A Simple Wrapper Around Amplify AppSync Simulator

This serverless plugin is a wrapper for amplify-appsync-simulator made for testing AppSync APIs built with serverless-appsync-plugin.

Install

npm install serverless-appsync-simulator
# or
yarn add serverless-appsync-simulator

Usage

This plugin relies on your serverless yml file and on the serverless-offline plugin.

plugins:
  - serverless-dynamodb-local # only if you need dynamodb resolvers and you don't have an external dynamodb
  - serverless-appsync-simulator
  - serverless-offline

Note: Order is important serverless-appsync-simulator must go before serverless-offline

To start the simulator, run the following command:

sls offline start

You should see in the logs something like:

...
Serverless: AppSync endpoint: http://localhost:20002/graphql
Serverless: GraphiQl: http://localhost:20002
...

Configuration

Put options under custom.appsync-simulator in your serverless.yml file

| option | default | description | | ------------------------ | -------------------------- | ---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- | --------- | | apiKey | 0123456789 | When using API_KEY as authentication type, the key to authenticate to the endpoint. | | port | 20002 | AppSync operations port; if using multiple APIs, the value of this option will be used as a starting point, and each other API will have a port of lastPort + 10 (e.g. 20002, 20012, 20022, etc.) | | wsPort | 20003 | AppSync subscriptions port; if using multiple APIs, the value of this option will be used as a starting point, and each other API will have a port of lastPort + 10 (e.g. 20003, 20013, 20023, etc.) | | location | . (base directory) | Location of the lambda functions handlers. | | refMap | {} | A mapping of resource resolutions for the Ref function | | getAttMap | {} | A mapping of resource resolutions for the GetAtt function | | importValueMap | {} | A mapping of resource resolutions for the ImportValue function | | functions | {} | A mapping of external functions for providing invoke url for external fucntions | | dynamoDb.endpoint | http://localhost:8000 | Dynamodb endpoint. Specify it if you're not using serverless-dynamodb-local. Otherwise, port is taken from dynamodb-local conf | | dynamoDb.region | localhost | Dynamodb region. Specify it if you're connecting to a remote Dynamodb intance. | | dynamoDb.accessKeyId | DEFAULT_ACCESS_KEY | AWS Access Key ID to access DynamoDB | | dynamoDb.secretAccessKey | DEFAULT_SECRET | AWS Secret Key to access DynamoDB | | dynamoDb.sessionToken | DEFAULT_ACCESS_TOKEEN | AWS Session Token to access DynamoDB, only if you have temporary security credentials configured on AWS | | dynamoDb.* | | You can add every configuration accepted by DynamoDB SDK | | rds.dbName | | Name of the database | | rds.dbHost | | Database host | | rds.dbDialect | | Database dialect. Possible values (mysql | postgres) | | rds.dbUsername | | Database username | | rds.dbPassword | | Database password | | rds.dbPort | | Database port | | watch | - *.graphql
- *.vtl | Array of glob patterns to watch for hot-reloading. |

Example:

custom:
  appsync-simulator:
    location: '.webpack/service' # use webpack build directory
    dynamoDb:
      endpoint: 'http://my-custom-dynamo:8000'

Hot-reloading

By default, the simulator will hot-relad when changes to *.graphql or *.vtl files are detected. Changes to *.yml files are not supported (yet? - this is a Serverless Framework limitation). You will need to restart the simulator each time you change yml files.

Hot-reloading relies on watchman. Make sure it is installed on your system.

You can change the files being watched with the watch option, which is then passed to watchman as the match expression.

e.g.

custom:
  appsync-simulator:
    watch:
      - ["match", "handlers/**/*.vtl", "wholename"] # => array is interpreted as the literal match expression
      - "*.graphql"                                 # => string like this is equivalent to `["match", "*.graphql"]`

Or you can opt-out by leaving an empty array or set the option to false

Note: Functions should not require hot-reloading, unless you are using a transpiler or a bundler (such as webpack, babel or typescript), un which case you should delegate hot-reloading to that instead.

Resource CloudFormation functions resolution

This plugin supports some resources resolution from the Ref, Fn::GetAtt and Fn::ImportValue functions in your yaml file. It also supports some other Cfn functions such as Fn::Join, Fb::Sub, etc.

Note: Under the hood, this features relies on the cfn-resolver-lib package. For more info on supported cfn functions, refer to the documentation

Basic usage

You can reference resources in your functions' environment variables (that will be accessible from your lambda functions) or datasource definitions. The plugin will automatically resolve them for you.

provider:
  environment:
    BUCKET_NAME:
      Ref: MyBucket # resolves to `my-bucket-name`

resources:
  Resources:
    MyDbTable:
      Type: AWS::DynamoDB::Table
      Properties:
        TableName: myTable
      ...
    MyBucket:
      Type: AWS::S3::Bucket
      Properties:
        BucketName: my-bucket-name
    ...

# in your appsync config
dataSources:
  - type: AMAZON_DYNAMODB
    name: dynamosource
    config:
      tableName:
        Ref: MyDbTable # resolves to `myTable`

Override (or mock) values

Sometimes, some references cannot be resolved, as they come from an Output from Cloudformation; or you might want to use mocked values in your local environment.

In those cases, you can define (or override) those values using the refMap, getAttMap and importValueMap options.

refMap takes a mapping of resource name to value pairs
getAttMap takes a mapping of resource name to attribute/values pairs
importValueMap takes a mapping of import name to values pairs

Example:

custom:
  appsync-simulator:
    refMap:
      # Override `MyDbTable` resolution from the previous example.
      MyDbTable: 'mock-myTable'
    getAttMap:
      # define ElasticSearchInstance DomainName
      ElasticSearchInstance:
        DomainEndpoint: 'localhost:9200'
    importValueMap:
      other-service-api-url: 'https://other.api.url.com/graphql'

# in your appsync config
dataSources:
  - type: AMAZON_ELASTICSEARCH
    name: elasticsource
    config:
      # endpoint resolves as 'http://localhost:9200'
      endpoint:
        Fn::Join:
          - ''
          - - https://
            - Fn::GetAtt:
                - ElasticSearchInstance
                - DomainEndpoint

Key-value mock notation

In some special cases you will need to use key-value mock nottation. Good example can be case when you need to include serverless stage value (${self:provider.stage}) in the import name.

This notation can be used with all mocks - refMap, getAttMap and importValueMap

provider:
  environment:
    FINISH_ACTIVITY_FUNCTION_ARN:
      Fn::ImportValue: other-service-api-${self:provider.stage}-url

custom:
  serverless-appsync-simulator:
    importValueMap:
      - key: other-service-api-${self:provider.stage}-url
        value: 'https://other.api.url.com/graphql'

Limitations

This plugin only tries to resolve the following parts of the yml tree:

provider.environment
functions[*].environment
custom.appSync

If you have the need of resolving others, feel free to open an issue and explain your use case.

For now, the supported resources to be automatically resovled by Ref: are:

DynamoDb tables
S3 Buckets

Feel free to open a PR or an issue to extend them as well.

External functions

When a function is not defined withing the current serverless file you can still call it by providing an invoke url which should point to a REST method. Make sure you specify "get" or "post" for the method. Default is "get", but you probably want "post".

custom:
  appsync-simulator:
    functions:
      addUser:
        url: http://localhost:3016/2015-03-31/functions/addUser/invocations
        method: post
      addPost:
        url: https://jsonplaceholder.typicode.com/posts
        method: post

Supported Resolver types

This plugin supports resolvers implemented by amplify-appsync-simulator, as well as custom resolvers.

From Aws Amplify:

NONE
AWS_LAMBDA
AMAZON_DYNAMODB
PIPELINE

Implemented by this plugin

AMAZON_ELASTIC_SEARCH
HTTP
RELATIONAL_DATABASE

Relational Database

Sample VTL for a create mutation

#set( $cols = [] )
#set( $vals = [] )
#foreach( $entry in $ctx.args.input.keySet() )
  #set( $regex = "([a-z])([A-Z]+)")
  #set( $replacement = "$1_$2")
  #set( $toSnake = $entry.replaceAll($regex, $replacement).toLowerCase() )
  #set( $discard = $cols.add("$toSnake") )
  #if( $util.isBoolean($ctx.args.input[$entry]) )
      #if( $ctx.args.input[$entry] )
        #set( $discard = $vals.add("1") )
      #else
        #set( $discard = $vals.add("0") )
      #end
  #else
      #set( $discard = $vals.add("'$ctx.args.input[$entry]'") )
  #end
#end
#set( $valStr = $vals.toString().replace("[","(").replace("]",")") )
#set( $colStr = $cols.toString().replace("[","(").replace("]",")") )
#if ( $valStr.substring(0, 1) != '(' )
  #set( $valStr = "($valStr)" )
#end
#if ( $colStr.substring(0, 1) != '(' )
  #set( $colStr = "($colStr)" )
#end
{
  "version": "2018-05-29",
  "statements":   ["INSERT INTO <name-of-table> $colStr VALUES $valStr", "SELECT * FROM    <name-of-table> ORDER BY id DESC LIMIT 1"]
}

Sample VTL for an update mutation

#set( $update = "" )
#set( $equals = "=" )
#foreach( $entry in $ctx.args.input.keySet() )
  #set( $cur = $ctx.args.input[$entry] )
  #set( $regex = "([a-z])([A-Z]+)")
  #set( $replacement = "$1_$2")
  #set( $toSnake = $entry.replaceAll($regex, $replacement).toLowerCase() )
  #if( $util.isBoolean($cur) )
      #if( $cur )
        #set ( $cur = "1" )
      #else
        #set ( $cur = "0" )
      #end
  #end
  #if ( $util.isNullOrEmpty($update) )
      #set($update = "$toSnake$equals'$cur'" )
  #else
      #set($update = "$update,$toSnake$equals'$cur'" )
  #end
#end
{
  "version": "2018-05-29",
  "statements":   ["UPDATE <name-of-table> SET $update WHERE id=$ctx.args.input.id", "SELECT * FROM <name-of-table> WHERE id=$ctx.args.input.id"]
}

Sample resolver for delete mutation

{
  "version": "2018-05-29",
  "statements":   ["UPDATE <name-of-table> set deleted_at=NOW() WHERE id=$ctx.args.id", "SELECT * FROM <name-of-table> WHERE id=$ctx.args.id"]
}

Sample mutation response VTL with support for handling AWSDateTime

#set ( $index = -1)
#set ( $result = $util.parseJson($ctx.result) )
#set ( $meta = $result.sqlStatementResults[1].columnMetadata)
#foreach ($column in $meta)
    #set ($index = $index + 1)
    #if ( $column["typeName"] == "timestamptz" )
        #set ($time = $result["sqlStatementResults"][1]["records"][0][$index]["stringValue"] )
        #set ( $nowEpochMillis = $util.time.parseFormattedToEpochMilliSeconds("$time.substring(0,19)+0000", "yyyy-MM-dd HH:mm:ssZ") )
        #set ( $isoDateTime = $util.time.epochMilliSecondsToISO8601($nowEpochMillis) )
        $util.qr( $result["sqlStatementResults"][1]["records"][0][$index].put("stringValue", "$isoDateTime") )
    #end
#end
#set ( $res = $util.parseJson($util.rds.toJsonString($util.toJson($result)))[1][0] )
#set ( $response = {} )
#foreach($mapKey in $res.keySet())
    #set ( $s = $mapKey.split("_") )
    #set ( $camelCase="" )
    #set ( $isFirst=true )
    #foreach($entry in $s)
        #if ( $isFirst )
          #set ( $first = $entry.substring(0,1) )
        #else
          #set ( $first = $entry.substring(0,1).toUpperCase() )
        #end
        #set ( $isFirst=false )
        #set ( $stringLength = $entry.length() )
        #set ( $remaining = $entry.substring(1, $stringLength) )
        #set ( $camelCase = "$camelCase$first$remaining" )
    #end
    $util.qr( $response.put("$camelCase", $res[$mapKey]) )
#end
$utils.toJson($response)

Using Variable Map

Variable map support is limited and does not differentiate numbers and strings data types, please inject them directly if needed.

Will be escaped properly: null, true, and false values.

{
  "version": "2018-05-29",
  "statements":   [
    "UPDATE <name-of-table> set deleted_at=NOW() WHERE id=:ID",
    "SELECT * FROM <name-of-table> WHERE id=:ID and unix_timestamp > $ctx.args.newerThan"
  ],
  variableMap: {
    ":ID": $ctx.args.id,
##    ":TIMESTAMP": $ctx.args.newerThan -- This will be handled as a string!!!
  }
}

Requires

serverless framework
serverless-appsync-plugin
serverless-offline
serverless-dynamodb-local (when using dynamodb resolvers only)
watchman (if Hot-reloading is desactivated it is not required)

Author: Serverless-appsync
Source Code: https://github.com/serverless-appsync/serverless-appsync-simulator
License: MIT License

#serverless #sync #graphql

Chloe Butler

1667425440

Pdf2gerb: Perl Script Converts PDF Files to Gerber format

pdf2gerb

Perl script converts PDF files to Gerber format

Pdf2Gerb generates Gerber 274X photoplotting and Excellon drill files from PDFs of a PCB. Up to three PDFs are used: the top copper layer, the bottom copper layer (for 2-sided PCBs), and an optional silk screen layer. The PDFs can be created directly from any PDF drawing software, or a PDF print driver can be used to capture the Print output if the drawing software does not directly support output to PDF.

The general workflow is as follows:

Design the PCB using your favorite CAD or drawing software.
Print the top and bottom copper and top silk screen layers to a PDF file.
Run Pdf2Gerb on the PDFs to create Gerber and Excellon files.
Use a Gerber viewer to double-check the output against the original PCB design.
Make adjustments as needed.
Submit the files to a PCB manufacturer.

Please note that Pdf2Gerb does NOT perform DRC (Design Rule Checks), as these will vary according to individual PCB manufacturer conventions and capabilities. Also note that Pdf2Gerb is not perfect, so the output files must always be checked before submitting them. As of version 1.6, Pdf2Gerb supports most PCB elements, such as round and square pads, round holes, traces, SMD pads, ground planes, no-fill areas, and panelization. However, because it interprets the graphical output of a Print function, there are limitations in what it can recognize (or there may be bugs).

See docs/Pdf2Gerb.pdf for install/setup, config, usage, and other info.

pdf2gerb_cfg.pm

#Pdf2Gerb config settings:
#Put this file in same folder/directory as pdf2gerb.pl itself (global settings),
#or copy to another folder/directory with PDFs if you want PCB-specific settings.
#There is only one user of this file, so we don't need a custom package or namespace.
#NOTE: all constants defined in here will be added to main namespace.
#package pdf2gerb_cfg;

use strict; #trap undef vars (easier debug)
use warnings; #other useful info (easier debug)


##############################################################################################
#configurable settings:
#change values here instead of in main pfg2gerb.pl file

use constant WANT_COLORS => ($^O !~ m/Win/); #ANSI colors no worky on Windows? this must be set < first DebugPrint() call

#just a little warning; set realistic expectations:
#DebugPrint("${\(CYAN)}Pdf2Gerb.pl ${\(VERSION)}, $^O O/S\n${\(YELLOW)}${\(BOLD)}${\(ITALIC)}This is EXPERIMENTAL software.  \nGerber files MAY CONTAIN ERRORS.  Please CHECK them before fabrication!${\(RESET)}", 0); #if WANT_DEBUG

use constant METRIC => FALSE; #set to TRUE for metric units (only affect final numbers in output files, not internal arithmetic)
use constant APERTURE_LIMIT => 0; #34; #max #apertures to use; generate warnings if too many apertures are used (0 to not check)
use constant DRILL_FMT => '2.4'; #'2.3'; #'2.4' is the default for PCB fab; change to '2.3' for CNC

use constant WANT_DEBUG => 0; #10; #level of debug wanted; higher == more, lower == less, 0 == none
use constant GERBER_DEBUG => 0; #level of debug to include in Gerber file; DON'T USE FOR FABRICATION
use constant WANT_STREAMS => FALSE; #TRUE; #save decompressed streams to files (for debug)
use constant WANT_ALLINPUT => FALSE; #TRUE; #save entire input stream (for debug ONLY)

#DebugPrint(sprintf("${\(CYAN)}DEBUG: stdout %d, gerber %d, want streams? %d, all input? %d, O/S: $^O, Perl: $]${\(RESET)}\n", WANT_DEBUG, GERBER_DEBUG, WANT_STREAMS, WANT_ALLINPUT), 1);
#DebugPrint(sprintf("max int = %d, min int = %d\n", MAXINT, MININT), 1);

#define standard trace and pad sizes to reduce scaling or PDF rendering errors:
#This avoids weird aperture settings and replaces them with more standardized values.
#(I'm not sure how photoplotters handle strange sizes).
#Fewer choices here gives more accurate mapping in the final Gerber files.
#units are in inches
use constant TOOL_SIZES => #add more as desired
(
#round or square pads (> 0) and drills (< 0):
    .010, -.001,  #tiny pads for SMD; dummy drill size (too small for practical use, but needed so StandardTool will use this entry)
    .031, -.014,  #used for vias
    .041, -.020,  #smallest non-filled plated hole
    .051, -.025,
    .056, -.029,  #useful for IC pins
    .070, -.033,
    .075, -.040,  #heavier leads
#    .090, -.043,  #NOTE: 600 dpi is not high enough resolution to reliably distinguish between .043" and .046", so choose 1 of the 2 here
    .100, -.046,
    .115, -.052,
    .130, -.061,
    .140, -.067,
    .150, -.079,
    .175, -.088,
    .190, -.093,
    .200, -.100,
    .220, -.110,
    .160, -.125,  #useful for mounting holes
#some additional pad sizes without holes (repeat a previous hole size if you just want the pad size):
    .090, -.040,  #want a .090 pad option, but use dummy hole size
    .065, -.040, #.065 x .065 rect pad
    .035, -.040, #.035 x .065 rect pad
#traces:
    .001,  #too thin for real traces; use only for board outlines
    .006,  #minimum real trace width; mainly used for text
    .008,  #mainly used for mid-sized text, not traces
    .010,  #minimum recommended trace width for low-current signals
    .012,
    .015,  #moderate low-voltage current
    .020,  #heavier trace for power, ground (even if a lighter one is adequate)
    .025,
    .030,  #heavy-current traces; be careful with these ones!
    .040,
    .050,
    .060,
    .080,
    .100,
    .120,
);
#Areas larger than the values below will be filled with parallel lines:
#This cuts down on the number of aperture sizes used.
#Set to 0 to always use an aperture or drill, regardless of size.
use constant { MAX_APERTURE => max((TOOL_SIZES)) + .004, MAX_DRILL => -min((TOOL_SIZES)) + .004 }; #max aperture and drill sizes (plus a little tolerance)
#DebugPrint(sprintf("using %d standard tool sizes: %s, max aper %.3f, max drill %.3f\n", scalar((TOOL_SIZES)), join(", ", (TOOL_SIZES)), MAX_APERTURE, MAX_DRILL), 1);

#NOTE: Compare the PDF to the original CAD file to check the accuracy of the PDF rendering and parsing!
#for example, the CAD software I used generated the following circles for holes:
#CAD hole size:   parsed PDF diameter:      error:
#  .014                .016                +.002
#  .020                .02267              +.00267
#  .025                .026                +.001
#  .029                .03167              +.00267
#  .033                .036                +.003
#  .040                .04267              +.00267
#This was usually ~ .002" - .003" too big compared to the hole as displayed in the CAD software.
#To compensate for PDF rendering errors (either during CAD Print function or PDF parsing logic), adjust the values below as needed.
#units are pixels; for example, a value of 2.4 at 600 dpi = .0004 inch, 2 at 600 dpi = .0033"
use constant
{
    HOLE_ADJUST => -0.004 * 600, #-2.6, #holes seemed to be slightly oversized (by .002" - .004"), so shrink them a little
    RNDPAD_ADJUST => -0.003 * 600, #-2, #-2.4, #round pads seemed to be slightly oversized, so shrink them a little
    SQRPAD_ADJUST => +0.001 * 600, #+.5, #square pads are sometimes too small by .00067, so bump them up a little
    RECTPAD_ADJUST => 0, #(pixels) rectangular pads seem to be okay? (not tested much)
    TRACE_ADJUST => 0, #(pixels) traces seemed to be okay?
    REDUCE_TOLERANCE => .001, #(inches) allow this much variation when reducing circles and rects
};

#Also, my CAD's Print function or the PDF print driver I used was a little off for circles, so define some additional adjustment values here:
#Values are added to X/Y coordinates; units are pixels; for example, a value of 1 at 600 dpi would be ~= .002 inch
use constant
{
    CIRCLE_ADJUST_MINX => 0,
    CIRCLE_ADJUST_MINY => -0.001 * 600, #-1, #circles were a little too high, so nudge them a little lower
    CIRCLE_ADJUST_MAXX => +0.001 * 600, #+1, #circles were a little too far to the left, so nudge them a little to the right
    CIRCLE_ADJUST_MAXY => 0,
    SUBST_CIRCLE_CLIPRECT => FALSE, #generate circle and substitute for clip rects (to compensate for the way some CAD software draws circles)
    WANT_CLIPRECT => TRUE, #FALSE, #AI doesn't need clip rect at all? should be on normally?
    RECT_COMPLETION => FALSE, #TRUE, #fill in 4th side of rect when 3 sides found
};

#allow .012 clearance around pads for solder mask:
#This value effectively adjusts pad sizes in the TOOL_SIZES list above (only for solder mask layers).
use constant SOLDER_MARGIN => +.012; #units are inches

#line join/cap styles:
use constant
{
    CAP_NONE => 0, #butt (none); line is exact length
    CAP_ROUND => 1, #round cap/join; line overhangs by a semi-circle at either end
    CAP_SQUARE => 2, #square cap/join; line overhangs by a half square on either end
    CAP_OVERRIDE => FALSE, #cap style overrides drawing logic
};

#number of elements in each shape type:
use constant
{
    RECT_SHAPELEN => 6, #x0, y0, x1, y1, count, "rect" (start, end corners)
    LINE_SHAPELEN => 6, #x0, y0, x1, y1, count, "line" (line seg)
    CURVE_SHAPELEN => 10, #xstart, ystart, x0, y0, x1, y1, xend, yend, count, "curve" (bezier 2 points)
    CIRCLE_SHAPELEN => 5, #x, y, 5, count, "circle" (center + radius)
};
#const my %SHAPELEN =
#Readonly my %SHAPELEN =>
our %SHAPELEN =
(
    rect => RECT_SHAPELEN,
    line => LINE_SHAPELEN,
    curve => CURVE_SHAPELEN,
    circle => CIRCLE_SHAPELEN,
);

#panelization:
#This will repeat the entire body the number of times indicated along the X or Y axes (files grow accordingly).
#Display elements that overhang PCB boundary can be squashed or left as-is (typically text or other silk screen markings).
#Set "overhangs" TRUE to allow overhangs, FALSE to truncate them.
#xpad and ypad allow margins to be added around outer edge of panelized PCB.
use constant PANELIZE => {'x' => 1, 'y' => 1, 'xpad' => 0, 'ypad' => 0, 'overhangs' => TRUE}; #number of times to repeat in X and Y directions

# Set this to 1 if you need TurboCAD support.
#$turboCAD = FALSE; #is this still needed as an option?

#CIRCAD pad generation uses an appropriate aperture, then moves it (stroke) "a little" - we use this to find pads and distinguish them from PCB holes.
use constant PAD_STROKE => 0.3; #0.0005 * 600; #units are pixels
#convert very short traces to pads or holes:
use constant TRACE_MINLEN => .001; #units are inches
#use constant ALWAYS_XY => TRUE; #FALSE; #force XY even if X or Y doesn't change; NOTE: needs to be TRUE for all pads to show in FlatCAM and ViewPlot
use constant REMOVE_POLARITY => FALSE; #TRUE; #set to remove subtractive (negative) polarity; NOTE: must be FALSE for ground planes

#PDF uses "points", each point = 1/72 inch
#combined with a PDF scale factor of .12, this gives 600 dpi resolution (1/72 * .12 = 600 dpi)
use constant INCHES_PER_POINT => 1/72; #0.0138888889; #multiply point-size by this to get inches

# The precision used when computing a bezier curve. Higher numbers are more precise but slower (and generate larger files).
#$bezierPrecision = 100;
use constant BEZIER_PRECISION => 36; #100; #use const; reduced for faster rendering (mainly used for silk screen and thermal pads)

# Ground planes and silk screen or larger copper rectangles or circles are filled line-by-line using this resolution.
use constant FILL_WIDTH => .01; #fill at most 0.01 inch at a time

# The max number of characters to read into memory
use constant MAX_BYTES => 10 * M; #bumped up to 10 MB, use const

use constant DUP_DRILL1 => TRUE; #FALSE; #kludge: ViewPlot doesn't load drill files that are too small so duplicate first tool

my $runtime = time(); #Time::HiRes::gettimeofday(); #measure my execution time

print STDERR "Loaded config settings from '${\(__FILE__)}'.\n";
1; #last value must be truthful to indicate successful load


#############################################################################################
#junk/experiment:

#use Package::Constants;
#use Exporter qw(import); #https://perldoc.perl.org/Exporter.html

#my $caller = "pdf2gerb::";

#sub cfg
#{
#    my $proto = shift;
#    my $class = ref($proto) || $proto;
#    my $settings =
#    {
#        $WANT_DEBUG => 990, #10; #level of debug wanted; higher == more, lower == less, 0 == none
#    };
#    bless($settings, $class);
#    return $settings;
#}

#use constant HELLO => "hi there2"; #"main::HELLO" => "hi there";
#use constant GOODBYE => 14; #"main::GOODBYE" => 12;

#print STDERR "read cfg file\n";

#our @EXPORT_OK = Package::Constants->list(__PACKAGE__); #https://www.perlmonks.org/?node_id=1072691; NOTE: "_OK" skips short/common names

#print STDERR scalar(@EXPORT_OK) . " consts exported:\n";
#foreach(@EXPORT_OK) { print STDERR "$_\n"; }
#my $val = main::thing("xyz");
#print STDERR "caller gave me $val\n";
#foreach my $arg (@ARGV) { print STDERR "arg $arg\n"; }

Download Details:

Author: swannman
Source Code: https://github.com/swannman/pdf2gerb

License: GPL-3.0 license

#perl

Anissa Barrows

1669099573

What Is Face Recognition? Facial Recognition with Python and OpenCV

In this article, we will know what is face recognition and how is different from face detection. We will go briefly over the theory of face recognition and then jump on to the coding section. At the end of this article, you will be able to make a face recognition program for recognizing faces in images as well as on a live webcam feed.

What is Face Detection?

In computer vision, one essential problem we are trying to figure out is to automatically detect objects in an image without human intervention. Face detection can be thought of as such a problem where we detect human faces in an image. There may be slight differences in the faces of humans but overall, it is safe to say that there are certain features that are associated with all the human faces. There are various face detection algorithms but Viola-Jones Algorithm is one of the oldest methods that is also used today and we will use the same later in the article. You can go through the Viola-Jones Algorithm after completing this article as I’ll link it at the end of this article.

Face detection is usually the first step towards many face-related technologies, such as face recognition or verification. However, face detection can have very useful applications. The most successful application of face detection would probably be photo taking. When you take a photo of your friends, the face detection algorithm built into your digital camera detects where the faces are and adjusts the focus accordingly.

For a tutorial on Real-Time Face detection

What is Face Recognition?

face recognition

Now that we are successful in making such algorithms that can detect faces, can we also recognise whose faces are they?

Face recognition is a method of identifying or verifying the identity of an individual using their face. There are various algorithms that can do face recognition but their accuracy might vary. Here I am going to describe how we do face recognition using deep learning.

So now let us understand how we recognise faces using deep learning. We make use of face embedding in which each face is converted into a vector and this technique is called deep metric learning. Let me further divide this process into three simple steps for easy understanding:

Face Detection: The very first task we perform is detecting faces in the image or video stream. Now that we know the exact location/coordinates of face, we extract this face for further processing ahead.

Feature Extraction: Now that we have cropped the face out of the image, we extract features from it. Here we are going to use face embeddings to extract the features out of the face. A neural network takes an image of the person’s face as input and outputs a vector which represents the most important features of a face. In machine learning, this vector is called embedding and thus we call this vector as face embedding. Now how does this help in recognizing faces of different persons?

While training the neural network, the network learns to output similar vectors for faces that look similar. For example, if I have multiple images of faces within different timespan, of course, some of the features of my face might change but not up to much extent. So in this case the vectors associated with the faces are similar or in short, they are very close in the vector space. Take a look at the below diagram for a rough idea:

Now after training the network, the network learns to output vectors that are closer to each other(similar) for faces of the same person(looking similar). The above vectors now transform into:

We are not going to train such a network here as it takes a significant amount of data and computation power to train such networks. We will use a pre-trained network trained by Davis King on a dataset of ~3 million images. The network outputs a vector of 128 numbers which represent the most important features of a face.

Now that we know how this network works, let us see how we use this network on our own data. We pass all the images in our data to this pre-trained network to get the respective embeddings and save these embeddings in a file for the next step.

Comparing faces: Now that we have face embeddings for every face in our data saved in a file, the next step is to recognise a new t image that is not in our data. So the first step is to compute the face embedding for the image using the same network we used above and then compare this embedding with the rest of the embeddings we have. We recognise the face if the generated embedding is closer or similar to any other embedding as shown below:

So we passed two images, one of the images is of Vladimir Putin and other of George W. Bush. In our example above, we did not save the embeddings for Putin but we saved the embeddings of Bush. Thus when we compared the two new embeddings with the existing ones, the vector for Bush is closer to the other face embeddings of Bush whereas the face embeddings of Putin are not closer to any other embedding and thus the program cannot recognise him.

What is OpenCV

In the field of Artificial Intelligence, Computer Vision is one of the most interesting and Challenging tasks. Computer Vision acts like a bridge between Computer Software and visualizations around us. It allows computer software to understand and learn about the visualizations in the surroundings. For Example: Based on the color, shape and size determining the fruit. This task can be very easy for the human brain however in the Computer Vision pipeline, first we gather the data, then we perform the data processing activities and then we train and teach the model to understand how to distinguish between the fruits based on size, shape and color of fruit.

Currently, various packages are present to perform machine learning, deep learning and computer vision tasks. By far, computer vision is the best module for such complex activities. OpenCV is an open-source library. It is supported by various programming languages such as R, Python. It runs on most of the platforms such as Windows, Linux and MacOS.

To know more about how face recognition works on opencv, check out the free course on face recognition in opencv.

Advantages of OpenCV:

OpenCV is an open-source library and is free of cost.
As compared to other libraries, it is fast since it is written in C/C++.
It works better on System with lesser RAM
To supports most of the Operating Systems such as Windows, Linux and MacOS.

Installation:

Here we will be focusing on installing OpenCV for python only. We can install OpenCV using pip or conda(for anaconda environment).

Using pip:

Using pip, the installation process of openCV can be done by using the following command in the command prompt.

pip install opencv-python

Anaconda:

If you are using anaconda environment, either you can execute the above code in anaconda prompt or you can execute the following code in anaconda prompt.

conda install -c conda-forge opencv

Face Recognition using Python

In this section, we shall implement face recognition using OpenCV and Python. First, let us see the libraries we will need and how to install them:

OpenCV
dlib
Face_recognition

OpenCV is an image and video processing library and is used for image and video analysis, like facial detection, license plate reading, photo editing, advanced robotic vision, optical character recognition, and a whole lot more.

The dlib library, maintained by Davis King, contains our implementation of “deep metric learning” which is used to construct our face embeddings used for the actual recognition process.

The face_recognition library, created by Adam Geitgey, wraps around dlib’s facial recognition functionality, and this library is super easy to work with and we will be using this in our code. Remember to install dlib library first before you install face_recognition.

To install OpenCV, type in command prompt

pip install opencv-python

I have tried various ways to install dlib on Windows but the easiest of all of them is via Anaconda. First, install Anaconda (here is a guide to install it) and then use this command in your command prompt:

conda install -c conda-forge dlib

Next to install face_recognition, type in command prompt

pip install face_recognition

Now that we have all the dependencies installed, let us start coding. We will have to create three files, one will take our dataset and extract face embedding for each face using dlib. Next, we will save these embedding in a file.

In the next file we will compare the faces with the existing the recognise faces in images and next we will do the same but recognise faces in live webcam feed

Extracting features from Face

First, you need to get a dataset or even create one of you own. Just make sure to arrange all images in folders with each folder containing images of just one person.

Next, save the dataset in a folder the same as you are going to make the file. Now here is the code:

from imutils import paths

import face_recognition

import pickle

import cv2

import os

#get paths of each file in folder named Images

#Images here contains my data(folders of various persons)

imagePaths = list(paths.list_images('Images'))

knownEncodings = []

knownNames = []

# loop over the image paths

for (i, imagePath) in enumerate(imagePaths):

# extract the person name from the image path

name = imagePath.split(os.path.sep)[-2]

# load the input image and convert it from BGR (OpenCV ordering)

# to dlib ordering (RGB)

image = cv2.imread(imagePath)

rgb = cv2.cvtColor(image, cv2.COLOR_BGR2RGB)

#Use Face_recognition to locate faces

boxes = face_recognition.face_locations(rgb,model='hog')

# compute the facial embedding for the face

encodings = face_recognition.face_encodings(rgb, boxes)

# loop over the encodings

for encoding in encodings:

knownEncodings.append(encoding)

knownNames.append(name)

#save emcodings along with their names in dictionary data

data = {"encodings": knownEncodings, "names": knownNames}

#use pickle to save data into a file for later use

f = open("face_enc", "wb")

f.write(pickle.dumps(data))

f.close()

Now that we have stored the embedding in a file named “face_enc”, we can use them to recognise faces in images or live video stream.

Face Recognition in Live webcam Feed

Here is the script to recognise faces on a live webcam feed:

import face_recognition

import imutils

import pickle

import time

import cv2

import os

#find path of xml file containing haarcascade file

cascPathface = os.path.dirname(

cv2.__file__) + "/data/haarcascade_frontalface_alt2.xml"

# load the harcaascade in the cascade classifier

faceCascade = cv2.CascadeClassifier(cascPathface)

# load the known faces and embeddings saved in last file

data = pickle.loads(open('face_enc', "rb").read())

print("Streaming started")

video_capture = cv2.VideoCapture(0)

# loop over frames from the video file stream

while True:

# grab the frame from the threaded video stream

ret, frame = video_capture.read()

gray = cv2.cvtColor(frame, cv2.COLOR_BGR2GRAY)

faces = faceCascade.detectMultiScale(gray,

scaleFactor=1.1,

minNeighbors=5,

minSize=(60, 60),

flags=cv2.CASCADE_SCALE_IMAGE)

# convert the input frame from BGR to RGB

rgb = cv2.cvtColor(frame, cv2.COLOR_BGR2RGB)

# the facial embeddings for face in input

encodings = face_recognition.face_encodings(rgb)

names = []

# loop over the facial embeddings incase

# we have multiple embeddings for multiple fcaes

for encoding in encodings:

#Compare encodings with encodings in data["encodings"]

#Matches contain array with boolean values and True for the embeddings it matches closely

#and False for rest

matches = face_recognition.compare_faces(data["encodings"],

encoding)

#set name =inknown if no encoding matches

name = "Unknown"

# check to see if we have found a match

if True in matches:

#Find positions at which we get True and store them

matchedIdxs = [i for (i, b) in enumerate(matches) if b]

counts = {}

# loop over the matched indexes and maintain a count for

# each recognized face face

for i in matchedIdxs:

#Check the names at respective indexes we stored in matchedIdxs

name = data["names"][i]

#increase count for the name we got

counts[name] = counts.get(name, 0) + 1

#set name which has highest count

name = max(counts, key=counts.get)

# update the list of names

names.append(name)

# loop over the recognized faces

for ((x, y, w, h), name) in zip(faces, names):

# rescale the face coordinates

# draw the predicted face name on the image

cv2.rectangle(frame, (x, y), (x + w, y + h), (0, 255, 0), 2)

cv2.putText(frame, name, (x, y), cv2.FONT_HERSHEY_SIMPLEX,

0.75, (0, 255, 0), 2)

cv2.imshow("Frame", frame)

if cv2.waitKey(1) & 0xFF == ord('q'):

break

video_capture.release()

cv2.destroyAllWindows()

https://www.youtube.com/watch?v=fLnGdkZxRkg

Although in the example above we have used haar cascade to detect faces, you can also use face_recognition.face_locations to detect a face as we did in the previous script

Face Recognition in Images

The script for detecting and recognising faces in images is almost similar to what you saw above. Try it yourself and if you can’t take a look at the code below:

import face_recognition

import imutils

import pickle

import time

import cv2

import os

#find path of xml file containing haarcascade file

cascPathface = os.path.dirname(

cv2.__file__) + "/data/haarcascade_frontalface_alt2.xml"

# load the harcaascade in the cascade classifier

faceCascade = cv2.CascadeClassifier(cascPathface)

# load the known faces and embeddings saved in last file

data = pickle.loads(open('face_enc', "rb").read())

#Find path to the image you want to detect face and pass it here

image = cv2.imread(Path-to-img)

rgb = cv2.cvtColor(image, cv2.COLOR_BGR2RGB)

#convert image to Greyscale for haarcascade

gray = cv2.cvtColor(image, cv2.COLOR_BGR2GRAY)

faces = faceCascade.detectMultiScale(gray,

scaleFactor=1.1,

minNeighbors=5,

minSize=(60, 60),

flags=cv2.CASCADE_SCALE_IMAGE)

# the facial embeddings for face in input

encodings = face_recognition.face_encodings(rgb)

names = []

# loop over the facial embeddings incase

# we have multiple embeddings for multiple fcaes

for encoding in encodings:

#Compare encodings with encodings in data["encodings"]

#Matches contain array with boolean values and True for the embeddings it matches closely

#and False for rest

matches = face_recognition.compare_faces(data["encodings"],

encoding)

#set name =inknown if no encoding matches

name = "Unknown"

# check to see if we have found a match

if True in matches:

#Find positions at which we get True and store them

matchedIdxs = [i for (i, b) in enumerate(matches) if b]

counts = {}

# loop over the matched indexes and maintain a count for

# each recognized face face

for i in matchedIdxs:

#Check the names at respective indexes we stored in matchedIdxs

name = data["names"][i]

#increase count for the name we got

counts[name] = counts.get(name, 0) + 1

#set name which has highest count

name = max(counts, key=counts.get)

# update the list of names

names.append(name)

# loop over the recognized faces

for ((x, y, w, h), name) in zip(faces, names):

# rescale the face coordinates

# draw the predicted face name on the image

cv2.rectangle(image, (x, y), (x + w, y + h), (0, 255, 0), 2)

cv2.putText(image, name, (x, y), cv2.FONT_HERSHEY_SIMPLEX,

0.75, (0, 255, 0), 2)

cv2.imshow("Frame", image)

cv2.waitKey(0)

Output:

InputOutput

This brings us to the end of this article where we learned about face recognition.

You can also upskill with Great Learning’s PGP Artificial Intelligence and Machine Learning Course. The course offers mentorship from industry leaders, and you will also have the opportunity to work on real-time industry-relevant projects.

Original article source at: https://www.mygreatlearning.com

#python #opencv

Hermann Frami

1651319520

Serverless APIGateway Service Proxy

This Serverless Framework plugin supports the AWS service proxy integration feature of API Gateway. You can directly connect API Gateway to AWS services without Lambda.

Install

Run serverless plugin install in your Serverless project.

serverless plugin install -n serverless-apigateway-service-proxy

Supported AWS services

Here is a services list which this plugin supports for now. But will expand to other services in the feature. Please pull request if you are intersted in it.

Kinesis Streams
SQS
S3
SNS
DynamoDB
EventBridge

How to use

Define settings of the AWS services you want to integrate under custom > apiGatewayServiceProxies and run serverless deploy.

Kinesis

Sample syntax for Kinesis proxy in serverless.yml.

custom:
  apiGatewayServiceProxies:
    - kinesis: # partitionkey is set apigateway requestid by default
        path: /kinesis
        method: post
        streamName: { Ref: 'YourStream' }
        cors: true
    - kinesis:
        path: /kinesis
        method: post
        partitionKey: 'hardcordedkey' # use static partitionkey
        streamName: { Ref: 'YourStream' }
        cors: true
    - kinesis:
        path: /kinesis/{myKey} # use path parameter
        method: post
        partitionKey:
          pathParam: myKey
        streamName: { Ref: 'YourStream' }
        cors: true
    - kinesis:
        path: /kinesis
        method: post
        partitionKey:
          bodyParam: data.myKey # use body parameter
        streamName: { Ref: 'YourStream' }
        cors: true
    - kinesis:
        path: /kinesis
        method: post
        partitionKey:
          queryStringParam: myKey # use query string param
        streamName: { Ref: 'YourStream' }
        cors: true
    - kinesis: # PutRecords
        path: /kinesis
        method: post
        action: PutRecords
        streamName: { Ref: 'YourStream' }
        cors: true

resources:
  Resources:
    YourStream:
      Type: AWS::Kinesis::Stream
      Properties:
        ShardCount: 1

Sample request after deploying.

curl https://xxxxxxx.execute-api.us-east-1.amazonaws.com/dev/kinesis -d '{"message": "some data"}'  -H 'Content-Type:application/json'

SQS

Sample syntax for SQS proxy in serverless.yml.

custom:
  apiGatewayServiceProxies:
    - sqs:
        path: /sqs
        method: post
        queueName: { 'Fn::GetAtt': ['SQSQueue', 'QueueName'] }
        cors: true

resources:
  Resources:
    SQSQueue:
      Type: 'AWS::SQS::Queue'

Sample request after deploying.

curl https://xxxxxx.execute-api.us-east-1.amazonaws.com/dev/sqs -d '{"message": "testtest"}' -H 'Content-Type:application/json'

Customizing request parameters

If you'd like to pass additional data to the integration request, you can do so by including your custom API Gateway request parameters in serverless.yml like so:

custom:
  apiGatewayServiceProxies:
    - sqs:
        path: /queue
        method: post
        queueName: !GetAtt MyQueue.QueueName
        cors: true

        requestParameters:
          'integration.request.querystring.MessageAttribute.1.Name': "'cognitoIdentityId'"
          'integration.request.querystring.MessageAttribute.1.Value.StringValue': 'context.identity.cognitoIdentityId'
          'integration.request.querystring.MessageAttribute.1.Value.DataType': "'String'"
          'integration.request.querystring.MessageAttribute.2.Name': "'cognitoAuthenticationProvider'"
          'integration.request.querystring.MessageAttribute.2.Value.StringValue': 'context.identity.cognitoAuthenticationProvider'
          'integration.request.querystring.MessageAttribute.2.Value.DataType': "'String'"

The alternative way to pass MessageAttribute parameters is via a request body mapping template.

Customizing request body mapping templates

See the SQS section under Customizing request body mapping templates

Customizing responses

Simplified response template customization

You can get a simple customization of the responses by providing a template for the possible responses. The template is assumed to be application/json.

custom:
  apiGatewayServiceProxies:
    - sqs:
        path: /queue
        method: post
        queueName: !GetAtt MyQueue.QueueName
        cors: true
        response:
          template:
            # `success` is used when the integration response is 200
            success: |-
              { "message: "accepted" }
            # `clientError` is used when the integration response is 400
            clientError: |-
              { "message": "there is an error in your request" }
            # `serverError` is used when the integration response is 500
            serverError: |-
              { "message": "there was an error handling your request" }

Full response customization

If you want more control over the integration response, you can provide an array of objects for the response value:

custom:
  apiGatewayServiceProxies:
    - sqs:
        path: /queue
        method: post
        queueName: !GetAtt MyQueue.QueueName
        cors: true
        response:
          - statusCode: 200
            selectionPattern: '2\\d{2}'
            responseParameters: {}
            responseTemplates:
              application/json: |-
                { "message": "accepted" }

The object keys correspond to the API Gateway integration response object.

S3

Sample syntax for S3 proxy in serverless.yml.

custom:
  apiGatewayServiceProxies:
    - s3:
        path: /s3
        method: post
        action: PutObject
        bucket:
          Ref: S3Bucket
        key: static-key.json # use static key
        cors: true

    - s3:
        path: /s3/{myKey} # use path param
        method: get
        action: GetObject
        bucket:
          Ref: S3Bucket
        key:
          pathParam: myKey
        cors: true

    - s3:
        path: /s3
        method: delete
        action: DeleteObject
        bucket:
          Ref: S3Bucket
        key:
          queryStringParam: key # use query string param
        cors: true

resources:
  Resources:
    S3Bucket:
      Type: 'AWS::S3::Bucket'

Sample request after deploying.

curl https://xxxxxx.execute-api.us-east-1.amazonaws.com/dev/s3 -d '{"message": "testtest"}' -H 'Content-Type:application/json'

Customizing request parameters

Similar to the SQS support, you can customize the default request parameters serverless.yml like so:

custom:
  apiGatewayServiceProxies:
    - s3:
        path: /s3
        method: post
        action: PutObject
        bucket:
          Ref: S3Bucket
        cors: true

        requestParameters:
          # if requestParameters has a 'integration.request.path.object' property you should remove the key setting
          'integration.request.path.object': 'context.requestId'
          'integration.request.header.cache-control': "'public, max-age=31536000, immutable'"

Customizing request templates

If you'd like use custom API Gateway request templates, you can do so like so:

custom:
  apiGatewayServiceProxies:
    - s3:
        path: /s3
        method: get
        action: GetObject
        bucket:
          Ref: S3Bucket
        request:
          template:
            application/json: |
              #set ($specialStuff = $context.request.header.x-special)
              #set ($context.requestOverride.path.object = $specialStuff.replaceAll('_', '-'))
              {}

Note that if the client does not provide a Content-Type header in the request, ApiGateway defaults to application/json.

Customize the Path Override in API Gateway

Added the new customization parameter that lets the user set a custom Path Override in API Gateway other than the {bucket}/{object} This parameter is optional and if not set, will fall back to {bucket}/{object} The Path Override will add {bucket}/ automatically in front

Please keep in mind, that key or path.object still needs to be set at the moment (maybe this will be made optional later on with this)

Usage (With 2 Path Parameters (folder and file and a fixed file extension)):

custom:
  apiGatewayServiceProxies:
    - s3:
        path: /s3/{folder}/{file}
        method: get
        action: GetObject
        pathOverride: '{folder}/{file}.xml'
        bucket:
          Ref: S3Bucket
        cors: true

        requestParameters:
          # if requestParameters has a 'integration.request.path.object' property you should remove the key setting
          'integration.request.path.folder': 'method.request.path.folder'
          'integration.request.path.file': 'method.request.path.file'
          'integration.request.path.object': 'context.requestId'
          'integration.request.header.cache-control': "'public, max-age=31536000, immutable'"

This will result in API Gateway setting the Path Override attribute to {bucket}/{folder}/{file}.xml So for example if you navigate to the API Gatway endpoint /language/en it will fetch the file in S3 from {bucket}/language/en.xml

Can use greedy, for deeper Folders

The forementioned example can also be shortened by a greedy approach. Thanks to @taylorreece for mentioning this.

custom:
  apiGatewayServiceProxies:
    - s3:
        path: /s3/{myPath+}
        method: get
        action: GetObject
        pathOverride: '{myPath}.xml'
        bucket:
          Ref: S3Bucket
        cors: true

        requestParameters:
          # if requestParameters has a 'integration.request.path.object' property you should remove the key setting
          'integration.request.path.myPath': 'method.request.path.myPath'
          'integration.request.path.object': 'context.requestId'
          'integration.request.header.cache-control': "'public, max-age=31536000, immutable'"

This will translate for example /s3/a/b/c to a/b/c.xml

Customizing responses

You can get a simple customization of the responses by providing a template for the possible responses. The template is assumed to be application/json.

custom:
  apiGatewayServiceProxies:
    - s3:
        path: /s3
        method: post
        action: PutObject
        bucket:
          Ref: S3Bucket
        key: static-key.json
        response:
          template:
            # `success` is used when the integration response is 200
            success: |-
              { "message: "accepted" }
            # `clientError` is used when the integration response is 400
            clientError: |-
              { "message": "there is an error in your request" }
            # `serverError` is used when the integration response is 500
            serverError: |-
              { "message": "there was an error handling your request" }

SNS

Sample syntax for SNS proxy in serverless.yml.

custom:
  apiGatewayServiceProxies:
    - sns:
        path: /sns
        method: post
        topicName: { 'Fn::GetAtt': ['SNSTopic', 'TopicName'] }
        cors: true

resources:
  Resources:
    SNSTopic:
      Type: AWS::SNS::Topic

Sample request after deploying.

curl https://xxxxxx.execute-api.us-east-1.amazonaws.com/dev/sns -d '{"message": "testtest"}' -H 'Content-Type:application/json'

Customizing responses

Simplified response template customization

You can get a simple customization of the responses by providing a template for the possible responses. The template is assumed to be application/json.

custom:
  apiGatewayServiceProxies:
    - sns:
        path: /sns
        method: post
        topicName: { 'Fn::GetAtt': ['SNSTopic', 'TopicName'] }
        cors: true
        response:
          template:
            # `success` is used when the integration response is 200
            success: |-
              { "message: "accepted" }
            # `clientError` is used when the integration response is 400
            clientError: |-
              { "message": "there is an error in your request" }
            # `serverError` is used when the integration response is 500
            serverError: |-
              { "message": "there was an error handling your request" }

Full response customization

If you want more control over the integration response, you can provide an array of objects for the response value:

custom:
  apiGatewayServiceProxies:
    - sns:
        path: /sns
        method: post
        topicName: { 'Fn::GetAtt': ['SNSTopic', 'TopicName'] }
        cors: true
        response:
          - statusCode: 200
            selectionPattern: '2\d{2}'
            responseParameters: {}
            responseTemplates:
              application/json: |-
                { "message": "accepted" }

The object keys correspond to the API Gateway integration response object.

Content Handling and Pass Through Behaviour customization

If you want to work with binary fata, you can not specify contentHandling and PassThrough inside the request object.

custom:
  apiGatewayServiceProxies:
    - sns:
        path: /sns
        method: post
        topicName: { 'Fn::GetAtt': ['SNSTopic', 'TopicName'] }
        request:
          contentHandling: CONVERT_TO_TEXT
          passThrough: WHEN_NO_TEMPLATES

The allowed values correspond with the API Gateway Method integration for ContentHandling and PassthroughBehavior

DynamoDB

Sample syntax for DynamoDB proxy in serverless.yml. Currently, the supported DynamoDB Operations are PutItem, GetItem and DeleteItem.

custom:
  apiGatewayServiceProxies:
    - dynamodb:
        path: /dynamodb/{id}/{sort}
        method: put
        tableName: { Ref: 'YourTable' }
        hashKey: # set pathParam or queryStringParam as a partitionkey.
          pathParam: id
          attributeType: S
        rangeKey: # required if also using sort key. set pathParam or queryStringParam.
          pathParam: sort
          attributeType: S
        action: PutItem # specify action to the table what you want
        condition: attribute_not_exists(Id) # optional Condition Expressions parameter for the table
        cors: true
    - dynamodb:
        path: /dynamodb
        method: get
        tableName: { Ref: 'YourTable' }
        hashKey:
          queryStringParam: id # use query string parameter
          attributeType: S
        rangeKey:
          queryStringParam: sort
          attributeType: S
        action: GetItem
        cors: true
    - dynamodb:
        path: /dynamodb/{id}
        method: delete
        tableName: { Ref: 'YourTable' }
        hashKey:
          pathParam: id
          attributeType: S
        action: DeleteItem
        cors: true

resources:
  Resources:
    YourTable:
      Type: AWS::DynamoDB::Table
      Properties:
        TableName: YourTable
        AttributeDefinitions:
          - AttributeName: id
            AttributeType: S
          - AttributeName: sort
            AttributeType: S
        KeySchema:
          - AttributeName: id
            KeyType: HASH
          - AttributeName: sort
            KeyType: RANGE
        ProvisionedThroughput:
          ReadCapacityUnits: 1
          WriteCapacityUnits: 1

Sample request after deploying.

curl -XPUT https://xxxxxxx.execute-api.us-east-1.amazonaws.com/dev/dynamodb/<hashKey>/<sortkey> \
 -d '{"name":{"S":"john"},"address":{"S":"xxxxx"}}' \
 -H 'Content-Type:application/json'

EventBridge

Sample syntax for EventBridge proxy in serverless.yml.

custom:
  apiGatewayServiceProxies:
    - eventbridge:  # source and detailType are hardcoded; detail defaults to POST body
        path: /eventbridge
        method: post
        source: 'hardcoded_source'
        detailType: 'hardcoded_detailType'
        eventBusName: { Ref: 'YourBusName' }
        cors: true
    - eventbridge:  # source and detailType as path parameters
        path: /eventbridge/{detailTypeKey}/{sourceKey}
        method: post
        detailType:
          pathParam: detailTypeKey
        source:
          pathParam: sourceKey
        eventBusName: { Ref: 'YourBusName' }
        cors: true
    - eventbridge:  # source, detail, and detailType as body parameters
        path: /eventbridge/{detailTypeKey}/{sourceKey}
        method: post
        detailType:
          bodyParam: data.detailType
        source:
          bodyParam: data.source
        detail:
          bodyParam: data.detail
        eventBusName: { Ref: 'YourBusName' }
        cors: true

resources:
  Resources:
    YourBus:
      Type: AWS::Events::EventBus
      Properties:
        Name: YourEventBus

Sample request after deploying.

curl https://xxxxxxx.execute-api.us-east-1.amazonaws.com/dev/eventbridge -d '{"message": "some data"}'  -H 'Content-Type:application/json'

Common API Gateway features

Enabling CORS

To set CORS configurations for your HTTP endpoints, simply modify your event configurations as follows:

custom:
  apiGatewayServiceProxies:
    - kinesis:
        path: /kinesis
        method: post
        streamName: { Ref: 'YourStream' }
        cors: true

Setting cors to true assumes a default configuration which is equivalent to:

custom:
  apiGatewayServiceProxies:
    - kinesis:
        path: /kinesis
        method: post
        streamName: { Ref: 'YourStream' }
        cors:
          origin: '*'
          headers:
            - Content-Type
            - X-Amz-Date
            - Authorization
            - X-Api-Key
            - X-Amz-Security-Token
            - X-Amz-User-Agent
          allowCredentials: false

Configuring the cors property sets Access-Control-Allow-Origin, Access-Control-Allow-Headers, Access-Control-Allow-Methods,Access-Control-Allow-Credentials headers in the CORS preflight response. To enable the Access-Control-Max-Age preflight response header, set the maxAge property in the cors object:

custom:
  apiGatewayServiceProxies:
    - kinesis:
        path: /kinesis
        method: post
        streamName: { Ref: 'YourStream' }
        cors:
          origin: '*'
          maxAge: 86400

If you are using CloudFront or another CDN for your API Gateway, you may want to setup a Cache-Control header to allow for OPTIONS request to be cached to avoid the additional hop.

To enable the Cache-Control header on preflight response, set the cacheControl property in the cors object:

custom:
  apiGatewayServiceProxies:
    - kinesis:
        path: /kinesis
        method: post
        streamName: { Ref: 'YourStream' }
        cors:
          origin: '*'
          headers:
            - Content-Type
            - X-Amz-Date
            - Authorization
            - X-Api-Key
            - X-Amz-Security-Token
            - X-Amz-User-Agent
          allowCredentials: false
          cacheControl: 'max-age=600, s-maxage=600, proxy-revalidate' # Caches on browser and proxy for 10 minutes and doesnt allow proxy to serve out of date content

Adding Authorization

You can pass in any supported authorization type:

custom:
  apiGatewayServiceProxies:
    - sqs:
        path: /sqs
        method: post
        queueName: { 'Fn::GetAtt': ['SQSQueue', 'QueueName'] }
        cors: true

        # optional - defaults to 'NONE'
        authorizationType: 'AWS_IAM' # can be one of ['NONE', 'AWS_IAM', 'CUSTOM', 'COGNITO_USER_POOLS']

        # when using 'CUSTOM' authorization type, one should specify authorizerId
        # authorizerId: { Ref: 'AuthorizerLogicalId' }
        # when using 'COGNITO_USER_POOLS' authorization type, one can specify a list of authorization scopes
        # authorizationScopes: ['scope1','scope2']

resources:
  Resources:
    SQSQueue:
      Type: 'AWS::SQS::Queue'

Source: AWS::ApiGateway::Method docs

Enabling API Token Authentication

You can indicate whether the method requires clients to submit a valid API key using private flag:

custom:
  apiGatewayServiceProxies:
    - sqs:
        path: /sqs
        method: post
        queueName: { 'Fn::GetAtt': ['SQSQueue', 'QueueName'] }
        cors: true
        private: true

resources:
  Resources:
    SQSQueue:
      Type: 'AWS::SQS::Queue'

which is the same syntax used in Serverless framework.

Source: Serverless: Setting API keys for your Rest API

Source: AWS::ApiGateway::Method docs

Using a Custom IAM Role

By default, the plugin will generate a role with the required permissions for each service type that is configured.

You can configure your own role by setting the roleArn attribute:

custom:
  apiGatewayServiceProxies:
    - sqs:
        path: /sqs
        method: post
        queueName: { 'Fn::GetAtt': ['SQSQueue', 'QueueName'] }
        cors: true
        roleArn: # Optional. A default role is created when not configured
          Fn::GetAtt: [CustomS3Role, Arn]

resources:
  Resources:
    SQSQueue:
      Type: 'AWS::SQS::Queue'
    CustomS3Role:
      # Custom Role definition
      Type: 'AWS::IAM::Role'

Customizing API Gateway parameters

The plugin allows one to specify which parameters the API Gateway method accepts.

A common use case is to pass custom data to the integration request:

custom:
  apiGatewayServiceProxies:
    - sqs:
        path: /sqs
        method: post
        queueName: { 'Fn::GetAtt': ['SqsQueue', 'QueueName'] }
        cors: true
        acceptParameters:
          'method.request.header.Custom-Header': true
        requestParameters:
          'integration.request.querystring.MessageAttribute.1.Name': "'custom-Header'"
          'integration.request.querystring.MessageAttribute.1.Value.StringValue': 'method.request.header.Custom-Header'
          'integration.request.querystring.MessageAttribute.1.Value.DataType': "'String'"
resources:
  Resources:
    SqsQueue:
      Type: 'AWS::SQS::Queue'

Any published SQS message will have the Custom-Header value added as a message attribute.

Customizing request body mapping templates

Kinesis

If you'd like to add content types or customize the default templates, you can do so by including your custom API Gateway request mapping template in serverless.yml like so:

# Required for using Fn::Sub
plugins:
  - serverless-cloudformation-sub-variables

custom:
  apiGatewayServiceProxies:
    - kinesis:
        path: /kinesis
        method: post
        streamName: { Ref: 'MyStream' }
        request:
          template:
            text/plain:
              Fn::Sub:
                - |
                  #set($msgBody = $util.parseJson($input.body))
                  #set($msgId = $msgBody.MessageId)
                  {
                      "Data": "$util.base64Encode($input.body)",
                      "PartitionKey": "$msgId",
                      "StreamName": "#{MyStreamArn}"
                  }
                - MyStreamArn:
                    Fn::GetAtt: [MyStream, Arn]

It is important that the mapping template will return a valid application/json string

Source: How to connect SNS to Kinesis for cross-account delivery via API Gateway

SQS

Customizing SQS request templates requires us to force all requests to use an application/x-www-form-urlencoded style body. The plugin sets the Content-Type header to application/x-www-form-urlencoded for you, but API Gateway will still look for the template under the application/json request template type, so that is where you need to configure you request body in serverless.yml:

custom:
  apiGatewayServiceProxies:
    - sqs:
        path: /{version}/event/receiver
        method: post
        queueName: { 'Fn::GetAtt': ['SqsQueue', 'QueueName'] }
        request:
          template:
            application/json: |-
              #set ($body = $util.parseJson($input.body))
              Action=SendMessage##
              &MessageGroupId=$util.urlEncode($body.event_type)##
              &MessageDeduplicationId=$util.urlEncode($body.event_id)##
              &MessageAttribute.1.Name=$util.urlEncode("X-Custom-Signature")##
              &MessageAttribute.1.Value.DataType=String##
              &MessageAttribute.1.Value.StringValue=$util.urlEncode($input.params("X-Custom-Signature"))##
              &MessageBody=$util.urlEncode($input.body)

Note that the ## at the end of each line is an empty comment. In VTL this has the effect of stripping the newline from the end of the line (as it is commented out), which makes API Gateway read all the lines in the template as one line.

Be careful when mixing additional requestParameters into your SQS endpoint as you may overwrite the integration.request.header.Content-Type and stop the request template from being parsed correctly. You may also unintentionally create conflicts between parameters passed using requestParameters and those in your request template. Typically you should only use the request template if you need to manipulate the incoming request body in some way.

Your custom template must also set the Action and MessageBody parameters, as these will not be added for you by the plugin.

When using a custom request body, headers sent by a client will no longer be passed through to the SQS queue (PassthroughBehavior is automatically set to NEVER). You will need to pass through headers sent by the client explicitly in the request body. Also, any custom querystring parameters in the requestParameters array will be ignored. These also need to be added via the custom request body.

SNS

Similar to the Kinesis support, you can customize the default request mapping templates in serverless.yml like so:

# Required for using Fn::Sub
plugins:
  - serverless-cloudformation-sub-variables

custom:
  apiGatewayServiceProxies:
    - kinesis:
        path: /sns
        method: post
        topicName: { 'Fn::GetAtt': ['SNSTopic', 'TopicName'] }
        request:
          template:
            application/json:
              Fn::Sub:
                - "Action=Publish&Message=$util.urlEncode('This is a fixed message')&TopicArn=$util.urlEncode('#{MyTopicArn}')"
                - MyTopicArn: { Ref: MyTopic }

It is important that the mapping template will return a valid application/x-www-form-urlencoded string

Source: Connect AWS API Gateway directly to SNS using a service integration

Custom response body mapping templates

You can customize the response body by providing mapping templates for success, server errors (5xx) and client errors (4xx).

Templates must be in JSON format. If a template isn't provided, the integration response will be returned as-is to the client.

Kinesis Example

custom:
  apiGatewayServiceProxies:
    - kinesis:
        path: /kinesis
        method: post
        streamName: { Ref: 'MyStream' }
        response:
          template:
            success: |
              {
                "success": true
              }
            serverError: |
              {
                "success": false,
                "errorMessage": "Server Error"
              }
            clientError: |
              {
                "success": false,
                "errorMessage": "Client Error"
              }

Author: Serverless-operations
Source Code: https://github.com/serverless-operations/serverless-apigateway-service-proxy
License:

#serverless #api #aws

Lawson Wehner

1672833558

How to Use Bash Set Command

Bash has many environment variables for various purposes. The set command of Bash is used to modify or display the different attributes and parameters of the shell environment. This command has many options to perform the different types of tasks. The uses of set command for various purposes are described in this tutorial.

Syntax

set [options] [arguments]

This command can be used with different types of options and arguments for different purposes. If no option or argument is used with this command, the shell variables are printed. The minus sign (-) is used with the command’s option to enable that option and the plus sign (+) is used with the command’s option to disable that option.

Exit Values of Set Command

Three exit values can be returned by this command which are mentioned in the following:

Zero (0) is returned to complete the task successfully.
One (1) is returned if a failure occurs for any invalid argument.
One (1) is returned if a failure occurs for a missing argument.

Different Options of Set Command

The purposes of the most commonly used options of the set command are described in this part of the tutorial.

Option	Purpose
-a	It defines those variables or functions which are created or modified or exported.
-b	It informs the job termination.
-B	To do the task of the brace expansion.
-C	It disables the overwriting feature of the existing file.
-e	It exits for non-zero exit status value.
-f	It disables the filename generation task.
-h	It saves the location of the command where it has been used.
-m	It enables job control.
-n	It reads the commands.
-t	It exits from the command after executing a single command.
-u	It traces the unset variables.
-v	It prints the shell input lines.
-x	It displays the commands and their attributes sequentially. It is mainly used to debug the script.

Different Examples of the Set Command

The uses of set command with different options are shown in this part of this tutorial.

Example 1: Using the Set Command with -a Option

Create a Bash file with the following script that enables the “set –a” command and initialize three variables named $v1, $v2, and $v3. These variables can be accessed after executing the script.

#!/bin/bash
#Enable -a option to read the values of the variables
set -a
#Initialize three variables
v1=78
v2=50
v3=35

Run the script using the following command:

$ bash set1.bash

Read the values of the variable using the “echo” command:

$ echo $v1 $v2 $v3

The following output appears after executing the previous commands:

Example 2: Using the Set Command with -C Option

Run the “cat” command to create a text file named testfile.txt. Next, run the “set –C” command to disable the overwriting feature. Next, run the “cat” command again to overwrite the file to check whether the overwriting feature is disabled or not.

$ cat > testfile.txt
$ set -C
$ cat > testfile.txt

The following output appears after executing the previous commands:

Example 3: Using the Set Command with -x Option

Create a Bash file with the following script that declares a numeric array of 6 elements. The values of the array are printed using for loop.

#!/bin/bash
#Declare an array
arr=(67 3 90 56 2 80)
#iterate the array values
for value in ${arr[@]}
do
   echo $value
done

Execute the previous script by the following command:

$ bash set3.bash

Enable the debugging option using the following command:

$ set -x

The following output appears after executing the provided commands:

Example 4: Using the Set Command with -e Option

Create a Bash file with the following script that reads a file using the “cat” command before and after using the “set –e” command.

#!/bin/bash
#Read a non-existing file without setting set -e
cat myfile.txt
echo "Reading a file..."
#Set the set command with -e option
set -e
#Read a non-existing file after setting set -e
cat myfile.txt
echo "Reading a file..."

The following output appears after executing the provided commands. The first error message is shown because the file does not exist in the current location. The next message is then printed. But after executing the “set –e” command, the execution stops after displaying the error message.

Example 5: Using the Set Command with -u Option

Create a Bash file with the following script that initializes a variable but prints the initialized and uninitialized variable before and after using the “set –u” command.

#!/bin/bash
#Assign value to a variable
strvar="Bash Programming"
printf "$strvar $intvar\n"
#Set the set command with -u option
set -u
#Assign value to a variable
strvar="Bash Programming"
printf "\n$strvar $intvar\n"

The following output appears after executing the previous script. Here, the error is printed for the uninitialized variable:

Example 6: Using the Set Command with -f Option

Run the following command to print the list of all text files of the current location:

$ ls *.txt

Run the following command to disable the globbing:

$ set –f

Run the following command again to print the list of all text files of the current location:

$ ls *.txt

The following output appears after executing the previous script. Based on the output, the “ls *.txt” command did not work after setting “set –f” command:

Example 7: Split the String Using the Set Command with Variable

Create a Bash file with the following script that splits the string value based on the space using the “set – variable” command. The split values are printed later.

#!/bin/bash
#Define a string variable
myvar="Learn bash programming"
#Set the set command without option and with variable
set -- $myvar
#Print the split value
printf "$1\n$2\n$3\n"

The following output appears after executing the previous script. The string value is divided into three parts based on the space that is printed:

Conclusion

The uses of the different options of the “set” command are shown in this tutorial using multiple examples to know the basic uses of this command.

Original article source at: https://linuxhint.com/

#bash #set #command

How to Set Up Auditing System for The AWS Resources using AWS Config

What is GEEK

Buddha Community

A Simple Wrapper Around Amplify AppSync Simulator

Basic usage

Override (or mock) values

Key-value mock notation

Limitations

Relational Database

Sample VTL for a create mutation

Sample VTL for an update mutation

Sample resolver for delete mutation

Sample mutation response VTL with support for handling AWSDateTime

Using Variable Map

Pdf2gerb: Perl Script Converts PDF Files to Gerber format

pdf2gerb

pdf2gerb_cfg.pm

Download Details:

What Is Face Recognition? Facial Recognition with Python and OpenCV

What is Face Detection?

What is Face Recognition?

What is OpenCV

Face Recognition using Python

Extracting features from Face

Face Recognition in Live webcam Feed

Face Recognition in Images

Serverless APIGateway Service Proxy

Install

Supported AWS services

How to use

Kinesis

SQS

Customizing request parameters

Customizing request body mapping templates

Customizing responses

S3

Customizing request parameters

Customizing request templates

Customize the Path Override in API Gateway

Customizing responses

SNS

Customizing responses

DynamoDB

EventBridge

Common API Gateway features

Enabling CORS

Adding Authorization

Enabling API Token Authentication

Using a Custom IAM Role

Customizing API Gateway parameters

Customizing request body mapping templates

Kinesis

SQS

SNS

Custom response body mapping templates

Kinesis Example

How to Use Bash Set Command

Syntax

Exit Values of Set Command

Different Options of Set Command

Different Examples of the Set Command

Conclusion
