Cute_headers: Collection Of Cross-platform one-file C/C++ Libraries

Cute_headers

Various single-file cross-platform C/C++ headers implementing self-contained libraries.

How to Use

Generally these headers do not have dependencies and are intended to be included directly into your source (check each header for specific documentation at the top of the file). Each header has a LIBNAME_IMPLEMENTATION symbol; add this to a single translation unit in your code and include the header right after in order to define library symbols. Just include the header as normal otherwise.

Examples and Tests

Some headers also have example code or demos. In this repo just look for the corresponding examples or tests folders. The example folders are particularly useful for figuring out how to use a particular header.

Contact

Here's a link to the discord chat for cute_headers. Feel free to pop in and ask questions, make suggestions, or have a discussion. If anyone has used cute_headers it would be great to hear your experience! https://discord.gg/2DFHRmX

Another easy way to get a hold of me is on twitter @randypgaul.

FAQ

• What's the point of making a single file? Why is there implementation and static functions in the headers?

Including these headers is like including a normal header. However, to define the implementation each header looks something like this:

// Do this ONCE in a .c/.cpp file
#define LIBNAME_IMPLEMENTATION
#include "libname.h"

// Everywhere else, just include like a typical header
#include "libname.h"

This will turn the file into a header + c file combo, one time. The point of this is: A) handling the header or sending it to people is easy, no zip files or anything just copy and paste a single file; B) build scripts are a pain in the ass, and these single-file libs can be integrated into any project without modifying a single build script.

• Doesn't writing all the code in a header ruin compile times?

The stigma that header implementations slow compile time come from inline'd code and template spam. In either case every single translation unit must churn through the header and place inline versions of functions, or for templates generate various type-specific functions. It gets worse once the linker kicks in and needs to coalesce translation units together, deleting duplicated symbols. Often linkers are single-threaded tasks and can really bottleneck build times.

A well constructed single-file header will not use any templates and make use of inline sparingly. Additionally well constructed single-file headers use a #define to place implementation (the function definitions and symbols) into a single translation unit. In this way a well crafted single-file header is pretty much the best thing a C compiler can come across, as far as build times go. Especially when the header can optionally #define out unneeded features.

• Aren't these header only libraries just a new fad?

I personally don't really know if it's a fad or not, but these files aren't really just headers. They are headers with the .C file part (the implementation) attached to the end. It's two different files stuck together with the C preprocessor, but the implementation part never shows up unless the user does #define LIB_IMPLEMENTATION. This define step is the only integration step required to use these headers.

Unfortunately writing a good header library is pretty hard, so just any random header lib out there in the wild is probably not a good one. The STB and RJM are pretty good header libs, and are a good reference to get an idea at what a good header lib looks like. Mattias Gustavsson has my favorite collection of headers.

• What is the license?

Each lib contains license info at the end of the file. There is a choice between public domain, and zlib.

• I was looking for a header I've seen before, but it's missing. Where did it go?

Some of the unpopular or not so useful headers became deprecated, and live here now.

Download Details:

Author: RandyGaul
Source Code: https://github.com/RandyGaul/cute_headers

#audio #game #c #library #png #opengl

Glium: Safe OpenGL Wrapper for The Rust Language

Glium

Note to current and future Glium users:

Glium is no longer actively developed by its original author. That said, PRs are still welcome and maintenance is continued by the surrounding community.

Elegant and safe OpenGL wrapper.

Glium is an intermediate layer between OpenGL and your application. You still need to manually handle the graphics pipeline, but without having to use OpenGL's old and error-prone API.

[dependencies]
glium = "*"

Its objectives:

• Be safe to use. Many aspects of OpenGL that can trigger a crash if misused are automatically handled by glium.
• Provide an API that enforces good practices such as RAII or stateless function calls.
• Be compatible with all OpenGL versions that support shaders, providing a unified API when things diverge.
• Avoid all OpenGL errors beforehand.
• Produce optimized OpenGL function calls, and allow the user to easily use modern OpenGL techniques.

Link to the documentation

If you have some knowledge of OpenGL, the documentation and the examples should get you easily started.

Link to a work-in-progress tutorial

Why should I use Glium instead of raw OpenGL calls?

Easy to use:

Functions are higher level in glium than in OpenGL. Glium's API tries to be as Rusty as possible, and shouldn't be much different than using any other Rust library. Glium should allow you to do everything that OpenGL allows you to do, just through high-level functions. If something is missing, please open an issue.

You can directly pass vectors, matrices and images to glium instead of manipulating low-level data.

Thanks to glutin, glium is very easy to setup compared to raw OpenGL.

Glium provides easier ways to do common tasks. For example the VertexBuffer struct contains information about the vertex bindings, because you usually don't use several different bindings with the same vertex buffer. This reduces the overall complexity of OpenGL.

Glium handles framebuffer objects, samplers, and vertex array objects for you. You no longer need to create them explicitly as they are automatically created when needed and destroyed when their corresponding object is destroyed.

Glium is stateless. There are no set_something() functions in the entire library, and everything is done by parameter passing. The same set of function calls will always produce the same results, which greatly reduces the number of potential problems.

Safety:

Glium detects what would normally be errors or undefined behaviors in OpenGL, and panics, without calling glGetError which would be too slow. Examples include requesting a depth test when you don't have a depth buffer available, not binding any value to an attribute or uniform, or binding multiple textures with different dimensions to the same framebuffer.

If the OpenGL context triggers an error, then you have found a bug in glium. Please open an issue. Just like Rust does everything it can to avoid crashes, glium does everything it can to avoid OpenGL errors.

The OpenGL context is automatically handled by glium. You don't need to worry about thread safety, as it is forbidden to change the thread in which OpenGL objects operate. Glium also allows you to safely replace the current OpenGL context with another one that shares the same lists.

Glium enforces RAII. Creating a Texture2d struct creates a texture, and destroying the struct destroys the texture. It also uses Rust's borrow system to ensure that objects are still alive and in the right state when you use them. Glium provides the same guarantees with OpenGL objects that you have with regular objects in Rust.

High-level functions are much easier to use and thus less error-prone. For example there is no risk of making a mistake while specifying the names and offsets of your vertex attributes, since Glium automatically generates this data for you.

Robustness is automatically handled. If the OpenGL context is lost (because of a crash in the driver for example) then swapping buffers will return an error.

Compatibility:

In its default mode, Glium should be compatible with both OpenGL and OpenGL ES. If something doesn't work on OpenGL ES, please open an issue.

During initialization, Glium detects whether the context provides all the required functionality, and returns an Err if the device is too old. Glium tries to be as tolerant as possible, and should work with the majority of the OpenGL2-era devices.

Glium will attempt to use the latest, optimized versions of OpenGL functions. This includes buffer and texture immutable storage and direct state access. It will automatically fall back to older functions if they are not available.

Glium comes with a set of tests that you can run with cargo test. If your project/game doesn't work on specific hardware, you can try running Glium's tests on it to see what is wrong.

Performances:

State changes are optimized. The OpenGL state is only modified if the state actually differs. For example if you call draw with the IfLess depth test twice in a row, then glDepthFunc(GL_LESS) and glEnable(GL_DEPTH_TEST) will only be called the first time. If you then call draw with IfGreater, then only glDepthFunc(GL_GREATER) will be called.

Just like Rust is theoretically slower than C because of additional safety checks, glium is theoretically slower than well-prepared and optimized raw OpenGL calls. However in practice the difference is very low.

Fully optimized OpenGL code uses advanced techniques such as persistent mapping or bindless textures. These are hard to do and error-prone, but trivially easy to do with glium. You can easily get a huge performance boost just by doing the right function calls.

Since glium automatically avoids all OpenGL errors, you can safely use the GL_KHR_no_error extension when it is available. Using this extension should provide a good performance boost (but it is also very recent and not available anywhere for the moment).

Limitations:

Robustness isn't supported everywhere yet, so you can still get crashes if you do incorrect things in your shaders.

Glium gives you access to all the tools but doesn't prevent you from doing horribly slow things. Some knowledge of modern techniques is required if you want to reach maximum performances.

Glium pushes the Rust compiler to its limits. Stack overflows (inside the compiler), internal compiler errors, one-hour compile time, etc. happen more often than in smaller libraries.

Macros are yet work-in-progress; see glium-derive for details.

Download Details:

Author: Glium
Source Code: https://github.com/glium/glium
License: Apache-2.0 license

#rust #opengl #wrapper

Gephi: The Open Graph Viz Platform

Gephi - The Open Graph Viz Platform

Gephi is an award-winning open-source platform for visualizing and manipulating large graphs. It runs on Windows, Mac OS X and Linux. Localization is available in English, French, Spanish, Japanese, Russian, Brazilian Portuguese, Chinese, Czech, German and Romanian.

Fast Powered by a built-in OpenGL engine, Gephi is able to push the envelope with very large networks. Visualize networks up to a million elements. All actions (e.g. layout, filter, drag) run in real-time.

Simple Easy to install and get started. An UI that is centered around the visualization. Like Photoshop™ for graphs.

Modular Extend Gephi with plug-ins. The architecture is built on top of Apache Netbeans Platform and can be extended or reused easily through well-written APIs.

Download Gephi for Windows, Mac OS X and Linux and consult the release notes. Example datasets can be found on our wiki.

Install and use Gephi

Download and Install Gephi on your computer.

Get started with the Quick Start and follow the Tutorials. Load a sample dataset and start to play with the data.

If you run into any trouble or have questions consult our discussions.

Latest releases

Stable

• Latest stable release on gephi.org.

Development builds

Development builds are generated regularly. Current version is 0.10.2-SNAPSHOT

gephi-0.10.2-SNAPSHOT-windows-x64.exe (Windows)

gephi-0.10.2-SNAPSHOT-windows-x32.exe (Windows x32)

gephi-0.10.2-SNAPSHOT-macos-x64.dmg (Mac OS X)

gephi-0.10.2-SNAPSHOT-macos-aarch64.dmg (Mac OS X Silicon)

gephi-0.10.2-SNAPSHOT-linux-x64.tar.gz (Linux)

Developer Introduction

Gephi is developed in Java and uses OpenGL for its visualization engine. Built on the top of Netbeans Platform, it follows a loosely-coupled, modular architecture philosophy. Gephi is split into modules, which depend on other modules through well-written APIs. Plugins can reuse existing APIs, create new services and even replace a default implementation with a new one.

Consult the Javadoc for an overview of the APIs.

Requirements

Java JDK 11 (or later)

Apache Maven version 3.6.3 or later

Checkout and Build the sources

Fork the repository and clone

  git clone git@github.com:username/gephi.git

Run the following command or open the project in an IDE

  mvn -T 4 clean install

Once built, one can test running Gephi

  cd modules/application
  mvn nbm:cluster-app nbm:run-platform

Note that while Gephi can be built using JDK 11 or later, it currently requires JDK 11 to run.

Create Plug-ins

Gephi is extensible and lets developers create plug-ins to add new features, or to modify existing features. For example, you can create a new layout algorithm, add a metric, create a filter or a tool, support a new file format or database, or modify the visualization.

Plugins Portal

Plugins Quick Start (5 minutes)

Browse the plugins created by the community

We've created a Plugins Bootcamp to learn by examples.

Gephi Toolkit

The Gephi Toolkit project packages essential Gephi modules (Graph, Layout, Filters, IO…) in a standard Java library which any Java project can use for getting things done. It can be used on a server or command-line tool to do the same things Gephi does but automatically.

Download

GitHub Project

Toolkit Portal

Localization

We use Weblate for localization. Follow the guidelines on the wiki for more details how to contribute.

Icons

Gephi uses icons from various sources. The icons are licensed under the CC BY 3.0 license.

All icons can be found in the DesktopIcons module, organised by module name.

Download Details:

Author: Gephi
Source Code: https://github.com/gephi/gephi
License: GPL-3.0, Unknown licenses found

#java #visualization #opengl #graph

GFX: A low-overhead Vulkan-like GPU API for Rust

gfx-rs

gfx-rs is a low-level, cross-platform graphics and compute abstraction library in Rust. It consists of the following components:

gfx-hal deprecation

As of the v0.9 release, gfx-hal is now in maintenance mode. gfx-hal development was mainly driven by wgpu, which has now switched to its own GPU abstraction called wgpu-hal. For this reason, gfx-hal development has switched to maintenance only, until the developers figure out the story for gfx-portability. Read more about the transition in #3768.

hal

• gfx-hal which is gfx's hardware abstraction layer: a Vulkan-ic mostly unsafe API which translates to native graphics backends.
• gfx-backend-* which contains graphics backends for various platforms:
  • Vulkan (runs on Linux, Windows, and Android)
  • DirectX 12 and DirectX 11
  • Metal (runs on macOS and iOS)
  • OpenGL ES3 (runs on Linux/BSD, Android, and WASM/WebGL2)
• gfx-warden which is a data-driven reference test framework, used to verify consistency across all graphics backends.

gfx-rs is hard to use, it's recommended for performance-sensitive libraries and engines. If that's not your domain, take a look at wgpu-rs for a safe and simple alternative.

Hardware Abstraction Layer

The Hardware Abstraction Layer (HAL), is a thin, low-level graphics and compute layer which translates API calls to various backends, which allows for cross-platform support. The API of this layer is based on the Vulkan API, adapted to be more Rust-friendly.

Currently HAL has backends for Vulkan, DirectX 12/11, Metal, and OpenGL/OpenGL ES/WebGL.

The HAL layer is consumed directly by user applications or libraries. HAL is also used in efforts such as gfx-portability.

See the Big Picture blog post for connections.

The old gfx crate (pre-ll)

This repository was originally home to the gfx crate, which is now deprecated. You can find the latest versions of the code for that crate in the pre-ll branch of this repository.

The master branch of this repository is now focused on developing gfx-hal and its associated backend and helper libraries, as described above. gfx-hal is a complete rewrite of gfx, but it is not necessarily the direct successor to gfx. Instead, it serves a different purpose than the original gfx crate, by being "lower level" than the original. Hence, the name of gfx-hal was originally ll, which stands for "lower level", and the original gfx is now referred to as pre-ll.

The spiritual successor to the original gfx is actually wgpu, which stands on a similar level of abstraction to the old gfx crate, but with a modernized API that is more fit for being used over Vulkan/DX12/Metal. If you want something similar to the old gfx crate that is being actively developed, wgpu is probably what you're looking for, rather than gfx-hal.

Contributing

We are actively looking for new contributors and aim to be welcoming and helpful to anyone that is interested! We know the code base can be a bit intimidating in size and depth at first, and to this end we have a label on the issue tracker which marks issues that are new contributor friendly and have some basic direction for completion in the issue comments. If you have any questions about any of these issues (or any other issues) you may want to work on, please comment on GitHub and/or drop a message in our Matrix chat!

Download Details:

Author: gfx-rs
Source Code: https://github.com/gfx-rs/gfx
License: Apache-2.0, MIT licenses found

#rust #opengl #gpu #graphic

Azul: Desktop GUI Framework

Azul - Desktop GUI framework

Azul is a free, functional, reactive GUI framework for Rust, C and C++, built using the WebRender rendering engine and a CSS / HTML-like document object model for rapid development of beautiful, native desktop applications

Features

Azul uses webrender (the rendering engine behind Firefox) to render your UI, so it supports lots of common CSS features like:

• gradients (linear, radial, conic)
• box shadows
• SVG filters
• composition operators (multiply, darken, etc.)
• border styling
• border-radii
• scrolling / automatic overflow
• CSS transforms

See the list of supported CSS keys / values for more info.

On top of that, Azul features...

• lots of built-in widgets (Button, TextInput, CheckBox, ColorInput, TextInput, NumberInput)
• embedding OpenGL textures
• simplified HTML-like relative/absolute layout system based on CSS flexbox
• 60+ FPS animations via Animation API
• cross-platform native dialogs
• cross-platform text shaping and rendering
• SVG parsing and rendering
• shape tesselation for rendering large numbers of 2D lines, circles, rects, shapes, etc. in a single draw call
• managing off-main-thread tasks for I/O
• dynamic linking via shared library*
• usable from Rust, C, C++ and Python via auto-generated API bindings**
• HTML-to-Rust compilation for fast prototyping / hot reload

* static linking not yet available

** C++ bindings and Python are not yet stabilized and might not work depending on the branch you're using. They will be stabilized before the release.

Screenshots

Hello World

Python

from azul import *

class DataModel:
    def __init__(self, counter):
        self.counter = counter

def render_dom(data, info):

    label = Dom.text("{}".format(data.counter))
    label.set_inline_style("font-size: 50px;")

    button = Button("Increment counter")
    button.set_on_click(data, increment_counter)

    dom = Dom.body()
    dom.add_child(label)
    dom.add_child(button.dom())

    return dom.style(Css.empty())

def increment_counter(data, info):
    data.counter += 1;
    return Update.RefreshDom

app = App(DataModel(5), AppConfig(LayoutSolver.Default))
app.run(WindowCreateOptions(render_dom))

Rust

use azul::prelude::*;
use azul::widgets::{button::Button, label::Label};

struct DataModel {
    counter: usize,
}

extern "C"
fn render_dom(data: &mut RefAny, _: &mut LayoutInfo) -> StyledDom {

    let data = data.downcast_ref::<DataModel>()?;

    let label = Dom::text(format!("{}", data.counter))
        .with_inline_style("font-size: 50px;");

    let button = Button::new("Increment counter")
        .onmouseup(increment_counter, data.clone());

    Dom::body()
    .with_child(label)
    .with_child(button.dom())
    .style(Css::empty())
}

extern "C"
fn increment_counter(data: &mut RefAny, _: &mut CallbackInfo) -> Update {
    let mut data = data.downcast_mut::<DataModel>()?;
    data.counter += 1;
    Update::RefreshDom // call render_dom() again
}

fn main() {
    let initial_data = RefAny::new(DataModel { counter: 0 });
    let app = App::new(initial_data, AppConfig::default());
    app.run(WindowCreateOptions::new(render_dom));
}

C

#include "azul.h"

typedef struct {
    uint32_t counter;
} DataModel;

void DataModel_delete(DataModel* restrict A) { }
AZ_REFLECT(DataModel, DataModel_delete);

AzStyledDom render_dom(AzRefAny* data, AzLayoutInfo* info) {

    DataModelRef d = DataModelRef_create(data);
    if !(DataModel_downcastRef(data, &d)) {
        return AzStyledDom_empty();
    }

    char buffer [20];
    int written = snprintf(buffer, 20, "%d", d->counter);
    AzString const labelstring = AzString_copyFromBytes(&buffer, 0, written);
    AzDom label = AzDom_text(labelstring);
    AzString const inline_css = AzString_fromConstStr("font-size: 50px;");
    AzDom_setInlineStyle(&label, inline_css);

    AzString const buttontext = AzString_fromConstStr("Increment counter");
    AzButton button = AzButton_new(buttontext, AzRefAny_clone(data));
    AzButton_setOnClick(&button, incrementCounter);

    AzDom body = Dom_body();
    AzDom_addChild(body, AzButton_dom(&button));
    AzDom_addChild(body, label);

    AzCss global_css = AzCss_empty();
    return AzDom_style(body, global_css);
}

Update incrementCounter(RefAny* data, CallbackInfo* event) {
    DataModelRefMut d = DataModelRefMut_create(data);
    if !(DataModel_downcastRefMut(data, &d)) {
        return Update_DoNothing;
    }
    d->ptr.counter += 1;
    DataModelRefMut_delete(&d);
    return Update_RefreshDom;
}

int main() {
    DataModel model = { .counter = 5 };
    AzApp app = AzApp_new(DataModel_upcast(model), AzAppConfig_default());
    AzApp_run(app, AzWindowCreateOptions_new(render_dom));
    return 0;
}

Download Details:

Author: fschutt
Source Code: https://github.com/fschutt/azul
License: MPL-2.0 and 3 other licenses found

#rust #gui #opengl #cpp #desktop

WGPU: Safe & portable GPU abstraction in Rust, implementing WebGPU API

WGPU

wgpu is a cross-platform, safe, pure-rust graphics api. It runs natively on Vulkan, Metal, D3D12, D3D11, and OpenGLES; and on top of WebGPU on wasm.

The api is based on the WebGPU standard. It serves as the core of the WebGPU integration in Firefox, Servo, and Deno.

MSRV policy

Minimum Supported Rust Version is 1.64. It is enforced on CI (in "/.github/workflows/ci.yml") with RUST_VERSION variable. This version can only be upgraded in breaking releases.

The wgpu-core, wgpu-hal, and wgpu-types crates should never require an MSRV ahead of Firefox's MSRV for nightly builds, as determined by the value of MINIMUM_RUST_VERSION in python/mozboot/mozboot/util.py. However, Firefox uses cargo vendor to extract only those crates it actually uses, so the workspace's other crates can have more recent MSRVs.

Note for Rust 1.64: The workspace itself can even use a newer MSRV than Firefox, as long as the vendoring step's Cargo.toml rewriting removes any features Firefox's MSRV couldn't handle. For example, wgpu can use manifest key inheritance, added in Rust 1.64, even before Firefox reaches that MSRV, because cargo vendor copies inherited values directly into the individual crates' Cargo.toml files, producing 1.63-compatible files.

Getting Started

Rust

Rust examples can be found at wgpu/examples. You can run the examples with cargo run --example name. See the list of examples. For detailed instructions, look at Running the examples on the wiki.

If you are looking for a wgpu tutorial, look at the following:

• https://sotrh.github.io/learn-wgpu/

C/C++

To use wgpu in C/C++, you need wgpu-native.

Others

If you want to use wgpu in other languages, there are many bindings to wgpu-native from languages such as Python, D, Julia, Kotlin, and more. See the list.

Angle

Angle is a translation layer from GLES to other backends, developed by Google. We support running our GLES3 backend over it in order to reach platforms with GLES2 or DX11 support, which aren't accessible otherwise. In order to run with Angle, "angle" feature has to be enabled, and Angle libraries placed in a location visible to the application. These binaries can be downloaded from gfbuild-angle artifacts, manual compilation may be required on Macs with Apple silicon.

On Windows, you generally need to copy them into the working directory, in the same directory as the executable, or somewhere in your path. On Linux, you can point to them using LD_LIBRARY_PATH environment.

Environment Variables

All testing and example infrastructure shares the same set of environment variables that determine which Backend/GPU it will run on.

• WGPU_ADAPTER_NAME with a substring of the name of the adapter you want to use (ex. 1080 will match NVIDIA GeForce 1080ti).
• WGPU_BACKEND with a comma separated list of the backends you want to use (vulkan, metal, dx12, dx11, or gl).
• WGPU_POWER_PREF with the power preference to choose when a specific adapter name isn't specified (high or low)
• WGPU_DX12_COMPILER with the DX12 shader compiler you wish to use (dxc or fxc, note that dxc requires dxil.dll and dxcompiler.dll to be in the working directory otherwise it will fall back to fxc)

When running the CTS, use the variables DENO_WEBGPU_ADAPTER_NAME, DENO_WEBGPU_BACKEND, DENO_WEBGPU_POWER_PREFERENCE.

Testing

We have multiple methods of testing, each of which tests different qualities about wgpu. We automatically run our tests on CI if possible. The current state of CI testing:

Core Test Infrastructure

We use a tool called cargo nextest to run our tests. To install it, run cargo install cargo-nextest.

To run the test suite on the default device:

cargo nextest run --no-fail-fast

wgpu-info can run the tests once for each adapter on your system.

cargo run --bin wgpu-info -- cargo nextest run --no-fail-fast

Then to run an example's image comparison tests, run:

cargo nextest run <example-test-name> --no-fail-fast

Or run a part of the integration test suite:

cargo nextest run -p wgpu -- <name-of-test>

If you are a user and want a way to help contribute to wgpu, we always need more help writing test cases.

WebGPU Conformance Test Suite

WebGPU includes a Conformance Test Suite to validate that implementations are working correctly. We can run this CTS against wgpu.

To run the CTS, first you need to check it out:

git clone https://github.com/gpuweb/cts.git
cd cts
# works in bash and powershell
git checkout $(cat ../cts_runner/revision.txt)

To run a given set of tests:

# Must be inside the cts folder we just checked out, else this will fail
cargo run --manifest-path ../cts_runner/Cargo.toml -- ./tools/run_deno --verbose "<test string>"

To find the full list of tests, go to the online cts viewer.

The list of currently enabled CTS tests can be found here.

Tracking the WebGPU and WGSL draft specifications

The wgpu crate is meant to be an idiomatic Rust translation of the WebGPU API. That specification, along with its shading language, WGSL, are both still in the "Working Draft" phase, and while the general outlines are stable, details change frequently. Until the specification is stabilized, the wgpu crate and the version of WGSL it implements will likely differ from what is specified, as the implementation catches up.

Exactly which WGSL features wgpu supports depends on how you are using it:

When running as native code, wgpu uses the Naga crate to translate WGSL code into the shading language of your platform's native GPU API. Naga has a milestone for catching up to the WGSL specification, but in general there is no up-to-date summary of the differences between Naga and the WGSL spec.

When running in a web browser (by compilation to WebAssembly) without the "webgl" feature enabled, wgpu relies on the browser's own WebGPU implementation. WGSL shaders are simply passed through to the browser, so that determines which WGSL features you can use.

When running in a web browser with wgpu's "webgl" feature enabled, wgpu uses Naga to translate WGSL programs into GLSL. This uses the same version of Naga as if you were running wgpu as native code.

Coordinate Systems

wgpu uses the coordinate systems of D3D and Metal:

Render	Texture

Repo Overview

The repository hosts the following libraries:

• - User facing Rust API.
• - Internal WebGPU implementation.
• - Internal unsafe GPU API abstraction layer.
• - Rust types shared between all crates.
• - WebGPU implementation for the Deno JavaScript/TypeScript runtime

The following binaries:

• cts_runner - WebGPU Conformance Test Suite runner using deno_webgpu.
• player - standalone application for replaying the API traces.
• wgpu-info - program that prints out information about all the adapters on the system or invokes a command for every adapter.

For an overview of all the components in the gfx-rs ecosystem, see the big picture.

Community

We have the Matrix space with a few different rooms that form the wgpu community:

• - discussion of the library's development.
• - discussion of using the library and the surrounding ecosystem.
• - discussion of everything else.

Wiki

We have a wiki that serves as a knowledge base.

Supported Platforms

✅ = First Class Support — 🆗 = Best Effort Support — 🛠️ = Unsupported, but support in progress

Shader Support

wgpu supports shaders in WGSL, SPIR-V, and GLSL. Both HLSL and GLSL have compilers to target SPIR-V. All of these shader languages can be used with any backend, we will handle all of the conversion. Additionally, support for these shader inputs is not going away.

While WebGPU does not support any shading language other than WGSL, we will automatically convert your non-WGSL shaders if you're running on WebGPU.

WGSL is always supported by default, but GLSL and SPIR-V need features enabled to compile in support.

Note that the WGSL specification is still under development, so the draft specification does not exactly describe what wgpu supports. See below for details.

To enable SPIR-V shaders, enable the spirv feature of wgpu. To enable GLSL shaders, enable the glsl feature of wgpu.

Download Details:

Author: gfx-rs
Source Code: https://github.com/gfx-rs/wgpu
License: Apache-2.0, MIT licenses found

#rust #opengl #gpu

Android Filters Based on OpenGL (idea From GPUImage for iOS)

GPUImage for Android

Goal is to have something as similar to GPUImage as possible. Vertex and fragment shaders are exactly the same. That way it makes it easier to port filters from GPUImage iOS to Android.

Requirements

• Android 2.2 or higher (OpenGL ES 2.0)

Usage

Gradle dependency

repositories {
    mavenCentral()
}

dependencies {
    implementation 'jp.co.cyberagent.android:gpuimage:2.x.x'
}

Sample Code

With preview:

Java:

@Override
public void onCreate(final Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    setContentView(R.layout.activity);

    Uri imageUri = ...;
    gpuImage = new GPUImage(this);
    gpuImage.setGLSurfaceView((GLSurfaceView) findViewById(R.id.surfaceView));
    gpuImage.setImage(imageUri); // this loads image on the current thread, should be run in a thread
    gpuImage.setFilter(new GPUImageSepiaFilter());

    // Later when image should be saved saved:
    gpuImage.saveToPictures("GPUImage", "ImageWithFilter.jpg", null);
}

Kotlin:

public override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    setContentView(R.layout.activity_gallery)

    val imageUri: Uri = ...
    gpuImage = GPUImage(this)
    gpuImage.setGLSurfaceView(findViewById<GLSurfaceView>(R.id.surfaceView))
    gpuImage.setImage(imageUri) // this loads image on the current thread, should be run in a thread
    gpuImage.setFilter(GPUImageSepiaFilter())

    // Later when image should be saved saved:
    gpuImage.saveToPictures("GPUImage", "ImageWithFilter.jpg", null)
}

Using GPUImageView

<jp.co.cyberagent.android.gpuimage.GPUImageView
    android:id="@+id/gpuimageview"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    app:gpuimage_show_loading="false"
    app:gpuimage_surface_type="texture_view" /> <!-- surface_view or texture_view -->

Java:

@Override
public void onCreate(final Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    setContentView(R.layout.activity);

    Uri imageUri = ...;
    gpuImageView = findViewById(R.id.gpuimageview);
    gpuImageView.setImage(imageUri); // this loads image on the current thread, should be run in a thread
    gpuImageView.setFilter(new GPUImageSepiaFilter());

    // Later when image should be saved saved:
    gpuImageView.saveToPictures("GPUImage", "ImageWithFilter.jpg", null);
}

Kotlin:

public override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    setContentView(R.layout.activity_gallery)

    val imageUri: Uri = ...
    gpuImageView = findViewById<GPUImageView>(R.id.gpuimageview)
    gpuImageView.setImage(imageUri) // this loads image on the current thread, should be run in a thread
    gpuImageView.setFilter(GPUImageSepiaFilter())

    // Later when image should be saved saved:
    gpuImageView.saveToPictures("GPUImage", "ImageWithFilter.jpg", null)
}

Without preview:

Java:

public void onCreate(final Bundle savedInstanceState) {
    public void onCreate(final Bundle savedInstanceState) {
    Uri imageUri = ...;
    gpuImage = new GPUImage(context);
    gpuImage.setFilter(new GPUImageSobelEdgeDetection());
    gpuImage.setImage(imageUri);
    gpuImage.saveToPictures("GPUImage", "ImageWithFilter.jpg", null);
}

Kotlin:

public override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    setContentView(R.layout.activity_gallery)
    val imageUri: Uri = ...
    gpuImage = GPUImage(this)
    gpuImage.setFilter(GPUImageSepiaFilter())
    gpuImage.setImage(imageUri)
    gpuImage.saveToPictures("GPUImage", "ImageWithFilter.jpg", null)
}

Support status of GPUImage for iOS shaders

•  Saturation
•  Contrast
•  Brightness
•  Levels
•  Exposure
•  RGB
•  RGB Diation
•  Hue
•  White Balance
•  Monochrome
•  False Color
•  Sharpen
•  Unsharp Mask
•  Transform Operation
•  Crop
•  Gamma
•  Highlights and Shadows
•  Haze
•  Sepia Tone
•  Amatorka
•  Miss Etikate
•  Soft Elegance
•  Color Inversion
•  Solarize
•  Vibrance
•  Highlight and Shadow Tint
•  Luminance
•  Luminance Threshold
•  Average Color
•  Average Luminance
•  Average Luminance Threshold
•  Adaptive Threshold
•  Polar Pixellate
•  Pixellate
•  Polka Dot
•  Halftone
•  Crosshatch
•  Sobel Edge Detection
•  Prewitt Edge Detection
•  Canny Edge Detection
•  Threshold Sobel EdgeDetection
•  Harris Corner Detector
•  Noble Corner Detector
•  Shi Tomasi Feature Detector
•  Colour FAST Feature Detector
•  Low Pass Filter
•  High Pass Filter
•  Sketch Filter
•  Threshold Sketch Filter
•  Toon Filter
•  SmoothToon Filter
•  Tilt Shift
•  CGA Colorspace Filter
•  Posterize
•  Convolution 3x3
•  Emboss Filter
•  Laplacian
•  Chroma Keying
•  Kuwahara Filter
•  Kuwahara Radius3 Filter
•  Vignette
•  Gaussian Blur
•  Box Blur
•  Bilateral Blur
•  Motion Blur
•  Zoom Blur
•  iOS Blur
•  Median Filter
•  Swirl Distortion
•  Bulge Distortion
•  Pinch Distortion
•  Sphere Refraction
•  Glass Sphere Refraction
•  Stretch Distortion
•  Dilation
•  Erosion
•  Opening Filter
•  Closing Filter
•  Local Binary Pattern
•  Color Local Binary Pattern
•  Dissolve Blend
•  Chroma Key Blend
•  Add Blend
•  Divide Blend
•  Multiply Blend
•  Overlay Blend
•  Lighten Blend
•  Darken Blend
•  Color Burn Blend
•  Color Dodge Blend
•  Linear Burn Blend
•  Screen Blend
•  Difference Blend
•  Subtract Blend
•  Exclusion Blend
•  HardLight Blend
•  SoftLight Blend
•  Color Blend
•  Hue Blend
•  Saturation Blend
•  Luminosity Blend
•  Normal Blend
•  Source Over Blend
•  Alpha Blend
•  Non Maximum Suppression
•  Thresholded Non Maximum Suppression
•  Directional Non Maximum Suppression
•  Opacity
•  Weak Pixel Inclusion Filter
•  Color Matrix
•  Directional Sobel Edge Detection
•  Lookup
•  Tone Curve (*.acv files)

Others

•  Texture 3x3
•  Gray Scale

Gradle

Make sure that you run the clean target when using maven.

gradle clean assemble

Idea from: iOS GPUImage framework

Download Details:

Author: Cats-oss
Source Code: https://github.com/cats-oss/android-gpuimage

#android #java #opengl #ios

Craft: A simple Minecraft clone written in C using modern OpenGL

Craft

Minecraft clone for Windows, Mac OS X and Linux. Just a few thousand lines of C using modern OpenGL (shaders). Online multiplayer support is included using a Python-based server.

Features

• Simple but nice looking terrain generation using perlin / simplex noise.
• More than 10 types of blocks and more can be added easily.
• Supports plants (grass, flowers, trees, etc.) and transparency (glass).
• Simple clouds in the sky (they don't move).
• Day / night cycles and a textured sky dome.
• World changes persisted in a sqlite3 database.
• Multiplayer support!

Download

Mac and Windows binaries are available on the website.

http://www.michaelfogleman.com/craft/

See below to run from source.

Install Dependencies

Mac OS X

Download and install CMake if you don't already have it. You may use Homebrew to simplify the installation:

brew install cmake

Linux (Ubuntu)

sudo apt-get install cmake libglew-dev xorg-dev libcurl4-openssl-dev
sudo apt-get build-dep glfw

Windows

Download and install CMake and MinGW. Add C:\MinGW\bin to your PATH.

Download and install cURL so that CURL/lib and CURL/include are in your Program Files directory.

Use the following commands in place of the ones described in the next section.

cmake -G "MinGW Makefiles"
mingw32-make

Compile and Run

Once you have the dependencies (see above), run the following commands in your terminal.

git clone https://github.com/fogleman/Craft.git
cd Craft
cmake .
make
./craft

Multiplayer

After many years, craft.michaelfogleman.com has been taken down. See the Server section for info on self-hosting.

Client

You can connect to a server with command line arguments...

./craft [HOST [PORT]]

Or, with the "/online" command in the game itself.

/online [HOST [PORT]]

Server

You can run your own server or connect to mine. The server is written in Python but requires a compiled DLL so it can perform the terrain generation just like the client.

gcc -std=c99 -O3 -fPIC -shared -o world -I src -I deps/noise deps/noise/noise.c src/world.c
python server.py [HOST [PORT]]

Controls

• WASD to move forward, left, backward, right.
• Space to jump.
• Left Click to destroy a block.
• Right Click or Cmd + Left Click to create a block.
• Ctrl + Right Click to toggle a block as a light source.
• 1-9 to select the block type to create.
• E to cycle through the block types.
• Tab to toggle between walking and flying.
• ZXCVBN to move in exact directions along the XYZ axes.
• Left shift to zoom.
• F to show the scene in orthographic mode.
• O to observe players in the main view.
• P to observe players in the picture-in-picture view.
• T to type text into chat.
• Forward slash (/) to enter a command.
• Backquote (`) to write text on any block (signs).
• Arrow keys emulate mouse movement.
• Enter emulates mouse click.

Chat Commands

/goto [NAME]

Teleport to another user. If NAME is unspecified, a random user is chosen.

/list

Display a list of connected users.

/login NAME

Switch to another registered username. The login server will be re-contacted. The username is case-sensitive.

/logout

Unauthenticate and become a guest user. Automatic logins will not occur again until the /login command is re-issued.

/offline [FILE]

Switch to offline mode. FILE specifies the save file to use and defaults to "craft".

/online HOST [PORT]

Connect to the specified server.

/pq P Q

Teleport to the specified chunk.

/spawn

Teleport back to the spawn point.

Screenshot

Implementation Details

Terrain Generation

The terrain is generated using Simplex noise - a deterministic noise function seeded based on position. So the world will always be generated the same way in a given location.

The world is split up into 32x32 block chunks in the XZ plane (Y is up). This allows the world to be “infinite” (floating point precision is currently a problem at large X or Z values) and also makes it easier to manage the data. Only visible chunks need to be queried from the database.

Rendering

Only exposed faces are rendered. This is an important optimization as the vast majority of blocks are either completely hidden or are only exposing one or two faces. Each chunk records a one-block width overlap for each neighboring chunk so it knows which blocks along its perimeter are exposed.

Only visible chunks are rendered. A naive frustum-culling approach is used to test if a chunk is in the camera’s view. If it is not, it is not rendered. This results in a pretty decent performance improvement as well.

Chunk buffers are completely regenerated when a block is changed in that chunk, instead of trying to update the VBO.

Text is rendered using a bitmap atlas. Each character is rendered onto two triangles forming a 2D rectangle.

“Modern” OpenGL is used - no deprecated, fixed-function pipeline functions are used. Vertex buffer objects are used for position, normal and texture coordinates. Vertex and fragment shaders are used for rendering. Matrix manipulation functions are in matrix.c for translation, rotation, perspective, orthographic, etc. matrices. The 3D models are made up of very simple primitives - mostly cubes and rectangles. These models are generated in code in cube.c.

Transparency in glass blocks and plants (plants don’t take up the full rectangular shape of their triangle primitives) is implemented by discarding magenta-colored pixels in the fragment shader.

Database

User changes to the world are stored in a sqlite database. Only the delta is stored, so the default world is generated and then the user changes are applied on top when loading.

The main database table is named “block” and has columns p, q, x, y, z, w. (p, q) identifies the chunk, (x, y, z) identifies the block position and (w) identifies the block type. 0 represents an empty block (air).

In game, the chunks store their blocks in a hash map. An (x, y, z) key maps to a (w) value.

The y-position of blocks are limited to 0 <= y < 256. The upper limit is mainly an artificial limitation to prevent users from building unnecessarily tall structures. Users are not allowed to destroy blocks at y = 0 to avoid falling underneath the world.

Multiplayer

Multiplayer mode is implemented using plain-old sockets. A simple, ASCII, line-based protocol is used. Each line is made up of a command code and zero or more comma-separated arguments. The client requests chunks from the server with a simple command: C,p,q,key. “C” means “Chunk” and (p, q) identifies the chunk. The key is used for caching - the server will only send block updates that have been performed since the client last asked for that chunk. Block updates (in realtime or as part of a chunk request) are sent to the client in the format: B,p,q,x,y,z,w. After sending all of the blocks for a requested chunk, the server will send an updated cache key in the format: K,p,q,key. The client will store this key and use it the next time it needs to ask for that chunk. Player positions are sent in the format: P,pid,x,y,z,rx,ry. The pid is the player ID and the rx and ry values indicate the player’s rotation in two different axes. The client interpolates player positions from the past two position updates for smoother animation. The client sends its position to the server at most every 0.1 seconds (less if not moving).

Client-side caching to the sqlite database can be performance intensive when connecting to a server for the first time. For this reason, sqlite writes are performed on a background thread. All writes occur in a transaction for performance. The transaction is committed every 5 seconds as opposed to some logical amount of work completed. A ring / circular buffer is used as a queue for what data is to be written to the database.

In multiplayer mode, players can observe one another in the main view or in a picture-in-picture view. Implementation of the PnP was surprisingly simple - just change the viewport and render the scene again from the other player’s point of view.

Collision Testing

Hit testing (what block the user is pointing at) is implemented by scanning a ray from the player’s position outward, following their sight vector. This is not a precise method, so the step rate can be made smaller to be more accurate.

Collision testing simply adjusts the player’s position to remain a certain distance away from any adjacent blocks that are obstacles. (Clouds and plants are not marked as obstacles, so you pass right through them.)

Sky Dome

A textured sky dome is used for the sky. The X-coordinate of the texture represents time of day. The Y-values map from the bottom of the sky sphere to the top of the sky sphere. The player is always in the center of the sphere. The fragment shaders for the blocks also sample the sky texture to determine the appropriate fog color to blend with based on the block’s position relative to the backing sky.

Ambient Occlusion

Ambient occlusion is implemented as described on this page:

http://0fps.wordpress.com/2013/07/03/ambient-occlusion-for-minecraft-like-worlds/

Dependencies

• GLEW is used for managing OpenGL extensions across platforms.
• GLFW is used for cross-platform window management.
• CURL is used for HTTPS / SSL POST for the authentication process.
• lodepng is used for loading PNG textures.
• sqlite3 is used for saving the blocks added / removed by the user.
• tinycthread is used for cross-platform threading.

http://www.michaelfogleman.com/craft/

Download Details:

Author: Fogleman
Source Code: https://github.com/fogleman/Craft
License: MIT license

#c #game #minecraft #opengl

Free (as in Freedom) Open Source Clone Of The Age Of Empires II Engine

Openage

openage: a volunteer project to create a free engine clone of the Genie Engine used by Age of Empires, Age of Empires II (HD) and Star Wars: Galactic Battlegrounds, comparable to projects like OpenMW, OpenRA, OpenSAGE, OpenTTD and OpenRCT2. At the moment we focus our efforts on the integration of Age of Empires II, while being primarily aimed at POSIX platforms such as GNU/Linux.

openage uses the original game assets (such as sounds and graphics), but (for obvious reasons) doesn't ship them. To play, you require an original AoE II: TC, AoE II: HD or AoE II: DE installation (via Wine or Steam-Linux).

Technical foundation

Goals

• Fully authentic look and feel
  • This can only be approximated, since the behaviour of the original game is mostly undocumented, and guessing/experimenting can only get you this close
  • We will not implement useless artificial limitations (max 30 selectable units...)
• An easily-moddable content format: nyan yet another notation
• An integrated Python console and API, comparable to blender
• AI scripting in Python, you can use machine learning
  • here is some additional literature
• Re-creating free game assets
• Multiplayer (obviously)
• Matchmaking and ranking with a haskell masterserver
• Optionally, improvements over the original game
• Awesome infrastructure such as our own Kevin CI service

But beware, for sanity reasons:

• No network compatibility with the original game. You really wanna have the same problems again?
• No binary compatibility with the original game. A one-way script to convert maps/savegames/missions to openage is planned though.

Current State of the Project

Important notice: At the moment, "gameplay" is basically non-functional. We're implementing the internal game simulation (how units even do anything) with simplicity and extensibility in mind, so we had to get rid of the temporary (but kind of working) previous version. With these changes we can (finally) actually make use of our converted asset packs and our nyan API! We're working day and night to make gameplay return*. If you're interested, we wrote detailed explanations on our blog: Part 1, Part 2.

* may not actually be every day and night

Operating System	Build status
Debian Sid	Todo: Kevin #11
Ubuntu 22.04 LTS
macOS
Windows Server 2019
Windows Server 2022

Which platforms are supported?

• Linux (primary), Windows & macOS (at least we try :)

What features are currently implemented?

• See status page.

What's the plan?

• See doc/milestones.md. We also have lists of crazy xor good ideas and a technical overview for requested features.

Installation Packages

There's many missing parts for an actually working game. So if you "just wanna play", you'll be disappointed, unfortunately.

We strongly recommend to build the program from source to get the latest, greatest and shiniest project state :)

For Linux check at repology if your distribution has any packages available. Otherwise you need to build from source. We don't release *.deb, *.rpm, flatpack, snap or AppImage packages yet.

For Windows check our release page for the latest installer. Otherwise, you need to build from source.

For macOS we currently don't have any packages, you need to build from source.

If you need help, maybe our troubleshooting guide helps you.

Quickstart

How do I get this to run on my box?

• See doc/building.md.

I compiled everything. Now how do I run it?

• Execute ./bin/run.
• The convert script will transform original assets into openage formats, which are a lot saner and more moddable.
• Use your brain and react to the things you'll see.

Waaaaaah! It

• segfaults
• prints error messages I don't want to read
• ate my dog

All of those are features, not bugs.

To turn them off, use ./bin/run --dont-segfault --no-errors --dont-eat-dog.

If this still does not help, try our troubleshooting guide, the contact section or the bug tracker.

Contributing

You might ask yourself now "Yeah, this sounds cool and all, but how do I participate and get famous contribute useful features?".

Fortunately for you, there is a lot to do and we are very grateful for help.

Where do I start?

• The engine has several core parts that need help. You can look at the project related issues and find something for you, for example:
  • Asset Converter: Converts whatever proprietary format used by a Age of Empires 2 into open formats. Written mostly in Python 3. There are a lot of TODOs and beginner issues available right now, so it's a good place to get your feet wet.
  • Game simulation: Also known as the gameplay implementation. Written in C++, using the Entity-Component-System paradigm in addition to an event-driven simulation.
  • Documentation: We not only document code, but also anything technical about the Genie engine and its games. If you like documenting file formats or thoroughly investigating game mechanics, then this might be the right place to start.
• Check the issues labelled with good first issues. These are tasks that you can start right away and don't require much previous knowledge.
• Ask us in the chat. Someone there could need help with something.
• You can also take the initiative and fix a bug you found, create an issue for discussion or implement a feature that we never though of, but always wanted.

Ok, I found something. What now?

• Tell us, if you haven't already. Chances are that we have additional information and directions.
• Read the docs. They will answer most "administrative" questions like what code style is used and how the engine core parts are connected.
• Read the code and get familiar with the engine component you want to work with.
• Do not hesitate to ask us for help if you do not understand something.

How do I contribute my features/changes?

• Read the contributing guide.
• You can upload work in progress (WIP) versions or drafts of your contribution to get feedback or support.
• Tell us (again) when you want us to review your work.

I want to help, but I'm not a programmer...

Then openage might be a good reason to become one! We have many issues and tasks for beginners. You just have to ask and we'll find something. Alternatively, lurking is also allowed.

Cheers, happy hecking!

Development Process

What does openage development look like in practice?

• extensive synchronization!
• doc/development.md.

How can I help?

• doc/contributing.md.

All documentation is also in this repo:

• Code documentation is embedded in the sources for Doxygen (see doc readme).
• Have a look at the doc directory. This folder tends to get outdated when code changes.

Contact

Contact	Where?
Issue Tracker	GitHub SFTtech/openage
Development Blog	blog.openage.dev
Subreddit	/r/openage
Discussions	GitHub Discussions
Matrix Chat	#sfttech:matrix.org
Money Sink

Download Details:

Author: SFTtech
Source Code: https://github.com/SFTtech/openage
License: View license

#python #game #linux #opengl

Filament: Real-time Physically Based Rendering Engine for Android, iOS

Filament

Filament is a real-time physically based rendering engine for Android, iOS, Linux, macOS, Windows, and WebGL. It is designed to be as small as possible and as efficient as possible on Android.

Android

Android projects can simply declare Filament libraries as Maven dependencies:

repositories {
    // ...
    mavenCentral()
}

dependencies {
    implementation 'com.google.android.filament:filament-android:1.31.3'
}

Here are all the libraries available in the group com.google.android.filament:

Artifact	Description
	The Filament rendering engine itself.
	A glTF 2.0 loader for Filament, depends on filament-android.
	Trimmed version of gltfio that does not support some glTF extensions.
	KTX loading, Kotlin math, and camera utilities, depends on gltfio-android.
	A runtime material builder/compiler. This library is large but contains a full shader compiler/validator/optimizer and supports both OpenGL and Vulkan.
	A much smaller alternative to filamat-android that can only generate OpenGL shaders. It does not provide validation or optimizations.

iOS

iOS projects can use CocoaPods to install the latest release:

pod 'Filament', '~> 1.31.3'

Snapshots

If you prefer to live on the edge, you can download a continuous build by following the following steps:

1. Find the commit you're interested in.
2. Click the green check mark under the commit message.
3. Click on the Details link for the platform you're interested in.
4. On the top left click Summary, then in the Artifacts section choose the desired artifact.

Documentation

• Filament, an in-depth explanation of real-time physically based rendering, the graphics capabilities and implementation of Filament. This document explains the math and reasoning behind most of our decisions. This document is a good introduction to PBR for graphics programmers.
• Materials, the full reference documentation for our material system. This document explains our different material models, how to use the material compiler matc and how to write custom materials.
• Material Properties, a reference sheet for the standard material model.

Examples

Features

APIs

• Native C++ API for Android, iOS, Linux, macOS and Windows
• Java/JNI API for Android
• JavaScript API

Backends

• OpenGL 4.1+ for Linux, macOS and Windows
• OpenGL ES 3.0+ for Android and iOS
• Metal for macOS and iOS
• Vulkan 1.0 for Android, Linux, macOS, and Windows
• WebGL 2.0 for all platforms

Rendering

• Clustered forward renderer
• Cook-Torrance microfacet specular BRDF
• Lambertian diffuse BRDF
• Custom lighting/surface shading
• HDR/linear lighting
• Metallic workflow
• Clear coat
• Anisotropic lighting
• Approximated translucent (subsurface) materials
• Cloth/fabric/sheen shading
• Normal mapping & ambient occlusion mapping
• Image-based lighting
• Physically-based camera (shutter speed, sensitivity and aperture)
• Physical light units
• Point lights, spot lights, and directional light
• Specular anti-aliasing
• Point, spot, and directional light shadows
• Cascaded shadows
• EVSM, PCSS, DPCF, or PCF shadows
• Transparent shadows
• Contact shadows
• Screen-space ambient occlusion
• Screen-space reflections
• Screen-space refraction
• Global fog
• Dynamic resolution (with support for AMD FidelityFX FSR)

Post processing

• HDR bloom
• Depth of field bokeh
• Multiple tone mappers: generic (customizable), ACES, filmic, etc.
• Color and tone management: luminance scaling, gamut mapping
• Color grading: exposure, night adaptation, white balance, channel mixer, shadows/mid-tones/highlights, ASC CDL, contrast, saturation, etc.
• TAA, FXAA, MSAA
• Screen-space lens flares

glTF 2.0

Encodings

•  Embeded
•  Binary

Primitive Types

•  Points
•  Lines
•  Line Loop
•  Line Strip
•  Triangles
•  Triangle Strip
•  Triangle Fan

Animation

•  Transform animation
•  Linear interpolation
•  Morph animation
  •  Sparse accessor
•  Skin animation
•  Joint animation

Extensions

•  KHR_draco_mesh_compression
•  KHR_lights_punctual
•  KHR_materials_clearcoat
•  KHR_materials_emissive_strength
•  KHR_materials_ior
•  KHR_materials_pbrSpecularGlossiness
•  KHR_materials_sheen
•  KHR_materials_transmission
•  KHR_materials_unlit
•  KHR_materials_variants
•  KHR_materials_volume
•  KHR_mesh_quantization
•  KHR_texture_basisu
•  KHR_texture_transform
•  EXT_meshopt_compression

Rendering with Filament

Native Linux, macOS and Windows

You must create an Engine, a Renderer and a SwapChain. The SwapChain is created from a native window pointer (an NSView on macOS or a HWND on Windows for instance):

Engine* engine = Engine::create();
SwapChain* swapChain = engine->createSwapChain(nativeWindow);
Renderer* renderer = engine->createRenderer();

To render a frame you must then create a View, a Scene and a Camera:

Camera* camera = engine->createCamera(EntityManager::get().create());
View* view = engine->createView();
Scene* scene = engine->createScene();

view->setCamera(camera);
view->setScene(scene);

Renderables are added to the scene:

Entity renderable = EntityManager::get().create();
// build a quad
RenderableManager::Builder(1)
        .boundingBox({{ -1, -1, -1 }, { 1, 1, 1 }})
        .material(0, materialInstance)
        .geometry(0, RenderableManager::PrimitiveType::TRIANGLES, vertexBuffer, indexBuffer, 0, 6)
        .culling(false)
        .build(*engine, renderable);
scene->addEntity(renderable);

The material instance is obtained from a material, itself loaded from a binary blob generated by matc:

Material* material = Material::Builder()
        .package((void*) BAKED_MATERIAL_PACKAGE, sizeof(BAKED_MATERIAL_PACKAGE))
        .build(*engine);
MaterialInstance* materialInstance = material->createInstance();

To learn more about materials and matc, please refer to the materials documentation.

To render, simply pass the View to the Renderer:

// beginFrame() returns false if we need to skip a frame
if (renderer->beginFrame(swapChain)) {
    // for each View
    renderer->render(view);
    renderer->endFrame();
}

For complete examples of Linux, macOS and Windows Filament applications, look at the source files in the samples/ directory. These samples are all based on libs/filamentapp/ which contains the code that creates a native window with SDL2 and initializes the Filament engine, renderer and views.

For more information on how to prepare environment maps for image-based lighting please refer to BUILDING.md.

Android

See android/samples for examples of how to use Filament on Android.

You must always first initialize Filament by calling Filament.init().

Rendering with Filament on Android is similar to rendering from native code (the APIs are largely the same across languages). You can render into a Surface by passing a Surface to the createSwapChain method. This allows you to render to a SurfaceTexture, a TextureView or a SurfaceView. To make things easier we provide an Android specific API called UiHelper in the package com.google.android.filament.android. All you need to do is set a render callback on the helper and attach your SurfaceView or TextureView to it. You are still responsible for creating the swap chain in the onNativeWindowChanged() callback.

iOS

Filament is supported on iOS 11.0 and above. See ios/samples for examples of using Filament on iOS.

Filament on iOS is largely the same as native rendering with C++. A CAEAGLLayer or CAMetalLayer is passed to the createSwapChain method. Filament for iOS supports both Metal (preferred) and OpenGL ES.

Assets

To get started you can use the textures and environment maps found respectively in third_party/textures and third_party/environments. These assets are under CC0 license. Please refer to their respective URL.txt files to know more about the original authors.

Environments must be pre-processed using cmgen or using the libiblprefilter library.

How to make contributions

Please read and follow the steps in CONTRIBUTING.md. Make sure you are familiar with the code style.

Directory structure

This repository not only contains the core Filament engine, but also its supporting libraries and tools.

• android: Android libraries and projects
  • filamat-android: Filament material generation library (AAR) for Android
  • filament-android: Filament library (AAR) for Android
  • filament-utils-android: Extra utilities (KTX loader, math types, etc.)
  • gltfio-android: Filament glTF loading library (AAR) for Android
  • samples: Android-specific Filament samples
• art: Source for various artworks (logos, PDF manuals, etc.)
• assets: 3D assets to use with sample applications
• build: CMake build scripts
• docs: Documentation
  • math: Mathematica notebooks used to explore BRDFs, equations, etc.
• filament: Filament rendering engine (minimal dependencies)
  • backend: Rendering backends/drivers (Vulkan, Metal, OpenGL/ES)
• ide: Configuration files for IDEs (CLion, etc.)
• ios: Sample projects for iOS
• libs: Libraries
  • bluegl: OpenGL bindings for macOS, Linux and Windows
  • bluevk: Vulkan bindings for macOS, Linux, Windows and Android
  • camutils: Camera manipulation utilities
  • filabridge: Library shared by the Filament engine and host tools
  • filaflat: Serialization/deserialization library used for materials
  • filagui: Helper library for Dear ImGui
  • filamat: Material generation library
  • filamentapp: SDL2 skeleton to build sample apps
  • filameshio: Tiny filamesh parsing library (see also tools/filamesh)
  • geometry: Mesh-related utilities
  • gltfio: Loader for glTF 2.0
  • ibl: IBL generation tools
  • image: Image filtering and simple transforms
  • imageio: Image file reading / writing, only intended for internal use
  • matdbg: DebugServer for inspecting shaders at run-time (debug builds only)
  • math: Math library
  • mathio: Math types support for output streams
  • utils: Utility library (threads, memory, data structures, etc.)
  • viewer: glTF viewer library (requires gltfio)
• samples: Sample desktop applications
• shaders: Shaders used by filamat and matc
• third_party: External libraries and assets
  • environments: Environment maps under CC0 license that can be used with cmgen
  • models: Models under permissive licenses
  • textures: Textures under CC0 license
• tools: Host tools
  • cmgen: Image-based lighting asset generator
  • filamesh: Mesh converter
  • glslminifier: Minifies GLSL source code
  • matc: Material compiler
  • matinfo Displays information about materials compiled with matc
  • mipgen Generates a series of miplevels from a source image
  • normal-blending: Tool to blend normal maps
  • resgen Aggregates binary blobs into embeddable resources
  • roughness-prefilter: Pre-filters a roughness map from a normal map to reduce aliasing
  • specular-color: Computes the specular color of conductors based on spectral data
• web: JavaScript bindings, documentation, and samples

Download

Download Filament releases to access stable builds. Filament release archives contains host-side tools that are required to generate assets.

Make sure you always use tools from the same release as the runtime library. This is particularly important for matc (material compiler).

If you'd rather build Filament yourself, please refer to our build manual.

Download Details:

Author: Google
Source Code: https://github.com/google/filament
License: Apache-2.0 license

#cpluplus #android #webgl #realtime #opengl

Tinyrenderer: A Brief Computer Graphics / Rendering Course

Tinyrenderer

Tiny Renderer or how OpenGL works: software rendering in 500 lines of code

compilation

git clone https://github.com/ssloy/tinyrenderer.git &&
cd tinyrenderer &&
mkdir build &&
cd build &&
cmake .. &&
cmake --build . -j &&
./tinyrenderer ../obj/diablo3_pose/diablo3_pose.obj ../obj/floor.obj

The rendered image is saved to framebuffer.tga.

You can open the project in Gitpod, a free online dev evironment for GitHub:

On open, the editor will compile & run the program as well as open the resulting image in the editor's preview. Just change the code in the editor and rerun the script (use the terminal's history) to see updated images.

The main idea

My source code is irrelevant. Read the wiki and implement your own renderer. Only when you suffer through all the tiny details you will learn what is going on.

In this series of articles, I want to show the way OpenGL works by writing its clone (a much simplified one). Surprisingly enough, I often meet people who cannot overcome the initial hurdle of learning OpenGL / DirectX. Thus, I have prepared a short series of lectures, after which my students show quite good renderers.

So, the task is formulated as follows: using no third-party libraries (especially graphic ones), get something like this picture:

Warning: this is a training material that will loosely repeat the structure of the OpenGL library. It will be a software renderer. I do not want to show how to write applications for OpenGL. I want to show how OpenGL works. I am deeply convinced that it is impossible to write efficient applications using 3D libraries without understanding this.

I will try to make the final code about 500 lines. My students need 10 to 20 programming hours to begin making such renderers. At the input, we get a test file with a polygonal wire + pictures with textures. At the output, we’ll get a rendered model. No graphical interface, the program simply generates an image.

Since the goal is to minimize external dependencies, I give my students just one class that allows working with TGA files. It’s one of the simplest formats that supports images in RGB/RGBA/black and white formats. So, as a starting point, we’ll obtain a simple way to work with pictures. You should note that the only functionality available at the very beginning (in addition to loading and saving images) is the capability to set the color of one pixel.

There are no functions for drawing line segments and triangles. We’ll have to do all of this by hand. I provide my source code that I write in parallel with students. But I would not recommend using it, as this doesn’t make sense. The entire code is available on github, and here you will find the source code I give to my students.

#include "tgaimage.h"
const TGAColor white = TGAColor(255, 255, 255, 255);
const TGAColor red   = TGAColor(255, 0,   0,   255);
int main(int argc, char** argv) {
        TGAImage image(100, 100, TGAImage::RGB);
        image.set(52, 41, red);
        image.write_tga_file("output.tga");`
        return 0;
}

output.tga should look something like this:

Teaser: few examples made with the renderer

Check the wiki for the detailed lessons.

Download Details:

Author: ssloy
Source Code: https://github.com/ssloy/tinyrenderer
License: View license

#cpluplus #learning #tutorial #opengl

Kitty: Cross-platform, Fast, Feature-rich, GPU Based Terminal

Kitty - the fast, feature-rich, cross-platform, GPU based terminal

Packaging status in various repositories:

See the kitty website.

Frequently Asked Questions

To ask other questions about kitty usage, use either the discussions on GitHub or the Reddit community

Download Details:

Author: Kovidgoyal
Source Code: https://github.com/kovidgoyal/kitty
License: GPL-3.0 license

#python #c #terminal #opengl

HTY360Player: Open Source iOS 360 Degree Panorama Video Player

🎺🎺🎺🎺🎺🎺🎺🎺🎺🎺🎺 The Metal with Swift 5.0 version is comming 🎺🎺🎺🎺🎺🎺🎺🎺🎺🎺🎺

360 VR Player

A Open Source, Ad-free, Native and Universal 360 dgree panorama video player for iOS.

About

HTY360Player is a 360 degree panorama video player for iOS.

Tutorial (Swift)

How to Create a 360 Video Player with OpenGL ES 3.0 and GLKit in iOS

Features

• Play Online 360° Video

• Play Local 360° Video

Todo

• Metal version.

Contributing

1. Fork it
2. Create your feature branch (git checkout -b my-new-feature)
3. Commit your changes (git commit -am 'Add awesome feature')
4. Push to the branch (git push origin my-new-feature)
5. Create a new Pull Request

Download Details:

Author: Hanton
Source Code: https://github.com/hanton/HTY360Player
License: MIT license

#swift #ios #opengl #objective-c

StarWars.iOS: This Component Implements Transition animation

StarWars Animation

This component implements transition animation to crumble view-controller into tiny pieces.

Check this project on dribbble.

Also, read how it was done in our blog

Requirements

• iOS 8.0+
• Xcode 8
• Swift 4

Installing with CocoaPods

use_frameworks!
pod 'StarWars', '~> 2.0'

Usage

At first, import StarWars:

import StarWars

Then just implement class of UIViewControllerTransitioningDelegate that will return our animation form method animationControllerForDismissedController and assign it to transitioningDelegate of viewController that you want to dismiss.

override func prepareForSegue(segue: UIStoryboardSegue, sender: AnyObject?) {
    let destination = segue.destinationViewController
    destination.transitioningDelegate = self
}

func animationControllerForDismissedController(dismissed: UIViewController) -> UIViewControllerAnimatedTransitioning? {
    return StarWarsGLAnimator()
}

There are also two things you can customize in the Star Wars animation: duration and sprite sizes. Let’s see how you can do this:

let animator = StarWarsGLAnimator()
animator.duration = 2
animator.spriteWidth = 8

Have fun! :)

Let us know!

We’d be really happy if you sent us links to your projects where you use our component. Just send an email to github@yalantis.com And do let us know if you have any questions or suggestion regarding the animation.

P.S. We’re going to publish more awesomeness wrapped in code and a tutorial on how to make UI for iOS (Android) better than better. Stay tuned!

Version history

• 1.0 Swift 2.0
• 2.0 Adds Swift 3.0 support
• 3.0 Adds Swift 4.0 support
• 4.0 Adds Swift 5.0 support

Download Details:

Author: Yalantis
Source Code: https://github.com/Yalantis/StarWars.iOS
License: MIT license

#swift #ios #research #opengl #animation

GLFW.jl: Julia interface to GLFW

GLFW.jl

Julia interface to GLFW 3, a multi-platform library for creating windows with OpenGL or OpenGL ES contexts and receiving many kinds of input. GLFW has native support for Windows, OS X and many Unix-like systems using the X Window System, such as Linux and FreeBSD.

Example

using GLFW

# Create a window and its OpenGL context
window = GLFW.CreateWindow(640, 480, "GLFW.jl")

# Make the window's context current
GLFW.MakeContextCurrent(window)

# Loop until the user closes the window
while !GLFW.WindowShouldClose(window)

    # Render here

    # Swap front and back buffers
    GLFW.SwapBuffers(window)

    # Poll for and process events
    GLFW.PollEvents()
end

GLFW.DestroyWindow(window)

Interface

Read the GLFW documentation for detailed instructions on how to use the library. The Julia interface is almost identical to the underlying C interface, with a few notable differences:

• Clipboard (glfwGetClipboard, glfwSetClipboard) and time (glfwGetTime, glfwSetTime) functions have been omitted because Julia's standard library already supports similar functionality.
• glfwInit and glfwTerminate are called automatically using the __init__ and atexit functions. While it is okay to still call them explicitly, it is redundant and not required.

Footnotes

• Special thanks to @afterwise for writing an early implementation of GLFW 3 support.

Download Details:

Author: JuliaGL
Source Code: https://github.com/JuliaGL/GLFW.jl
License: MIT license

#julia #opengl
