|---|---|
| A | 0 |
| B | ∞ |
| C | ∞ |
| D | ∞ |
| E | ∞ |
Step #2 - Find the distance from current node
The next thing to do after choosing a node is to find the distance from it to the unvisited nodes around it.
The two unvisited nodes directly linked to A are B and C.
To get the distance from A to B:
0 + 4 = 4
0 being the value of the current node (A), and 4 being the distance between A and B in the graph.
To get the distance from A to C:
0 + 2 = 2
Step #3 - Update table with known distances
In the last step, we got 4 and 2 as the values of B and C respectively. So we'll update the table with those values:
| NODE | SHORTEST DISTANCE FROM FIXED NODE |
|---|---|
| A | 0 |
| B | 4 |
| C | 2 |
| D | ∞ |
| E | ∞ |
Step #4 - Update arrays
At this point, the first iteration is complete. We'll move node A to the visited nodes array:
Visited nodes = [A]
Unvisited nodes = [B,C,D,E]
Before we proceed to the next iteration, you should know the following:
- Once a node has been visited, it cannot be linked to the current node. Refer to step #2 in the iteration above and step #2 in the next iteration.
- A node cannot be visited twice.
- You can only update the shortest known distance if you get a value smaller than the recorded distance.
Iteration #2
Step #1 - Pick an unvisited node
We have four unvisited nodes — [B,C,D,E]. So how do you know which node to pick for the next iteration?
Well, we pick the node with the smallest known distance recorded in the table. Here's the table:
| NODE | SHORTEST DISTANCE FROM FIXED NODE |
|---|---|
| A | 0 |
| B | 4 |
| C | 2 |
| D | ∞ |
| E | ∞ |
So we're going with node C.
Step #2 - Find the distance from current node
To find the distance from the current node to the fixed node, we have to consider the nodes linked to the current node.
The nodes linked to the current node are A and B.
But A has been visited in the previous iteration so it will not be linked to the current node. That is:
From the diagram above,
- The green color denotes the current node.
- The blue color denotes the visited nodes. We cannot link to them or visit them again.
- The red color shows the link from the unvisited nodes to the current node.
To find the distance from C to B:
2 + 1 = 3
2 above is recorded distance for node C while 1 is the distance between C and B in the graph.
Step #3 - Update table with known distances
In the last step, we got the value of B to be 3. In the first iteration, it was 4.
We're going to update the distance in the table to 3.
| NODE | SHORTEST DISTANCE FROM FIXED NODE |
|---|---|
| A | 0 |
| B | 3 |
| C | 2 |
| D | ∞ |
| E | ∞ |
So, A --> B = 4 (First iteration).
A --> C --> B = 3 (Second iteration).
The algorithm has helped us find the shortest path to B from A.
Step #4 - Update arrays
We're done with the last visited node. Let's add it to the visited nodes array:
Visited nodes = [A,C]
Unvisited nodes = [B,D,E]
Iteration #3
Step #1 - Pick an unvisited node
We're down to three unvisited nodes — [B,D,E]. From the array, B has the shortest known distance.
To restate what is going on in the diagram above:
- The green color denotes the current node.
- The blue color denotes the visited nodes. We cannot link to them or visit them again.
- The red color shows the link from the unvisited nodes to the current node.
Step #2 - Find the distance from current node
The nodes linked to the current node are D and E.
B (the current node) has a value of 3. Therefore,
For node D, 3 + 3 = 6.
For node E, 3 + 2 = 5.
Step #3 - Update table with known distances
| NODE | SHORTEST DISTANCE FROM FIXED NODE |
|---|---|
| A | 0 |
| B | 3 |
| C | 2 |
| D | 6 |
| E | 5 |
Step #4 - Update arrays
Visited nodes = [A,C,B]
Unvisited nodes = [D,E]
Iteration #4
Step #1 - Pick an unvisited node
Like other iterations, we'll go with the unvisited node with the shortest known distance. That is E.
Step #2 - Find the distance from current node
According to our table, E has a value of 5.
For D in the current iteration,
5 + 5 = 10.
The value gotten for D here is 10, which is greater than the recorded value of 6 in the previous iteration. For this reason, we'll not update the table.
Step #3 - Update table with known distances
Our table remains the same:
| NODE | SHORTEST DISTANCE FROM FIXED NODE |
|---|---|
| A | 0 |
| B | 3 |
| C | 2 |
| D | 6 |
| E | 5 |
Step #4 - Update arrays
Visited nodes = [A,C,B,E]
Unvisited nodes = [D]
Iteration #5
Step #1 - Pick an unvisited node
We're currently left with one node in the unvisited array — D.
Step #2 - Find the distance from current node
The algorithm has gotten to the last iteration. This is because all nodes linked to the current node have been visited already so we can't link to them.
Step #3 - Update table with known distances
Our table remains the same:
| NODE | SHORTEST DISTANCE FROM FIXED NODE |
|---|---|
| A | 0 |
| B | 3 |
| C | 2 |
| D | 6 |
| E | 5 |
At this point, we have updated the table with the shortest distance from the fixed node to every other node in the graph.
Step #4 - Update arrays
Visited nodes = [A,C,B,E,D]
Unvisited nodes = []
As can be seen above, we have no nodes left to visit. Using Dijkstra's algorithm, we've found the shortest distance from the fixed node to others nodes in the graph.
Dijkstra's Algorithm Pseudocode Example
The pseudocode example in this section was gotten from Wikipedia. Here it is:
1 function Dijkstra(Graph, source):
2
3 for each vertex v in Graph.Vertices:
4 dist[v] ← INFINITY
5 prev[v] ← UNDEFINED
6 add v to Q
7 dist[source] ← 0
8
9 while Q is not empty:
10 u ← vertex in Q with min dist[u]
11 remove u from Q
12
13 for each neighbor v of u still in Q:
14 alt ← dist[u] + Graph.Edges(u, v)
15 if alt < dist[v]:
16 dist[v] ← alt
17 prev[v] ← u
18
19 return dist[], prev[]Applications of Dijkstra's Algorithm
Here are some of the common applications of Dijkstra's algorithm:
- In maps to get the shortest distance between locations. An example is Google Maps.
- In telecommunications to determine transmission rate.
- In robotic design to determine shortest path for automated robots.
Summary
In this article, we talked about Dijkstra's algorithm. It is used to find the shortest distance from a fixed node to all other nodes in a graph.
We started by giving a brief summary of how the algorithm works.
We then had a look at an example that further explained Dijkstra's algorithm in steps using visual guides.
We concluded with a pseudocode example and some of the applications of Dijkstra's algorithm.
Happy coding!
Original article source at https://www.freecodecamp.org
#algorithm #datastructures
