Build an ASP.NET Core application with Docker and Visual Studio

Build an ASP.NET Core application with Docker and Visual Studio

In this article will guide you building, running, and debugging an ASP.NET Core application with Docker and Visual Studio ...

Development frameworks, platforms, and tools that do not offer a rich development experience will ultimately lack in adoption. Docker is an amazing technology but, what is the development experience like? Not too long ago, I wrote about creating and debugging an ASP.NET Core Docker container in two different ways.

  1. Visual Studio 2017 (Windows)
  2. Visual Studio Code (Linux)

With the launching of Visual Studio 2019 recently, I felt compelled to target one more IDE  .

PREREQUISITES

The first step is making sure Visual Studio is set up correctly. This is a simple as installing Visual Studio 2019 with the .NET Core cross-platform development workload installed. More specifically, if you select Individual Components, you need to ensure that the Container Development Tools component is selected as shown below.

Lastly, you will need to have Docker Desktop for Windows installed if you haven’t already. Once this is done, we are ready to create an ASP.NET Core Docker container in Visual Studio.

___________________________________________________________________________________

You may also like: Tutorial Laravel 6 with Docker and Docker-Compose

____________________________________________________________________________________

CREATING AN ASP.NET CORE DOCKER CONTAINER

As explained in this blog post, the new project dialog in Visual Studio has been given an overhaul. I have become quite accustomed to the previous version however, I must admit the improvements are very intuitive. For this tutorial, we will select the ASP.NET Core Web Application template and click Next.

Once this is done, we can give our new project a name, location, and solution name. As you can see, this process is much more like a wizard as opposed to the monolithic dialog that was used in previous versions.

Now we can provide some more specifics for our new application. For the purposes of this example we will select the API project template. That said, a key piece can be found in the advanced section. Here we want to select Enable Docker Support and make sure Linux is selected in the following drop-down.

Similar to when working with Visual Studio 2017, a Dockerfile is generated with four named build stages (base, build, publish, and final). Multistage builds are helpful to optimize layers and keep our Dockerfile easy to maintain.

FROM mcr.microsoft.com/dotnet/core/aspnet:2.1-stretch-slim AS base
WORKDIR /app
EXPOSE 80
EXPOSE 443

FROM mcr.microsoft.com/dotnet/core/sdk:2.1-stretch AS build
WORKDIR /src
COPY ["JrTech.Docker.Vs2019/JrTech.Docker.Vs2019.csproj", "JrTech.Docker.Vs2019/"]
RUN dotnet restore "JrTech.Docker.Vs2019/JrTech.Docker.Vs2019.csproj"
COPY . .
WORKDIR "/src/JrTech.Docker.Vs2019"
RUN dotnet build "JrTech.Docker.Vs2019.csproj" -c Release -o /app

FROM build AS publish
RUN dotnet publish "JrTech.Docker.Vs2019.csproj" -c Release -o /app

FROM base AS final
WORKDIR /app
COPY --from=publish /app .
ENTRYPOINT ["dotnet", "JrTech.Docker.Vs2019.dll"]

Next lets take a look at how our application gets built and deployed as a container.

BUILDING THE CONTAINER

Prior to building or debugging our application, we will already notice some activity in the Container Tools output in the output window.

========== Checking for Container Prerequisites ==========
Verifying that Docker Desktop is installed...
Docker Desktop is installed.
========== Verifying that Docker Desktop is running... ==========
Verifying that Docker Desktop is running...
Docker Desktop is running.
========== Verifying Docker OS ==========
Verifying that Docker Desktop's operating system mode matches the project's target operating system...
Docker Desktop's operating system mode matches the project's target operating system.
========== Pulling Required Images ==========
Checking for missing Docker images...
Docker images are ready.
========== Warming up container(s) for JrTech.Docker.Vs2019 ==========
Starting up container(s)...
docker build -f "C:\Users\jason\source\repos\JrTech.Docker.Vs2019\JrTech.Docker.Vs2019\Dockerfile" -t jrtechdockervs2019:dev --target base --label "com.microsoft.created-by=visual-studio" --label "com.microsoft.visual-studio.project-name=JrTech.Docker.Vs2019" "C:\Users\jason\source\repos\JrTech.Docker.Vs2019"
Sending build context to Docker daemon 18.94kB
Step 1/6 : FROM mcr.microsoft.com/dotnet/core/aspnet:2.1-stretch-slim AS base
---> 9a8e320a271f
Step 2/6 : WORKDIR /app
---> Using cache
---> 3bca35715a51
Step 3/6 : EXPOSE 80
---> Using cache
---> 854d77a40024
Step 4/6 : EXPOSE 443
---> Using cache
---> 962750b42169
Step 5/6 : LABEL com.microsoft.created-by=visual-studio
---> Using cache
---> 09e977d58879
Step 6/6 : LABEL com.microsoft.visual-studio.project-name=JrTech.Docker.Vs2019
---> Using cache
---> 5053ced48dc0
Successfully built 5053ced48dc0
Successfully tagged jrtechdockervs2019:dev
SECURITY WARNING: You are building a Docker image from Windows against a non-Windows Docker host. All files and directories added to build context will have '-rwxr-xr-x' permissions. It is recommended to double check and reset permissions for sensitive files and directories.
docker run -dt -v "C:\Users\jason\vsdbg\vs2017u5:/remote_debugger:rw" -v "C:\Users\jason\source\repos\JrTech.Docker.Vs2019\JrTech.Docker.Vs2019:/app" -v "C:\Users\jason\AppData\Roaming\Microsoft\UserSecrets:/root/.microsoft/usersecrets:ro" -v "C:\Users\jason\AppData\Roaming\ASP.NET\Https:/root/.aspnet/https:ro" -v "C:\Users\jason.nuget\packages:/root/.nuget/fallbackpackages2" -v "C:\Program Files\dotnet\sdk\NuGetFallbackFolder:/root/.nuget/fallbackpackages" -e "DOTNET_USE_POLLING_FILE_WATCHER=1" -e "ASPNETCORE_ENVIRONMENT=Development" -e "NUGET_PACKAGES=/root/.nuget/fallbackpackages2" -e "NUGET_FALLBACK_PACKAGES=/root/.nuget/fallbackpackages;/root/.nuget/fallbackpackages2" -p 49558:80 -p 44304:443 --entrypoint tail jrtechdockervs2019:dev -f /dev/null
e93c776e500a98321e35fa1c02d2d89e6f64ff92f4c3e945f635f9c590f17d70
Container started successfully.
========== Finished ==========

This is a new optimization added to Visual Studio 2019. In order to allow our application to build, deploy, and run quickly Visual Studio preemptively creates a container. We can see the container by running docker ps from the command line.

E:\Software\cmder_mini
λ docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
e93c776e500a jrtechdockervs2019:dev "tail -f /dev/null" 20 seconds ago Up 19 seconds 0.0.0.0:49558->80/tcp, 0.0.0.0:44304->443/tcp flamboyant_shirley

With the http and https ports exposed, the container is primed and ready to go. If we open a browser and browse to the http port, 49558 in my case, we see that we do not get a response yet. This makes sense because while our container is started, nothing is actually deployed to it yet.

To build and deploy our application to the running container, we must debug using the Docker configuration profile. This should be selected by default. Once we are up and running, we can see that our application is available through http/https ports that were exposed in our Docker container.

We can also see that the same container that was started when we created our application is still running. When we run our application a new container isn’t created, rather the output from our project is copied into the running container. We can see this by observing the running containers which shows or original container is still running.

E:\Software\cmder_mini
λ docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
e93c776e500a jrtechdockervs2019:dev "tail -f /dev/null" 7 minutes ago Up 7 minutes 0.0.0.0:49558->80/tcp, 0.0.0.0:44304->443/tcp flamboyant_shirley

Visual Studio remotely attaches to the process running inside the container. This gives us the ability to set breakpoints and debug our application while it is running.

The development experience in Visual Studio 2019 is very similar to Visual Studio 2017 as it pertains to building Docker containers. That said, there are some nice enhancements under the hood that make the development process even more seemless. It is great to Microsoft’s continued investment in this great new technology!

Happy Coding!

Further Reading

How To Set Up Laravel, Nginx, and MySQL with Docker Compose

Containerizing a Node.js Application for Development With Docker Compose

Docker Basics: Docker Compose

Originally published by JROB5756  at espressocoder.com

++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

Thanks for reading :heart: If you liked this post, share it with all of your programming buddies! Follow me on Facebook | Twitter


Angular and ASP.NET Core

Angular and ASP.NET Core

​ The [Angular CLI](https://cli.angular.io/ "Angular CLI") provides a way to develop front-end applications using angular that hides a lot of details. For example there's no requirement to understand how [Webpack](https://webpack.js.org/ "Webpack") or [SystemJS](https://github.com/systemjs/systemjs "SystemJS") work. ​ In fact, if you don't know a little bit about Webpack, which is what is used to build the latest version of Angular applications, the CLI almost looks like magic. You just need to do a ng new and ng serve --open and you have a working Angular application open in your web browser. ​ The fact that the CLI hides all the plumbing might lead to questions like: "How do I use Angular with ASP.NET Core?". ​ ![](https://res.cloudinary.com/practicaldev/image/fetch/s--dKBafg3O--/c_limit%2Cf_auto%2Cfl_progressive%2Cq_auto%2Cw_880/http://www.blinkingcaret.com/wp-content/uploads/2018/01/asp_net_core_and_angular_logo.png) ​ I hope that by the end of this blog post it will be clear to you how you can answer that question (and not only with ASP.NET Core, with whichever technology you want to use your Angular app with). ​ You see, an angular app is an app in and of itself, it does need to be "served" somehow by a web server. ​ When you compile an angular application you are producing a set of JavaScript, CSS and one index.html file. That's it. ​ The default folder where those "artifacts" get copied to is yourApplicationFolder/dist. You can check it out by going to your Angular application and doing an ng build. ​ Go on, I'll wait. ​ When you do ng serve --open you are actually using a stand-alone web server ([webpack-dev-server](https://github.com/webpack/webpack-dev-server "webpack-dev-server")) to serve that index.html file in the dist folder. ​ The rest of this blog post will describe several approaches that you can take for using Angular with ASP.NET Core. The first is to have ASP.NET Core serve the Angular files. ​ The second approach is to have Angular and ASP.NET Core as different applications. There's an example of how to achieve this using Nginx where both Angular and ASP.NET Core are served using port 80 and in IIS where each application is served from its own port. ​ The final part of the post describes a setup that I consider ideal where you can use Angular's ng serve during development. ​ This post is quite long but the sections are fairly independent. If your are only interested in the last section and you are using Windows I recommend also reading the section on how to configure Angular in IIS. ## Using ASP.NET Core to serve the Angular application ​ It can be argued that serving an Angular application "within" ASP.NET Core is wasteful in terms of resources. In the end the Angular application is just a set of static files, there's no need to have the request for those files go through the ASP.NET Core middleware pipeline. ​ There might be some good reasons for doing it though, also there's no harm in knowing how to do it and since it seems to be a common approach, being familiar with it might be useful. ​ One important thing to know in order to understand how we can serve an ASP.NET Core and Angular application together is to understand how a request is processed in ASP.NET Core. ​ When you run an ASP.NET Core application your request goes through a "pipeline" of [middlewares](https://docs.microsoft.com/en-us/aspnet/core/fundamentals/middleware?tabs=aspnetcore2x "middlewares"). Every time a request comes in it goes through the middlewares in the order they are defined, and then in reverse order. ​ Every middleware has an opportunity to change the request or response two times, once before the other middlewares have been executed, and then after the other middlewares have executed. This allows for a middleware at the top of the pipeline to handle for example, a 401 response set by a middleware further down in the pipeline. ​ An example of this are the authentication middlewares that change a 401 response to a 302 redirect to a login page. The Angular CLI provides a way to develop front-end applications using angular that hides a lot of details. For example there’s no requirement to understand how Webpack or SystemJS work.

The Angular CLI provides a way to develop front-end applications using angular that hides a lot of details. For example there's no requirement to understand how Webpack or SystemJS work.

In fact, if you don't know a little bit about Webpack, which is what is used to build the latest version of Angular applications, the CLI almost looks like magic. You just need to do a ng new and ng serve --open and you have a working Angular application open in your web browser.

The fact that the CLI hides all the plumbing might lead to questions like: "How do I use Angular with ASP.NET Core?".

I hope that by the end of this blog post it will be clear to you how you can answer that question (and not only with ASP.NET Core, with whichever technology you want to use your Angular app with).

You see, an angular app is an app in and of itself, it does need to be "served" somehow by a web server.

When you compile an angular application you are producing a set of JavaScript, CSS and one index.html file. That's it.

The default folder where those "artifacts" get copied to is yourApplicationFolder/dist. You can check it out by going to your Angular application and doing an ng build.

Go on, I'll wait.

When you do ng serve --open you are actually using a stand-alone web server (webpack-dev-server) to serve that index.html file in the dist folder.

The rest of this blog post will describe several approaches that you can take for using Angular with ASP.NET Core. The first is to have ASP.NET Core serve the Angular files.

The second approach is to have Angular and ASP.NET Core as different applications. There's an example of how to achieve this using Nginx where both Angular and ASP.NET Core are served using port 80 and in IIS where each application is served from its own port.

The final part of the post describes a setup that I consider ideal where you can use Angular's ng serve during development.

This post is quite long but the sections are fairly independent. If your are only interested in the last section and you are using Windows I recommend also reading the section on how to configure Angular in IIS.

Using ASP.NET Core to serve the Angular application

It can be argued that serving an Angular application "within" ASP.NET Core is wasteful in terms of resources. In the end the Angular application is just a set of static files, there's no need to have the request for those files go through the ASP.NET Core middleware pipeline.

There might be some good reasons for doing it though, also there's no harm in knowing how to do it and since it seems to be a common approach, being familiar with it might be useful.

One important thing to know in order to understand how we can serve an ASP.NET Core and Angular application together is to understand how a request is processed in ASP.NET Core.

When you run an ASP.NET Core application your request goes through a "pipeline" of middlewares. Every time a request comes in it goes through the middlewares in the order they are defined, and then in reverse order.

Every middleware has an opportunity to change the request or response two times, once before the other middlewares have been executed, and then after the other middlewares have executed. This allows for a middleware at the top of the pipeline to handle for example, a 401 response set by a middleware further down in the pipeline.

An example of this are the authentication middlewares that change a 401 response to a 302 redirect to a login page.

You can find the definition of this pipeline on the Startup.cs file, in the Configure method. For example, here's the pipeline that you get when you do a dotnet new mvc:

public void Configure(IApplicationBuilder app, IHostingEnvironment env)
{
    if (env.IsDevelopment())
    {
        app.UseDeveloperExceptionPage();
    }
    else
    {
        app.UseExceptionHandler("/Home/Error");
    }

    app.UseStaticFiles();

    app.UseMvc(routes =>
    {
        routes.MapRoute(
            name: "default",
            template: "{controller=Home}/{action=Index}/{id?}");
    });
}

Every time a request comes in to this ASP.NET Core application it can go through at most three middlewares. First the DeveloperExceptionPage/ExceptionHandler middleware depending if the ASP.NET Core application is running in development mode or not. Then the StaticFiles middleware and then finally the Mvc middleware.

The middleware that is key here is StaticFiles. This is the middleware that serves files contained in the wwwroot folder, i.e. if a request comes in for index.html and there's an index.html file at wwwroot/index.html then that file is sent to the client. StaticFiles middleware won't call the middlewares below it after this (in this case it would be Mvc).

You can probably already see how this could work with an Angular application. Just put it under wwwroot.

That's absolutely correct, however there's a detail about StaticFiles that is important to know. StaticFiles won't try to do any guesses for you, i.e. if your request is for /, StaticFiles won't look for /index.html. It will just assume that this request isn't supposed to be handled by it and it will call the next middleware in the pipeline, in this case Mvc.

For this approach to work you need another middleware named DefaultFiles which must come before StaticFiles in the pipeline:

//...
app.UseDefaultFiles();
app.UseStaticFiles();
//...

DefaultFiles will cause cause StaticFiles to look for index.html if the url ends with /.

Now the only thing left to do is to configure your Angular CLI to compile to your ASP.NET Core application's wwwroot folder.

If you look in your Angular's application folder you'll find a .angular-cli.json file. In that file look for the outDir property:

...
"apps": [
{
    ...
    "outDir": "dist",
...

Change it from "dist" to the path of your ASP.NET Core's wwwroot folder. Run ng build in your Angular application and now if you run your ASP.NET Core web application you should see your Angular application in the browser.

A nice development workflow is to run the Angular CLI build in watch mode: In a console window do ng build --watch or ng build -w if you want to save a few key strokes, and leave it running. Now every time you make a change in your Angular application you can just refresh the browser and see the change (you also need to have your ASP.NET Core application running).

There is one thing missing from this approach, though. Deep-linking support, i.e. if your Angular application uses routing and you send a user a url with a valid Angular route (e.g http://yourapplication.com/products/5) the receiving user won't be able to open it. Trying to get to that route will result in a 404 Not Found response.

That's because the request will go all the way through your ASP.NET Core application's pipeline and when it reaches the MVC middleware it won't know what to do with it and will set the response's status code to 404 Page Not Found.

What we can do is at the top of the pipeline we look for a 404 response that is about to be sent and change its path to our Angular application's index.html file (that way what gets served is the Angular application which will know what to do with the url in terms of routing). After this we make the request go through the pipeline again:

//add this at the start of Configure
app.Use(async (HttpContext context, Func<Task> next) =>
{
    await next.Invoke();

    if (context.Response.StatusCode == 404)
    {
        context.Request.Path = new PathString("/index.html");
        await next.Invoke();
    }
});

That fixes deep links but introduces a new problem. What if your web api (that you've implemented in your ASP.NET Core application) needs to send a 404 response. That's something more than reasonable to do. Instead of a 404, the service call will receive a 200 response with index.html.

The solution here is to look at the url and decide if it's intended for the web api or an Angular route. Usually a call to the web api will have /api in the url. That's a simple test to perform and it will solve this problem. Here's the revised version of a custom middleware that solves this problem:

//add this at the start of Configure
app.Use(async (HttpContext context, Func<Task> next) =>
{
    await next.Invoke();

    if (context.Response.StatusCode == 404 && !context.Request.Path.Value.Contains("/api")))
    {
        context.Request.Path = new PathString("/index.html");
        await next.Invoke();
    }
});

One last note about this approach. I've seen examples where the Angular application is in the same Visual Studio solution as the ASP.NET application. Visual Studio (not VS Code) will try to compile the typescript files. If you are using ng build -w you'll want Visual Studio to leave your Typescript files alone. To do that open your project's .csproj and add in any PropertyGroup:

<TypescriptCompileBlocked>true</TypescriptCompileBlocked>

Nginx

Nginx is a web server that can act as a reverse proxy for ASP.NET Core applications and which is also very good at serving static content.

The setup for having an Angular application work with ASP.NET Core is much simpler in Nginx. You just need a configuration similar to this:

server {
    listen 80;

    location / {
        root /pathToYourAngularApplication/dist;
        index index.html;
        try_files $uri $uri/ /index.html;
    }

    location /api/ {
        proxy_pass http://localhost:5000;
    }
}

This is how a typical Nginx configuration file looks like. If you are not familiar with Nginx and ASP.NET Core I recommend my blog post: HTTPS in ASP.NET Core from Scratch. It has a section with instructions on how to install and setup websites using Nginx.

This configuration allows us to have both the Angular and ASP.NET Core application on port 80. Let's look at the important parts in it.

The listen 80 statement establishes that Nginx will respond to requests coming in on port 80.

The location blocks are where we are going to define how our two applications will be served (Angular and ASP.NET). Each time a request comes in, Nginx will look at the URL and try to find the location block that best matches it. In this case the location blocks urls act like a "prefix match", i.e., the first block will match every URL (every url that starts with a /). The second location block matches URLs that start with /api/.

Nginx picks the most "specific" location block, so even though a request for /api/users would match both location blocks, since the second one (/api/) is more specific, it will be the one that would be used to handle the request.

In the first location block (/):

root /pathToYourAngularApplication/dist sets the path where static content will be looked for as the location where your compiled Angular application files are (dist is the CLI's default output folder).

index index.html specifies which file should be served for URLs that end in /.

try_files $uri $uri/ /index.html can be read this way: check if there's a file that matches the normalized URL (e.g. http://www.yourwebsite.com/assets/image.jpg -> /assets/image.jpg), if that file does not exist try the normalized URL plus a / (e.g. http://www.yourwebsite.com/documents -> /documents/ -> /documents/index.html because of the index rule). If all of that fails serve the file /index.html.

Serving /index.html if no match is found is what enables us to use deep linking. For example a URL such as http://www.yourwebsite.com/documentswith no math in the file system will be served with the Angular application's index.html. Index.html will load all the necessary files for the Angular application to run, specifically the routing module. The routing module will then look at the url, and according to the routes defined in the angular app will decide which component to load.

Finally, the last location block. It instructs Nginx to forward the requests that start with /api/ to a webserver that is listening on port 5000 on localhost. That will be your ASP.NET Core's application.

One note about the Nginx's syntax for proxy_pass. It matters a lot if the URL for the application has a / at the end or not. The url in proxy_pass is treated differently if it has what is described in [Nginx's documentation as a "optional URI"](http://nginx.org/en/docs/http/ngx_http_proxy_module.html#proxy_pass "Nginx's documentation as a "optional URI"") (optional URI isn't a great name, since in the end a URL is a URI).

An example of a URL with an optional URI is: http://localhost:5000/optionalURI/. If the location's path is /api/, then a request for http://yourwebsite.com/api/users will be forwarded to your ASP.NET Core's application as http://localhost:5000/optionalURI/users.

That's why not adding the / at the end in proxy_pass is so important, because if you do (e.g.: proxy_pass http://localhost:5000/;) it falls into the "optional URI" category (it will be interpreted as an empty optional URI), and a request for http://yourwebsite.com/api/users will be seen in your ASP.NET Core's application as a request for http://localhost:5000/users.

If you don't add the / at the end (e.g.: proxy_pass http://localhost:5000;) then a request for http://yourwebsite.com/api/users will be seen in the ASP.NET Core application as a request for http://localhost:5000/api/userswhich is probably what you want.

If you need a more complete example that explains how you can make this work outside a development-time scenario (i.e. have your ASP.NET Core application auto start and remain online even if there's an exception) check out HTTPS in ASP.NET Core from Scratch where there's an example describing how you can use Supervisor to keep the ASP.NET application running even in the event of errors (by auto restarting it).

IIS

With IIS it becomes very cumbersome to have a configuration similar to what we can do with Nginx where both the Angular and ASP.NET Core applications are served on port 80.

To understand why it makes it easier if we understand the IIS concepts of Website and Application. When you create a website you define (among other settings) the port (e.g. 80) where it will be served from. A website can then have several applications "inside" it, all of which will share the website configuration (and therefore be served on the same port).

We could for example put our Angular application inside the "Default Web Site" and the ASP.NET Core one as an IIS Application under it, and call it for example "api".

If the "Default Web Site" responds at http://localhost, then the ASP.NET Core application could be at http://localhost/api. Which seems to be exactly what we want. However, the requests for http://localhost/api would be seen in ASP.NET Core without the api in the url.

As far as I know there's no way to change this behavior.

This means your ASP.NET Core application will behave differently when running inside IIS vs when executed directly (either in Visual Studio or with dotnet run).

To make matters worse an ASP.NET Core application needs to be published (dotnet publish) for it to work in IIS. It's not like a non-Core ASP.NET application where you can just point an IIS Application to the folder that contains the ASP.NET application's files .

So when using IIS the reasonable options are to either have ASP.NET Core serve the angular application as it was described in the first section of this article or have two separate Websites.

Lets walk-though the process of creating two separate websites. First a website for the Angular project and then for ASP.NET Core.

Angular in IIS

We'll be adding a Website named MyNgWebSite on port 80. That means that if you have a "Default Web Site", which in all likelihood you'll have, you need to stop it or change its bindings since the default for it is port 80.

But before we get there we need to create an application pool for our Angular application. Right click on Application Pools in IIS Manager:

The Application Pool for an Angular application does not require Managed Code (we only need to serve static files). We should choose "No Managed Code" in the .NET CLR Version:

We can now add a new IIS web site and set the new application pool we created as its application pool:

The physical path should be set to where your Angular project is being compiled to, usually this is the dist folder.

If you were to try to access http://localhost right now (and assuming that you stopped the "Default Web Site" or used a different port than 80) you would get a permissions error. That's because when you create an application pool a ["virtual" user is created](https://docs.microsoft.com/en-us/iis/manage/configuring-security/application-pool-identities ""virtual" user is created"). That user is a local user and must have permissions to access the folder that contains the files you are trying to serve.

That user's name is IIS AppPool\ApplicationPoolName, in this example it's IIS AppPool\ApplicationPoolForAngular.

Go to the folder that contains the compiled Angular project, right click on it and select properties, go to the security tab, click edit, then add and finally add the application pool user:

We should now be able to access your Angular application if you go to http://localhost.

We still need to do one more thing though. Enable deep-linking support.

If you have routes in your Angular application these won't work if someone tries to access them from "outside" the Angular app. What this means is that if navigating to http://localhost/documents is valid inside the Angular application and you send that url to someone else, when that someone else clicks the link they will be greeted with a 404 page from IIS.

That's because there is no documents folder nor index file inside it for IIS to serve. We need to tell IIS that it must serve the file index.html when someone tries to access a URL that does not exists.

We are going to use the same mechanism used for having a custom 404 page, but instead of a 404 page we'll serve the Angular application.

To achieve this we need to create a web.config file and put it in the src folder of the Angular application with this inside:

<?xml version="1.0" encoding="UTF-8"?>
<configuration>
    <system.webServer>
        <httpErrors errorMode="Custom" existingResponse="Replace">
            <remove statusCode="404"/>
            <error statusCode="404" responseMode="ExecuteURL" path="/index.html"/>
        </httpErrors>
    </system.webServer>
</configuration>

A very quick explanation of what's going on. We are using httpErrors with an errorMode="Custom" and existingResponse="Replace". This instructs IIS to replace the default error pages with the one we are about to specify.

remove statusCode="404" will remove any custom settings for 404 pages if they already exist.

error statusCode="404" responseMode="ExecuteURL" path="/index.html" will configure IIS to execute the /index.html url if there's a 404 error. This will effectively serve your Angular application and won't change the URL seen by the client.

Now we need to edit the .angular-cli.json file so that web.config gets copied to the output folder as an asset when the application is compiled. The assets section is under "app", here's an example:

{
"$schema": "./node_modules/@angular/cli/lib/config/schema.json",
"project": {
    "name": "your-app"
},
"apps": [
    {
    "root": "src",
    "outDir": "dist",
    "assets": [
        "assets",
        "favicon.ico",
        "web.config"
    ],
    "index": "index.html",
...

ASP.NET Core in IIS

The process for the configuring an ASP.NET Core application in IIS is similar, although we need to select a different port.

But before you start you need to make sure you have the ASP.NET Core Module for IIS installed. It might already be installed if you installed the .Net Core SDK, however the best way to make sure is to go to IIS Manager and see if it's in the modules' list:

If you don't have it you can find more information about it here and a direct link to download it here.

This module takes care of starting and keeping an ASP.NET Core application running.

Before we create the website in IIS we need the published version of the ASP.NET Core application. You can do that in the command line with dotnet publish or, in full Visual Studio, right click on the project and select Publish, then click publish to folder.

Create a new Website and point it to the ASP.NET Core project published folder, give it a different port number (for example 8080) and create an Application Pool for it.

An application pool for an ASP.NET Core application is also unmanaged (No Managed Code). Although this might seem odd, it's because IIS is actually just acting as a reverse proxy.

Before we're able to run the ASP.NET Project using IIS we need to changed the published folder's permissions so that the Application Pool user can access it. If you don't you'll get this moderately unhelpful error message:

HTTP Error 500.19 - Internal Server Error> HTTP Error 500.19 - Internal Server Error

If you look at the Config Error section you'll see "Cannot read configuration file due to insufficient permissions", which pretty much says it all.

Go to the published folder and add the application pool user to the list of users with permissions over that folder.

Your ASP.NET Core application should now be available on the port you've selected when you created the website in IIS. However, if you try to call it from the Angular application you'll get this error "Failed to load ... No 'Access-Control-Allow-Origin' header is present on the requested resource...". Here's an example of how that would look like in the developer tools console tab:

That's because even though both our our Angular and ASP.NET Core applications are on the same domain, they are in different ports, and that's enough to qualify the request as a Cross Origin Resource Sharing (CORS) request in all browsers except IE.

We need to enable CORS on the ASP.NET Core application. To do that we need to add the package Microsoft.AspNetCore.Cors and in ConfigureServices(IServiceCollection services... method in Startup.csadd services.AddCors():

public void ConfigureServices(IServiceCollection services)
{
    //...
    services.AddCors();
    //...
}

And in the Configure method we need to create a "policy" that says that we are expecting requests from http://localhost. We should do that before the MVC middleware:

public void Configure(IApplicationBuilder app, IHostingEnvironment env)
{
    //...
    app.UseCors(builder => builder.WithOrigins("http://localhost"));
    app.UseMvc();
}

You should be good to go. Your Angular and ASP.NET Core should both be working now.

Platform Agnostic Development Setup

Both Angular and ASP.NET Core applications provide ways to detect if they are running in development or production mode. That can be leveraged to create a setup that works both in Linux, Windows or Mac.

The easiest way to run an Angular application is to use run ng serve. That spins up a webpack development server that serves the Angular application on port 4200 by default.

This also has the advantage of having hot module replacing, which means you can see your changes to the Angular application as soon as you make then without even having to refresh the browser.

So ideally we want to run the Angular application this way.

For the ASP.NET Core application we want to run it without having to publish it which you would have to if it is being served by IIS.

This is the ideal development scenario, ng serve for Angular and dotnet run or running the ASP.NET Core from Visual Studio without having to publish it.

In this ideal scenario when developing we could have the Angular application running on port 4200 (through ng serve) and the ASP.NET Core application running on port 5000. When in production the Angular application would typically be served from port 80 and the ASP.NET Core application for port 8080 for example (or from a different server on port 80).

On the ASP.NET Core side of things we'd have to configure CORS to accept requests from port 4200 when in development and from port 80 when in production. In Startup.cs that would look like this:

public void ConfigureServices(IServiceCollection services)
{
    services.AddCors();
    //...
}

// This method gets called by the runtime. Use this method to configure the HTTP request pipeline.
public void Configure(IApplicationBuilder app, IHostingEnvironment env)
{
    //...
    if (env.IsDevelopment())
    {
        //...
        app.UseCors(builder => builder.WithOrigins("http://localhost:4200"));
    }else
    {
        app.UseCors(builder => builder.WithOrigins("http://localhost"));
    }

    app.UseMvc();
}

That takes care of the ASP.NET Core application.

For Angular we need to leverage the environemnt.ts and environemnt.prod.ts files. You can find then under a folder name environemnts under the src folder on an Angular project.

What you put on environment.ts will be available when you run in development mode (the default) and the values in environment.prod.ts will be used when in production. To compile the Angular project with the environment set to production use the --env=prod flag (e.g. ng build --env=prod).

Here's a simple example of how the environment files could be configured to support our hypothetical scenario, environment.ts:

export const environment = {
    production: false,
    apiBaseUrl: "http://localhost:4200/"
};

environment.prod.ts:

export const environment = {
    production: true,
    apiBaseUrl: "http://localhost/"
};

In your Angular services, to get to the environment values you just need to import the environment (always environment and not environment.prod):

import { Injectable } from '@angular/core';
import { HttpClient } from '@angular/common/http';
import { environment } from '../environments/environment';

@Injectable()
export class MyServiceService {

    constructor(private httpClient: HttpClient) { }

    getStuff(){
        return this.httpClient.get(`${environment.apiBaseUrl}/api/suff`);
    }
}

This approach would work even if you host on Nginx or IIS so probably the best option if you need/want to support having developers using different platforms of if you just want to compare performance between them.

“Visual Studio has added the full set of dependencies for ASP.NET MVC 5 to project” Can I reverse it?

By mistake I create a MVC 5 Controler instead Web Api 2 Controller in my .NET Web API Project and I received the following message:

By mistake I create a MVC 5 Controler instead Web Api 2 Controller in my .NET Web API Project and I received the following message:

Visual Studio has added the full set of dependencies for ASP.NET MVC 5 to project 'PROJECT_NAME'.
The Global.asax.cs file in the project may require additional changes to enable ASP.NET MVC.
  1. Add the following namespace references:
  2. using System.Web.Mvc; using System.Web.Routing; using System.Web.Optimization;
  3. If the code does not already define an Application_Start method, add the following method:
  4. protected void Application_Start() { }
  5. Add the following lines to the end of the Application_Start method:
  6. AreaRegistration.RegisterAllAreas(); RouteConfig.RegisterRoutes(RouteTable.Routes); FilterConfig.RegisterGlobalFilters(GlobalFilters.Filters); BundleConfig.RegisterBundles(BundleTable.Bundles);

Is there a simple way to reverse this? Do I have to delete unnecessary files and dependencies one by one manually? Will previously created Api controllers work without changes?

Any help or assistance would be greatly appreciated.
