HTML Canvas | Draw Text on HTML5 Canvas with JavaScript

How to Draw Text on HTML5 Canvas Using JavaScript

In today's video I'll show you how easy it is to draw text on the HTML5 canvas using JavaScript. We take a look at filling text, outlined text and centering text.

For your reference, check this out:

Draw text on an HTML canvas using JavaScript

Learn how to use the HTML5 canvas element to draw and style text

The canvas element (new to HTML5) is used to draw 2D graphics into an HTML document. Using Javascript you can draw a wide range of objects into an HTML canvas such as lines, text, images and shapes using several built in functions. Drawing text on an HTML5 canvas is a useful ability that you can use to add extra information to any data, images or shapes you have previously drawn on your canvas.

Adding a canvas to your HTML document and interacting with it in Javascript

To use Javascript to interact with an HTML canvas, you will first need to add the canvas element into your HTML document like so:

<canvas id="testCanvas" width="200" height="200">

In this example we give the canvas a fixed width and height to make it easier to keep track of co-ordinates. This canvas will be used throughout the tutorial.

Once the canvas element has been added to your HTML document, you must then acquire a context object from it by retrieving the canvas element and calling the getContext("2d") method.

var canvas = document.getElementById("testCanvas");
var context = canvas.getContext("2d");

With the context object you can call certain functions that will allow you to draw objects to the canvas.

Drawing text onto your HTML canvas using Javascript

Once the 2D context object has been acquired you can start drawing text onto your HTML canvas. Drawing text can either be done using the fillText() method or the strokeText() method of the context object.

Both the fillText() and strokeText() methods take 4 arguments (of which 3 are required):

  • text: A string value containing the text you wish to draw to the canvas
  • X: The X coordinate of where to start drawing the string to your canvas
  • Y: The X coordinate of where to start drawing the string to your canvas
  • max-width (optional) : The maximum pixel width of drawn text

The main difference between the two methods is that strokeText() will only draw the outlines for each letter whereas fillText() will also fill the inside of the text.

Drawing text using the fillText() method:

var canvas = document.getElementById( "testCanvas" );
var context = canvas.getContext( "2d" );
// change font and font-size for better visibilty
context.font = "30px Impact";
// draw "Test text" at X = 10 and Y = 30
context.fillText( "Test text", 10, 30 );

The text drawn to the canvas will look like this:


Drawing text to an HTML canvas using fillText()


Drawing text using the strokeText() method:

var canvas = document.getElementById( "testCanvas" );
var context = canvas.getContext( "2d" );
// change font and font-size for better visibilty
context.font = "30px Impact";
// draw "Test text" at X = 10 and Y = 30
context.strokeText( "Test text", 10, 30 );

The text drawn to the canvas will look like this:


Drawing text to an HTML canvas using strokeText()


Styling your text before drawing it onto your canvas

There are several properties of the 2D context object that you can use to change the appearance and style of the text you draw to your canvas.

Changing the font and font-size :

To change the font and font-size you can make use of the font property of the context object, simply provide a font-size in pixels and the name of the font you want to use such as Verdana.

var canvas = document.getElementById( "testCanvas" );
var context = canvas.getContext( "2d" );
// change font and font-size for better visibilty
context.font = "40px Verdana";
// draw "Test text" at X = 10 and Y = 30
context.fillText( "Test text", 10, 30 );

The text drawn to the canvas will look like this:


Changing font and font-size before drawing to canvas


Changing the font color: The fillStyle property of the context object can be used to change the color of the text (it can also add a gradient or pattern). To change the color using this property, simply give a valid HTML color as a value.

var canvas = document.getElementById( "testCanvas" );
var context = canvas.getContext( "2d" );
// change font and font-size for better visibilty
context.font = "30px Impact";
// change font color
context.fillStyle = "red";
// draw "Test text" at X = 10 and Y = 30
context.strokeText( "Test text", 10, 30 );

The text drawn to the canvas will look like this:


Changing font color before drawing to canvas


Changing the alignment of your text: By using the textAlign property of the context object, you can change the alignment of your text relative to the given X position given for fillText() or strokeText(). There are several values from which you can choose:

  • start: Drawn text will begin at the given X position
  • end: Drawn text will end at the given X position
  • left: The starting point for text will be to its left (essentially the same as start)
  • right: The ending point for text will be to its right (essentially the same as end)
  • center: Drawn text will center itself around the given X position

As an example, let's create a canvas with text using each of these values and the same X point.

var canvas = document.getElementById( "testCanvas" );
var context = canvas.getContext( "2d" );
// change font and font-size for better visibilty
context.font = "30px Arial";
// draw each string with same X value but different alignment
context.textAlign = "start";
context.fillText( "start", 80, 30 );
context.textAlign = "end";
context.fillText( "end", 80, 60 );
context.textAlign = "left";
context.fillText( "left", 80, 90 );
context.textAlign = "right";
context.fillText( "right", 80, 120 );
context.textAlign = "center";
context.fillText( "center", 80, 150 );

The text drawn to the canvas will look like this:


Changing text alignment before drawing to canvas
