Component-wrapper for Collapse animation with React-motion

React-collapse

Component-wrapper for collapse animation for elements with variable (and dynamic) height

Installation

NPM

npm install --save react-collapse

yarn

yarn add react-collapse

1998 Script Tag:

<script src="https://unpkg.com/react/umd/react.production.min.js"></script>
<script src="https://unpkg.com/react-collapse/build/react-collapse.min.js"></script>
(Module exposed as `ReactCollapse`)

Usage

1. Add a CSS transition

.ReactCollapse--collapse {
  transition: height 500ms;
}

IMPORTANT: Without adding a CSS transition there will be no animation and component will open/close instantly.

2. Content is always mounted (default)

import {Collapse} from 'react-collapse';

// ...
<Collapse isOpened={true || false}>
  <div>Random content</div>
</Collapse>

3. Content unmounts when collapsed

Use Unmount component provided as:

import {UnmountClosed} from 'react-collapse';

// ...
<UnmountClosed isOpened={true || false}>
  <div>Random content</div>
</UnmountClosed>

Example example/App/AutoUnmount.js

4. Controlled and accessible

If you want a controlled and accessible implementation, check out this example

Options

isOpened: PropTypes.boolean.isRequired

Expands or collapses content.

children: PropTypes.node.isRequired

One or multiple children with static, variable or dynamic height.

<Collapse isOpened={true}>
  <p>Paragraph of text</p>
  <p>Another paragraph is also OK</p>
  <p>Images and any other content are ok too</p>
  <img src="nyancat.gif" />
</Collapse>

theme: PropTypes.objectOf(PropTypes.string)

It is possible to set className for extra div elements that ReactCollapse creates.

Example:

<Collapse theme={{collapse: 'foo', content: 'bar'}}>
  <div>Customly animated container</div>
</Collapse>

Default values:

const theme = {
  collapse: 'ReactCollapse--collapse',
  content: 'ReactCollapse--content'
}

Which ends up in the following markup:

<div class="ReactCollapse--collapse">
  <div class="ReactCollapse--content">
    {children}
  </div>
</div>

IMPORTANT: these are not style objects, but class names!

onRest, onWork: PropTypes.func

Callback functions, triggered when animation has completed (onRest) or has just started (onWork)

Both functions are called with argument:

const arg = {
  isFullyOpened: true || false, // `true` only when Collapse reached final height
  isFullyClosed: true || false, // `true` only when Collapse is fully closed and height is zero
  isOpened: true || false, // `true` if Collapse has any non-zero height
  containerHeight: 123, // current pixel height of Collapse container (changes until reaches `contentHeight`)
  contentHeight: 123 // determined height of supplied Content
}

<Collapse onRest={console.log} onWork={console.log}>
  <div>Container text</div>
</Collapse>

Example example/App/Hooks.js

initialStyle: PropTypes.shape

initialStyle: PropTypes.shape({
  height: PropTypes.oneOfType([PropTypes.string, PropTypes.number]),
  overflow: PropTypes.string
})

You may control initial element style, for example to force initial animation from 0 to height by using initialStyle={{height: '0px', overflow: 'hidden'}}

IMPORTANT Any updates to this prop will be ignored after first render. Default value is determined based on initial isOpened value:

  initialStyle = props.isOpened
    ? {height: 'auto', overflow: 'initial'}
    : {height: '0px', overflow: 'hidden'};

Example: example/App/ForceInitialAnimation.js

checkTimeout: PropTypes.number

Number in ms.

Collapse will check height after thins timeout to determine if animation is completed, the shorter the number - the faster onRest will be triggered and the quicker height: auto will be applied. The downside - more calculations. Default value is: 50.

Pass-through props

IMPORTANT Collapse does not support any pass-through props, so any non-supported props will be ignored

Because we need to have control over when Collapse component is updated and it is not possible or very hard to achieve when any random props can be passed to the component.

Behaviour notes

initially opened Collapse elements will be statically rendered with no animation. You can override this behaviour by using initialStyle prop

due to the complexity of margins and their potentially collapsible nature, ReactCollapse does not support (vertical) margins on their children. It might lead to the animation "jumping" to its correct height at the end of expanding. To avoid this, use padding instead of margin. See #101 for more details

Migrating from v4 to v5

v5 was another complete rewrite that happened quite a while ago, it was published as @nkbt/react-collapse and tested in real projects for a long time and now fully ready to be used.

In the most common scenario upgrade is trivial (add CSS transition to collapse element), but if you were using a few deprecated props - there might be some extra work required.

Luckily almost every deprecated callback or prop has fully working analogue in v5. Unfortunately not all of them could maintain full backward compatibility, so please check this migration guide below.

1. Change in behaviour

New Collapse does not implement animations anymore, it only determines Content height and updates Collapse wrapper height to match it. Only after Collapse height reaches Content height (animation finished), Collapse's style is updated to have height: auto; overflow: initial.

The implications is that you will need to update your CSS with transition:

.ReactCollapse--collapse {
  transition: height 500ms;
}

IMPORTANT: Without adding a CSS transition there will be no animation and component will open/close instantly.

2. New props or updated props

onRest/onWork callbacks (see above for full description). Though onRest did exist previously, now it is called with arguments containing few operational params and flags.

initialStyle you may control initial element style, for example to force initial animation from 0 to height by using initialStyle={{height: '0px', overflow: 'hidden'}} IMPORTANT Any updates to this prop will be ignored after first render. Default value is:

  initialStyle = props.isOpened
    ? {height: 'auto', overflow: 'initial'}
    : {height: '0px', overflow: 'hidden'};

checkTimeout number in ms. Collapse will check height after thins timeout to determine if animation is completed, the shorter the number - the faster onRest will be triggered and the quicker height: auto will be applied. The downside - more calculations. Default value is: 50.

3. Deprecated props (not available in v5)

Pass-through props - any unknown props passed to Collapse component will be ignored

hasNestedCollapse - no longer necessary, as v5 does not care if there are nested Collapse elements, see example/App/Nested.js

fixedHeight - no longer necessary, just set whatever height you need for content element and Collapse will work as expected, see example/App/VariableHeight.js

springConfig - as new Collapse relies on simple CSS transitions (or your own implementation of animation) and does not use react-collapse, springConfig is no longer necessary. You can control control animation with css like

.ReactCollapse--collapse {
  transition: height 500ms;
}

forceInitialAnimation - you can use new prop initialStyle={{height: '0px', overflow: 'hidden'}} instead, so when new height will be set after component is rendered - it should naturally animate.

onMeasure - please use onRest and onWork instead and pick contentHeight from argument

<Collapse
  onRest={({contentHeight}) => console.log(contentHeight)}
  onWork={({contentHeight}) => console.log(contentHeight)}>
  <div>content</div>
</Collapse>

onRender - since animations are fully controlled by external app (e.g. with CSS) we no draw each frame and do not actually re-render component anymore, so it is impossible to have onRender callback

Development and testing

Currently is being developed and tested with the latest stable Node on OSX.

To run example covering all ReactCollapse features, use yarn start, which will compile example/Example.js

git clone git@github.com:nkbt/react-collapse.git
cd react-collapse
yarn install
yarn start

# then
open http://localhost:8080

Tests

# to run ESLint check
yarn lint

# to run tests
yarn test

Demo

http://nkbt.github.io/react-collapse

Codepen demo

http://codepen.io/nkbt/pen/MarzEg

Download Details:

Author: nkbt
Source Code: https://github.com/nkbt/react-collapse
License: MIT license
