A Self-hosted Archiving Service integrated with Internet Archive


Wayback is a tool that supports running as a command-line tool and docker container, purpose to snapshot webpage to time capsules.


  • Free and open-source
  • Cross-platform compatibility
  • Batch wayback URLs for faster archiving
  • Built-in CLI (wayback) for convenient use
  • Serve as a Tor Hidden Service or local web entry for added privacy and accessibility
  • Easier wayback to Internet Archive, archive.today, IPFS and Telegraph integration
  • Interactive with IRC, Matrix, Telegram bot, Discord bot, Mastodon, and Twitter as a daemon service for convenient use
  • Supports publishing wayback results to Telegram channel, Mastodon, and GitHub Issues for sharing
  • Supports storing archived files to disk for offline use
  • Download streaming media (requires FFmpeg) for convenient media archiving.


The simplest, cross-platform way is to download from GitHub Releases and place the executable file in your PATH.

From source:

go install github.com/wabarc/wayback/cmd/wayback@latest

From GitHub Releases:

curl -fsSL https://github.com/wabarc/wayback/raw/main/install.sh | sh

or via Bina:

curl -fsSL https://bina.egoist.dev/wabarc/wayback | sh

Using Snapcraft (on GNU/Linux)

sudo snap install wayback

Via APT:

curl -fsSL https://repo.wabarc.eu.org/apt/gpg.key | sudo gpg --dearmor -o /usr/share/keyrings/packages.wabarc.gpg
echo "deb [arch=amd64,arm64,armhf signed-by=/usr/share/keyrings/packages.wabarc.gpg] https://repo.wabarc.eu.org/apt/ /" | sudo tee /etc/apt/sources.list.d/wayback.list
sudo apt update
sudo apt install wayback

Via RPM:

sudo rpm --import https://repo.wabarc.eu.org/yum/gpg.key
sudo tee /etc/yum.repos.d/wayback.repo > /dev/null <<EOT
name=Wayback Archiver

sudo dnf install -y wayback

Via Homebrew:

brew tap wabarc/wayback
brew install wayback


Command line

$ wayback -h

A command-line tool and daemon service for archiving webpages.

  wayback [flags]

  wayback https://www.wikipedia.org
  wayback https://www.fsf.org https://www.eff.org
  wayback --ia https://www.fsf.org
  wayback --ia --is -d telegram -t your-telegram-bot-token
    WAYBACK_SECRET=YOUR-PINATA-SECRET wayback --ip https://www.fsf.org

      --chatid string      Telegram channel id
  -c, --config string      Configuration file path, defaults: ./wayback.conf, ~/wayback.conf, /etc/wayback.conf
  -d, --daemon strings     Run as daemon service, supported services are telegram, web, mastodon, twitter, discord, slack, irc
      --debug              Enable debug mode (default mode is false)
  -h, --help               help for wayback
      --ia                 Wayback webpages to Internet Archive
      --info               Show application information
      --ip                 Wayback webpages to IPFS
      --ipfs-host string   IPFS daemon host, do not require, unless enable ipfs (default "")
  -m, --ipfs-mode string   IPFS mode (default "pinner")
  -p, --ipfs-port uint     IPFS daemon port (default 5001)
      --is                 Wayback webpages to Archive Today
      --ph                 Wayback webpages to Telegraph
      --print              Show application configurations
  -t, --token string       Telegram Bot API Token
      --tor                Snapshot webpage via Tor anonymity network
      --tor-key string     The private key for Tor Hidden Service
  -v, --version            version for wayback


Wayback one or more url to Internet Archive and archive.today:

wayback https://www.wikipedia.org

wayback https://www.fsf.org https://www.eff.org

Wayback url to Internet Archive or archive.today or IPFS:

// Internet Archive
$ wayback --ia https://www.fsf.org

// archive.today
$ wayback --is https://www.fsf.org

$ wayback --ip https://www.fsf.org

For using IPFS, also can specify a pinning service:

$ export WAYBACK_SLOT=pinata
$ wayback --ip https://www.fsf.org

// or

$ WAYBACK_SECRET=YOUR-PINATA-SECRET wayback --ip https://www.fsf.org

More details about pinning service.

With telegram bot:

wayback --ia --is --ip -d telegram -t your-telegram-bot-token

Publish message to your Telegram channel at the same time:

wayback --ia --is --ip -d telegram -t your-telegram-bot-token --chatid your-telegram-channel-name

Also can run with debug mode:

wayback -d telegram -t YOUR-BOT-TOKEN --debug

Both serve on Telegram and Tor hidden service:

wayback -d telegram -t YOUT-BOT-TOKEN -d web

URLs from file:

wayback url.txt
cat url.txt | wayback

Configuration Parameters

By default, wayback looks for configuration options from this files, the following are parsed:

  • ./wayback.conf
  • ~/wayback.conf
  • /etc/wayback.conf

Use the -c / --config option to specify the build definition file to use.

You can also specify configuration options either via command flags or via environment variables, an overview of all options below.

FlagsEnvironment VariableDefaultDescription
--debugDEBUGfalseEnable debug mode, override LOG_LEVEL
-c, --config--Configuration file path, defaults: ./wayback.conf, ~/wayback.conf, /etc/wayback.conf
-LOG_TIMEtrueDisplay the date and time in log messages
-LOG_LEVELinfoLog level, supported level are debug, info, warn, error, fatal, defaults to info
-ENABLE_METRICSfalseEnable metrics collector
-WAYBACK_LISTEN_ADDR0.0.0.0:8964The listen address for the HTTP server
-CHROME_REMOTE_ADDR-Chrome/Chromium remote debugging address, for screenshot, format: host:port, wss://domain.tld
-WAYBACK_POOLING_SIZE3Number of worker pool for wayback at once
-WAYBACK_BOLT_PATH./wayback.dbFile path of bolt database
-WAYBACK_STORAGE_DIR-Directory to store binary file, e.g. PDF, html file
-WAYBACK_MAX_MEDIA_SIZE512MBMax size to limit download stream media
-WAYBACK_MEDIA_SITES-Extra media websites wish to be supported, separate with comma
-WAYBACK_TIMEOUT300Timeout for single wayback request, defaults to 300 second
-WAYBACK_MAX_RETRIES2Max retries for single wayback request, defaults to 2
-WAYBACK_USERAGENTWaybackArchiver/1.0User-Agent for a wayback request
-WAYBACK_FALLBACKoffUse Google cache as a fallback if the original webpage is unavailable
-WAYBACK_MEILI_ENDPOINT-Meilisearch API endpoint
-WAYBACK_MEILI_INDEXINGcapsulesMeilisearch indexing name
-WAYBACK_MEILI_APIKEY-Meilisearch admin API key
-d, --daemon--Run as daemon service, e.g. telegram, web, mastodon, twitter, discord
--iaWAYBACK_ENABLE_IAtrueWayback webpages to Internet Archive
--isWAYBACK_ENABLE_IStrueWayback webpages to Archive Today
--ipWAYBACK_ENABLE_IPfalseWayback webpages to IPFS
--phWAYBACK_ENABLE_PHfalseWayback webpages to Telegra.ph, required Chrome/Chromium
--ipfs-hostWAYBACK_IPFS_HOST127.0.0.1IPFS daemon service host
-p, --ipfs-portWAYBACK_IPFS_PORT5001IPFS daemon service port
-m, --ipfs-modeWAYBACK_IPFS_MODEpinnerIPFS mode for preserve webpage, e.g. daemon, pinner
-WAYBACK_IPFS_TARGETweb3storageThe IPFS pinning service is used to store files, supported pinners: infura, pinata, nftstorage, web3storage.
-WAYBACK_IPFS_APIKEY-Apikey of the IPFS pinning service
-WAYBACK_IPFS_SECRET-Secret of the IPFS pinning service
-WAYBACK_GITHUB_TOKEN-GitHub Personal Access Token, required the repo scope
-WAYBACK_GITHUB_OWNER-GitHub account name
-WAYBACK_GITHUB_REPO-GitHub repository to publish results
-WAYBACK_NOTION_TOKEN-Notion integration token
-WAYBACK_NOTION_DATABASE_ID-Notion database ID for archiving results
-t, --tokenWAYBACK_TELEGRAM_TOKEN-Telegram Bot API Token
--chatidWAYBACK_TELEGRAM_CHANNEL-The Telegram public/private channel id to publish archive result
-WAYBACK_TELEGRAM_HELPTEXT-The help text for Telegram command
-WAYBACK_MASTODON_SERVER-Domain of Mastodon instance
-WAYBACK_MASTODON_KEY-The client key of your Mastodon application
-WAYBACK_MASTODON_SECRET-The client secret of your Mastodon application
-WAYBACK_MASTODON_TOKEN-The access token of your Mastodon application
-WAYBACK_TWITTER_CONSUMER_KEY-The customer key of your Twitter application
-WAYBACK_TWITTER_CONSUMER_SECRET-The customer secret of your Twitter application
-WAYBACK_TWITTER_ACCESS_TOKEN-The access token of your Twitter application
-WAYBACK_TWITTER_ACCESS_SECRET-The access secret of your Twitter application
-WAYBACK_IRC_SERVERirc.libera.chat:6697IRC server, required TLS
-WAYBACK_MATRIX_HOMESERVERhttps://matrix.orgMatrix homeserver
-WAYBACK_MATRIX_USERID-Matrix unique user ID, format: @foo:example.com
-WAYBACK_MATRIX_ROOMID-Matrix internal room ID, format: !bar:example.com
-WAYBACK_DISCORD_BOT_TOKEN-Discord bot authorization token
-WAYBACK_DISCORD_CHANNEL-Discord channel ID, find channel ID
-WAYBACK_DISCORD_HELPTEXT-The help text for Discord command
-WAYBACK_SLACK_APP_TOKEN-App-Level Token of Slack app
-WAYBACK_SLACK_BOT_TOKEN-Bot User OAuth Token for Slack workspace, use User OAuth Token if requires create external link
-WAYBACK_SLACK_CHANNEL-Channel ID of Slack channel
-WAYBACK_SLACK_HELPTEXT-The help text for Slack slash command
-WAYBACK_NOSTR_RELAY_URLwss://nostr.developer.liNostr relay server url, multiple separated by comma
-WAYBACK_NOSTR_PRIVATE_KEY-The private key of a Nostr account
--torWAYBACK_USE_TORfalseSnapshot webpage via Tor anonymity network
--tor-keyWAYBACK_TOR_PRIVKEY-The private key for Tor Hidden Service
-WAYBACK_TOR_LOCAL_PORT8964Local port for Tor Hidden Service, also support for a reverse proxy. This is ignored if WAYBACK_LISTEN_ADDR is set.
-WAYBACK_TOR_REMOTE_PORTS80Remote ports for Tor Hidden Service, e.g. WAYBACK_TOR_REMOTE_PORTS=80,81
-WAYBACK_SLOT-Pinning service for IPFS mode of pinner, see ipfs-pinner
-WAYBACK_APIKEY-API key for pinning service
-WAYBACK_SECRET-API secret for pinning service

If both of the definition file and environment variables are specified, they are all will be read and apply, and preferred from the environment variable for the same item.

Prints the resulting options of the targets with --print, in a Go struct with type, without running the wayback.


docker pull wabarc/wayback
docker run -d wabarc/wayback wayback -d telegram -t YOUR-BOT-TOKEN # without telegram channel
docker run -d wabarc/wayback wayback -d telegram -t YOUR-BOT-TOKEN -c YOUR-CHANNEL-USERNAME # with telegram channel

1-Click Deploy

Deploy Deploy to Render



For a comprehensive guide, please refer to the complete documentation.


We encourage all contributions to this repository! Open an issue! Or open a Pull Request!

If you're interested in contributing to wayback itself, read our contributing guide to get started.

Note: All interaction here should conform to the Code of Conduct.

Supported Golang version: See .github/workflows/testing.yml

Download Details:

Author: Wabarc
Source Code: https://github.com/wabarc/wayback
License: GPL-3.0 license

#heroku #screenshot #twitter #telegram #matrix #go #golang

A Self-hosted Archiving Service integrated with Internet Archive
Royce  Reinger

Royce Reinger


Fast Python Collaborative Filtering for Implicit Feedback Datasets


Fast Python Collaborative Filtering for Implicit Datasets.

This project provides fast Python implementations of several different popular recommendation algorithms for implicit feedback datasets:

Alternating Least Squares as described in the papers Collaborative Filtering for Implicit Feedback Datasets and Applications of the Conjugate Gradient Method for Implicit Feedback Collaborative Filtering.

Bayesian Personalized Ranking.

Logistic Matrix Factorization

Item-Item Nearest Neighbour models using Cosine, TFIDF or BM25 as a distance metric.

All models have multi-threaded training routines, using Cython and OpenMP to fit the models in parallel among all available CPU cores. In addition, the ALS and BPR models both have custom CUDA kernels - enabling fitting on compatible GPU's. Approximate nearest neighbours libraries such as Annoy, NMSLIB and Faiss can also be used by Implicit to speed up making recommendations.


Implicit can be installed from pypi with:

pip install implicit

Installing with pip will use prebuilt binary wheels on x86_64 Linux, Windows and OSX. These wheels include GPU support on Linux.

Implicit can also be installed with conda:

# CPU only package
conda install -c conda-forge implicit

# CPU+GPU package
conda install -c conda-forge implicit implicit-proc=*=gpu

Basic Usage

import implicit

# initialize a model
model = implicit.als.AlternatingLeastSquares(factors=50)

# train the model on a sparse matrix of user/item/confidence weights

# recommend items for a user
recommendations = model.recommend(userid, user_item_data[userid])

# find related items
related = model.similar_items(itemid)

The examples folder has a program showing how to use this to compute similar artists on the last.fm dataset.

For more information see the documentation.

Articles about Implicit

These blog posts describe the algorithms that power this library:

There are also several other articles about using Implicit to build recommendation systems:


This library requires SciPy version 0.16 or later and Python version 3.6 or later.

GPU Support requires at least version 11 of the NVidia CUDA Toolkit.

This library is tested with Python 3.7, 3.8, 3.9, 3.10 and 3.11 on Ubuntu, OSX and Windows.


Simple benchmarks comparing the ALS fitting time versus Spark can be found here.

Optimal Configuration

I'd recommend configuring SciPy to use Intel's MKL matrix libraries. One easy way of doing this is by installing the Anaconda Python distribution.

For systems using OpenBLAS, I highly recommend setting 'export OPENBLAS_NUM_THREADS=1'. This disables its internal multithreading ability, which leads to substantial speedups for this package. Likewise for Intel MKL, setting 'export MKL_NUM_THREADS=1' should also be set.

Download Details:

Author: Benfred
Source Code: https://github.com/benfred/implicit
License: MIT license

#machinelearning #filtering #matrix #factors

Fast Python Collaborative Filtering for Implicit Feedback Datasets
Royce  Reinger

Royce Reinger


A Python Implementation Of LightFM, A Hybrid Recommendation Algorithm


LightFM is a Python implementation of a number of popular recommendation algorithms for both implicit and explicit feedback, including efficient implementation of BPR and WARP ranking losses. It's easy to use, fast (via multithreaded model estimation), and produces high quality results.

It also makes it possible to incorporate both item and user metadata into the traditional matrix factorization algorithms. It represents each user and item as the sum of the latent representations of their features, thus allowing recommendations to generalise to new items (via item features) and to new users (via user features).


Install from pip:

pip install lightfm

or Conda:

conda install -c conda-forge lightfm


Fitting an implicit feedback model on the MovieLens 100k dataset is very easy:

from lightfm import LightFM
from lightfm.datasets import fetch_movielens
from lightfm.evaluation import precision_at_k

# Load the MovieLens 100k dataset. Only five
# star ratings are treated as positive.
data = fetch_movielens(min_rating=5.0)

# Instantiate and train the model
model = LightFM(loss='warp')
model.fit(data['train'], epochs=30, num_threads=2)

# Evaluate the trained model
test_precision = precision_at_k(model, data['test'], k=5).mean()

Articles and tutorials on using LightFM

  1. Learning to Rank Sketchfab Models with LightFM
  2. Metadata Embeddings for User and Item Cold-start Recommendations
  3. Recommendation Systems - Learn Python for Data Science
  4. Using LightFM to Recommend Projects to Consultants

How to cite

Please cite LightFM if it helps your research. You can use the following BibTeX entry:

  author    = {Maciej Kula},
  editor    = {Toine Bogers and
               Marijn Koolen},
  title     = {Metadata Embeddings for User and Item Cold-start Recommendations},
  booktitle = {Proceedings of the 2nd Workshop on New Trends on Content-Based Recommender
               Systems co-located with 9th {ACM} Conference on Recommender Systems
               (RecSys 2015), Vienna, Austria, September 16-20, 2015.},
  series    = {{CEUR} Workshop Proceedings},
  volume    = {1448},
  pages     = {14--21},
  publisher = {CEUR-WS.org},
  year      = {2015},
  url       = {http://ceur-ws.org/Vol-1448/paper4.pdf},


Pull requests are welcome. To install for development:

  1. Clone the repository: git clone git@github.com:lyst/lightfm.git
  2. Setup a virtual environment: cd lightfm && python3 -m venv venv && source ./venv/bin/activate
  3. Install it for development using pip: pip install -e . && pip install -r test-requirements.txt
  4. You can run tests by running ./venv/bin/py.test tests.
  5. LightFM uses black to enforce code formatting and flake8 for linting, see lint-requirements.txt.
  6. [Optional]: You can install pre-commit to locally enfore formatting and linting. Install with:
pip install pre-commit
pre-commit install

When making changes to the .pyx extension files, you'll need to run python setup.py cythonize in order to produce the extension .c files before running pip install -e ..

Build status
LinuxCircle CI
OSX (OpenMP disabled)Travis CI
Windows (OpenMP disabled)Appveyor

For more details, see the Documentation.

Need help? Contact me via email, Twitter, or Gitter.

Download Details:

Author: lyst
Source Code: https://github.com/lyst/lightfm
License: Apache-2.0 license

#machinelearning #python #matrix

A Python Implementation Of LightFM, A Hybrid Recommendation Algorithm

Matrix ChatGPT Bot: Talk to ChatGPT Via Your Favourite Matrix Client!

Matrix ChatGPT Bot

Talk to ChatGPT via your favourite Matrix client!

Screenshot of Element iOS app showing conversation with bot

This is an unofficial Matrix bot that uses https://github.com/transitive-bullshit/chatgpt-api to access the unofficial ChatGPT API.

It is worth reading the authentication instructions for the unofficial ChatGPT API.

Your user-agent and IP address must match from the real browser window you're logged in with to the one you're using for ChatGPTAPI. This means that you currently can't log in with your laptop and then run the bot on a server or proxy somewhere.

Cloudflare will still sometimes ask you to complete a CAPTCHA, so you may need to keep an eye on it and manually resolve the CAPTCHA.

You should not be using this ChatGPT account while the bot is using it, because that browser window may refresh one of your tokens and invalidate the bot's session.

If your OpenAI account uses Google Auth, you shouldn't encounter any of the more complicated Recaptchas — and can avoid using paid third-party CAPTCHA solving providers. To use Google auth, make sure your OpenAI account is using Google and then set IS_GOOGLE_LOGIN to true.


  • Create an unencrypted room
  • Add the bot
  • Start chatting away!


  • Shows typing indicator as ChatGPT is thinking!
  • Doesn't yet support encryption
    • Two lines of code can be uncommented to enable it, however "unable to decrypt" messages appear
    • If you have time to look into fixing this PRs very welcome :)

Setting up the account

  • Create a new Matrix account on Matrix.org (or your favourite server)
  • Go to the settings and get the access token
  • Add the details to your environment vars. One way of doing this is adding this to a file called .env:
# https://matrix.org if your account is on matrix.org.


# With the @ and :DOMAIN, ie @SOMETHING:DOMAIN


Come and join #matrix-chatgpt-bot:matrix.org with your favourite Matrix chat client! If you've never set up a Matrix client before I'd recomend following the prompts at https://element.io/get-started to download and sign into Element.

Local development setup

  • Run yarn
  • Run yarn build

Running in "prod"

  • yarn
  • yarn build
  • yarn start

Running with Docker

docker build . -t matrix-chatgpt-bot
docker run --cap-add=SYS_ADMIN -it matrix-chatgpt-bot

Note: Without -it flags in the command above you won't be able to stop the container using Ctrl-C

Download Details:

Author: jakecoppinger
Source Code: https://github.com/jakecoppinger/matrix-chatgpt-bot

License: AGPL-3.0 license


Matrix ChatGPT Bot: Talk to ChatGPT Via Your Favourite Matrix Client!

HSL.jl: Julia interface to The HSL Mathematical Software Library


These are the beginnings of a set of interfaces to HSL packages for sparse linear algebra.

Certain HSL packages are freely available to all, others are freely available to academics only. Please refer to the website above for licensing information. In all cases, users are responsible for obtaining HSL packages.


julia> ]
pkg> add HSL

At this point, make sure that there isn't a stray METIS library on your library path. You especially want to make sure that METIS 5 is not accessible because the HSL library currently interfaced only supports METIS 4. If you have such library accessible, it is important to remove it from the library path, at least temporarily. For example, if you are on OSX and are using Homebrew, you can hide METIS 5 with brew unlink metis. After the install procedure is complete, it is fine to link metis again with brew link metis.

Set the environment variable HSL_ARCHIVES_PATH to specify where the source archives tar.gz and zip are stored. You can use the zip archives as long as unzip is installed on your system. If archives are stored in different folders, you can also set the environment variable <ALGNAME>_PATH, e.g. HSL_MA57_PATH or MC21_PATH. The HSL Julia module will take care of compilation. Once the source archives have been placed in the locations indicated by the environment variables, run

julia> ]
pkg> build HSL
pkg> test HSL

Note that a C and Fortran compilers are required. Should it be necessary, you can set the compilers to use by setting the environment variables

  • HSL_FC: the Fortran 90/95 compiler (default: gfortran)
  • HSL_F77: the Fortran 77 compiler (default: the same as FC)
  • HSL_CC: the C compiler (default: gcc).

Supported Packages


Supported versions:

  • 2.6.0
  • 2.7.0

HSL_MA97: an OpenMP-based direct solver for symmetric linear systems. Example:

using MatrixMarket
using HSL

K = MatrixMarket.mmread("K.mtx")  # only the lower triangle
rhs = readdlm("rhs.rhs")

LBL = Ma97(K)
x = ma97_solve(LBL, rhs)  # or x = LBL \ rhs

Rectangular Systems

There is a convenience interface to solve rectangular systems that complements the sparse QR factorization in Julia.

When A is m-by-n with m < n and has full row rank,

(x, y) = ma97_solve(A, b)

solves for the minimum-norm solution, i.e., x such that Ax = b and x + Aᵀ y = 0. The call

(x, y) = ma97_min_norm(A, b)

is also defined, and is equivalent to the above.

When m > n and has full column rank,

(r, x) = ma97_solve(A, b)

solves for the least-squares solution, i.e., x such that r = b - Ax satisfies Aᵀ r = 0. The call

(r, x) = ma97_least_squares(A, b)

is also defined, and is equivalent to the above.


HSL_MA57 version 5.2.0: a sparse, multifrontal solver for symmetric linear systems. Example:

using MatrixMarket
using HSL

K = MatrixMarket.mmread("examples/K_0.mtx")  # only the lower triangle
rhs = readdlm("examples/rhs_0.rhs")
rhss = hcat(rhs, rhs)

## factorize and solve
LDL = Ma57(K)
x = ma57_solve(LDL, rhs)  # or x = LBL \ rhs
norm(K*x - rhs)
xx = ma57_solve(LDL, rhss)  # or x = LBL \ rhss

Rectangular Systems

There is a convenience interface to solve rectangular systems that complements the sparse QR factorization in Julia.

When A is m-by-n with m < n and has full row rank,

(x, y) = ma57_solve(A, b)

solves for the minimum-norm solution, i.e., x such that Ax = b and x + Aᵀ y = 0. The call

(x, y) = ma57_min_norm(A, b)

is also defined, and is equivalent to the above.

When m > n and has full column rank,

(r, x) = ma57_solve(A, b)

solves for the least-squares solution, i.e., x such that r = b - Ax satisfies Aᵀ r = 0. The call

(r, x) = ma57_least_squares(A, b)

is also defined, and is equivalent to the above. Example:

using MatrixMarket
using HSL

K = MatrixMarket.mmread("examples/K_0.mtx")  # only the lower triangle
rhs = readdlm("examples/rhs_0.rhs")

## solve min norm
K_mn = K[1:200,:]
x_mn, y_mn = ma57_min_norm(K_mn, rhs[1:200]) # == ma57_solve(K_mn, rhs[1:200])

## solve least squares
K_ls = K[:,1:200]
r_ls, x_ls = ma57_least_squares(K_ls, rhs)   # == ma57_solve(K_ls, rhs)


  •  Convenient constructor for rectangular matrices to enable \
  •  Convenient access to control parameters, especially pivot tolerance
  •  Real single precision arithmetic (e59c501)
  •  Complex single precision arithmetic (e59c501)
  •  Complex double precision arithmetic (e59c501)

Download Details:

Author: JuliaSmoothOptimizers
Source Code: https://github.com/JuliaSmoothOptimizers/HSL.jl
License: View license

#julia #algebra #matrix

HSL.jl: Julia interface to The HSL Mathematical Software Library

Positive-definite "approximations" to Matrices



PositiveFactorizations is a package for computing a positive definite matrix decomposition (factorization) from an arbitrary symmetric input. The motivating application is optimization (Newton or quasi-Newton methods), in which the canonical search direction -H\g (H being the Hessian and g the gradient) may not be a descent direction if H is not positive definite. This package provides an efficient approach to computing -Htilde\g, where Htilde is equal to H if H is positive definite, and otherwise is a positive definite matrix that is "spiritually like H."

The approach favored here is different from the well-known Gill-Murray-Wright approach of computing the Cholesky factorization of H+E, where E is a minimal correction needed to make H+E positive-definite (sometimes known as GMW81). See the discussion starting here for justification; briefly, the idea of a small correction conflates large negative eigenvalues with numerical roundoff error, which (when stated that way) seems like a puzzling choice. In contrast, this package provides methods that are largely equivalent to taking the absolute value of the diagonals D in an LDLT factorization, and setting any "tiny" diagonals (those consistent with roundoff error) to 1. For a diagonal matrix with some entries negative, this results in approximately twice the correction used in GMW81.


Given a symmetric matrix H, compute a positive factorization F like this:

F = cholesky(Positive, H, [pivot=Val{false}])

Pivoting (turned on with Val{true}) can make the correction smaller and increase accuracy, but is not necessary for existence or stability.

For a little more information, call ldlt instead:

F, d = ldlt(Positive, H, [pivot=Val{false}])

F will be the same as for cholesky, but this also returns d, a vector of Int8 with values +1, 0, or -1 indicating the sign of the diagonal as encountered during processing (so in order of rows/columns if not using pivoting, in order of pivot if using pivoting). This output can be useful for determining whether the original matrix was already positive (semi)definite.

Note that cholesky/ldlt can be used with any matrix, even those which lack a conventional LDLT factorization. For example, the matrix [0 1; 1 0] is factored as L = [1 0; 0 1] (the identity matrix), with all entries of d being 0. Symmetry is assumed but not checked; only the lower-triangle of the input is used.

cholesky is recommended because it is very efficient. A slower alternative is to use eigen:

F = eigen(Positive, H)

which may be easier to reason about from the standpoint of fundamental linear algebra.

Download Details:

Author: Timholy
Source Code: https://github.com/timholy/PositiveFactorizations.jl
License: View license

#julia #matrix

Positive-definite "approximations" to Matrices

HemirealFactorizations.jl: Matrix Factorizations Over The Hemireals



Cholesky factorizations over the hemireals can be computed for arbitrary symmetric matrices, including singular and indefinite matrices. For singular matrices, the behavior is reminiscent of the singular value decomposition, but the performance is much better.


After creating a symmetric matrix A, compute its Cholesky factorization over the hemireal numbers like this:

F = cholfact(PureHemi, A)

Then you can use F to solve equations, e.g.,

x = F\b

If A is singular, this should be the least-squares solution.

Supported operations

You can compute F*F' or say rank(F). You can also convert F into matrix form with convert(Matrix, F).

To support all operations, you need to be running at least a version of julia-0.5-dev that is current with master as of 2015-12-11. However, many operations also work on julia-0.4.


F = cholfact(PureHemi, A, δ; blocksize=default)


  • δ is the tolerance on the diagonal values of A during factorization; any with magnitudes smaller than δ will be treated as if they are 0.
  • blocksize controls the performance of the factorization algorithm.

Download Details:

Author: Timholy
Source Code: https://github.com/timholy/HemirealFactorizations.jl
License: View license

#julia #matrix

HemirealFactorizations.jl: Matrix Factorizations Over The Hemireals
Rupert  Beatty

Rupert Beatty


Surge: A Swift Library That Uses The Accelerate Framework


Surge is a Swift library that uses the Accelerate framework to provide high-performance functions for matrix math, digital signal processing, and image manipulation.

Accelerate exposes SIMD instructions available in modern CPUs to significantly improve performance of certain calculations. Because of its relative obscurity and inconvenient APIs, Accelerate is not commonly used by developers, which is a shame, since many applications could benefit from these performance optimizations.

Surge aims to bring Accelerate to the mainstream, making it as easy (and nearly as fast, in most cases) to perform computation over a set of numbers as for a single member.

Though, keep in mind: Accelerate is not a silver bullet. Under certain conditions, such as performing simple calculations over a small data set, Accelerate can be out-performed by conventional algorithms. Always benchmark to determine the performance characteristics of each potential approach.

Curious about the name Surge? (And Jounce?) Back in the mid 90's, Apple, IBM, and Motorola teamed up to create AltiVec (a.k.a the Velocity Engine), which provided a SIMD instruction set for the PowerPC architecture. When Apple made the switch to Intel CPUs, AltiVec was ported to the x86 architecture and rechristened Accelerate. The derivative of Accelerate (and second derivative of Velocity) is known as either jerk, jolt, surge, or lurch; if you take the derivative of surge, you get the jounce --- hence the name of this library and its parent organization.


The infrastructure and best practices for distributing Swift libraries are currently in flux during this beta period of Swift & Xcode. In the meantime, you can add Surge as a git submodule, drag the Surge.xcodeproj file into your Xcode project, and add Surge.framework as a dependency for your target.

Surge uses Swift 5. This means that your code has to be written in Swift 5 due to current binary compatibility limitations.

Swift Package Manager

To use Swift Package Manager add Surge to your Package.swift file:

let package = Package(
    name: "myproject",
    dependencies: [
        .package(url: "https://github.com/Jounce/Surge.git", .upToNextMajor(from: "2.3.2")),
    targets: [
            name: "myproject",
            dependencies: ["Surge"]),

Then run swift build.


To use CocoaPods add Surge to your Podfile:

source 'https://github.com/CocoaPods/Specs.git'
platform :ios, '10.0'

target '<Your Target Name>' do
    pod 'Surge', '~> 2.3.2'

Then run pod install.


To use Carthage add Surge to your Cartfile:

github "Jounce/Surge" ~> 2.3.2

Then run carthage update and use the framework in Carthage/Build/<platform>.


Computing Sum of [Double]

import Surge

let n = [1.0, 2.0, 3.0, 4.0, 5.0]
let sum = Surge.sum(n) // 15.0

Computing Product of Two [Double]s

import Surge

let a = [1.0, 3.0, 5.0, 7.0]
let b = [2.0, 4.0, 6.0, 8.0]

let product = Surge.elmul(a, b) // [2.0, 12.0, 30.0, 56.0]

General Arithmetic Operations


Addition functions & operators

ArgumentsFunctionOperatorIn-Place Operator
(Array, Array)add.+ (infix).+= (infix)
(Array, Scalar)add+ (infix)+= (infix)
(Matrix, Matrix)add+ (infix)+= (infix)
(Matrix, Scalar)n/an/an/a
(Vector, Vector)add+ (infix)+= (infix)
(Vector, Scalar)add+ (infix)+= (infix)


Subtraction functions & operators

ArgumentsFunctionOperatorIn-Place Operator
(Array, Array)sub.- (infix).-= (infix)
(Array, Scalar)sub- (infix)-= (infix)
(Matrix, Matrix)sub- (infix)-= (infix)
(Matrix, Scalar)n/an/an/a
(Vector, Vector)sub- (infix)-= (infix)
(Vector, Scalar)sub- (infix)-= (infix)


Multiplication functions & operators

ArgumentsFunctionOperatorIn-Place Operator
(Array, Array)mul.* (infix).*= (infix)
(Array, Scalar)mul* (infix)*= (infix)
(Matrix, Matrix)mul* (infix)n/a
(Matrix, Vector)mul* (infix)n/a
(Matrix, Scalar)mul* (infix)n/a
(Vector, Matrix)mul* (infix)n/a
(Vector, Scalar)mul* (infix)*= (infix)
(Scalar, Array)mul* (infix)n/a
(Scalar, Matrix)mul* (infix)n/a
(Scalar, Vector)mul* (infix)n/a

Element-wise multiplication

Element-wise multiplication functions & operators

ArgumentsFunctionOperatorIn-Place Operator
(Matrix, Matrix)elmuln/an/a
(Vector, Vector)elmul.* (infix).*= (infix)


Division functions & operators

ArgumentsFunctionOperatorIn-Place Operator
(Array, Array)div./ (infix)./= (infix)
(Array, Scalar)div/ (infix)/= (infix)
(Matrix, Matrix)div/ (infix)n/a
(Matrix, Scalar)n/a/ (infix)n/a
(Vector, Scalar)div/ (infix)/= (infix)

Element-wise Division

Element-wise multiplication functions & operators

ArgumentsFunctionOperatorIn-Place Operator
(Vector, Vector)eldiv./ (infix)./= (infix)


Modulo functions & operators

ArgumentsFunctionOperatorIn-Place Operator
(Array, Array)mod.% (infix)n/a
(Array, Scalar)mod% (infix)n/a


Remainder functions & operators

ArgumentsFunctionOperatorIn-Place Operator
(Array, Array)remaindern/an/a
(Array, Scalar)remaindern/an/a

Square Root

Square root functions & operators

ArgumentsFunctionOperatorIn-Place Operator


Sum functions & operator

ArgumentsFunctionOperatorIn-Place Operator

Dot Product

Dot product functions & operators

ArgumentsFunctionOperatorIn-Place Operator
(Array, Array)dot (infix)n/a
(Vector, Vector)dot (infix)n/a


Distance functions & operators

ArgumentsFunctionOperatorIn-Place Operator
(Array, Array)distn/an/a
(Vector, Vector)distn/an/a

Squared Distance

Squared distance functions & operators

ArgumentsFunctionOperatorIn-Place Operator
(Array, Array)distSqn/an/a
(Vector, Vector)distSqn/an/a


Power functions & operators

ArgumentsFunctionOperatorIn-Place Operator
(Array, Array)pow.** (infix).**= (infix)
(Array, Scalar)pow** (infix)**= (infix)
(Matrix, Scalar)pown/an/a
(Vector, Vector)pown/an/a

(Serial exponentiation: a ** b ** c == a ** (b ** c))


Exponential functions & operators

ArgumentsFunctionOperatorIn-Place Operator

Trigonometric Operations

Trigonometric functions & operators


(Array)sincosSine & Cosine

Arc Sine/Cosine/Tangent

(Array)asinArc Sine
(Array)acosArc Cosine
(Array)atanArc Tangent

Hyperbolic Sine/Cosine/Tangent

(Array)sinhHyperbolic Sine
(Array)coshHyperbolic Cosine
(Array)tanhHyperbolic Tangent

Inverse Hyperbolic Sine/Cosine/Tangent

(Array)asinhInverse Hyperbolic Sine
(Array)acoshInverse Hyperbolic Cosine
(Array)atanhInverse Hyperbolic Tangent

Radians ↔︎ Degrees

(Array)rad2degRadians to Degrees
(Array)deg2radDegrees to Radians

Exponential Function

Exponential functions & operators

(Array)expBase-e Exponential Function
(Array)exp2Base-2 Exponential Function


Exponential functions & operators

(Array)logBase-e Logarithm
(Array)log2Base-2 Logarithm
(Array)log10Base-10 Logarithm
(Array)logbBase-b Logarithm

Statistical Operations

Statistical functions & operators


(Array)asumAbsolute Summation




(Array)meamgMean of Magnitudes
(Array)measqMean of Squares
(Array)stdStandard Deviation

Auxiliary Functions

Auxiliary functions & operators

Rounding Functions

(Array)truncInteger truncation

Absolute value

ArgumentsFunctionIn-Place FunctionOperatorIn-Place Operator

Signum function

ArgumentsFunctionIn-Place FunctionOperatorIn-Place Operator

Multiplicative inverse

ArgumentsFunctionIn-Place FunctionOperatorIn-Place Operator

Matrix-specific Operations

Matrix-specific functions & operators

Matrix Inversion

ArgumentsFunctionIn-Place FunctionOperatorIn-Place Operator

Matrix Transposition

ArgumentsFunctionIn-Place FunctionOperatorIn-Place Operator
(Matrix)transposen/a (postfix)n/a

Matrix Determinant

ArgumentsFunctionIn-Place FunctionOperatorIn-Place Operator

Eigen Decomposition

ArgumentsFunctionIn-Place FunctionOperatorIn-Place Operator

DSP-specific Operations

Fast fourier transform functions & operators

Fast Fourier Transform

ArgumentsFunctionIn-Place FunctionOperatorIn-Place Operator


ArgumentsFunctionIn-Place FunctionOperatorIn-Place Operator
(Array, Array)convn/an/an/a


ArgumentsFunctionIn-Place FunctionOperatorIn-Place Operator
(Array, Array)xcorrn/an/an/a

Download Details:

Author: Jounce
Source Code: https://github.com/Jounce/Surge
License: MIT license

#swift #math #matrix #arithmetic

Surge: A Swift Library That Uses The Accelerate Framework

Fast Matrix Multiplication and Division for toeplitz Matrices in Julia


Fast matrix multiplication and division for Toeplitz, Hankel and circulant matrices in Julia


Multiplication of large matrices and sqrt, inv, LinearAlgebra.eigvals, LinearAlgebra.ldiv!, and LinearAlgebra.pinv for circulant matrices are computed with FFTs. To be able to use these methods, you have to install and load a package that implements the AbstractFFTs.jl interface such as FFTW.jl:

using FFTW

If you perform multiple calculations with FFTs, it can be more efficient to initialize the required arrays and plan the FFT only once. You can precompute the FFT factorization with LinearAlgebra.factorize and then use the factorization for the FFT-based computations.

Supported matrices


A Toeplitz matrix has constant diagonals. It can be constructed using


where vc are the entries in the first column and vr are the entries in the first row, where vc[1] must equal vr[1]. For example.

Toeplitz(1:3, [1.,4.,5.])

is a sparse representation of the matrix

[ 1.0  4.0  5.0
  2.0  1.0  4.0
  3.0  2.0  1.0 ]


A symmetric Toeplitz matrix is a symmetric matrix with constant diagonals. It can be constructed with


where vc are the entries of the first column. For example,

SymmetricToeplitz([1.0, 2.0, 3.0])

is a sparse representation of the matrix

[ 1.0  2.0  3.0
  2.0  1.0  2.0
  3.0  2.0  1.0 ]


A triangular Toeplitz matrix can be constructed using


where uplo is either :L or :U and ve are the rows or columns, respectively. For example,


is a sparse representation of the matrix

[ 1.0  0.0  0.0
  2.0  1.0  0.0
  3.0  2.0  1.0 ]


A Hankel matrix has constant anti-diagonals. It can be constructed using


where vc are the entries in the first column and vr are the entries in the last row, where vc[end] must equal vr[1]. For example.

Hankel([1.,2.,3.], 3:5)

is a sparse representation of the matrix

[  1.0  2.0  3.0
   2.0  3.0  4.0
   3.0  4.0  5.0 ]


A circulant matrix is a special case of a Toeplitz matrix with periodic end conditions. It can be constructed using


where vc is a vector with the entries for the first column. For example:

Circulant([1.0, 2.0, 3.0])

is a sparse representation of the matrix

[  1.0  3.0  2.0
   2.0  1.0  3.0
   3.0  2.0  1.0 ]

Download Details:

Author: JuliaMatrices
Source Code: https://github.com/JuliaMatrices/ToeplitzMatrices.jl
License: MIT license

#julia #matrix

Fast Matrix Multiplication and Division for toeplitz Matrices in Julia

SparseVectorMatrix.jl: SparseMatrices As A Vector Of SparseVectors


This packages provides an alternative implementation of SparseMatrices that maintains a vector of SparseVectors. Such an implementation is best used when all matrix operations require access to just one column each.


using SparseVectorMatrix

# Random Generation
a = svmrand(100, 100, 0.1)

# Getindex
a[:, 1]                      # Returns an entire column quickly
a[1, :]                      # Returns an entire row, but slowly.

# SetIndex
a[:, 1] = 1:100              # Assign an entire column quickly.
a[1, :] = 1:100              # Assign an entire row, by slowly.

b = svmrand(100, 100, 0.1)
hcat(a, b)                   # Concatenates horizontally. Very fast.
vcat(a, b)                   # Concatenates vertically. Not as fast.

arr = [svmrand(100, 100, 0.1) for i in 1:4]
hvcat((2,2), arr..)          # Grid Concatenation. Quite fast.

What's supported?

  • svmrand (Similar to sprand)
  • getindex
  • setindex
  • hcat
  • vcat
  • hvcat
  • A bunch of other basic methods like nnz, size, full, etc.



Download Details:

Author: Pranavtbhat
Source Code: https://github.com/pranavtbhat/SparseVectorMatrix.jl
License: View license

#julia #vector #matrix

SparseVectorMatrix.jl: SparseMatrices As A Vector Of SparseVectors

WoodburyMatrices: Support for The Woodbury Matrix Identity For Julia


This package provides support for the Woodbury matrix identity for the Julia programming language. This is a generalization of the Sherman-Morrison formula. Note that the Woodbury matrix identity is notorious for floating-point roundoff errors, so be prepared for a certain amount of inaccuracy in the result.


Woodbury Matrices

using WoodburyMatrices
W = Woodbury(A, U, C, V)

creates a Woodbury matrix from the A, U, C, and V matrices representing A + U*C*V. These matrices can be dense or sparse (or generally any type of AbstractMatrix), with the caveat that inv(inv(C) + V*(A\U)) will be calculated explicitly and hence needs to be representable with the available resources. (In many applications, this is a fairly small matrix.)

Here are some of the things you can do with a Woodbury matrix:

  • Matrix(W) converts to its dense representation.
  • W\b solves the equation W*x = b for x.
  • W*x computes the product.
  • det(W) computes the determinant of W.
  • α*W and W1 + W2.

It's worth emphasizing that A can be supplied as a factorization, which makes W\b and det(W) more efficient.

SymWoodbury Matrices

using WoodburyMatrices
W = SymWoodbury(A, B, D)

creates a SymWoodbury matrix, a symmetric version of a Woodbury matrix representing A + B*D*B'. In addition to the features above, SymWoodbury also supports "squaring" W*W.

Download Details:

Author: Timholy
Source Code: https://github.com/timholy/WoodburyMatrices.jl
License: View license

#julia #matrix

WoodburyMatrices: Support for The Woodbury Matrix Identity For Julia

Julia Package for Matrix Pseudospectra and Related Quantities



Pseudospectra is a Julia package for computing pseudospectra of non-symmetric matrices, and plotting them along with eigenvalues ("spectral portraits"). Some related computations and plots are also provided.

Mathematical background

Whereas the spectrum of a matrix is the set of its eigenvalues, a pseudospectrum is the set of complex numbers "close" to the spectrum in some practical sense.

More precisely, the ϵ-pseudospectrum of a matrix A, σ_ϵ(A), is the set of complex numbers λ such that

  • λ is an eigenvalue of some matrix A+E, where the norm of the perturbation ‖E‖ < ϵ, or
  • the resolvent norm ‖(A-λI)^(-1)‖ > 1/ϵ,

(the definitions are equivalent). This sense of "closeness" is trivial for Hermitian matrices, but interesting for others. Specifically, this package is currently limited to the unweighted 2-norm.

Among other things, pseudospectra:

  • elucidate transient behavior hidden to eigen-analysis, and
  • indicate the utility of eigenvalues extracted via iterative methods like eigs (from the Arpack package).

See the Pseudospectra gateway for details, references, and more.

Aside: the simple interface

To study a moderate-sized matrix with minimal user effort, follow this example:

using Plots, Pseudospectra, LinearAlgebra
B=diagm(1 => fill(2im,n-1), 2 => fill(-1,n-2), 3 => fill(2,n-3), -2 => fill(-4,n-2), -3 => fill(-2im, n-3))

example figure

The figure shows a section of the complex plane with eigenvalues and contours of log10(ϵ).

Package context

Pseudospectra.jl (along with a QML-based GUI, in the forthcoming PseudospectraView package) is essentially a translation of the acclaimed MATLAB-based EigTool (homepage here), code now hosted on GitHub.

No endorsement or promotion of Pseudospectra.jl by the authors of EigTool is implied.

Specific documentation for Pseudospectra is a work in progress; a draft is available here. See the examples and tests for more.

Note on packaging/requirements

The plotting interface is somewhat schizophrenic. Drivers are included for Plots.jl and/or PyPlot.jl (i.e., PyPlot is a useful back end for Plots as used here; other Plots backends have been partially tested). Experimental support for Makie.jl is also available.

Although this package is designed with an eye to plotting results, the computational routines are usable without a plotting package, To avoid forcing potential users to install a particular one, none are specified in the formal package requirements. The setgs function can import one conditionally.

Some functions used for examples require other packages. They should give a useful complaint if invoked without that support.


This package should be included in the General registry by the time anyone else sees this paragraph, so the normal Pkg commands to add Pseudospectra should suffice.

In the interim, install by adding this repository explicitly with the package manager.


Basic usage

Minimal use of the REPL interface is as follows:

using Plots
using Pseudospectra
A = your_matrix_generating_function()
ps_data = new_matrix(A)
# modify, e.g., for higher resolution
options = Dict{Symbol,Any}(:npts => 100)

This should show a contour plot of log10(ϵ) in the vicinity of the spectrum, which is the standard display of a spectral portrait. More elaborate capabilities are exhibited (as always) in the examples and test folders.


This software is provided by the copyright holders and contributors "as is" and any express or implied warranties, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose are disclaimed. In no event shall the copyright holder or contributors be liable for any direct, indirect, incidental, special, exemplary, or consequential damages (including, but not limited to, procurement of substitute goods or services; loss of use, data, or profits; or business interruption) however caused and on any theory of liability, whether in contract, strict liability, or tort (including negligence or otherwise) arising in any way out of the use of this software, even if advised of the possibility of such damage.

Note on licensing

Most of the package is under a BSD license, in accordance with derivation from EigTool. See individual source files for exceptions.

Download Details:

Author: RalphAS
Source Code: https://github.com/RalphAS/Pseudospectra.jl
License: View license

#julia #matrix

Julia Package for Matrix Pseudospectra and Related Quantities

MatrixDepot.jl: An Extensible Test Matrix Collection for Julia

Matrix Depot

An extensible test matrix collection for Julia.

Give access to a wealth of sample and test matrices and accompanying data. A set of matrices is generated locally (with arguments controlling the special case). Another set is loaded from one of the publicly accessible matrix collections SuiteSparse Matrix Collection (formerly University of Florida Matrix Collection) and the Matrix Market Collection, the latter being obsolescent.

Access is like

using MatrixDepot
?MatrixDepot                    # display package help info
A = matrixdepot("hilb", 10)     # locally generated hilbert matrix dimensions (10,10)
A = matrixdepot("HB/1138_bus")  # named matrix of the SuiteSparse Collection


md = mdopen("*/bfly")   # named matrix with some extra data
A = md.A
co = md.coord
tx = md("Gname_10.txt")
md.<tab><tab>           # overview of the "fields" of md returning like
                        # A m n dnz nnz coord Gname_10.txt  G_10 Gcoord_10

or also

mdinfo("gravity")                 # text info about the selected matrix
md = mdopen("gravity", 10, false) # localy generated example with rhs and solution
A = md.A
b = md.b
x = md.x


NOTE: If you use Windows, you need to install MinGW/MSYS or Cygwin in order to use the SuiteSparse sparse and MatrixMarket matrix collection interface.

To install the release version, type

julia> Pkg.add("MatrixDepot")



Matrix Names

Every Matrix type has a unique name, which is a string of one of the forms:

  1. "name" - used for matrices, which are generated locally.
  2. "dir/name" - for all matrices of the SuiteSparse collection.
  3. "dir/subdir/name" - for all matrices of the MatrixMarket collection.

The names are similar to relative path names, separated by a slash character. The components of the name must not contain any of the characters "/*[]".


a set of matrices may be assigned to predefined or user-defined groups. The group names are represented as Julia symbols in the form :symmetric. The group names are therefore restricted to valid Julia identifiers, that means start with a letter and contain only letters, digits, and '_'.

Numeric Identifiers

Every matrix has a numeric identifier, which is unique for its area:

builtin(id) - one of the built-in matrix generators - currently id ∈ 1:59.

user(id) - a user-defined matrix generator - starting with 1.

sp(id) - one of the SuiteSparse collection. The integer ids are the 'official' ident numbers assigned by the collection. Currently id ∈ 1:3000.

mm(id) - one of the MatrixMarket collection. Here id follows the ordering of the index file of the collection.

Sets of Matrix Names - Pattern

For some functions it makes sense to have lists of matrix names to operate on, for example to select a set matrices with certain properties. These sets are descibed by 'Patterns', which are applied to matrix names and also to other matrix properties.

The following pattern types are supported:

"name" - a string matching exactly a matrix name

"shell-pattern" - a string with shell wildcards '?', '*', "[...]" included.

r"egular expression" - a regular expression to match the matrix name.

:group - one of the defined group names; match all matrices in the group

qualified numeric identifiers - examples builtin(10), sp(1:5, 7), mm(1), sp(:)

predicate_function - the name of a predefined or user-defined boolean function of the internal data type MatrixData. Example: issymmetric.

abstract vector of sub-patterns - OR - any of the sub-pattern matches

tuple of sub-patterns - AND - all of the sub-patterns match

~pattern - negation of a pattern the \neg - operator ~ may be applied to all patterns

To express OR and AND, the binary operators | and & and ( / ) are preferred.


"gravity" | "HB/*" & ~(ishermitian & iscomplex) & ~sp(20:30)

The set of all known matrices can be expressed as empty tuple (). In a shell- pattern the double ** matches also slash characters, in contrast to the single *.

A convenient form of a predicate-generator is


where expression is a valid Julia boolean expression, which may access all properties of MatrixData as literal variable names.


@pred(author == "J. Brown") is translated to: d -> :author in propertynames(d) && d.author == "J. Brown"

@pred(500_000 <= n * m < 1_000_000) restricts the size of matched matrices.

@pred(10^4 <= n <= 2*10^4 && n == m && nnz / n > 10 ) in average more than 10 entries per row

There is s set of predefined predicate functions including: (issymmetric, ishermitian, isgeneral, isskew, isreal, iscomplex, isboolean, islocal, isremote, isloaded, isunloaded, isbuiltin, isuser, issparse)

Special predicate generators keyword(word...) and hasdata(symbol...) allow to support keyword-search and check for the existence of meta-data. For example: hasdata(:x) & ~keyword("fluid" provides solution (x) and does not mention "fluid".

Accessing Data

Listing matrices with certain properties

mdinfo()           # overview
listgroups()       # list all defined group names
mdlist(pattern)    # array of matrix names according to pattern
listdata(pattern)  # array of `MatrixData`objects according to pattern
listnames(pattern) # MD-formatted listing of all names according to pattern
listdir("*//*") # MD-formatted -  group over part before `//` - count matching

Information about matrices

mdinfo()        # overview over database
mdinfo(pattern) # individual documentation about matrix(es) matching pattern

Generating a matrix

A = matrixdepot("kahan", 10) generates a matrix using one of the buit-in generators

md = mdopen("kahan", 10) returns a handle md; matrix can be obtained by A = md.A

Accessing Meta-Data

In general the first form is preferrable, if only the pure matrix is required. For remote collections no arguments are used.

The second form allows to access all types of 'meta-data', which may be available for some local or remote matrices.


md = mdopen("spikes", 5, false); A = md.A; b = md.b; x = md.x

md = mdopen("Rommes/bips07_1998"); A = md.A; v = md.iv; title = md.data.title; nodenames = md("nodename.txt")

The last example shows, how to access textual meta-data, when the name contains Julia non-word characters. Also if the metadata-name is stored in a varaible, the last form has to be used.

meta = metasymbols(md)[2]; sec_matrix = md(meta)

The function metasymbols returns a list of all symbols denoting metadata provided by md. Wether expressed as symbols or strings does not matter.

The system function propertynames(md) returns all data of md. That includes size information and metadata.

propertynames(md.data) gives an overview about all attributes of the md.data::MatrixData, which can for example be used in the @pred definitions.

Backoffice Jobs

The remote data are originally stored at the remote web-site of one of the matrix collections. Before they are presented to the user, they are downloaded to local disk storage, which serves as a permanent cache.

By default, the data directory is a scratchspace managed by Scratch.jl, but can be changed by setting the MATRIXDEPOT_DATA environment variable.

The data directory can be queried by

julia> MatrixDepot.data_dir()

The occasional user needs not bother about downloads, because that is done in the background if matrix files are missing on the local disk.

The same is true for the data required by mdinfo(pattern). Actually these are stored in separate files if the full matrix files (which may be huge) are not yet loaded.

Bulk Downloads

Load Header Data

A download job to transmit a subset of remote matrix files may be started to load header data for all files. Header data always include the matrix type according to the matrix-market-format and the size values m row-number, n = columns-number, and dnz number of stored data of the main sparse matrix.

MatrixDepot.loadinfo(pattern) where pattern defines the subset.

That is possible for the SuiteSparse collection and the NIST MatrixMarket collection. The patterns can always refer to matrix names and id numbers. In the case of SuiteSparse collection, also the metadata "date", "kind", "m", "n", "nnz" are available and can be used, before individual matrix data have been loaded. They are contained in a data file obtained from the remote site. For MatrixMarket collection, patterns are restricted to names and id numbers.

In general it would be possible by loadinfo("**") to load all header data. That would last maybe an hour and generate some traffic for the remote sites. Nevertheless it is not necessary to do so, if you don't need the header data for the following task.

Load Complete Data Files

MatrixDepot.load(pattern) loads all data files for the patterns. Patterns can only refer to attributes, which are already available. In the case of SuiteSparse that includes the size info "date", "kind", "m", "n", and "nnz" and all additional attributes loaded in the previous step, which include "author", "title", "notes", and keywords. In the case of MatrixMarket you can only refer to "m", "n", and "dnz", if previously loaded with the header data.

Please do not: MatrixDepot.load("**"). That would require some day(s) to finish and include some really big data files (~100GB), which could be more than your disks can hold.

Make a reasonable selection, before you start a bulk download. Local and already loaded matrices are skipped automatically.


MatrixDepot.load(sp(:) & @pred(nnz < 100_000)) to download only problems with given number of stored entries in the main matrix.

Sample Session

To see an overview of the matrices in the collection, type

julia> using MatrixDepot

julia> mdinfo()
  Currently loaded Matrices

–––––––––– ––––––––––– ––––––––––– ––––––––––– –––––––––– –––––––––––– ––––––––––– ––––––––––– ––––––––––––– ––––––––––––
1 baart    7 circul    13 fiedler  19 gravity  25 invhilb 31 magic     37 parter   43 randcorr 49 shaw       55 ursell
2 binomial 8 clement   14 forsythe 20 grcar    26 invol   32 minij     38 pascal   44 rando    50 smallworld 56 vand
3 blur     9 companion 15 foxgood  21 hadamard 27 kahan   33 moler     39 pei      45 randsvd  51 spikes     57 wathen
4 cauchy   10 deriv2   16 frank    22 hankel   28 kms     34 neumann   40 phillips 46 rohess   52 toeplitz   58 wilkinson
5 chebspec 11 dingdong 17 gilbert  23 heat     29 lehmer  35 oscillate 41 poisson  47 rosser   53 tridiag    59 wing
6 chow     12 erdrey   18 golub    24 hilb     30 lotkin  36 parallax  42 prolate  48 sampling 54 triw

1 randsym

–––––– ––––––– ––––– –––– ––––– ––––– ––––––– ––––––– –––––– –––––– ––––––– –––––– –––––––––
all    builtin local user eigen graph illcond inverse posdef random regprob sparse symmetric

Suite Sparse of
–––––––––––– ––––
2770         2833

MatrixMarket of
–––––––––––– –––
488          498

We can generate a 4-by-4 Hilbert matrix by typing

julia> matrixdepot("hilb", 4)
4x4 Array{Float64,2}:
 1.0       0.5       0.333333  0.25
 0.5       0.333333  0.25      0.2
 0.333333  0.25      0.2       0.166667
 0.25      0.2       0.166667  0.142857

We can type the matrix name to get documentation about the matrix.

julia> mdinfo("hilb")
     Hilbert matrix

  The Hilbert matrix has (i,j) element 1/(i+j-1). It is notorious for being
  ill conditioned. It is symmetric positive definite and totally positive.

  Input options:

    •  [type,] dim: the dimension of the matrix;

    •  [type,] row_dim, col_dim: the row and column dimensions.

  Groups: ["inverse", "ill-cond", "symmetric", "pos-def"]


  M. D. Choi, Tricks or treats with the Hilbert matrix, Amer. Math. Monthly,
  90 (1983), pp. 301-312.

  N. J. Higham, Accuracy and Stability of Numerical Algorithms, second
  edition, Society for Industrial and Applied Mathematics, Philadelphia, PA,
  USA, 2002; sec. 28.1.

We can also specify the data type for locally generated matrices.

julia> matrixdepot("hilb", Float16, 5, 3)
5x3 Array{Float16,2}:
 1.0      0.5      0.33325
 0.5      0.33325  0.25
 0.33325  0.25     0.19995
 0.25     0.19995  0.16663
 0.19995  0.16663  0.14282

julia> matrixdepot("hilb", Rational{Int}, 4)
4x4 Array{Rational{T<:Integer},2}:
 1//1  1//2  1//3  1//4
 1//2  1//3  1//4  1//5
 1//3  1//4  1//5  1//6
 1//4  1//5  1//6  1//7

Matrices can be accessed by a variety of patterns and composed patterns. Integer numbers i refer to the ident numbers in sp(i), mm(i), builtin(i), user(i). Here sp ... denote the supported matrix collections SuiteSparse (formerly UFL), Matrix Market, built-in, user-defined.

julia> mdlist(sp(1))    # here sp(1) is the ident number of the SuiteSparse collection

julia> listnames(builtin(1, 5:10))    # the internal numbering of the builtin-functions
––––––– –––––––– –––– –––––– ––––––– ––––––––– ––––––
baart   chebspec chow circul clement companion deriv2

julia> mdlist(builtin(1:4, 6, 10:15) | user(1:10) )
12-element Array{String,1}:

While the listnames command renders the output as markdown table, the internal mdlist produces an array of valid matrix names.

We can type a group name to see all the matrices in that group. Group names are always written as symbols to distinguish them form matrix names and pattern, which are always strings.

julia> listnames(:symmetric)
–––––––– –––––––– ––––––– –––––– ––––––––– –––––––– ––––––– –––––––––
cauchy   dingdong hilb    lehmer oscillate poisson  randsym wilkinson
circul   fiedler  invhilb minij  pascal    prolate  tridiag
clement  hankel   kms     moler  pei       randcorr wathen

Extend Matrix Depot

It is possible to extend the builtin local problems with user defined generators and groups. We can add new matrix generators and define new groups of matrices.


Weijian Zhang and Nicholas J. Higham, "Matrix Depot: An Extensible Test Matrix Collection for Julia", PeerJ Comput. Sci., 2:e58 (2016), [pdf]

Nicholas J. Higham, "Algorithm 694, A Collection of Test Matrices in MATLAB", ACM Trans. Math. Software, vol. 17. (1991), pp 289-305 [pdf] [doi]

T.A. Davis and Y. Hu, "The University of Florida Sparse Matrix Collection", ACM Transaction on Mathematical Software, vol. 38, Issue 1, (2011), pp 1:1-1:25 [pdf]

R.F. Boisvert, R. Pozo, K. A. Remington, R. F. Barrett, & J. Dongarra, " Matrix Market: a web resource for test matrix collections", Quality of Numerical Software (1996) (pp. 125-137). [pdf]

Per Christian Hansen, "Test Matrices for Regularization Methods", SIAM Journal on Scientific Computing, vol. 16, 2, (1995) pp.506-512. [pdf] [doi]

Release Notes

Download Details:

Author: https://github.com/JuliaMatrices/MatrixDepot.jl
Source Code: https://github.com/JuliaMatrices/MatrixDepot.jl
License: View license

#julia #test #matrix

MatrixDepot.jl: An Extensible Test Matrix Collection for Julia

LowRankApprox.jl: Fast Low-rank Matrix Approximation in Julia


This Julia package provides fast low-rank approximation algorithms for BLAS/LAPACK-compatible matrices based on some of the latest technology in adaptive randomized matrix sketching. Currently implemented algorithms include:

  • sketch methods:
    • random Gaussian
    • random subset
    • subsampled random Fourier transform
    • sparse random Gaussian
  • partial range finder
  • partial factorizations:
    • QR decomposition
    • interpolative decomposition
    • singular value decomposition
    • Hermitian eigendecomposition
    • CUR decomposition
  • spectral norm estimation

By "partial", we mean essentially that these algorithms are early-terminating, i.e., they are not simply post-truncated versions of their standard counterparts. There is also support for "matrix-free" linear operators described only through their action on vectors. All methods accept a number of options specifying, e.g., the rank, estimated absolute precision, and estimated relative precision of approximation.

Our implementation borrows heavily from the perspective espoused by N. Halko, P.G. Martinsson, J.A. Tropp. Finding structure with randomness: Probabilistic algorithms for constructing approximate matrix decompositions. SIAM Rev. 53 (2): 217-288, 2011., except that we choose the interpolative decomposition (ID) as our basic form of approximation instead of matrix range projection. The reason is that the latter requires expensive matrix-matrix multiplication to contract to the relevant subspace, while the former can sometimes be computed much faster, depending on the accelerated sketching strategy employed.

This package has been developed with performance in mind, and early tests have shown large speedups over similar codes written in MATLAB and Python (and even some in Fortran and C). For example, computing an ID of a Hilbert matrix of order 1024 to relative precision ~1e-15 takes:

  • ~0.02 s using LowRankApprox in Julia
  • ~0.07 s using SciPy in Python (calling a Fortran backend; see PyMatrixID)
  • ~0.3 s in MATLAB

This difference can be attributed in part to both algorithmic improvements as well as to some low-level optimizations.


To install LowRankApprox, simply type:


at the Julia prompt. The package can then be imported as usual with using or import.

Getting Started

To illustrate the usage of this package, let's consider the computation of a partial QR decomposition of a Hilbert matrix, which is well known to have low rank. First, we load LowRankApprox via:

using LowRankApprox

Then we construct a Hilbert matrix with:

n = 1024
A = matrixlib(:hilb, n, n)

A partial QR decomposition can then be computed using:

F = pqrfact(A)

This returns a PartialQR factorization with variables Q, R, and p denoting the unitary, trapezoidal, and permutation factors, respectively, constituting the decomposition. Alternatively, these can be extracted directly with:

Q, R, p = pqr(A)

but the factorized form is often more convenient as it also implements various arithmetic operations. For example, the commands:

x = rand(n)
y = F *x
z = F'*x

automatically invoke specialized multiplication routines to rapidly compute y and z using the low-rank structure of F.

The rank of the factorization can be retrieved by F[:k], which in this example usually gives 26 or 27. The reason for this variability is that the default interface uses randomized Gaussian sketching for acceleration. Likewise, the actual approximation error is also random but can be efficiently and robustly estimated:

aerr = snormdiff(A, F)
rerr = aerr / snorm(A)

This computes the absolute and relative errors in the spectral norm using power iteration. Here, the relative error achieved should be on the order of machine epsilon. (You may see a warning about exceeding the iteration limit, but this is harmless in this case.)

The default interface requests ~1e-15 estimated relative precision. To request, say, only 1e-12 relative precision, use:

F = pqrfact(A, rtol=1e-12)

which returns a factorization of rank ~22. We can also directly control the rank instead with, e.g.:

F = pqrfact(A, rank=20)

Using both together as in:

F = pqrfact(A, rank=20, rtol=1e-12)

sets two separate termination criteria: one on reaching rank 20 and the other on achieving estimated relative precision 1e-12---with the computation completing upon either of these being fulfilled. Many other options are available as well. All keyword arguments can also be encapsulated into an LRAOptions type for convenience. For example, we can equivalently write the above as:

opts = LRAOptions(rank=20, rtol=1e-12)
F = pqrfact(A, opts)

For further details, see the Options section.

All aforementioned considerations also apply when the input is a linear operator, i.e., when the matrix is described not by its entries but by its action on vectors. To demonstrate, we can convert A to type LinearOperator as follows:

L = LinearOperator(A)

which inherits and stores methods for applying the matrix and its adjoint. (This command actually recognizes A as Hermitian and forms L as a HermitianLinearOperator.) A partial QR decomposition can then be computed with:

F = pqrfact(L)

just as in the previous case. Of course, there is no real benefit to doing so in this particular example; the advantage comes when considering complicated matrix products that can be represented implicitly as a single LinearOperator. For instance, A*A can be represented as L*L without ever forming the resultant matrix explicitly, and we can even encapsulate entire factorizations as linear operators to exploit fast multiplication:

L = LinearOperator(F)

Linear operators can be scaled, added, and composed together using the usual syntax. All methods in LowRankApprox transparently support both matrices and linear operators.

Low-Rank Factorizations

We now detail the various low-rank approximations implemented, which all nominally return compact Factorization types storing the matrix factors in structured form. All such factorizations provide optimized multiplication routines. Furthermore, the rank of any factorization F can be queried with F[:k] and the matrix approximant defined by F can be reconstructed as Matrix(F). For concreteness of exposition, assume in the following that A has size m by n with factorization rank F[:k] = k. Note that certain matrix identities below should be interpreted only as equalities up to the approximation precision.

QR Decomposition

A partial QR decomposition is a factorization A[:,p] = Q*R, where Q is m by k with orthonormal columns, R is k by n and upper trapezoidal, and p is a permutation vector. Such a decomposition can be computed with:

F = pqrfact(A, args...)

or more explicitly with:

Q, R, p = pqr(A, args...)

The former returns a PartialQR factorization with access methods:

  • F[:Q]: Q factor as type Matrix
  • F[:R]: R factor as type UpperTrapezoidal
  • F[:p]: p permutation as type Vector
  • F[:P]: p permutation as type ColumnPermutation

Both F[:R] and F[:P] are represented as structured matrices, complete with their own arithmetic operations, and together permit the alternative approximation formula A*F[:P] = F[:Q]*F[:R]. The factorization form additionally supports least squares solution by left-division.

We can also compute a partial QR decomposition of A' (that is, pivoting on rows instead of columns) without necessarily constructing the matrix transpose explicitly by writing:

F = pqrfact(:c, A, args...)

and similarly with pqr. The default interface is equivalent to, e.g.:

F = pqrfact(:n, A, args...)

for "no transpose". It is also possible to generate only a subset of the partial QR factors for further efficiency; see Options.

The above methods do not modify the input matrix A and may make a copy of the data in order to enforce this (whether this is actually necessary depends on the type of input and the sketch method used). Potentially more efficient versions that reserve the right to overwrite A are available as pqrfact! and pqr!, respectively.

Interpolative Decomposition (ID)

The ID is based on the approximation A[:,rd] = A[:,sk]*T, where sk is a set of k "skeleton" columns, rd is a set of n - k "redundant" columns, and T is a k by n - k interpolation matrix. It follows that A[:,p] = C*V, where p = [sk; rd], C = A[:,sk], and V = [Matrix(I,k,k) T]. An ID can be computed by:

V = idfact(A, args...)


sk, rd, T = id(A, args...)

Here, V is of type IDPackedV and defines the V factor above but can also implicitly represent the entire ID via:

  • V[:sk]: sk columns as type Vector
  • V[:rd]: rd columns as type Vector
  • V[:p]: p permutation as type Vector
  • V[:P]: p permutation as type ColumnPermutation
  • V[:T]: T factor as type Matrix

To actually produce the ID itself, use:

F = ID(A, V)


F = ID(A, sk, rd, T)

which returns an ID factorization that can be directly compared with A. This factorization has access methods:

  • F[:C]: C factor as type Matrix
  • F[:V]: V factor as type IDPackedV

in addition to those defined for IDPackedV.

As with the partial QR decomposition, an ID can be computed for A' instead (that is, finding skeleton rows as opposed to columns) in the same way, e.g.:

V = idfact(:c, A, args...)

The default interface is equivalent to passing :n as the first argument. Moreover, modifying versions of the above are available as idfact! and id!.

Singular Value Decomposition (SVD)

A partial SVD is a factorization A = U*S*V', where U and V are m by k and n by k, respectively, both with orthonormal columns, and S is k by k and diagonal with nonincreasing nonnegative real entries. It can be computed with:

F = psvdfact(A, args...)


U, S, V = psvd(A, args...)

The factorization is of type PartialSVD and has access methods:

  • F[:U]: U factor as type Matrix
  • F[:S]: S factor as type Vector
  • F[:V]: V factor as type Matrix
  • F[:Vt]: V' factor as type Matrix

Note that the underlying SVD routine forms V' as output, so F[:Vt] is easier to extract than F[:V]. Least squares solution is also supported using left-division. Furthermore, if just the singular values are required, then we can use:

S = psvdvals(A, args...)

Hermitian Eigendecomposition

A partial Hermitian eigendecomposition of an n by n Hermitian matrix A is a factorization A = U*S*U', where U is n by k with orthonormal columns and S is k by k and diagonal with nondecreasing real entries. It is very similar to a partial Hermitian SVD and can be computed by:

F = pheigfact(A, args...)


vals, vecs = pheig(A, args...)

where we have followed the Julia convention of letting vals denote the eigenvalues comprising S and vecs denote the eigenvector matrix U. The factorization is of type PartialHermitianEigen and has access methods:

  • F[:values]: vals as type Vector
  • F[:vectors]: vecs as type Matrix

It also supports least squares solution by left-division. If only the eigenvalues are desired, use instead:

vals = pheigvals(A, args...)

CUR Decomposition

A CUR decomposition is a factorization A = C*U*R, where C = A[:,cols] and R = A[rows,:] consist of k columns and rows, respectively, from A and U = inv(A[rows,cols]). The basis rows and columns can be computed with:

U = curfact(A, args...)


rows, cols = cur(A, args...)

The former is of type CURPackedU (or HermitianCURPackedU if A is Hermitian or SymmetricCURPackedU if symmetric) and has access methods:

  • U[:cols]: cols columns as type Vector
  • U[:rows]: rows rows as type Vector

To produce the corresponding CUR decomposition, use:

F = CUR(A, U)


F = CUR(A, rows, cols)

which returns a CUR factorization (or HermitianCUR if A is Hermitian or SymmetricCUR if symmetric), with access methods:

  • F[:C]: C factor as type Matrix
  • F[:U]: U factor as type Factorization
  • F[:R]: R factor as type Matrix

in addition to those defined for CURPackedU. If F is of type HermitianCUR, then F[:R] = F[:C]', while if F has type SymmetricCUR, then F[:R] = transpose(F[:C]). Note that because of conditioning issues, U is not stored explicitly but rather in factored form, nominally as type SVD but practically as PartialHermitianEigen if U has type HermitianCURPackedU or PartialSVD otherwise (for convenient arithmetic operations).

Modifying versions of the above are available as curfact! and cur!.

Sketch Methods

Matrix sketching is a core component of this package and its proper use is critical for high performance. For an m by n matrix A, a sketch of order k takes the form B = S*A, where S is a k by m sampling matrix (see below). Sketches can similarly be constructed for sampling from the right or for multiplying against A'. The idea is that B contains a compressed representation of A up to rank approximately k, which can then be efficiently processed to recover information about A.

The default sketch method defines S as a Gaussian random matrix. Other sketch methods can be specified using the keyword sketch. For example, setting:

opts = LRAOptions(sketch=:srft, args...)

or equivalently:

opts = LRAOptions(args...)
opts.sketch = :srft

then passing to, e.g.:

V = idfact(A, opts)

computes an ID with sketching via a subsampled random Fourier transform (SRFT). This can also be done more directly with:

V = idfact(A, sketch=:srft)

A list of supported sketch methods is given below. To disable sketching altogether, use:

opts.sketch = :none

In addition to its integration with low-rank factorization methods, sketches can also be generated independently by:

B = sketch(A, order, args...)

Other interfaces include:

  • B = sketch(:left, :n, A, order, args...) to compute B = S*A
  • B = sketch(:left, :c, A, order, args...) to compute B = S*A'
  • B = sketch(:right, :n, A, order, args...) to compute B = A*S
  • B = sketch(:right, :c, A, order, args...) to compute B = A'*S

We also provide adaptive routines to automatically sketch with increasing orders until a specified error tolerance is met, as detected by early termination of an unaccelerated partial QR decomposition. This adaptive sketching forms the basis for essentially all higher-level algorithms in LowRankApprox and can be called with:

F = sketchfact(A, args...)

Like sketch, a more detailed interface is also available as:

F = sketchfact(side, trans, A, args...)

Random Gaussian

The canonical sampling matrix is a Gaussian random matrix with entries drawn independently from the standard normal distribution (or with real and imaginary parts each drawn independently if A is complex). To use this sketch method, set:

opts.sketch = :randn

There is also support for power iteration to improve accuracy when the spectral gap (up to rank k) is small. This computes, e.g., B = S*(A*A')^p*A (or simply B = S*A^(p + 1) if A is Hermitian) instead of just B = S*A, with all intermediate matrix products orthogonalized for stability.

For generic A, Gaussian sketching has complexity O(k*m*n). In principle, this can make it the most expensive stage of computing a fast low-rank approximation (though in practice it is still very effective). There is a somewhat serious effort to develop sketch methods with lower computational cost, which is addressed in part by the following techniques.

Random Subset

Perhaps the simplest matrix sketch is just a random subset of rows or columns, with complexity O(k*m) or O(k*n) as appropriate. This can be specified with:

opts.sketch = :sub

The linear growth in matrix dimension is obviously attractive, but note that this method can fail if the matrix is not sufficiently "regular", e.g., if it contains a few large isolated entries. Random subselection is only implemented for type AbstractMatrix.

Subsampled Random Fourier Transform (SRFT)

An alternative approach based on imposing structure in the sampling matrix is the SRFT, which has the form S = R*F*D (if applying from the left), where R is a random permutation matrix of size k by m, F is the discrete Fourier transform (DFT) of order m, and D is a random diagonal unitary scaling. Due to the DFT structure, this can be applied in only O(m*n*log(k)) operations (but beware that the constant is quite high). To use this method, set:

opts.sketch = :srft

For real A, our SRFT implementation uses only real arithmetic by separately computing real and imaginary parts as in a standard real-to-real DFT. Only AbstractMatrix types are supported.

Sparse Random Gaussian

As a modification of Gaussian sketching, we provide also a "sparse" random Gaussian sampling scheme, wherein S is restricted to have only O(m) or O(n) nonzeros, depending on the dimension to be contracted. Considering the case B = S*A for concreteness, each row of S is taken to be nonzero in only O(m/k) columns, with full coverage of A maintained by evenly spreading these nonzero indices among the rows of S. The complexity of computing B is O(m*n). Sparse Gaussian sketching can be specified with:

opts.sketch = :sprn

and is only implemented for type AbstractMatrix. Power iteration is not supported since any subsequent matrix application would devolve back to having O(k*m*n) cost.

Other Capabilities

We also provide a few other useful relevant algorithms as follows. Let A be an m by n matrix.

Partial Range

A basis for the partial range of A of rank k is an m by k matrix Q with orthonormal columns such that A = Q*Q'*A. Such a basis can be computed with:

Q = prange(A, args...)

Fast range approximation using sketching is supported.

The default interface computes a basis for the column space of A. To capture the row space instead, use:

Q = prange(:c, A, args...)

which is equivalent to computing the partial range of A'. The resulting matrix Q is n by k with orthonormal rows and satisfies A = A*Q*Q'. It is also possible to approximate both the row and column spaces simultaneously with:

Q = prange(:b, A, args...)

Then A = Q*Q'*A*Q*Q'.

A possibly modifying version is available as prange!.

Spectral Norm Estimation

The spectral norm of A can be rapidly computed using randomized power iteration via:

err = snorm(A, args...)

Similarly, the spectral norm difference of two matrices A and B can be computed with:

err = snormdiff(A, B, args...)

which admits both a convenient and efficient way to test the accuracy of our low-rank approximations.

Core Algorithm

The underlying algorithm behind LowRankApprox is the pivoted QR decomposition, with the magnitudes of the pivots providing an estimate of the approximation error incurred at each truncation rank. Here, we use an early-terminating variant of the LAPACK routine GEQP3. The partial QR decomposition so constructed is then leveraged into an ID to support the various other factorizations.

Due to its fundamental importance, we can also perform optional determinant maximization post-processing to obtain a (strong) rank-revealing QR (RRQR) decomposition. This ensures that we select the best column pivots and can further improve numerical precision and stability.


Numerous options are exposed by the LRAOptions type, which we will cover by logical function below.

Accuracy Options

The accuracy of any low-rank approximation (in the spectral norm) is controlled by the following parameters:

  • atol: absolute tolerance of approximation (default: 0)
  • rtol: relative tolerance of approximation (default: 5*eps())
  • rank: maximum rank of approximation (default: -1)

Each parameter specifies an independent termination criterion; the computation completes when any of them are met. Currently, atol and rtol are checked against QR pivot magnitudes and thus accuracy can only be approximately guaranteed, though the resulting errors should be of the correct order.

Iterative RRQR post-processing is also available:

  • maxdet_niter: maximum number of iterations for determinant maximization (default: -1)
  • maxdet_tol: relative tolerance for determinant maximization (default: -1)

If maxdet_tol < 0, no post-processing is done; otherwise, as above, each parameter specifies an independent termination criterion. These options have an impact on all factorizations (i.e., not just QR) since they all involve, at some level, approximations based on the QR. For example, computing an ID via an RRQR guarantees that the interpolation matrix T satisfies maxabs(T) < 1 + maxdet_tol (assuming no early termination due to maxdet_niter).

The parameters atol and rtol are also used for the spectral norm estimation routines snorm and snormdiff to specify the requested precision of the (scalar) norm output.

Sketching Options

The following parameters govern matrix sketching:

  • sketch: sketch method, one of :none, :randn (default), :srft, :sub, or :sprn
  • sketch_randn_niter: number of power iterations for Gaussian sketching (default: 0)
  • sketchfact_adap: whether to compute a sketched factorization adaptively by successively doubling the sketch order (default: true); if false only takes effect if rank >= 0, in which case a single sketch of order rank is (partially) factorized
  • sketchfact_randn_samp: oversampling function for Gaussian sketching (default: n -> n + 8)
  • sketchfact_srft_samp: oversampling function for SRFT sketching (default: n -> n + 8)
  • sketchfact_sub_samp: oversampling function for subset sketching (default: n -> 4*n + 8)

The oversampling functions take as input a desired approximation rank and return a corresponding sketch order designed to be able to capture it with high probability. No oversampling function is used for sparse random Gaussian sketching due to its special form.

Other Options

Other available options include:

  • nb: computational block size, used in various settings (default: 32)
  • pheig_orthtol: eigenvalue relative tolerance to identify degenerate subspaces, within which eigenvectors are re-orthonormalized (to combat LAPACK issue; default: sqrt(eps()))
  • pqrfact_retval: string containing keys indicating which outputs to return from pqrfact (default: "qr")
    • "q": orthonormal Q matrix
    • "r": trapezoidal R matrix
    • "t": interpolation T matrix (for ID)
  • snorm_niter: maximum number of iterations for spectral norm estimation (default: 32)
  • verb: whether to print verbose messages, used sparingly (default: true)

Note that pqrfact always returns the permutation vector p so that no specification is needed in pqrfact_retval. If pqrfact_retval = "qr" (in some order), then the output factorization has type PartialQR; otherwise, it is of type PartialQRFactors, which is simply a container type with no defined arithmetic operations. All keys other than "q", "r", and "t" are ignored.

Computational Complexity

Below, we summarize the leading-order computational costs of each factorization function depending on the sketch type. Assume an input AbstractMatrix of size m by n with numerical rank k << min(m, n) and O(1) cost to compute each entry. Then, first, for a non-adaptive computation (i.e., k is known essentially a priori):

pqrk*m*nk*m*nk^2*(m + n)m*n*log(k)m*n
idk*m*nk*m*nk^2*n + k*mm*n*log(k)m*n
svdk*m*nk*m*nk^2*(m + n)m*n*log(k)m*n
pheigk*m*nk*m*nk^2*(m + n)m*n*log(k)m*n
curk*m*nk*m*nk^2*(m + n)m*n*log(k)m*n

The cost given for the ID is for the default column-oriented version; to obtain the operation count for a row-oriented ID, simply switch the roles of m and n. Note also that pheig is only applicable to square matrices, i.e., m = n.

All of the above remain unchanged for sketchfact_adap = true with the exception of the following, in which case the costs become:

  • sketch = :srft: m*n*log(k)^2
  • sketch = :sprn: m*n*log(k)

uniformly across all functions.

Download Details:

Author: JuliaMatrices
Source Code: https://github.com/JuliaMatrices/LowRankApprox.jl
License: View license

#julia #matrix

LowRankApprox.jl: Fast Low-rank Matrix Approximation in Julia
Nat  Grady

Nat Grady


ScatterMatrixD3: R Htmlwidget Wrapper Around The D3 Scatterplot Matrix


R Htmlwidget Wrapper Around The D3 Scatterplot Matrix

This is a htmlwidget wrapper around Benjie Chen's extension of Mike Bostock's scatterplot matrix.



   data = iris

Download Details:

Author: jcizel
Source Code: https://github.com/jcizel/scatterMatrixD3

#r #d3 #matrix

ScatterMatrixD3: R Htmlwidget Wrapper Around The D3 Scatterplot Matrix
